Electrical Equipment & Systems

AC Motor Output Filters increase service life, reliability.
Motors

AC Motor Output Filters increase service life, reliability.

To increase service life and system reliability, FN5060 dv/dt filters protect AC motors from destructive effects of peak voltages and inrush amps.Â- Design does not employ capacitors or resistors, which facilitates installation. Reducing high-output dv/dt from IGBT motor drives and eliminating over-voltages caused by line reflections on motor cables, products offer typical dv/dt...

Read More »
LED Drivers include phase dimming control.
Power Supplies

LED Drivers include phase dimming control.

Designed for use in outdoor fixtures, constant-current LED-LT Series includes 6, 9, 12, 16, and 20 W models. Units provide line-voltage phase dimming that is compatible with both leading edge and trailing edge type dimmers. Available for 120 Vac or 230–277 Vac input, drivers feature IP66-rated cases and provide flicker-free output. Products areÂ- UL Type HL hazardous location rated,...

Read More »
Switches

Programmable Switches offer dimming and on/off control.

Offered in 1, 2, 3, 4, and 6 programmable button configurations, CXSW Switches are designed specifically for use with CX Lighting Panel. When connected to CX control panel's optional dimming card with standard CAT5 cable, 24 Vdc units provide on/off switching and continuous dimming. Each button can be assigned to any of 6 available control lines using hidden button and LED interface. Two...

Read More »
Miniature Latching Connectors suit LED applications.
Electrical Connectors

Miniature Latching Connectors suit LED applications.

Available with secure latching mechanism, PTSM Connectors can be locked together in lighting and other space-critical applications. Locking feature, which does not require any special tools, is compatible with existing PTSM headers, enabling connectors to be combined in multiple ways, such as wire-to-board, board-to-board, wire-to-wire, and through-board. Measuring 5 mm high with 2.5 mm pitch,...

Read More »
Power Supplies

Solar Inverter supports commercial and utility applications.

Featuring grid-tied, 3-phase, transformerless design, 80 kW Model M80U converts DC output from photovoltaic system into utility frequency AC with efficiency of 98.8%. Two-stage inverter has wide input range spanning 200–1,000 Vdc. To protect personnel and prevent damage from adverse environmental conditions, wall-mount string inverter employs separable structure that meets NEMA 4X Enclosure...

Read More »
Batteries

Proterra Announces Advancements in Battery Technology for Heavy Duty Transit

Improved Catalyst® XR Transit Vehicle will deliver 28% more range from the same storage volume BURLINGAME, Calif.Â- – Proterra, the market leader of zero-emission, battery-electric buses in North America, today announced a new battery design for the Proterra Catalyst® XR transit vehicle at the American Public Transportation Association Bus and Paratransit Conference (APTA), a...

Read More »
Busbars

Mersen to Exhibit during IMS 2016 (International Microwave Symposium Conference and Exhibition), May 24-26, 2016

NEWBURYPORT, MA — Mersen will showcase its broad line of innovative cooling and bus bar solutions for the radio and microwave electronics industry during the IMS 2016 (International Microwave Symposium Conference and Exhibition), May 24th – 26th in San Francisco, California.Â- Ã‚ Â Â Â Â Â  Mersen’s expert team of product managers and design...

Read More »
Surge Suppressors

Circuit Protection Devices address computing application demands.

With respective capacitance of 0.6 pF and 1.0 pF, GBLC03CIDNHP TVS array andÂ- SRV25-4LC port protection array shield networking, mobile, and other computing applications from destructive effects of electrical transients. Rated at 500 W for 8/20 µsec waveshape, GBLC03CIDNHP protects 1 power or I/O port. Offering 400 W peak pulse power per line (8/20...

Read More »
Switches

SPDT Silicon Switch reduces size, power in cellular RF front ends.

Manufactured using silicon technology andÂ- supplied in SMT 4 x 4 mm LFCSP, ADRF5130 is specified at 0.7–3.5 GHz with 0.6 dB typ insertion loss, isolation of 50 dB, linearity of +68 dBm, and peak power handling of 44 W during continuous operation mode. Features include 2,000 V ESD protection on all device pins and fast CMOS-compatible control interface with

Read More »
Mission-Critical Power Supplies suit military, industrial use.
Power Supplies

Mission-Critical Power Supplies suit military, industrial use.

Providing 2,000/3,000/4,000Â- W output with voltages from 3.3–48 Vdc, DCR2U Series accepts inputs of 80–265 Vac at 47–440 HZ, PFC; 240–400 Vdc; or 115/200 Vac, 3-phase at 360–440 Hz (IAW MIL-STD-704 and DO-160). Custom inputs are also available. Designed to be mounted in 19 in. racks, products require 2U (3.50 in.) space and are designed to meet MIL-STD-810F...

Read More »
Tekna Manufacturing LLC Announces NFPA 99 Compliant Model 7200 Multiplace Chamber
Sponsored

Tekna Manufacturing LLC Announces NFPA 99 Compliant Model 7200 Multiplace Chamber

Tekna is a leader in Monoplace and Multiplace Hyperbaric Chambers for Hyperbaric Oxygen Therapy (HBOT), offering products that set the standard for quality and innovation. Our new 7200 series of multiplace chambers is a state-of-the-art system that integrates advanced engineering with a plethora of features and options making it the industry's premier HBOT system. To learn more, see our video.

Read More »
