Electrical Equipment & Systems

Low-Jitter Retimers optimize video and camera signal quality
Circuits

Low-Jitter Retimers optimize video and camera signal quality

Enabling extended signal range over long traces, connectors, and cables without degradation, Low-Power Retimers optimize video and camera signal quality in PCs, mobile devices, HDTVs, and automotive infotainment systems. Models DP159 and TMDS181 include adaptive equalization up to 15 dB and support multi-gigabit signals, such as DisplayPort and HDMI, up to 6 Gbps. Model DPHY440 is a 4-by-1-Gbps...

Read More »
Sensors / Detectors / Transducers

Reference Design Kit creates solar-powered sensor beacons.

With CYALKIT-E02 Reference Design Kit, users can develop solar-powered Wireless Sensor Node that can sense temperature and humidity around its location and transmit data using Bluetooth® Low Energy connectivity. Measuring 25 mm in diameter, battery-free sensor integrates Energy Harvesting PMICs, EZ-BLE™ PRoC™ module, and 15 x 15 mm solar cell that enables operation using 100 lux of...

Read More »
Sensorless 3-Phase Motor Controller aids BLDC implementation.
Motor Controllers and Drives

Sensorless 3-Phase Motor Controller aids BLDC implementation.

Supporting 5.5–20Â- V operating range (4.5–40 V transient), AEC-Q100-qualified LV8907UW enables streamlined solutions for driving 3-phase brushless motors. IC, in base configuration, can operate without external MCU and does not require any programming. Open- and closed-loop speed control are possible. For more complex applications, LV8907UW can support MCU via integrated linear...

Read More »
AC/DC 250 W Power Supplies carry medical and ITE certifications.
Power Supplies

AC/DC 250 W Power Supplies carry medical and ITE certifications.

Operating with up to 94% efficiency, TDK-Lambda CUS200M series operates from universalÂ- of 85–265 Vac input and can deliver 200 W when convection cooled and up to 250 W with 1.5 m/sec airflow. Nominal outputs, adjustable via potentiometer, include 12, 18, 24, and 48 Vdc, and such features as remote on/off and 5 V standby output are standard on all models. Drawing

Read More »
Nanoparticle Containment Enclosures feature ductless design.
Containment Systems

Nanoparticle Containment Enclosures feature ductless design.

Designed to contain nanomaterial particles that are 100 nm or less in diameter, Purair® NANO Enclosures are suited for aerospace, research, and pharmaceutical applications. Units are constructed with stainless steel infrastructure, powder coated FFU, and dual filtration options. Available in 24, 36, or 48 in. widths, enclosures include filter clamping that eliminates bypass leakage, exhaust...

Read More »
Power Interface Module supports ATCA applications.
Power Supplies

Power Interface Module supports ATCA applications.

Available in 2.28 x 1.45 x 0.84 in. quarter-brick format, Model PIM4610PD simplifies design in blade server applications based on ATCA and PICMG 3.7 systems. Unit operates over input range of 36–75 V, delivering 864 W with 54 V input, 768 W at 48 V, and 600 W at 37.5 V. Offering up to 98.8% efficiency at 600 W, module provides energy monitoring via I2C or PMBus. Low-EMI design techniques ensure...

Read More »
Managed Ethernet Switches support DLR redundancy mechanism.
Switches

Managed Ethernet Switches support DLR redundancy mechanism.

Supporting Common Industrial Protocol for use in EtherNet/IP networks, Series 7000 features recovery times of less than 3 ms, enabling switch-over to be performed quickly in event of failure. Switches support Device Level Ring redundancy mechanism and enable up to 6 non-DLR-capable devices to be integrated into ring. Functions such as IGMP snooping, multicast source detection, and auto-query port...

Read More »
Power Supplies

Three-Phase UPS supports large to hyperscale data centers.

Providing flexible operating modes and pay-as-you-grow architecture, Galaxy VX™ Uninterruptible Power Supply is suited for large facilities, data centers, and business-critical applications. In Double Conversion Mode, unit minimizes switching losses using 4-level conversion technology. EcoMode delivers up to 99% efficiency, and ECOnversion Mode offers hybrid between Eco Mode and Double...

Read More »
Microscopes

FEI Launches Three New Tools for Next-Generation Semiconductor Manufacturing

New solutions are designed to address the challenges of 7nm technology node metrology and defect/failure analysis.Â-  Hillsboro, Ore. - FEI (NASDAQ: FEIC) announced today the release of three new tools for process control and defect/failure analysis in advanced semiconductor manufacturing. Two of the tools are specifically targeted at the 7nm node, and all are designed to allow manufacturers...

Read More »
Signal Processors

Multicore Processors optimize audio system applications.

Using 2 SHARC+ cores and advanced DSP accelerators, ADSP-SC57x/ADSP-2157x Processors deliver greater than 6 giga-floating-point operations/second. Combination of SHARC technology with ARM® Cortex-A5 system control capability provides solution for complex applications such as Dolby Atmos®, DTS:X®, or active noise cancellation with headroom remaining for further audio...

Read More »
Gorbel Introduces New Mobile Fall Protection Unit
Sponsored

Gorbel Introduces New Mobile Fall Protection Unit

Providing adequate fall protection is always a critical consideration and one that in many cases can be difficult to ensure. The new Mobile Fall Protection Unit is designed to facilitate positive fall protection in applications that would typically be difficult or impossible to provide with standard methods. To learn all about the advantages and convenience, see our video.

Read More »
