Press Release Summary:
Capable of clamping input ESD waveform of 15 kV to less than 7 V in matter of nanoseconds, Models ESD7L5.0D and NUP4212 protect ESD sensitive ICs. Offered in 1.2 x 1.2 x 0.5 mm SOT-723 package, ESD7L5.0D protects 2 high speed data lines at 0.5 pF capacitance/line as well as D+ and D- lines of USB2.0 port. Available in 1.6 x 1.6 x 0.5 mm UDFN-6 package, NUP4212 protects 4 high speed data lines at 0.7 pF/line and 2 Vcc power lines as well as D+, D-, and Vcc line on 2 USB ports.
Original Press Release:
ON Semiconductor Expands ESD Protection Portfolio with Award Winning Ultra-Low Capacitance Technology
Company maintains leadership position in high performance ESD protection solutions with industry's lowest clamping voltage products in space saving micro packages
PHOENIX, Ariz. - June 19, 2008 - ON Semiconductor (Nasdaq: ONNN), a global leader in power management and circuit protection semiconductor solutions, today announced the expansion of its high performance off-chip ESD protection portfolio with the introduction of two best-in-class devices - the ESD7L5.0D and the NUP4212. These new products have been designed using ON Semiconductor's propriety integrated ESD protection platform, which enhances clamping performance while maintaining low capacitance and small die size.
The ESD7L5.0D protects two high speed data lines at 0.5 pico farad (pF) capacitance per line in the tiny 1.2 mm x 1.2 mm x 0.5 mm SOT-723 package. Integrating ON Semiconductor's low capacitance technology into a 3-pin package provides the designer with a solution to protect the D+ and D- lines of a USB2.0 port with a single device. The ESD7L5.0D can also be connected cathode to cathode to protect a single bi-directional line at 0.25 pF, ideal for protecting high frequency RF antenna lines.
The NUP4212 protects four high speed data lines at 0.7 pF per line and 2 Vcc power lines in the compact 1.6 mm x 1.6 mm x 0.5 mm UDFN-6 package. This enables the designer to protect the D+ and D- lines plus the Vcc line on two USB ports with a single integrated solution.
Both new devices share key features which distinguish the company's proprietary technology from competitive offerings. The ESD7L5.0D and NUP4212 are capable of clamping an input ESD waveform of 15 kilovolt (kV) to less than 7 volts (V) in a matter of nanoseconds, ensuring the highest levels of protection for today's ESD sensitive integrated circuits (IC). Other low capacitance off-chip ESD protection technologies, such as polymer and ceramic-based varistors, offer low capacitance, but their ESD clamping voltage is significantly higher than the ON Semiconductor solution. In addition, the ON Semiconductor silicon devices are free from wearout mechanisms that affect the reliability and performance of passive technologies after multiple surge events such as ESD.
"ON Semiconductor is continuing to expand its leadership in high performance ESD protection solutions with the introduction of ultra low capacitance products targeting high speed data applications," said Mamoon Rashid, ON Semiconductor vice president and general manager of the company's Discrete Products Division. "Next generation portable applications require improved performance and increased design flexibility at higher and higher data rates. ON Semiconductor continues to respond to this trend by introducing a complete family of low capacitance ESD protection solutions".
The first product introduced on this technology platform, the ESD9L5.0S, was awarded Electronic Products magazine's 2007 "Product of the Year" award for a significant advance in technology, its application and innovation in design.
The ESD7L5.0DT5G is available in a SOT-723 package and is priced at $0.20 USD per unit in 8,000 units quantities. The NUP4212 is available in a UDFN-6 package and is priced at $0.608 USD per unit in 3,000 unit quantities.
About ON Semiconductor
With its global logistics network and strong product portfolio, ON Semiconductor (Nasdaq: ONNN) is a preferred supplier of efficient power solutions to customers in the power supply, automotive, communication, computer, consumer, medical, industrial, mobile phone, and military/aerospace markets. The company's broad portfolio includes power, analog, DSP, mixed-signal, advance logic, clock management and standard component devices. Global corporate headquarters are located in Phoenix, Arizona. The company operates a network of manufacturing facilities, sales offices and design centers in key markets throughout North America, Europe, and the Asia Pacific regions.
For more information, visit www.onsemi.com.
For additional technical information, visit the ON Semiconductor Circuit Protection website www.onsemi.com/circuitprotection
