Automated AC Power Sources are available in 4 models.

Press Release Summary:

Suited for use on bench-top or in rack mount, 7000 Series AC power sources are offered as model 7004, 400 VA; model 7008, 800 VA; model 7016, 1.6 kVA; and model 7040, 4 kVA. Products feature graphic LCD on front panel that monitors voltage, frequency, current, peak current, power, and power factor simultaneously. Rotary knob can be used to control voltage or frequency, or output waveform, and to simulate voltage surges and drops on devices under test. Standard USB/RS-232 interface is included.

Original Press Release:

New Automated AC Power Sources from Associated Power Technologies

New 7000 Series of Automated AC Power Sources offers four models and provides advanced features ideal for a variety of power applications!

Diamond Bar, CA - Announced today from Associated Power Technologies, Inc. (APT) is the release of their 7000 Series of AC power sources. The 7000 series features four models: the 7004 400 VA AC Power Source, the 7008 800 VA AC Power Source, the 7016 1.6 kVA AC Power Source, and the 7040 4 kVA AC Power Source. These full-featured AC Power Sources offer automation control and several enhanced features and protection circuits. The 7000 series includes a standard USB/RS-232 interface but is also available with optional Ethernet or GPIB interface.

Switch-mode technology and a direct coupled output make these sources light weight and efficient for use on the bench-top or in a rack mount. The graphic LCD display provides real-time data on the front panel and can easily monitor voltage, frequency, current, peak current, power and power factor simultaneously. The 7000 series also provides an easy-to-use local interface that allows operators to get tests up and running quickly. A front panel rotary knob can be used to adjust voltage or frequency during testing, the starting or ending phase angle of the output waveform, and simulate the effect of voltage surges and drops on your DUT for transient testing. All of these features combine to make the 7000 Series ideal for a variety of power applications.

Series Features

o 50 built-in memory locations with 9 test steps can be linked to quickly store and recall test parameters for multiple product testing applications

o Surge/Drop features simulate voltage variations, brownouts and transient voltage conditions

o Adjust the starting and ending angle of the output waveform

o LCD display monitors voltage, current, peak current, power and power factor

o Adjustable delay time, ramp up time, and test duration

o Independent, adjustable high and low limits for voltage, current, frequency, power, and power factor

o Power Up feature configures the output relay for quick and efficient testing

o Constant current output with over current fold back feature

o Front panel lockout and password protection

o Standard USB/RS-232 interface with no charge optional Ethernet and GPIB interfaces available

o Rotary knob to adjust voltage and frequency on the fly

o CE Marked

Pricing for the 7000 Series is:

Model Description Price
7004 400VA Automated AC Power Source $3,195.00
7008 800VA Automated AC Power Source $4,195.00
7016 1.6kVA Automated AC Power Source $6,395.00
7040 4kVA Automated AC Power Source $8,695.00

Associated Power Technologies, Inc. (APT) provides AC power sources for a variety of test & measurement, avionics, manufacturing, and military applications. When you choose APT, you're choosing a partner that will continue to help you for the life of your product, no matter what the application. All APT instruments come with a standard 2-year warranty, a 45-day no questions asked return policy, and guaranteed 24 hour shipment. | Web:
