Company News

Vishay

63 Lancaster Ave., Malvern, PA, 19355, USA

  • 610-644-1300

Latest New Product News from
Vishay

Electronic Components & Devices

Thick Film Chip Resistors feature AgPd terminations.

Jul 08, 2016

Equipped with silver/palladium terminations for conductive gluing in automotive and industrial applications, RCA-AP e4 Series offers advanced sulfur resistance and high-temperature operation to +175°C. Devices provide resistance from 1 Ω to 10 MΩ with tolerances of ±1% and ±5%, TCR of ±100 ppm/K, and operating voltage of 75 V. Available in 0603 case size with flip chip design and... Read More

Electrical Equipment & Systems

Hybrid Solid-State Relays offer reliability, noiseless switching.

Jul 05, 2016

Suited for use as replacements for traditional electromechanical relays in telecommunications, industrial, security system, and metering applications, 1 Form A hybrid solid-state relays include single-channel VOR1142B4 and dual-channel VOR2142A8 and VOR2142B8. These NO, SPST switches, which share modular hybrid construction that allows high-performance MOSFETs for switch output, feature... Read More

Electronic Components & Devices

Transmitter Coil saves space in Qi wireless charging pads.

Jul 01, 2016

Designed for use with WPC-compatible wireless receiver coils, Model IWTX-47R0BE-11 6.3 µH features low inductance of 6.3 µH at 200 kHz with +5% inductance tolerance, DCR of 38 mΩ (±10%) at +25°C, and Q of 190 typical at 200 kHz. Powdered-iron-based, A11 type transmitter coil for 5 V applications offers durable construction with high permeability shielding and efficiency greater than... Read More

Electronic Components & Devices

Energy Storage Capacitors come in power and energy versions.

Jun 29, 2016

Available in 16 x 20 mm to 18 x 31 mm case sizes, 220 EDLC ENYCAP™ Series offers power density to 4.1 Wh/kg, capacitance values from 15–40 F, and max rated voltage of 2.7 V. Electrical double-layer energy storage capacitors feature very low internal resistance and rapid charge/discharge performance. RoHS-compliant, through-hole devices are suited for energy harvesting, power backup, and UPS... Read More

Electronic Components & Devices

High-Current Inductor targets automotive applications.

Jun 29, 2016

Supplied in 5050 case with 6.4 mm profile, Model IHLP-5050FD-8A provides inductance values from 0.22–22 µH. Device features +180° continuous operating temperature rating and frequency range up to 2 MHz, exceeding AEC-Q200 requirements for DC/DC converters and high-current noise filters in high-temperature automotive systems. RoHS-compliant inductor handles high transient current spikes... Read More

Electronic Components & Devices

N-Channel MOSFETs support synchronous buck applications.

Jun 24, 2016

To save space and power in synchronous buck converters used for automotive applications, 12 V Model SQJ202EP and 20 V Model SQJ200EP each combine high- and low-side MOSFET in 5 x 6 mm PowerPAK® SO-8L dual asymmetric package. AEC-Q101-qualified devices offer high temperature operation to +175°C. SQJ202EP is suited for applications with bus voltages ≤ 8 V and offers low max on-resistance... Read More

Electronic Components & Devices

Grid Resistors feature stainless steel resistive element.

Jun 22, 2016

Utilizing magnetic stainless steel material, GRE1, GRE2, and NGR Grid Resistors provide TCR of ±365 ppm/°C and deliver corrosion resistance for dynamic braking resistors, testing of load banks, and motor control. Devices utilizing non-magnetic stainless steel alloy offer TCR of ±930 ppm/°C. GRE1 and GRE2 models combine power ratings up to 24 kW with operating temperatures to... Read More

Electronic Components & Devices

Radial Aluminum Capacitors operate at up to 150°C.

Jun 21, 2016

Available in 10 case sizes from 10 x 12 mm to 18 x 35 mm, AEC-Q200-qualified 160 RLA Series targets automotive and industrial applications. Devices offer impedance down to 23 mΩ at 100 kHz, ripple current to 2,000 mA at +150°C, and capacitance from 33–3,300 µF over 16–50 V range. As polarized aluminum electrolytic capacitors with non-solid electrolytes, self-healing dielectrics, and... Read More

Electronic Components & Devices

SMT Thick Film Chip Attenuator has balanced pi filter schematic.

Jun 16, 2016

In resistor array package, CZB replaces 3 or more discrete devices to reduce board space requirements and simplify manufacturing process in telecom/mobile wireless products. Delivering tolerance matching and temperature tracking to maximize performance in signal attenuation applications, product provides 1.0–10.0 dB attenuation with down to ± 0.3 dB attenuation tolerance. Attenuator... Read More

Electronic Components & Devices, Vision Systems

Dual Color Emitting Diode offers radiant power to 9.5 mW.

Jun 14, 2016

Offered in 2 x 2 x 0.87 mm package for use in wearables and medical monitoring systems, SurfLight™ VSMD66694 features wavelengths of 660 nm (red) and 940 nm (IR) with radiant power of 9.5 mW and 8.5 mW, respectively. Device has narrow spectral bandwidth of 20 nm at 660 nm and provides balanced signal levels for SpO2 and pulse rate monitoring. Suitable for high pulse current operation to 1 A at... Read More

Electronic Components & Devices

Thick Film Chip Resistor Dividers save space and simplify designs.

Jun 09, 2016

Offering various termination styles and materials, CDMV series conserves space, simplifies designs, and promotes design flexibility in high-voltage industrial and alternative energy equipment. Devices offer working voltages up to 1.4 kV and provide single-component replacement for multiple discrete resistors in voltage division applications. As 2 resistors integrated into one 2512... Read More

Electronic Components & Devices

Axial Cemented, Fusible Wirewound Safety Resistor offers safe, silent fusing.

Jun 06, 2016

RoHS-compliant AC01..CS delivers safe and silent fusing operation during overload conditions while withstanding pulse voltages of at least 2 kV (1.2 / 50 µs) per IEC 61000-4-5 for resistance values ≥ 75 Ω. Solution combines fusing time of <30 sec for 32 W overload with nonflammable silicon cement coating for immediate interruption without flame and explosion when AC mains voltage... Read More

Electronic Components & Devices

Automotive Grade MLCCs operate up to +175°C.

Jun 01, 2016

Built for extreme automotive operating conditions, K...H Series HOTcap Devices combine operating temperature of +175°C with capacitance range of 100 pF to 1 µF and capacitance tolerances as tight as ±5%. Radial-leaded, multilayer ceramic chip capacitors offer straight or crimped leads with spacing of 2.5 mm and 5.0 mm. Available in Ceramic Class 1 and 2 with C0G and X0U dielectrics,... Read More

Display & Presentation Equipment, Electrical Equipment & Systems, Electronic Components & Devices

Ceramic UV LED with Silicone Lens replaces mercury lamps.

May 31, 2016

Targeting medical, industrial, and printing applications, ceramic-based VLMU3510-365-130 is built on InGaN technology, comes in 3.45 x 3.45 mm SMT package, and has up to 25,000 hr lifetime. Typical radiant power is 690 mW at 500 mA and 945 mW at 700 mA in wavelength range of 362.5–370 nm, emission angle is 130°, and radiant intensity is 315 mW/sr at 700 mA. Shock resistance and... Read More

Electronic Components & Devices

Aluminum Polymer Capacitors feature conductive technology.

May 26, 2016

Suitable for portable electronics and consumer and telecom applications, Models 180 CPS and 18 CPL deliver ripple current of 2,350–6,100 and 900–5,400 mA at 100 kHz, respectively. Model 180 CPS, available in case sizes from 5.3 x 5.3 x 5.7 to 10.4 x 10.4 x 12.6 mm, offers useful life of 2,500 hr at +105°C and impedance from 9–35 mΩ, while Model 181 CPL, available in case sizes from 6.6... Read More

Electronic Components & Devices

Ceramic Disc Capacitors offer capacitance up to 20 nF.

May 24, 2016

Featuring C0G, U2J, P3K, R3L, X7R, and Y5U ceramic dielectrics, 440L Series provides high reliability for Class X1 (760 VAC) and Class Y1 (500 VAC) applications in accordance with IEC 60384-14, 4th edition. AC-line-rated devices feature tolerances down to ±10% and operate over temperature range of -30 to +125°C. Consisting of 2 silver-plated ceramic discs with tinned copper connection leads... Read More

Electronic Components & Devices

Automotive SMD Aluminum Capacitors have extended voltage ratings.

May 20, 2016

Respectively rated to 100 and 80 V, 146 CTI and 160 CLA series are comprised of polarized aluminum electrolytic capacitors with non-solid, self-healing electrolytes for automotive and industrial applications. There are 9 case sizes for 146 CTI series, which supports operation to +125 °C, while 160 CLA series includes 6 case sizes and operates to +150°C. Qualified to... Read More

Electronic Components & Devices

Fast Body Diode MOSFETs are rated for voltages to 650 V.

May 10, 2016

Increasing voltage headroom for soft switching in industrial, telecom, and renewable energy applications, models SiHx21N65EF (21 A), SiHx28N65EF (28 A), and SiHG33N65EF (33 A) offer respective on-resistance down to 157, 102, and 95 mΩ. Reverse recovery charge (Qrr) allows devices to block full breakdown voltage to help avoid failure from shoot-through and thermal overstress as well as... Read More

Sensors Monitors & Transducers, Test & Measuring Instruments

Integrated UV Light Sensor delivers optimized sensitivity.

May 06, 2016

Designed to convert solar UV light intensity to digital data, VEML6075 provides measurement of signal strength and allows for true UVI calculation in portable/mobile devices and weather stations. Incorporated IC has 5 sensitive areas, and Filtron technology optimizes UV sensitivity and linearity. Offering individual UVA and UVB channels with 16-bit resolution and respective sensitivity of... Read More

Electronic Components & Devices

Axial-Leaded Thick Film Resistor has flameproof silicone coating.

May 04, 2016

Handling up to 15 kV, FHV Axial series is optimized for pulse applications in industrial power supplies and lab/medical equipment. Construction includes high-temperature fired cermet film resistive element and high-purity 96% alumina core. With non-inductive design offered in 9 case sizes, these planar through-hole resistors provide resistance from 100Â Ω to 10 GΩ, tolerances down to... Read More
