Telecentric Lenses provide selectable field of view.

October 30, 2014

Available in 0.5X–1.0X and 1.0X–3.0X options, TECHSPEC® Variable Magnification Telecentric Lenses feature resolutions of >20% at 75 lp/mm across fields of view ranging from 2.93–17.96 mm. Adjustable iris allows for depth of field control for flexibility in variety of gauging and measurement applications. Featuring C-mount compatible design with 2/3 in. sensor coverage, adjustable f/6 lenses exhibit typical telecentricity of <0.1° and distortion of <0.1% at 588 nm. Read More

Vision Systems

Digital Cameras deliver Full-HD live images to monitor.

October 29, 2014

Intended for microscopy applications, 5 MP Model DP27 and 3 MP Model DP22 offer frame rates of 22 and 30 fps, respectively. Progressive readout ensures fluid and true-to-life experience, suitable for both analysis and viewing comfort. High-Fidelity Mode generates images which are true to oculars, while Normal Mode optimizes colors for pale stained samples or for clearly presenting to audience. When using phase-contrast, Cell Culture Mode produces balanced image, free from typical fringes. Read More

Vision Systems, Electrical Equipment & Systems, Display & Presentation Equipment

TFT OGS Display features PCAP adapter.

October 24, 2014

With 95.04 x 53.856 active area and 16.7M color depth, 4.3 in. UMSH-8864MD-6T measures 105.5 x 67.2 x 5.52 mm and features 24-bit RGB parallel interface. Display has sensor on cover glass layer (lens) and COG driving IC package. Latter utilizes Himax chip and PAP117 PCAP controller. While LED lifetime is rated at 50,000 hr, typical contrast is 500, brightness is 450 nits cd/m², and response time is 5 msec. At 12.1 in. wide PCAP connects chip to motherboard using RockTouch cable. Read More

Electronic Components & Devices, Vision Systems, Electrical Equipment & Systems

LED Lighting Fixture operates in hazardous locations.

October 23, 2014

Delivering up to 23,500 lm with efficiency of 110 lm/W, SafeSite LED High Bay is suitable for oil, gas, and petrochemical environments. Class I, Division 1 unit operates from 100–277 Vac at ambient temperatures ranging from -40 to +65°C and provides T5 temperature rating at 50°C. Supplied with 6 kV surge protection, IP66/NEMA4X-certified high bay is available with custom in-house designed optics including medium and wide distribution types. Read More

Software, Vision Systems, Automatic ID

Multi-Camera Software facilitates packaging inspection.

October 23, 2014

In addition to controlling and visualizing inspections of up to 4 machine vision smart cameras at once, Visionscape® I-PAK® VH Software is capable of advanced label inspection and barcode validation as well as grouping and rejecting items based on color. Program can set up and save inspection jobs to user's PC, which can be loaded to Vision HAWK cameras in case of line changeover. With database of password-protected usernames, manufacturers can gate access to certain software capabilities. Read More

Vision Systems, Optics & Photonics

Telecentric Lenses work with up to 16 MP resolution sensors.

October 23, 2014

Designed for semiconductor and electronics inspection, measurement, and gauging applications, TECHSPEC® High Resolution Telecentric Lenses for 1 in. Sensors feature high-light throughput f/6 designs while exhibiting <0.1° telecentricity and <0.1% distortion. Double-sided telecentric design promotes sharp image while minimizing errors for optimal measurement accuracy. Lenses support up to 16 mm max diagonal sensors and accommodate up to 16 MP resolution sensors. Read More

Vision Systems

HD Digital Video Tracker offers electronic image processing.

October 21, 2014

Consuming just 4 W of power, ADEPT4000 simultaneously performs target tracking with any SD/HD-­SDI or parallel digital video signal, electronic video stabilization, moving target detection, and video compression. Tracker incorporates onboard serial links and Ethernet, allowing it to interface to most platforms. Supplied in sub-credit card-sized package, ADEPT4000 is intended for space-constrained environments such as autonomous unmanned vehicles and man-portable systems. Read More

Vision Systems, Optics & Photonics, Robotics

Time Lapse Cameras monitor worksite activity remotely.

October 17, 2014

Used for remotely monitoring job sites, construction cams take photo every 15 min for each 12-hr time period and wirelessly route those photos to secure website. Project owners and developers can view, download, and email pictures at their discretion. Upon project completion, end-users are provided with time lapse video of all work accomplished. Cameras, offering 5 MP photos and zoom lens, are designed to facilitate use and installation. Read More
