Timers & Clocks

ON-Delay Interval Timer (1/16 DIN) provides multifunction support.

November 16, 2015

Model 405AE features on-delay and interval timing modes that each features 8 selectable time ranges and SPDT contact output configuration (5 A resistive). In on-delay mode, contacts transfer at time-out. In interval mode, contact transfer occurs when power is applied to device and released at time-out. Power options include 110 Vac and 24 Vac/dc, and 1/16 DIN housing carries IP40 rating for face plate. Analog dial is optimized for readability, and LED status indicator is standard. Read More

Timers & Clocks, Test & Measuring Instruments

Multi-Range Industrial Timer/Counter offers 10-in-1 functionality.

March 6, 2015

Offering 10 operating modes in one unit, Model 385AR series works with proximity switches, solid state devices, and potential-free contact encoders. Respective input speeds of 3 Hz, 30 Hz, and 5 kHz are standard, and unit incorporates 12 Vdc 30 mA sensor power supply with short circuit protection and options for front panel or remote reset. Supplied in 48 x 48 mm housing featuring 2 SPST (NO) 5 A @ 230 Vac contacts, unit offers dual setpoints, programmable input scaling, and batch counting. Read More

Electrical Equipment & Systems, Timers & Clocks

Single-Mode ON-Delay Industrial Timer comes in compact package.

July 22, 2014

Accepting 110 Vac (50 or 60 Hz) supply voltage, single-function Model 175SO-110 has low-profile (17.5 mm), DIN rail-mount housing and provides timing control within OEM and industrial applications. UL-listed and CE-certified product features 5 A SPDT relay output contact configuration, LED indication, and 10 unique, user-selectable time ranges that can be selected from 0.1 sec to 3 hr. Time range and scale are configurable via front facing knobs. Read More

Test & Measuring Instruments, Timers & Clocks

Ethernet Time Interval Counter contains 5 time-stampers.

October 28, 2013

Controlled via 100 Mbit Ethernet and USB interfaces, 5-channel Model T680 is suited for industrial and laboratory test and measurement. Each channel can snapshot time of rising edge of one electrical input, to 12.2 ps resolution with 48-bit range. In time-stamp mode, individual time stamps may be read, and in TIC mode, channel 0 may be used as start time reference for channels 1–4, with option to acquire times after or before/after start event. Read More

Timers & Clocks, Electronic Components & Devices

System Timers cut standby power consumption.

August 26, 2013

Drawing only 30 nA of current, Model TPL5000 with watchdog timer and Model TPL5100 with MOS driver replace microcontroller's internal timer, allowing MCU to remain in low-power sleep mode. TPL5000's selectable timing delay can be set from 1–64 sec to further extend battery life in applications such as smoke detectors. It can also be programmed for 16- to 1,024-sec intervals in energy harvesters, wireless sensor nodes, and data loggers, where measurement data changes slowly. Read More

Timers & Clocks

Countdown Timer features 1 1/2 in. digits.

January 16, 2013

Viewable from 60 ft, Traceable® Extra, Extra, Large Digit Countdown Timer can time up to 99 minutes, 59 seconds with 1 sec resolution and 0.01% accuracy. Three-key operation enables users to program countdown settings in 1 sec increments. After counting down, alarm sounds and timer counts up to indicate elapsed time since alarming. Measuring 3 1/8 x 2 ¾ x 1 in., timer is supplied with battery, flip-open stand, clip, magnet, and Traceable® Certificate. Read More

Timers & Clocks

Multifunction Timers use solid state relay technology.

December 14, 2012

Housed in 11 mm wide DIN rail mounted package, SeriesOne DR Timers provide 8 microprocessor-based timing functions with 18 possible variations. Basic timing function selection is user settable via screw slot rotary switches on side of timers, while unit and fine timing adjustments are made on front panel. Designed for direct control of resistive and inductive loads, series is available with solid state output ratings of either 6 A/24–280 Vac or 6 A/1–60 Vdc, both at 40°C ambient temperature. Read More

Timers & Clocks

Compact Timer offers count up/down operation and clock.

July 13, 2012

With resolution of 1 sec and accuracy of 0.01%, Traceable® Flashing LED Big-Digit Dual Channel Timer allows simultaneous programming of 2 different activities from 99 hr, 59 min, 59 sec to 1 sec. Each channel has distinct electronic alarm and visual indicator when zero is reached. Alarm silences automatically after 1 minute or may be turned off manually. For repetitive timing, 3½ x 3 x ¼ in. unit permits setting 2 countdown times into memory. Multiple mounting options are available. Read More

Timers & Clocks, Electronic Components & Devices

Timer IC combines low power consumption, ease of programming.

April 27, 2012

Supplied in low-profile, 8-pin, 2 x 2 mm TDFN package with exposed back-side paddle, TS3001 CMOS oscillator/timer consumes 1 µA supply current at 25 kHz and operates from single 0.9-1.8 V supply. Operation is specified over -40 to +85°C range, and timer frequency is set with one resistor. Additional characteristics include frequency out period drift of 0.021%/°C, PWMOUT duty cycle range of 12%-90%, and output driver resistance of 160 ohm. Read More

Test & Measuring Instruments, Timers & Clocks

Multifunction Devices operate as timers, counters, tachometers.

April 19, 2012

Available in standard 1/16 DIN size, CTT series accepts voltage and non-voltage inputs from NPN, PNP, or dry contact sensors and can operate as digital counter, timer, combination timer/counter, or tachometer. Counting speeds are selectable to 10,000 cycles/sec, and double-line, 6-digit, 2-color LCDs present values and facilitate setup. While Output 1 is SPST relay and NPN transistor that operate concurrently, Output 2 is available as SPDT relay or NPN transistor. Read More

Timers & Clocks

Dual Channel Timer has programmable memory.

April 17, 2012

With 1 sec resolution and 0.01% accuracy, Traceable® Flashing LED Big-Digit Dual Channel Timer allows simultaneous timing on 2 distinct channels from 99 hr, 59 min, 59 sec to 1 sec. Each channel has distinct electronic alarm and visual indicator for when zero is reached. Alarm may be turned off or will silence automatically after 1 min. The 5/8 in. high LCD digits promote readability, and adjustable volume has 3 settings to accommodate environmental requirements. Read More

Timers & Clocks, Electronic Components & Devices

Silicon Timer IC requires 1 resistor and 1 capacitor.

March 1, 2012

Housed in 2 x 2 mm TDFN-8 package, Model TS3002 is fully specified to operate at 1 V while consuming 1 µA supply current at output frequency of 25 kHz. Single-supply CMOS oscillator/timer requires just 1 resistor and 1 capacitor to set output frequency. Operating from -40 to +85°C with FOUT Period Drift of 0.044%/°C, device is suited for portable and battery-powered equipment. Read More

Timers & Clocks

Adjustable Alarm Timer provides 0.01% accuracy.

February 24, 2012

Featuring 1 in. high digits and microcomputer chip that allows memory to store countdown settings, Traceable® Flashing LED Alert Big-Digit Alarm Timer counts down from 99 minutes, 59 seconds to 1 second. When zero is reached, timer starts counting up to show time elapsed since alarm sounded. Adjustable alarm has 3 settings: high volume for noisy areas, low for quiet environments, and muted for visual flashing only. To assure accuracy, serial-numbered Traceable® Certificate is provided. Read More

Test & Measuring Instruments, Timers & Clocks

Frequency Counter/Timers feature LXI Class C compliance.

October 21, 2010

Offering base bandwidth of 350 MHz and options up to 15 GHz, RF and universal 53200 series delivers up to 12 digits/sec continuous-count, gap-free frequency resolution and 20 psec single-shot time interval resolution. LXI/Ethernet and USB 2.0 are standard, facilitating connection to PC test system instruments or network, and internal memory stores 1M readings. Along with post-measurement analysis capabilities, product provides math and statistical information. Read More

Timers & Clocks

Programmable Timer supports industrial OEM applications.

September 27, 2010

Intended for applications requiring daily or weekly schedule, Model 7DT-2CH features 2 independent control channels, 2 outputs, and 16 A contacts in DIN rail mounting package. Unit is programmable via 4 keys, with LCD providing visible indication of output, mode, day, and time, with minimum interval of 1 sec. Switching can be achieved either automatically according to program or manually. Supporting AC or DC voltage requirements, timer conforms to EN 61812-1 and EN61010-1 testing standards. Read More

Timers & Clocks

Solid-State Electronic Timer features rugged housing.

May 7, 2010

Incorporated into vibration-resistant composite encapsulant housing, Canfield Connector TMLT is solid-state timer which offers 16 timer modes of operation and 14 time ranges, from 0.5-2,000 sec. Voltage range is 24-240 Vac at 50/60 Hz and 12-240 Vdc, while maximum current draw is 2 mA. Product's onboard indicator light aids troubleshooting, and mounting is accomplished via through hole supporting up to ¼ in. screw or DIN rail-mount adapter plate. Read More

Test & Measuring Instruments, Timers & Clocks

Counters/Timers combine panel meter features, other options.

April 15, 2010

Supplied in 28 x 51 mm housing with IP65 front bezel, CUB7 counters and timers offer panel meter features and are available in low- (28 Vdc max) and high-voltage (50-250 Vac max) input formats. Each model provides 22-gauge wires for external connections, but optional wiring terminal block is available. Along with 3 LCD options, features include front panel keypads, count speeds up to 10 kHz, and internal lithium battery that delivers up to 7 years of uninterrupted operation. Read More

Test & Measuring Instruments, Timers & Clocks

Batch Counter/Timer offers presetable operation.

January 4, 2010

Able to be preset to any number from 0000-9999 via menu activation keys, Model PBC has two 4-digit, 7-segment, color-coded displays: red for count and green for preset. Unit is suited for various uses - Up or Down Counter or Timer - and accepts different input types, including dry contact, TTL/CMOS, or high voltage. Being µP-based, this all-electronic and microprocessor-based product can be configured for many modes, such as count or time in engineering units. Read More

Timers & Clocks

Timer Accessory controls power supply output.

December 30, 2009

Housed in ABS enclosure with No. 22 AWG wires for inputs and outputs, Model GTIM-2 will allow supply of output voltage for 3 hours after pressing ON button and includes LED indicators for visual status. Accessory module has rated input voltage of 12 Vdc and input/output power rating of 0.5 A/6 W. Designed for use in 0-40°C environments, Model GTIM-2 complies with international Safety and EMI/RFI Regulations, EMC Directives/CE and FCC Class B for ITE/Medical Applications. Read More

Timers & Clocks

Digital Timer includes audible alarm.

June 12, 2009

Providing accurate countdown timing for variety of applications, Series LCT316 can be triggered remotely using digital input terminals or locally via set button. Time intervals can be set up to 999 minutes or seconds. Operating from 32-158°F, timer includes LED status light to show time and operation, and internal buzzer to alert when time interval has expired. Read More
