Despatch Industries
Lakeville, MN 55044
Aug 03, 2005 Model PCO2-14â„¢ optimizes polyimide cure process for semiconductor wafer devices. It enables consistent, reproducible cure process for all wafers by combining Class 10 clean process operation, inert atmosphere capabilities with less than 20 ppm of oxygen, temperatures up to 350°C, and ±1% part uniformity. Oven can be networked and controlled from central location, and atmosphere data can be monitored and recorded throughout cycle.

Research, Inc.
Brooklyn Park, MN 55428
Jul 11, 2005 Suited for automotive and appliance industries, ProfileIR generates intense short wave infrared energy (NIR) in heating chamber with 6 independently controlled heating zones that immediately cure surface of rubber to cast and hold profile shape. Surface cure also eliminates scuff marks and creates smooth, unblemished appearance on final product. Moveable base can be positioned on extrusion line, and chamber can be tilted to accommodate droop in line.

Grieve Corporation, The
Round Lake, IL 60073-2898
Jun 21, 2005 With workspace dimensions of 35 x 31 x 42 in., portable No. 947 uses 750 cfm, ¾ hp recirculating blower to produce horizontal airflow across load, which is heated by 9.6 kW installed in Nichrome wire heating elements. Oven features 4 in. thick insulated walls, stainless steel exterior, Type 430 stainless steel interior, and top-mounted heat chamber. Dual, independently operating doors provide access to workload, and 2 tiers of 5 shelves are supported on rollers.

Grieve Corporation, The
Round Lake, IL 60073-2898
Jun 17, 2005 With workspace dimensions of 24 x 36 x 27 in., No. 962 Class 100 cleanroom cabinet oven uses 600 cfm, ¾ hp recirculating blower to deliver horizontal airflow to workload, which is heated by 10 kW installed in Incoloy-sheathed tubular elements. Unit features 4 in. insulated walls, stainless steel exterior, as well as front and rear single access doors. Digital programming and recording temperature controller activates dampers and locks access doors during cycle.

Grieve Corporation, The
Round Lake, IL 60073-2898
Jun 14, 2005 With 26 x 22 x 16 in. workspace dimensions, No. 952 has 3 kW Incoloy-sheathed tubular elements and employs 1/80 hp recirculating blower to create convection air movement in chamber. Unit includes programmable and recording temperature controller with 10 in. dia circular chart as well as manual reset excess temperature controller. Construction includes 3 in. insulated walls, aluminized steel exterior, and Type 430 stainless steel interior.

Heraeus Noblelight Inc.
Duluth, GA 30096
May 26, 2005 Suited for production of brake pads, dual-zone, 162 kW oven employs 30 medium-wave emitters on wire belt conveyor for curing anti-corrosion coating that provides protection to pad against water damage during operation. Control panel features 5 selector switches that each control 6 emitters, which may be set to zero, 50%, or 100% power. Control panel also features potentiometer that sets conveyor speed from 0.5–2.0 m/min.

Wisconsin Infrared Systems
East Troy, WI 53120
Apr 29, 2005 Suited for automotive industry to cure water-based coatings on cow hides, model 808CM09516 cures 18 g of wet paint in 1 min and removes moisture associated with cure process via variable-frequency-driven exhaust system. Oven utilizes SunCatâ„¢ heater that uses catalyst technology and operates at temperatures from 800–1,700°F. Combustion blower feeds oxygen to face of heater, heating parts not in line of sight of IR. Product is rated at 1,408,000 BTUH @ 2 psi.

Wisconsin Infrared Systems
East Troy, WI 53120
Apr 14, 2005 Featuring 3 zones that provide uniform heat across web, model Web Dryer/IR/E removes moisture on steel web from 1/8–½ in. thick. Oven uses medium-wave, rapid response heaters and lets users turn off zones when drying smaller web widths. With heaters mounted to heat from top-down and bottom-up, unit can operate coil temperatures up to 2,000°F. Casters enable unit to be moved off web line as required and heating capacity is rated at 200 kW.

Wisconsin Oven Corp.
East Troy, WI 53120
Apr 13, 2005 With heating capacity of 200 kW, WebDryer/IR/E dries moisture on steel web ranging from 1/8–½ in. thick and running up to 200 fpm. Three zones provide uniform heat across web and can be turned off when drying smaller web widths. Featuring tongue and groove panel construction with 6 in. of insulation, oven uses medium-wave, rapid response heaters and can operate coil temperatures up to 2,000°F. Unit is rated for 200–600°F and is mounted on casters.

Grieve Corporation, The
Round Lake, IL 60073-2898
Mar 24, 2005 With workspace dimensions of 24 x 24 x 24 in., electrically-heated, top-loading No. 943 features 26 kW installed in nickel chrome wire coils, which are supported by vacuum-formed ceramic fiber. Insulated walls integrate 5 in. of 2,300°F ceramic fiber blanket and 2 in. of block insulation. Unit includes 6½ in. thick furnace floor made of castable refractory materials; air-operated, vertical lift door; and reinforced ½ in. steel top plate.

Grieve Corporation, The
Round Lake, IL 60073-2898
Feb 07, 2005 With workspace dimensions of 36 x 120 x 36 in., No. 938 has aluminized steel exterior; Type 304, 2B finish stainless steel interior; and 10 in. insulated walls. Electrically-heated oven has 80 kW installed in Incoloy-sheathed tubular heating elements and 6,000 cfm, 5 hp recirculating blower that provides universal front to rear airflow to load. Also included, 975 cfm blower pulls air through air jacket on inner oven for cooling.

Grieve Corporation, The
Round Lake, IL 60073-2898
Jan 18, 2005 No. 839 electrically heated, 850°F walk-in oven offers workspace dimensions of 72 x 120 x 72 in. Featuring 12,500 cfm, 10 hp recirculating blower, oven provides combination horizontal/vertical airflow to workload. It has aluminized steel exterior and interior with 7 in. thick insulated walls plus 4 in. thick insulated floor with built-in truck wheel guide tracks. Inner door gasket seals against door plug, and outer door gasket seals directly against front face of the oven.

Wisconsin Oven Corp.
East Troy, WI 53120
Jan 11, 2005 Featuring 1,000°F max continuous operating temperature, 9 ovens feature 18 x 5 x 2 ft work chamber with 2 conveyor belts. Each conveyor lane includes 24 in. wide, 304 stainless steel, 1 x 1 in. flat wire belt and is driven by separate variable-speed dc drive. Heated with direct-fired burner rated for 1,800,000 BTU/hr, ovens have NEMA 12 control panel and plug-mounted blower rated for 30,600 cfm @ 25 hp. Ductwork is arranged for bottom-up vertical airflow.

Wisconsin Infrared Systems
East Troy, WI 53120
Dec 20, 2004 Rated for 200–600°F, indexing batch oven employs 12 SunCatâ„¢ Gas Catalytic Medium-Wave burners, each rated at 88,000 BTUH. Able to operate at temperatures to 1,700°F, IR heaters have combustion blower that feeds oxygen to face of heater and acts as source for convective air. Oven features 14 ft x 6 ft x 10 ft 6 in. work chamber, 4 in. thick tongue and groove panel construction, modulating exhaust damper, and multiple zones with selective operation.

Wisconsin Infrared Systems
East Troy, WI 53120
Dec 08, 2004 Model ISC-102-4Z Medium Wave Infrared Seat Dewrinkling Oven has multiple zones that provide optimum heat to different areas of automotive seats. Heating panels are fabricated of type 430 stainless steel and can be moved in multiple directions. It utilizes medium-wave quartz goldenrod tube technology and features snap-in ceramic blocks. Control package uses PLC to store multiple recipes, reducing changeover time.

Wisconsin Oven Corp.
East Troy, WI 53120
Dec 06, 2004 With 27 x 9 x 9 ft clear work chamber, natural gas fired Model SWH-9279-G has max continuous temperature rating of 500°F and delivers heated air through adjustable duct for uniform distribution. Burner, rated for 1.5 MBTUH, and recirculation blower, rated for 18,500 cfm @ 20 hp, are located in roof-mounted heater house. Oven body is fabricated with 4 in. thick tongue and groove panel assemblies, while interior sheet metal and ductwork feature aluminized sheet metal.

Grieve Corporation, The
Round Lake, IL 60073-2898
Nov 23, 2004 Seven-zone, gas-heated No. 919 features max operating temperatures of 350°F in Zones 1–4 and 1,000°F in Zones 5–7. Modulating natural gas burners in Zones 1-4 are rated 400,000 btu/hr. while Zones 5-7 are rated 500,000 btu/hr. Measuring ½ in. wide, stainless steel, balanced weave conveyor belt is powered by 1 hp motor drive, variable from 1.5–30 ipm. Two 36 in. tubeaxial fans, each driven by 5 hp motor, push/pull air through oven's cooling zone.

Wisconsin Oven Corp.
East Troy, WI 53120
Nov 10, 2004 With inside work chamber dimensions of 8 x 10 x 8 ft, natural gas-fired Model EWN-810-8G8 is rated for continuous max temperature of 800°F. Oven body is fabricated with 6 in. thick tongue and groove panel assemblies and is reinforced with structural steel. Unit is heated with Eclipse 650,000 btu/hr direct-fired burner and uses plug-mounted, belt-driven, recirculation blower rated 8,600 cfm at 7½ hp to provide combination airflow through work chamber.

Wisconsin Oven Corp.
East Troy, WI 53120
Nov 01, 2004 Featuring 7 x 21 x 8 ft work chamber, natural gas fired Batch-7/21/8-G is rated for max temperature of 500°F. Body is fabricated with 4 in. thick tongue and groove panel assemblies, and reinforced with structural steel. Interior sheet metal and ductwork features aluminized sheet metal bonded finish, which is resistant to corrosion, flaking, and peeling. Motor-operated linkage opens exhaust and fresh air dampers, while blower provides over 31 air changes/min.

Wisconsin Oven Corp.
East Troy, WI 53120
Oct 26, 2004 Measuring 21 x 25 x 22 ft, Propane Gas-Fired Batch Oven is fabricated with 6 in. thick tongue and groove panel assemblies and reinforced with structural steel. Interior sheet metal and ductwork feature aluminized sheet metal for resistance to corrosion, flaking, and peeling. Bi-parting doors at each end allow flow through operation and include FM-approved explosion relief latches. Notch in each set of doors allows installation of overhead trolley rail system.
