Large-Capacity Walk-in Ovens support 650°F max operation.

January 28, 2016

Respectively featuring 476 and 952 ft³ capacities, TAD/TFD3-48 and TAD/TFD3-96 are available with Class A configurations and electric or gas heat. Both models feature uniflow airflow for uniform temperatures; high-volume fans deliver heated air through adjustable louvers from both sides of chamber. Used for aging, bonding, curing, drying, finish baking, and heat treating, ovens are equipped with Watlow F4T temperature controller and high limit controller with 4.3 in. graphical touchscreen. Read More

Thermal & Heating Equipment

Electrically Heated Walk-In Oven reaches 500°F.

January 28, 2016

Along with 36 x 300 x 36 in. workspace, No. 958 features 60 KW installed in lncoloy sheathed tubular heating elements and 4,200 cfm, 3 hp recirculating blower that provides combination airflow to workload. Construction includes 4 in. insulated walls, aluminized steel interior and exterior, 2 in. insulated floor with channel guide tracks, and 2 fixture supports with flanged wheels. In addition to multiple controllers, features include top mounted heat chamber and single front and rear door. Read More

Thermal & Heating Equipment

Portable Electric Conveyor Oven uniformly dries alloy steel parts.

January 14, 2016

Able to dry parts that are inconsistent in shape and wet on all sides, 120 in. 350°F electric conveyor oven supplies air from both top and bottom. Dual Vertical airflow pattern maximizes product surface area contact and provides uniform heating. In addition to flat wire mesh belt conveyor with belt and slider bed fabricated from 304 stainless steel, features include steel casters, multiple controllers, and 20 ft long, heavy-duty, power cord with 480 V pin and sleeve plug/receptacle. Read More

Thermal & Heating Equipment

Truck Oven operates up to 500°F.

December 23, 2015

Providing 48 x 36 x 96 in. workspace dimensions, No. 899 is equipped with 24 kW Nichrome wire heating elements and 1,000 cfm, 1 hp recirculating blower that provides vertical upward airflow to workload. Oven has 4 in. insulated walls, aluminized steel exterior, and Type 304 2B finish stainless steel interior. Controls include 10 in. circular chart recorder, manual reset excess temperature controller, digital indicating temperature controller, and recirculating blower airflow safety switch. Read More

Thermal & Heating Equipment

Industrial Oven removes diesel truck exhaust filter moisture.

December 18, 2015

Designed for diesel engine manufacturer, custom natural gas-fired oven removes moisture from exhaust filters used in diesel truck engines. Truck-in oven, constructed with heavy-duty, welded steel frame, dries insulated, stainless-steel and cordierite-ceramic filters at 1,200°F. Features include 18,000 cfm, compound, horizontal air circulation system and 144 ft³ internal workspace. Oven accommodates two 3-tiered, stainless-steel hand trucks, each carrying 12 filter assemblies. Read More

Thermal & Heating Equipment

Top-Loading 650°F Oven achieves 650°F max temperature.

November 27, 2015

Constructed with 5 in. insulated walls, aluminized steel interior and exterior, and reinforced ¼ in. steel plate top, No. 812 features air-operated rear hinged door and wear bars at sides of workspace. Workspace is reinforced for 3,000 lb loading at removable subway grate. While 40 kW installed in Incoloy-sheathed tubular elements heat 72 x 36 x 36 in. workspace, 3,300 cfm, 2 hp recirculating blower provides horizontal airflow to workload. Multiple controllers are included as standard. Read More

Thermal & Heating Equipment, Laboratory and Research Supplies & Equipment

Cleanroom Conveyor Oven cures low-friction coating onto vials.

November 25, 2015

Electrically heated Gruenberg NFPA 86 Class A Conveyor Oven cures thin coating onto glass vials, used in pharmaceutical industry, to produce low-friction surface. This 4-module, 400°C oven, which contains 3 heating chambers and one chamber for cooling, processes 120 vials/min as they advance in trays along >30 ft conveyor belt. Installed in each chamber, 1,750 cfm, vertical-down, air-circulation system with HEPA filters ensures uniform heat distribution. Read More

Thermal & Heating Equipment

Aluminum Melting and Holding Furnace has 13,700 lb max capacity.

October 27, 2015

Along with steel plate construction and steel member-reinforced shell, aluminum melting and holding furnace (gas fired) features roof-mounted, nozzle-mix radiant burner; pneumatic flue damper; drain tap; and UL-listed control panel. Holding capacity is 13,700 lb, and melting rate is 1,500 lb/hr. While preheat hearth with full width door is used for loading ingot, clamshell door is used for loading scrap. Dip well on each side provides molten aluminum to 2 die casting machines. Read More

Materials & Material Processing, Thermal & Heating Equipment

Walk-In Preheating Oven reaches temperatures up to 900°F.

October 26, 2015

Along with 50 x 96 x 96 in. workspace, No. 846 features 8 in. thick insulated walls, 6 in. insulated floor, aluminized steel interior and exterior, and removable, top-mounted heat chamber. One 7,800 cfm, 5 hp, recirculating blower provides combination airflow to workload, and access to Type 304, 2B finish stainless steel heat chamber interior is facilitated by 2 independent doors (front and rear). Floor of each opening is reinforced for 5,000 lb loading at removable subway grate. Read More

Thermal & Heating Equipment

Cabinet Oven operates up to 1,050°F.

September 23, 2015

Providing workspace dimensions of 50 x 50 x 50 in., electrically heated No. 1036 utilizes 80 KW Incoloy-sheathed tubular elements to heat oven chamber, and 3,750 cfm, 3 hp recirculating blower to provide horizontal airflow to workload. Oven is constructed with 10 in. thick insulated walls, aluminized steel exterior, and Type 304 stainless steel interior with 2B finish. System comes equipped with digital indicating temperature controller and recirculating blower airflow safety switch. Read More

Thermal & Heating Equipment, Materials & Material Processing

Gas-Heated Belt Conveyor Oven attains 850°F max temperature.

August 28, 2015

Along with 36 in. x 18 ft x 15 in. workspace, No. 867 has 800,000 BTU/hr installed in natural gas burner and one 12,500 cfm, 10 hp stainless steel recirculating blower. Oven travel length comprises 3 ft open belt loading and unloading zones, 18 ft insulated heat zone with recirculated airflow, and 30 in. wide, 304 stainless steel woven wire conveyor belt. Latter features 3 in. high flex plate edges and is driven by ½ hp motor v-belt drive capable of variable speed operation from 1–19 ipm. Read More

Thermal & Heating Equipment

Drum/Tote Oven safely heats flammable materials.

August 21, 2015

Suitable for Class I, Div I areas, Sahara Hot Box delivers precise temperature control and uniformity. Heating capability is based on application requirements, and steam, hot oil, or hot water can also be used as heating medium. Suited for heating hard-to-melt materials, forklift-portable Model E8 is insulated and features steel construction as well as built-in spill containment. Design also includes digital temperature control, independent over-temperature control, and air circulation blower. Read More

Thermal & Heating Equipment, Materials & Material Processing

High Temperature Ovens operate up to 1,000°F.

August 4, 2015

Featuring horizontal recirculating airflow to ensure temperature uniformity of ±5.6°C at 538°C, Models RAF and RFF are suited for annealing, aging, stress relieving, and other process critical applications. Class A Model RFF is designed to meet NFPA 86 requirements for applications that involve flammable solvents. Available in cabinet and benchtop sizes (4.2, 19, and 35 ft³), furnaces have Protocol 3™ microprocessor-based temperature and hi-limit controller with LCD and real-time clock. Read More

Thermal & Heating Equipment, Material Handling & Storage

Belt Conveyor Oven quickly dries coatings.

July 27, 2015

Featuring stainless steel wire mesh belt, electrically heated Belt Conveyor Oven dries coating on fasteners at rate of 1,300 parts/hr. Oven has max temperature rating of 400°F and 4 ft 6 in. x 7 ft 3 in. x 6 in. work chamber. Utilizing 6,000 cfm at 7 ½ hp belt driven blower and top-down airflow, recirculation system maximizes heating rates and temperature uniformity. Other features include variable speed drive for conveyor, SSR heater control, and digital recorder for chamber temperature. Read More

Thermal & Heating Equipment, Materials & Material Processing

Electrically Heated Walk-In Oven operates up to 1,200°F.

June 24, 2015

Offering 48 x 60 x 72 in. workspace, No. 901 utilizes 120 kW Incoloy-sheathed tubular elements to heat oven chamber and 12,500 cfm, 10 hp recirculating blower for horizontal airflow to workload. Unit features 10 in. thick insulated walls, comprising 2 in. of 1,900°F block and 8 in. of 10 lb/cf density rockwool. Constructed with aluminized steel exterior and Type 304, 2B finish stainless steel interior, oven has inner/outer door gaskets and 7 in. insulated floor with truck wheel guide tracks. Read More

Thermal & Heating Equipment, Materials & Material Processing

Universal Style Oven heats heavy metal dies to 550°F.

May 22, 2015

Providing 24 x 24 x 24 in. workspace dimensions, electrically heated No. 1034 utilizes 7 kW Incoloy-sheathed tubular elements to heat oven chamber and 400 cfm, 1/3 hp recirculating blower to provide universal front-to-rear airflow to workload. Oven features 6 in. insulated walls, aluminized steel exterior, and Type 304 SS interior with 2B finish. Measuring 24 x 24 in., two shelves are rated at 300 lb each and supported by rollers. Integral oven leg stand is also provided. Read More

Thermal & Heating Equipment

Electric Vertical Conveyor Oven operates at up to 250°F.

March 25, 2015

Offering 30 x 65 x 83 in. workspace dimensions, No. 963 utilizes Incoloy-sheathed tubular elements to heat oven chamber and 6,000 cfm, 5 hp recirculating blower to provide vertical upward airflow to workload. Oven has 4 in. insulated walls, aluminized steel exterior/interior, top-mounted heat chamber, and 2 independent doors for access to workspace and chamber. Measuring 24 x 6 in., product trays are supported at each side by roller chain and driven by ¾ hp motor, controlled by VFD. Read More

Thermal & Heating Equipment, Materials & Material Processing, Laboratory and Research Supplies & Equipment

Benchtop Oven suits production and laboratory applications.

March 23, 2015

Supporting USB, Modbus, and Ethernet communications, datalogging LAC features 304 stainless steel interior, horizontal recirculating airflow, and ±2.5°C temperature uniformity at temperatures up to 500°F. Controls, heater, and fan are located on top for ergonomics and service access convenience. Available for processing flammable solvents or removing large amounts of moisture, standard Class A (NFPA 86) model includes pressure relief panel, purge timer, exhaust fan, and safety circuitry. Read More

Thermal & Heating Equipment, Materials & Material Processing

Cabinet Oven heats metal parts to remove deposits.

January 22, 2015

Operating up to 1,250°F and providing 50 x 50 x 50 in. workspace dimensions, No. 975 is equipped with 160 kW Incoloy-sheathed tubular elements that heat oven chamber, and 6,000 cfm 5 hp recirculating blower that provides horizontal airflow to workload. Electrically heated oven has 10 in. insulated walls comprising 2 in. of 1,900°F block insulation and 8 in. of 10 lb/cf density rockwool insulation. Insulated floor is reinforced for 1,000 lb loading with ¼ in. thick, Type 304 SS plate.
Read More

Thermal & Heating Equipment

Gas Fired Preheating Oven offers 4-6 parts/min throughput.

January 20, 2015

Used for heating aluminum billets, which enter press to be forged into pistons, 12 ft 9 in. x 11 ft 4 in. x 12 ft gas fired preheating oven can produce 240–360 parts/hr. Furnace temperature is 850°F (950°F max), and dwell time is 30 min. Integral sensor detects 3 in. dia x 2.5–4 in. long products in place at oven exit, and extractor/pusher pushes billets onto transfer conveyor. Gas convection equipment includes nozzle mixing type burners with integral blower. Read More
