Validation and Test Instruments

Test & Measuring Instruments

Data Loggers feature wired LAN connection.

July 31, 2015

Designed to provide temperature and humidity measurement, 2-channel TR-7nw Series Thermo Recorders have wired LAN connection and ability to upload data automatically to cloud storage service. Using Access Point mode, users can view recorded data directly from smartphones and tablets without network. Loggers operate from one AA alkaline battery and offer direct data download via USB. Applications include cold chain temperature monitoring, environmental monitoring, and life science/laboratory uses. Read More

Display & Presentation Equipment, Test & Measuring Instruments

Video Management System provides accurate metadata capture.

July 27, 2015

Designed to capture critical situational data and combine it with camera and sensor data, VRD1 High-Definition VMS is suited for fixed and rotor-wing aircraft used in aerospace, defense, SAR, and public safety missions. Rugged COTS-based system captures, compresses, distributes, switches, outputs, records, and streams/downlinks video via Ethernet. To provide flight crews with viewing flexibility, system supports video scaling, windowing, and quad picture-in-picture/picture-by-picture display. Read More

Test & Measuring Instruments

VNA Calibration Kits come in 50 and 75 ohm versions.

July 27, 2015

Featuring all necessary Short Circuits, Open Circuits, Loads, and Thru (SOLT) components required for proper testing, General Purpose VNA Calibration Kits are designed for fine-tuning and calibration of sensitive test equipment in engineering labs, production environments, and quality testing facilities. Kits include 50 Ω, 3.5 mm version up to 26.5 GHz; 50 Ω, 3.5 mm version up to 8.5 GHz; and 75 Ω Type-F kit operating to 3 GHz. Read More

Test & Measuring Instruments

Ultrasound Systems inspect internally corroded pipes.

July 23, 2015

Providing tools for C-Scan imaging, 2-axis MapSCANNER and MapROVER detect wall thickness loss due to corrosion, abrasion, or erosion. Semi-automated MapSCANNER works with HydroFORM or Dual Linear Array phased array corrosion mapping solutions, while fully automated MapROVER works with HydroFORM solution. MapROVER utilizes 4 magnetic wheels that are motorized for constant data acquisition up to 147 mm/s. Motorized raster arm enables 600 mm scan width traveling at speed up to 900 mm/s. Read More

Test & Measuring Instruments

DAQ Systems monitor processes independent of PC.

July 23, 2015

Combining analog and digital inputs with ability to acquire data via PROFIBUS, ModBus, and OPC, ProfiMessage and Expert Devices are suited for process monitoring tasks. Devices provide independent acquisition and monitoring of infinite number of channels, and can directly record and report limit value violations without need for PC support. Limit value violations can also be portrayed in alarm list. Data is permanently and securely recorded to Delphin ProfiSignal database. Read More

Test & Measuring Instruments

Temperature Calibration Software ensures consistent results.

July 21, 2015

MET/TEMP II v5.0 automates batch calibrations of platinum resistance thermometers, liquid-in-glass and bimetallic thermometers, thermistors, and thermocouple sensors to standardize testing for consistent results. Solution also calculates characterization of coefficients and generates calibration reports. Along with Windows® 7/8 compatibility, features include support for such temperature calibration sources as 9190A Ultra-Cool Field Metrology Well and 9118A Thermocouple Calibration Furnace. Read More

Test & Measuring Instruments, Electrical Equipment & Systems, Controls & Controllers

Solar Simulation Interface tests photovoltaic I-V curves.

July 20, 2015

Offered as user-installable, plug-and-play option for SM3300 Series programmable DC power supplies, INT MOD SIM (Simulation Interface Module) offers custom programmable table for complex I-V curve simulation. PV simulation interface can also be used for simulation of foldback current limit and testing dynamic Maximum Power Point Trackers (MPPT) efficiency to EN 50530 standard. Features include Windows Web interface GUI and compensation for voltage drop in load leads without sense wires. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Roughness Sensor enables all measurements on one CMM.

July 16, 2015

Simplifying QA workflow, ZEISS ROTOS is used via stylus changer interface on probe of coordinate measuring machine (CMM) under full CNC control and enables standard-compliant measurement of roughness and waviness on one CMM. All features of technical drawing can be fully captured with one CMM and displayed in one report, and various measuring positions can be reached without rechucking. Rotary axis can turn full 360° and be tilted perpendicularly to provide tilt range of 160°.
Read More

Test & Measuring Instruments, Optics & Photonics

Microscope System utilizes angle measuring eyepiece.

July 14, 2015

Available for modular tool microscope system, AME-5M Goniometer Eyepiece measures over 360° to accuracy of 5' (minutes) by use of rotary Vernier and crosshair eyepiece. Unit features white scale on black background and can be enlarged by 10X magnifier. Modular design enables user to attain magnifications from 3X–800X using choice of 3 microscope body styles, 3 rack-and-pinion mounting brackets, 2 illuminators, and 2 video adapters. System can handle workpieces up to 7 in. in length. Read More

Test & Measuring Instruments

BGA Interposer probes DDR4 x16 designs with logic analyzer.

July 13, 2015

Sized to test designs with tight space restrictions, Keysight W4636A lets engineers capture address and command signals, as well as subset of data signals, for debugging designs and performing functional validation measurements for data rates up to 2,400 Mbps. This DDR4 x16 two-wing, small-KOV (keep-out volume) BGA interposer provides direct access to balls of JEDEC-standard DDR4 x16 96-ball DRAM with low loading and minimal impact to signal integrity on embedded-system designs. Read More

Test & Measuring Instruments, Materials & Material Processing

Reflow Simulator accommodates full size PCBs for testing.

July 9, 2015

By using hot air of upper heater and extreme infrared radiation of lower heater together, MALCOM RDT-250C can reproduce temperature profile of reflow oven while allowing operators to observe melting state of solder paste and record process. Local matrix control system of upper heater enables reflow soldering of PCB in which thermal capacity is balanced with best heating temperature. Operator can observe state of soldering through wide glass windows from rear of unit. Read More

Test & Measuring Instruments

Inspection System ensures quality of reflecting surfaces.

July 9, 2015

Integrating all components into compact device with height-adjustable legs, reflectCONTROL Compact comes in 2D version that recognizes defects on reflecting surfaces and 3D version that measures reflecting surfaces at submicrometer accuracies. Housing includes monitor for striped pattern protection, as well as up to 2 cameras. To avoid interference from ambient light, measuring field can be darkened on all 4 sides. System can be integrated into production lines via Ethernet interface. Read More

Test & Measuring Instruments

Universal Datalogger utilizes FPGA technology.

July 9, 2015

Featuring 24-bit ADC that ensures precision sampling rates up to 50 measurements/sec/channel, Expert Logger comes in 3 versions capable of processing 16, 32, or 46 analog input channels. Analog inputs are galvanically isolated from each other, and up to 8 digital inputs/outputs and one SDI-12 interface are also available. Internal 4 GB memory independently stores up to 100 million measurements, and access to stored data is via USB, WLAN, or remote cellular connection to Internet via UMTS/LTE. Read More

Test & Measuring Instruments

Video Inspection System features lightweight portable design.

July 7, 2015

Weighing 14 lb, Gen-Eye SDP combines all features of full-size video inspection system in portable package. System includes 10.4 in. sunlight-readable LCD, built-in 4-hr rechargeable battery for remote applications far from power source, and Wi-Fi transmitter that sends video to smartphone or tablet. With app, users can view and record video inspections at up to 300–500 ft. Additional features include built-in waterproof keyboard and integral SD recorder that stores up to 32 GB on one card. Read More

Test & Measuring Instruments

Data Logger utilizes user-replaceable probes.

July 6, 2015

Depending on measurement range of attached RTD probe, HiTemp140-M12 is capable of recording temperatures from -328° to 1,562°F. Logger features user-programmable recording interval ranging from 4 readings/sec to once every 24 hours, and is capable of storing up to 43,690 time and date stamped readings. Inheriting IP rating of probe it is being used with, logger meets IP needs of everything from dry heat sterilization to high moisture environments, including steam sterilization cycle monitoring. Read More

Test & Measuring Instruments, Vision Systems, Optics & Photonics

Industrial Videoscope delivers high quality still images, video.

July 2, 2015

Series C enables remote visual inspections of manufactured parts, structures, or areas that have limited direct visual access. While insertion tube maneuverability is enabled via flexible distal tip and spring neck design, combination of 8 brightness settings, glare reduction, high-intensity LED, and light-sensitive CCD camera chip technologies enables capture of images with desired brightness. Thumb-driven joystick controls 360° articulation of distal tip and up to 120° angulation. Read More

Test & Measuring Instruments, Food Processing & Preparation

Refillable Permeation Tubes accommodate light hydrocarbons.

July 1, 2015

Used in FlexStream™ calibration gas generator to produce ppm and ppb mixtures directly from pure gases, Trace Source™ 57 Series only use gas phase of compound. Controlling pressure in tube allows high-vapor pressure compounds – methane, ethane, ethylene – to be dispensed by permeation. Emission rate is proportional to compound pressure in tube, and attainable single-step dilution ratios from 1000:1 to >50,000,000:1 allow ppb mixtures to be made directly from pure analyte compound. Read More

Test & Measuring Instruments, Electrical Equipment & Systems, Vision Systems, Laboratory and Research Supplies & Equipment

X-Ray Generators suit medical radiography applications.

June 30, 2015

Featuring 450 kHz maximum output frequency, Z Series X-Ray Generators offer various options, including dual speed starter, dual filament drive, and variety of control console choices. Units are available from 32–65 kW peak power with 40–150 kV output voltage, and up to 5 different manual and AEC operating modes. Measuring 595 x 410 x 475 mm, generators have flexible interface that facilitates integration, installation, calibration, and service. Read More

Machinery & Machining Tools, Test & Measuring Instruments

3D Printer Materials Development Kit accelerates R&D.

June 26, 2015

Combining fast test cycle times with small build volume, RAM10™ 3D Printer Materials Development Kit provides open materials development system that uses ViriPrint™ software and includes fluids manifold, electronics, and spreader bars. Ability for users to change powder, binder, firing parameters, tubing, and powder deposition subsystems enables distributed development of new materials sets as well as scale-up to larger systems. Read More

Machinery & Machining Tools, Test & Measuring Instruments

Configurable Control Platform improves operational efficacy.

June 26, 2015

Improving utilization of existing tools and assets, Automation Platform consists of two programmable automation control options; I/O modules for interfacing to any type of sensor, actuator, valve, etc; and Controls Workbench software for configuration, process monitoring, tuning, and data storage. Library of process routine templates and function blocks facilitates implementation, and leveraging of Umetrics analytical solutions improves automation via real-time actionable data insights. Read More
