Testers

HVAC, Test & Measuring Instruments, Sensors, Monitors & Transducers

Humidity/Temperature Transmitter has duct mounted design.

February 27, 2015

Intended for HVAC and building technology sectors, EE150 employs housing concept, compact design, and Ø 6 mm probe that simplify mounting to facilitate installation. IP65/NEMA 4 enclosure protects electronics, measured values are issued via two 0–10 V or 4–20 mA analog outputs, and capacitive E+E humidity sensor element ensures long-term, stable measurement results. Also included, PTFE filter cap protects sensing head against contamination. Read More

Test & Measuring Instruments

Particle Sizing Probe offers granulation monitoring.

February 25, 2015

Featuring measuring range of 50–6,000 µm for powders, pellets, and granules, Parsum IPP-80 enables real-time monitoring of agglomeration, coating, and granulation processes. Inline probe includes built-in self-diagnostic tools and uses spatial filter velocimetry to provide continuous particle size and size distribution data. With no moving parts and stable optics, sanitary stainless steel unit is resistant to vibration, requires no manual alignment, and is specified for hygienic environments. Read More

Test & Measuring Instruments

BGA Interposer probes DDR4 x16 designs with logic analyzer.

February 24, 2015

Used for testing DDR4 x16 DRAM designs with U4154B logic analyzer, W4631A captures address, command, and data signals for debugging designs and making validation measurements. Solution connects directly to balls of DRAM with DDR4 96 ball riser (included) or optional 3rd party socket, enabling operation and acquisition with minimal impact to signal integrity on embedded system design. Interposer can be used with E5849A probes for high-data-rate (up to 3.2 Gbps) DDR4 DRAM designs. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Vector Network Analyzer is designed for testing RF components.

February 24, 2015

Comprising 2- and 4-port configurations offering frequency coverage from 9 kHz to 4.5, 6.5, or 9 GHz, E5080A ENA series provides functionalities for measuring active and passive RF components for R&D and manufacturing environments. Analyzer uses Keysight PNA- and PXI-Series software architecture, which facilitates measurements across multiple Keysight VNAs, and offers color touchscreen display that accelerates access to basic measurements. Typ dynamic range is 147 dB. Read More

Test & Measuring Instruments

Handheld Pressure Calibrator delivers lab accuracy in field.

February 23, 2015

Designed for process control applications, HPC40 Series can replace several gauges or calibrators and provides deadweight tester accuracy in on-site instrument. This mA loop calibrator, suitable for pressures ranging from vacuum to 15,000 psi, delivers accuracy of 0.035% of reading for all ranges and is fully compensated from -20 to +50°C. Latter enables same accuracy whether measuring pressure, current, voltage, or temperature. Use is facilitated via single-layer UI and full-color display.
Read More

Optics & Photonics, Test & Measuring Instruments

Spectrophotometer offers auto-scanning capability.

February 16, 2015

Capable of automatically measuring color chart for profile creation in about 4 minutes, Model FD-9 can reduce scanning time and operator errors while optimizing measurement accuracy. LCD mounted on main body allows users to set up, operate, and monitor instrument. FD-9 can be used in network environment to serve multiple printers from all major manufacturers. With optional automatic sheet feeder, up to 100 charts can be loaded into feeder and measured continuously. Read More

Computer Hardware & Peripherals, Test & Measuring Instruments

Multifunctional Cable Tester incorporates full-color display.

February 16, 2015

Within one handheld unit, Net Prowler™ Pro Test Kit combines network testing (physical layer and link), IP device address mapping, cable troubleshooting, and PoE voltage testing. Functionality supports full cable testing on any category network, coax, or telephone cable, and display shows wire map, numbered ID remotes, and any faults. Network tests can also be saved for record keeping and printing using companion software application. Read More

Optics & Photonics, Test & Measuring Instruments

Portable Field Testers simplify FTTA and DAS deployments.

February 13, 2015

All-in-one Ethernet/optical FTB-700G Series and FTB-800 NetBlazer Series provide enhanced common public radio interface (CPRI) protocol testing solution. This feature helps field technicians to install and maintain fronthaul networks by testing connectivity and data integrity between remote radio head (RRH) and baseband unit (BBU) in fiber-fed cell towers. Also, CPRI functionality reduces unnecessary tower climbs. Both portable field testers also feature usability-optimized UIs. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Motor Drive Analyzer leverages high-definition oscilloscope.

February 11, 2015

Motor Drive Analyzers (MDAs) of MDA800 Series combine 3-phase power analyzer static (steady-state) calculations, dynamic 3-phase power and mechanical motor analysis capabilities, and high-bandwidth (350 MHz, 500 MHz, and 1 GHz) embedded control system debug in one instrument. Based on HDO8000 oscilloscope, products come standard with 8 input channels (16 digital channels optional) with 12-bit resolution, 2.5 GSps sample rate, and up to 250 Mpts/ch acquisition memory. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Viscosity Meter incorporates tuning fork design.

February 11, 2015

Providing accurate, fast-response viscosity and density monitoring, direct insertion Micro Motion® Fork Viscosity Meter is suited for demanding process applications such as oil-fired heater combustion control, HFO blending/production, and pump protection. Unit incorporates hazardous area approved head-mounted transmitter that can connect to control systems via digital and analog protocols. Meter is also capable of accepting and processing external signals from other field instrumentation. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Automatic ID

Handheld Analyzers offer 2 cable test options.

February 9, 2015

With Time Domain Reflectometry option, FieldFox Handheld Analyzers become suitable tool for any cable system test. Option measures impedance changes along cable and helps identify specific faults. FieldFox Extended Range Transmission Analysis option enables users to measure in-situ, long lossy microwave cables. With this option, 2 FieldFox instruments are deployed at each end of measured cable. One analyzer acts as source, while other acts as receiver. Read More

Test & Measuring Instruments

Contamination Test Systems check purity of electronics.

February 5, 2015

Designed to meet ANSI / J-STD-001 and IPC-TM-650 standards, SCS Ionograph SMD V and Ionograph BT Series allow accurate determination of purity of electronic components with SMT devices and bare and populated boards. SMD V provides accurate test functions directly at production site, has optional heating functions, and is fully controlled by SCS PowerView ™ software. SCS Ionograph BT Series is available according to customers' requirements in small, medium, or large version. Read More

Test & Measuring Instruments

Two-Wire Industrial Pressure Transmitter delivers 0.1% accuracy.

February 5, 2015

Incorporating temperature-compensated piezoresistive transducer for gauge pressure measurements of non-corrosive gases and liquids, Type 5000 converts signal pressure input into 4–20 mA or 10–50 mA output with 0.1% typ accuracy. Transducer offers dynamic response and is insensitive to mounting orientation and vibration. Zero and span adjustments are accessible from field wiring compartment, and connections are accessible via top cover removal. Various industry certifications are available. Read More

Test & Measuring Instruments

Temperature Data Loggers enable monitoring from anywhere.

January 30, 2015

Suitable for harsh industrial environments, T&D TR-71wf WiFi Temperature Dataloggers send data to cloud where it can be monitored from anywhere. Two-channel model monitors temperature from -40 to 230°F using external thermistor sensor. Whenever product’s temperature goes out of specification, wireless loggers will immediately send warning email over Internet or LAN network. Alert icon and graph showing color-coded values give users time to take corrective actions. Read More

Test & Measuring Instruments

Packaging Tester measures oxygen permeability.

January 30, 2015

With 3 integrated test cells, I-Oxtra 7700 Oxygen transmission Rate Testing System is designed to improve test efficiency and minimizes space requirements. System is designed according to ASTM D3985 (based on equal pressure method) as well as ASTM F2622, ASTM F1307, ASTM F1927, and ISO 15105-2. Film test ranges of 0.01–6,500 cm³•d (standard) and 0.07–65,000 cm³•d (optional) offer 0.001 cm³/m²•d resolution, while package test range of 0.0001–60 cm³/m²•d offers 0.00001 cm³/pkg•d resolution. Read More

Test & Measuring Instruments

NDT Instrument hastens complete electric motor health analysis.

January 27, 2015

Offering on-screen guidance, portable ALL-TEST PRO® 5 enables complete electric motor health analysis within minutes. This de-energized, non-destructive instrument offers complete stator and rotor analysis, auto diagnosis within AT5, as well as trending and reference testing. Route-based testing option is also included, and operation allows testing to be performed from distances of 1,000+ ft from motor control center. Latter accommodates inaccessible or hard-to-reach motors. Read More

Test & Measuring Instruments

Bit Error Rate Tester incorporates programmable ISI function.

January 27, 2015

Offering receiver characterization for single- and multi-lane devices operating up to 16 and 32 Gbps, J-BERT M8020A accelerates insight into digital designs. Integrated in each pattern generator channel, adjustable intersymbol interference (ISI) function enables channel loss emulation and streamlines test setup by eliminating need for external cabling and external ISI trace switching. ISI option supports range of loss up to 25 dB and 16 GHz with linear loss curves and fine step resolution. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Pressure Transducer features high-seed USBH output.

January 27, 2015

Available in gage, sealed gage, and absolute pressure models, PX51 features all-stainless steel construction and connects directly to computer. PC software takes data from transducer directly to digital domain, turning laptop or Windows®-based tablet (with USB connection) into virtual meter, chart recorder, or datalogger. Supplied with .NET APIs, command set for command-line access, and 6 ft USB cable, transducer supports use in harsh environments. Read More

Test & Measuring Instruments

UXM Wireless Test Set offers LTE-A carrier aggregation support.

January 26, 2015

Created for functional and RF design validation in 4G era and beyond, E7515A integrated signaling test set provides features that address evolving 3GPP LTE-Advanced carrier aggregation advancements. Support for multiple cells, downlink and uplink carrier aggregation, MIMO up to 4x2, and integrated fading helps users assess design readiness. Features address diverse UE test applications, including RF, data throughput, mobility, battery drain, functional, and OTA. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Differential Pressure Transducers utilize solid state sensor.

January 22, 2015

Based on micromachined silicon sensor, PX509HL Series provides stable reading with accuracy of 0.08% and broad compensated range of -20 to 85°C. Wet/wet differential pressure transducers operate in demanding industrial areas with ruggedized containment pressure up to 10,000 psi. Compensated overload range minimizes errors induced by large line pressures. Constructed of welded stainless steel, modular transducers offer user accessible potentiometers for zero and span. Read More
