Test Fixtures




(Showing headlines 1 - 20)   more ....
Swivel Lid Spring Pin BGA Socket supports geometric processors.

Swivel Lid Spring Pin BGA Socket supports geometric processors.

Ironwood Electronics, Inc    St. Paul, MN 55121
Feb 17, 2014 Designed for testing 10 x 8 mm, 0.5 mm pitch, 223-position, 15 x 19 ball array packages, Model SBT-BGA-7019 features stamped spring pin contactor with 31 g actuation force per ball and cycle life of 125,000 insertions. Contactor provides self inductance of 0.88 nH, insertion loss of less than 1 dB at 15.7 GHz, capacitance of 0.097 pF, and current capacity of 4 A at 30°C temperature rise. Mounted using supplied hardware on PCB with no soldering, socket features temperature range of -55 to +180°C.

Inline Production System supports programming and board test.

Inline Production System supports programming and board test.

GOEPEL electronics LLC    Austin, TX 78759
Dec 09, 2013 Designed for in-system programming and board test based on Embedded System Access technologies, RAPIDO™ can utilize planar downholders in sandwich construction to safely handle ultra-thin, rigid-flexible boards with contact gaps up to 50 mil. All fixtures are equipped with intelligent module for identification and data storage, ensuring compatibility between fixture and target board. In addition, bandwidth, UUT, and test program can be automatically configured to avoid manual faults.

Spring Pin Socket tests DFN6 electronic filters.

Ironwood Electronics, Inc    St. Paul, MN 55121
Nov 21, 2013 Designed for testing 3.1 x 3.45 mm DFN6 devices, Model CBT-QFN-7033 utilizes stamped spring pin contactor with 34 g actuation force per ball and cycle life of 10,000 insertions. Contactor features self inductance of 0.9 nH, insertion loss of less than 1 dB at 9.1 GHz, capacitance of 0.03 pF, and 2.2 A current capacity. Operating from -55 to +155°C, socket has clamshell lid and accommodates two DFN devices. Swivel compression plate enables vertical force without distorting device position.

Extreme Temperature Socket tests 9 x 9 mm QFN devices.

Extreme Temperature Socket tests 9 x 9 mm QFN devices.

Ironwood Electronics, Inc    St. Paul, MN 55121
Oct 03, 2013 Featuring stamped spring pin contactor with 31 g actuation force per ball and cycle life of 500,000 insertions, Model CBT-QFN-7031 tests Unisem's 124-lead, 0.5 mm pitch, QFN devices. Contactor features self inductance of 0.88 nH, insertion loss of less than 1 dB at 15.7 GHz, and capacitance of 0.097 pF. Current capacity is 4 A at 40°C temperature rise. Operating from -55 to +180°C, socket includes clamshell lid and 3 W heat sink with small DC fan.

High Power LED Reliability Testers are LM-80 qualified.

High Power LED Reliability Testers are LM-80 qualified.

EJ Thermal Technology, Inc.    Ft. Lauderdale, FL 33316
Sep 05, 2013 Self-contained HyrdoTower has up to 4 independently controlled thermal platforms for elevating and controlling temperatures of LEDs from 55 to 105°C for reliability testing. Modular design allows independent, concurrent temperature control for 4 separate purposes. HydroPac II offers 2 test positions and accommodates power loads up to 3,000 W, and HydroPac IV offers 2 independently controlled zones and up to 4 test positions and handles up to 6,000 W. Both have 35 to 85°C (105°C optional) range.

LGA Socket supports 2.54 mm pitch devices.

LGA Socket supports 2.54 mm pitch devices.

Ironwood Electronics, Inc    St. Paul, MN 55121
Jul 17, 2013 Designed to JEDEC STD. MO-220, Model CBT-LGA-5002 operates from -55 to 180°C and features IC guide for LGA edge alignment. Contactor consists of stamped spring pin with 19 g actuation force per pin and cycle life of 500,000 insertions. Unit has current capacity of 4 A, self inductance of 0.93 nH, insertion loss of less than 1 dB at 21.9 GHz, and capacitance of 0.097 pF. Mounted using supplied hardware on target PCB with no soldering, socket is suited for Burn-in and Test applications.

LGA Socket for Hand Test/Burn-In operates from -55 to +180°C.

Ironwood Electronics, Inc    St. Paul, MN 55121
May 16, 2013 Used to test LGA package with 25 x 21 mm body and 0.5 mm pitch, CBT-LGA-5000 features IC guide that promotes precise LGA edge alignment, clamshell lid, and compression screw for applying down force. Contactor is stamped spring pin with 31 g actuation force per pin and cycle life of 500,000 insertions. Properties include contactor self inductance of 0.88 nH, insertion loss of <1 dB at 15.7 GHz, and capacitance of 0.097 pF. Current capacity of each contactor is 4 A.

BGA Socket withstands extreme temperatures.

Ironwood Electronics, Inc    St. Paul, MN 55121
Mar 21, 2013 With temperature range of -55 to +155°C, Model CBT-BGA-7011 is designed for testing 3 x 3 mm, 0.4 mm pitch, 36-position, 6 x 6 ball array. Stamped spring pin contactor, providing current capacity of 2.2 A at 30°C temperature rise, features self inductance of 0.9 nH, insertion loss of less than 1 dB at 9.1 GHz, and capacitance of 0.03 pF. Mounted on target PCB using supplied hardware with no soldering required, socket includes floating guide for precise ball to pin alignment.

Texture Analyzer determines breaking point of lipstick.

Texture Analyzer determines breaking point of lipstick.

Brookfield Engineering Laboratories, Inc.    Middleboro, MA 02346
Oct 05, 2012 Able to operate in both compression and tension modes, stand-alone CT3 Texture Analyzer utilizes TA-LC Lipstick Cantilever Fixture to determine breaking point of lipstick and other similar products. Fixture has rounded blade that simulates pressures experienced during application. With TexturePro CT software, operator can automate test procedures and generate valuable analytical data.

MicroSD Socket operates from -55 to +180°C.

MicroSD Socket operates from -55 to +180°C.

Ironwood Electronics, Inc    St. Paul, MN 55121
Aug 21, 2012 Addressing high-performance requirements for Speed Class Rating, SBT-MicroSD-01 has stamped spring pin contactor with 19 g actuation force per pin and cycle life of 500,000 insertions. Self inductance of contactor is 0.93 nH, insertion loss is less than 1 dB at 21.9 GHz, and contact resistance is less than 16 mOhms. At 30°C temperature rise, current capacity of each contactor is 4 A. Specific configuration of package to be tested is 15 x 11 x 1.0 mm microSD form factor.

QC Test Fixtures target pharmaceutical marketplace.

QC Test Fixtures target pharmaceutical marketplace.

Brookfield Engineering Laboratories, Inc.    Middleboro, MA 02346
Apr 13, 2012 Designed for CT3 Tester, which operates in both compression and tension modes, TA-CLT Capsule Loop Tensile Test Fixture measures tensile breaking strength of hard gel capsules. Gel cap is mounted between 2 pins which pull apart, thereby measuring force required to rupture cap. Featuring guillotine type design, TA-BLS Bilayer Shear Jig measures force required to separate layers of multi-layer tablet. Tablet is placed in jig and cutting plate slices into tablet until adhesion fails.

Hi-Temp CSP Sockets enable testing of any area-array device.

Aries Electronics, Inc.    Bristol, PA 19007-6810
Dec 26, 2011 Accommodating use from -55 to +200°C, AR4HT Series incorporate low-profile (0.45 mm) contact structure that provides compliance for ATE testing and burn-in. Sockets work with various area-array devices, including BGA, LGA, QFN, DFN, CSP, MLCC, and POP, as well as bumped die with full and partial arrays. With life expectancy of 10,000+ actuations, products can accommodate IC devices with pitch of 0.4 mm or greater as well as mixed pitch environments.

Elastomer BGA Socket is intended for testing eMMC devices.

Ironwood Electronics, Inc    St. Paul, MN 55121
Nov 15, 2011 Designed for testing 0.5 mm pitch, 14 x 18 mm eMMC BGA device, SG-BGA-7219 connects all pins with 10 GHz bandwidth and operates with less than 1 dB insertion loss. Contact resistance is 20 mohm per I/O (typ), and mounting is accomplished via supplied hardware on target PCB without any soldering. Quick insertion method, using shoulder screws and swivel socket lid, accelerates IC change-out, while floating compression mechanism accommodates package manufacturing variations.

Extreme Temperature Test Socket handles 4.5 x 4.5 mm QFN devices.

Ironwood Electronics, Inc    St. Paul, MN 55121
Aug 24, 2011 Designed to test 0.4 mm pitch, 32-lead QFN devices with center ground pad, Model CBT-QFN-7008 features temperature range of -55 to +155°C. Etched spring pin contactor, with cycle life of 500,000 insertions, provides 0.95 nH self inductance, insertion loss of less than 1 dB at 7 GHz, and 0.097 pF capacitance. Current capacity of each contactor is 4.1 A at 60°C temperature rise. In addition, socket has wave spring with swivel compression plate for vertical force without distorting device position.

BGA Socket  supports LTE femtocell SoCs.

BGA Socket supports LTE femtocell SoCs.

Ironwood Electronics, Inc    St. Paul, MN 55121
Jul 01, 2011 Suited for hand test and temperature characterization as well as debugging in femtocell development, Model CBT-BGA-6015 has stamped spring pin contactor with 19 g actuation force per ball and cycle life of 500,000 insertions. Contactor features self inductance of 0.93 nH, insertion loss of less than 1 dB at 23.2 GHz, and contact resistance of less than 16 mW. Specific configuration of package to be tested in socket is BGA, 52.5 x 52.5 mm, 1 mm pitch, 2097 position, 51 x 51 ball array.

Extreme Temperature Socket accommodates 4 x 4 mm QFN device.

Ironwood Electronics, Inc    St. Paul, MN 55121
Jun 01, 2011 Addressing requirements for testing Amkor 24-lead QFN, CBT-QFN-7005 features stamped spring pin contactor with 26 g actuation force per ball and cycle life of 500,000 insertions. Contactor properties include 0.88 nH self inductance, less than 1 dB @ 15.7 GHz insertion loss, 0.097 pF capacitance, and 4 A @ 80°C temperature rise current capacity. Operating from -55 to +180°C, socket offers wave spring with swivel compression plate for vertical force without distorting device position.

High-Performance BGA Socket accomodates 23 x 23 mm packages.

Ironwood Electronics, Inc    St. Paul, MN 55121
May 16, 2011 Model SM-BGA-9000 for 23 x 23 mm, 0.8 mm pitch BGA packages operates at bandwidths up to 40 GHz with less than 1 dB of insertion loss. It dissipates 4.5 W with heat sink compression screw and can be customized up to 100 W with modified fin design and adding axial flow fan. Operating in temperatures from -55 to +150°C, unit offers contact resistance of 15 mW/pin as well as current capacity of 4 A/pin. Socket, constructed with shoulder screw and swivel lid, mounts on PCB with no soldering.

Triple Stacked BGA Socket tests processor, memory, and memory probe.

Triple Stacked BGA Socket tests processor, memory, and memory probe.

Ironwood Electronics, Inc    St. Paul, MN 55121
Apr 26, 2011 Model CBT-BGA-7007 features 0.5 mm pitch stamped spring pins with 26 g actuation force/ball, and 0.4 mm pitch etched spring pins with 34 g actuation force/ball, both which have cycle life of 500,000 insertions. Socket also features floating guide for precise ball-to-pin alignment. Operating in temperatures from -55 to +180°C, it is designed to test 12 x 12 mm, 0.4 mm BGA package in bottom socket and 12 x 12 mm, 0.5 mm pitch memory BGA in top socket. Unit mounts to PCB without soldering.

FPC Testing Socket features horse-shoe shaped contact.

FPC Testing Socket features horse-shoe shaped contact.

Yamaichi Electronics USA, Inc.    San Jose, CA 95134
Mar 31, 2011 Supporting ultra fine pitches down to 0.3 mm, LC Series Clip Type Socket features specially designed contacts that carry out micro wiping action, ensuring stable, low contact resistance. Elevator stage prevents FPC pads from being damaged or scratched while simultaneously protecting contacts during FPC load/unload operation. As output options, customer can choose discrete wiring, MIL Std., or FPC connector.

WLCSP Socket verifies IC function in development systems.

Ironwood Electronics, Inc    St. Paul, MN 55121
Mar 07, 2011 Operating at bandwidths up to 10 GHz with less than 1 dB insertion loss, SG-BGA-7203 allows testing of 2 different WLCSPs - 0.5 mm pitch, 40-ball WLCSP and 0.4 mm pitch, 30-ball - in one socket, side by side. Contact resistance is 20 mW typ per I/O, and socket connects all pins with 10 GHz bandwidth on all connections. Mounted without soldering on target PCB using supplied hardware, socket incorporates insertion method using shoulder screws and swivel socket lid to accelerate IC change-out.
