Other Meters

Sensors, Monitors & Transducers, Test & Measuring Instruments

Strain Gauge Meters power up to 12 load cells.

March 2, 2015

Designed for weight, millivolt, and force measurement applications, Model PD6100 and explosion proof Model PD8-6100 feature 1-button zeroing of display, auto-zero adjustment to prevent drift, and panel-mounted or rugged, field-mounted enclosure. Tare/Reset Tare function enables meters to compensate for anomalies, such as sludge buildup at bottom of empty tank. Accepting mV input signals up to 300 mV (unipolar) and ±250 mV (bipolar), both meters are rated for max current of 350 mA at 10 V. Read More

Test & Measuring Instruments, Communication Systems & Equipment, Software

Digital Multimeter integrates data visualization.

February 2, 2015

Integrating digital multimeter, digitizer for waveform capture, and capacitive touchscreen user interface, 7 ½-digit DMM7510 Graphical Sampling Multimeter is suited for device characterization, debugging, and analysis as well as production test/ATE. Multimeter provides 14 ppm basic 1-year DCV accuracy and measurement ranges to 100 mV, 1 Ω, and 10 µA. With 1 MS/sec, 18-bit digitizer, user can view and analyze current and voltage waveforms and transients without need for PC. Read More

Test & Measuring Instruments, Communication Systems & Equipment

Digital Panel Meter measures voltage to 300 V and current to 5 A.

January 26, 2015

Able to measure voltage, current, and apparent power, ProVu® PD6400 is NEMA4X/IP65 rated for use in panel or field under harsh environmental conditions. Independent, field-selectable current and voltage inputs accept up to 300 V and 5 A (AC or DC), and 1/8 DIN size unit also accepts current transformer inputs for higher measurements. Dual-line display features LED digits and warning lights with adjustable brightness, and Modbus® capability (Slave) enables network integration. Read More

Test & Measuring Instruments

Haze/Transmittance Meter delivers measurement precision.

January 12, 2015

Leveraging optics and LED technology, Haze-Gard i simultaneously measures total transmission, haze, and clarity according to ASTM and ISO test methods. Open design of measurement compartment facilitates sample analysis, and sample changing/positioning is unaffected by ambient light. While standard sample holder accommodates films and sheets, sample holders for taber abrasion test and cuvettes for liquids are optional. Operation is facilitated via color touchscreen display as well as footswitch. Read More

Test & Measuring Instruments

Gloss Meter measures curved surfaces.

December 12, 2014

Serving as reference instrument for measuring reflective appearance, Rhopoint IQ FLEX 20 Gloss-Haze-DOI-Goniophotometer is available in format specifically designed for curved surfaces and small and delicate parts. Unit offers results batching with user-definable names, Bluetooth compatibility for transmitting data, and full on-board statistics and graphs. Powered by rechargeable lithium ion battery, instrument delivers 20,000+ readings per charge and stores 999+ readings in memory. Read More

Test & Measuring Instruments, Labels, Tags, Signage & Equipment, Automatic ID

Wireless RFID Tag helps monitor weight of assets.

December 3, 2014

Featuring 4 channels for load cells with measurement ranges from 0–900 kfg per channel, Atlas RFID Sensor Tag is capable of transmitting unique identifier and associated weight measurement data to commercial EPC C1G2 reader without need for battery on tag. Device comes in variety of antenna designs and sizes to adapt performance to required application in 860–960 MHz band. With reading distance of 5 ft, magnetometer tag can be embedded in materials such as plastics or concrete. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Electronic Components & Devices

Magnetic Sensor IC facilitates HMI implementation.

November 19, 2014

Based on proprietary Triaxis® technology, Model MLX90393 measures changes in magnetic flux density along its X, Y, and Z axes. Programmable unit employs monolithic pixel cell arrangement and enables linear sensitivity across selectable 16-bit full-scale range from ±5 mT to ±50 mT. Using SPI and I2C interfaces, engineers can access various operating modes: continuous, single measurement, wake up on change, and burst mode. Supplied in 3 x 3 mm QFN package, IC draws 2.5 µA of current while idle. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Electronic Components & Devices

Integrated eCompass with Soft Gyro enhances smart devices.

October 21, 2014

Respectively supplied in 2 x 1 x 1.1 mm and 3 x 3 x 1.0 mm LGA packages, dc213 and dc312 single-chip eCompass solutions combine 3-axis accelerometer and 3-axis magnetometer. Products, which feature I²C interface and dedicated programmable interrupt, provide 9 DoF (Degree of Freedom) with soft gyroscope with MiraMEMS Xmotion™ software enabled. Pin-to-pin compatible with g-sensor series, eCompass solutions enhance smartphone and wearable device functionality. Read More

Test & Measuring Instruments

Indoor Air Quality Meter measures CO2, air temp, RH, and more.

October 17, 2014

Leveraging NDIR (non-dispersive infrared) technology, 800046 can be used to monitor IAQ in spaces as well as test air from HVAC equipment. Backlit simultaneous display shows CO2 level from 0–5,000 ppm, humidity from 0–100%, and air temperature from 14 to 140°F. User can also choose rotating display of dew point (8 to 140°F) and wet bulb temperature (-100 to 140°F) instead of air temperature. Additional calculations cover TWC (Time Weighted Average) and STEL (Short-Term Exposure Limit). Read More

Test & Measuring Instruments

Digital Multifunctional Meter performs environmental measurements.

October 13, 2014

Supplied with carrying case, operator's manual, portable mini-tripod, and 9 V battery, RH87 combines functionality of sound level, luminometer, relative humidity (RH) meter, and anemometer. This CE-compliant digital multifunctional environmental meter measures sound (dB), temperature, humidity, and light (Lux) and uses standard and metric units. Other features include backlit LCD as well as data hold and auto-ranging functions. Read More

Test & Measuring Instruments

Energy Management Submeter handles up to 3,000 A.

September 4, 2014

Utilizing split-core transformers or Rogowski coils, EZ Cube is available with single line LCD with status lights or full screen with Volts, Amps, etc. Auto-ranging design enables meter to support 120 V single phase up to 4-wire 277/480 V or 3-wire 480 V and everything in between. Automatic reading is possible through Modbus RTU via RS-485 or Ethernet connection. Ethernet version can download data directly to energy management system or users can access built-in web server for real-time data. Read More

Test & Measuring Instruments

Smart Interface Cable determines vehicle speed in real-time.

August 5, 2014

Featuring plug-and-play design, OBDII Odometer communicates with vehicle's on-board computer to determine current vehicle speed and outputs real-time vehicle speed over RS232 serial data interface. Navigation accuracy down to 0.05% of distance travelled is achieved when connected to Spatial series GPS/INS products. Smart interface cable has built-in support for 9 OBDII communication protocols and can, depending on vehicle, retrieve speed from ABS or transmission. Read More

Test & Measuring Instruments

Universal Meter operates on cellular and mesh AMI networks.

July 30, 2014

REXUniversal® meter incorporates point-to-point cellular communications technology, which expands number of rural and remote residential utility customers who can be served by smart meters and smart grid systems. Operating on Verizon (CDMA) and AT&T (GSM) cellular networks as well as mesh AMI networks, this integrated universal meter platform supports smart grid systems from diverse vendors.

Read More

Test & Measuring Instruments

Process Meter offers Ethernet and Internet connectivity.

July 18, 2014

Designed for signals such as 4–20 mA, 0–5 V, or 0–10 V, which require zero and span adjustment, Laureate Process Meter can be scaled to 5 full digits from front panel or remotely via software. Accuracy is 0.01% of FS ±2 counts, and conversion rate is 50 or 60 per second. Ethernet connectivity is provided via Ethernet interface board which plugs into host 1/8 DIN digital panel meter. Multiple meters can be connected to LAN or to Internet via router, or directly to host computer via Ethernet cable. Read More

Test & Measuring Instruments, Communication Systems & Equipment, Green & Clean

Power Meter is available with photovoltaic monitoring chip.

July 9, 2014

Able to be used for PV power plant monitoring, General Electric GE I-210+ with built-in Solar-Log® chip allows remote configuration of data logging and meter functions. Solar-Log chip monitors and logs incoming data from solar array with revenue-grade precision, including PBIs and SRECs. While chip can transmit data via 3G cellular modem or Ethernet, Solar-Log and GE Meter bus allows up to 16 more meters to be connected to monitoring system. Read More

Test & Measuring Instruments

Load Cell Meter delivers high-speed readings via Ethernet/Internet.

May 22, 2014

Laureate Model WM, Ethernet version, is high-sensitivity digital panel meter and controller for load cells, strain gauges, and microvolt signals. Ethernet connectivity is provided by Ethernet interface board, which plugs into host 1/8 DIN digital panel meter, and 10/100Base-T Ethernet interface is via RJ45 connector. As DC microvolt meter, unit provides sensitivity down to 20 mV FS with 1 µV resolution, and accuracy is 0.01% FS ±2 counts at rates up to 60/sec. Read More

Test & Measuring Instruments, Green & Clean, Services

Energy Monitoring Service helps maximize efficiency.

May 19, 2014

With cloud-based monitoring, Honeywell's Attune™ Energy Dashboard service provides facility managers with dashboard of energy usage and trends. Service accesses historical and real-time energy-usage data from variety of meters including E-Mon D-Mon submeters, electric, gas, water, steam, and BTU. By viewing and analyzing energy consumption information, managers gain insight into building and process performance, establish baseline patterns, and identify energy savings opportunities. Read More

Test & Measuring Instruments

True AC RMS Meter offers Ethernet connectivity.

May 12, 2014

Housed in 1/8 DIN case that meets NEMA 4X specifications when panel mounted, Laureate True AC RMS Meter delivers true RMS readings in 0–16 ms after completion of 1 input signal cycle, allowing power line anomalies to quickly be detected. Meter can also capture peak and valley readings that occur at rate of 50 or 60 Hz. Reading accuracy is 0.1% FS for signals from DC–10 kHz and signal amplitudes down to 0.1% FS. Ethernet connectivity is provided by Ethernet interface board that plugs into meter. Read More

Test & Measuring Instruments, Chemical Processing & Waste Management, Electrical Equipment & Systems

Handheld Irradiance Meter aids in solar panel positioning.

March 24, 2014

With its internal solar detector and meter, PVM210 helps solar/PV engineers locate most appropriate site to place solar panels. Form factor allows unit to be held in one hand while working on sloping roof or atop ladder. Along with measurement range up to 1,999 W/m² for solar power readings, unit features 3¾-digit LCD, data hold feature, and accuracy within ±10 W/m² or ±5% in sunlight. Unit can also verify stated short circuit current in conjunction with multimeter or clampmeter. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Electromagnetic Meter can be applied to diverse applications.

March 19, 2014

With ±2.5% + 6 digit accuracy, E100 Gauss Meter measures electromagnetic field strength (magnetic flux density). Readings are available in micro-Telsa or milli-Gauss, with respective ranges of 200 and 2,000. and ELF (Extremely Low Frequency) range is 30–300 Hz. In addition to measurements of electric field strength in TEM cells and absorber rooms, applications include mobile phone base station antenna radiation power density measurements, RF power measurement, and Wi-Fi detection/installation. Read More
