Extensometers

Sensors, Monitors & Transducers, Test & Measuring Instruments

Video Extensometer performs non-contact strain measurement.

December 22, 2014

Able to adapt to normal fluctuations of environmental conditions in lab and compatible with testing machines that uses ±10 V analog input, AVE 2 measures both modulus and strain to failure for diverse materials. Fully integrated device, which utilizes real-time 490 Hz data rate while achieving 1 micron accuracy, reduces errors from thermal and lighting variations common in most labs and can be used for strain measurement with Digital Image Correlation (DIC).
Read More

Test & Measuring Instruments

Furnace Extensometer has high-temperature, hot mountable design.

October 14, 2013

Suited for use on any load testing system, Model 3549 is available for use to 1,600°C and mounts on included slide bracket. Gauge length is automatically set prior to mounting on test specimen, which allows for hot mounting after thermal equilibrium has been reached. User can set contact force against test specimen, allowing even and repeatable contact force while also limiting contact force induced errors. Design reduces influence from nominal external vibrations. Read More

Test & Measuring Instruments

Automatic Contacting Extensometer enhances materials testing.

January 21, 2013

Meeting ISO 9513, ASTM E83, and ISO 527-1 (2011) requirements, AutoX750 is used to determine such calculations as modulus, offset yield, and plastic (non-proportional) elongation to failure during materials testing routines. Accuracy and travel make this product suited for tensile and flexure testing of various materials, including composites, metals, and plastics. Such features as automatic gauge length positioning and attachment to test specimen further lend to productivity. Read More

Test & Measuring Instruments

Automatic Contacting Extensometer has rugged construction.

July 28, 2009

Suited for any application requiring measurement of linear strain, universal MFX 500 is used to determine calculations including modules, offset yield, and plastic (non-proportional) elongation to failure. Unit is controlled via USB interface and Instron 3300 and 5500 Series testing machines with Bluehill® 2 software. Featuring roller style mounting, unit provides resolution of 0.1 µm and meets ISO 9513, ASTM E83, and EN10002-1/ISO 6892 requirements. Read More

Electronic Components & Devices, Sensors, Monitors & Transducers, Test & Measuring Instruments

High Pressure and Chemically Resistant LVDTs Enhance Performance of Extensometers Used to Monitor Structural Integrity of Offshore Platforms

February 9, 2009

Pennsauken, NJ, January 16, 2009 - To ensure the ongoing stability of offshore drilling platforms, the structural integrity of production risers, catenary risers, tendons and platform legs and braces are constantly monitored. Macro Sensors (www.macrosensors.com), specialists in the manufacture of LVDT-based linear position sensors and gaging probes, designed a pressure-balanced, oil-filled and...Read More

Test & Measuring Instruments, Thermal & Heating Equipment

ADMET Offers UTM Accessories - Extended Travel Extensometer and Environmental Chambers

January 23, 2008

NORWOOD, Mass. - Nov. 27, 2007 - ADMET Inc., a provider of integrated materials testing systems, supplies a full range of Universal Testing Machines (UTMs) and accessories, including specialty extensometers and environmental chambers for testing specimens under controlled conditions. The company today announced new additions to its extensive accessories catalog. Among the new accessories, ADMET...Read More

Test & Measuring Instruments

Instron's Non-Contacting Video Extensometers Granted Patents

July 12, 2007

Instron, a leading provider of testing equipment designed to evaluate mechanical properties of materials and components, announces that the innovative technologies employed in its non-contacting Advanced Video Extensometer (AVE) and Standard Video Extensometers (SVE ) have been awarded US and European patents (US 7,047,819 B2 and EP 1 424 547 B1). These devices allow highly accurate strain...Read More

Test & Measuring Instruments

Zwick Shows Award Winning Pendulum Impact Tester at Chinaplas 2007

May 1, 2007

At Chinaplas 2007 (21-24 May) in Guangzhou, Zwick presents its new, award winning pendulum impact tester HIT 5.5P among other solutions for the plastic and rubber industry. The development of the new tester resulted in the "MATERIALICA Design Award" for Zwick and features a revolutionary new dual carbon rod pendulum. This has resulted in a product with much higher stiffness and accuracy than...Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Video Extensometer is available with 4 fields of view.

September 28, 2006

Model videoXtens extensometer is capable of simultaneously measuring longitudinal and transverse strain and is used for measurement of r and n values to ISO 10113 and ISO 10275, respectively, on sheet steel. It is utilized in materials testing applications where contact with specimen is impractical and includes software to record real-time video stream of test. Extensometer complies with Class 1 of ISO 9513 and B2 of ASTM E83. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

Video Extensometer features non-contact measurement design.

July 17, 2006

Along with integrated software that facilitates setup and consistent calibration, advanced video extensometer (AVE) uses digital camera and real-time image processing to make strain measurements on material test samples. Non-contact measurement design ensures extensometer has no influence on specimen, eliminating possibility of damage. Solid-state unit is available with 3 fields of view and transverse strain measurement capabilities. Read More
