Upconverters and Power Amplifiers range from 25-100 W.
Norsat International Inc.
Richmond, BC V6V2N2
Apr 15, 2014
Comprising Ku-band block upconverters and solid state power amplifiers, ATOM Series is available for standard, extended, and custom frequency Ku-bands in 25, 40, 50, and 100 W configurations. Units provide off-the-shelf options, such as wideband, fast switching, and active or passive cooling. Available with custom RF output options from 13.0–17.5 GHz for non-traditional frequencies, devices are suited for portable VSAT, Satcom on the Move, Radar, TWTA replacement, and airborne terminals.
I/P Transmitters offer switch-selectable output.
Moore Industries International, Inc.
North Hills, CA 91343
Apr 09, 2014
Designed to meet NEMA 4X requirements, IPH2/IPX2 Current-to-Pressure Transmitters accept current signal from DCS, PLC, or other control system and convert it into pneumatic signal to provide proportional control of valves, actuators, and other pneumatically controlled devices. Two-wire units feature 22 direct and reverse output ranges, with switch-selectable reverse output standard on IPX2. In addition, IPX2 is explosion proof for hazardous areas and offers removable electronics module.
Signal Converters/Isolators enable increased analog functionality.
Richmond, VA 23236
Apr 02, 2014
At 6 mm wide, ACT20M signal isolation and conversion models increase breadth of analog functionality and provide converting, conditioning, and isolation for temperature sensors and bipolar DC sources. Adjustable switch provides access to hundreds of temperature range combinations per model, selection of outputs (voltage/mA), response time, and wire-break failure mode. Auxiliary powered variants can be used with power rail option, and isolating and non-isolating converters are available.
In-Line Charge Converters provide ±5.0 V output.
PCB Piezotronics, Inc.
Depew, NY 14043 2495
Apr 02, 2014
Suited for use with high temperature piezoelectric sensors operating in environments up to 500°F, Series 422E5x ICP® Charge Converters offer 5 gain options and come in small, rugged package. Units are placed between sensor and any ICP® powered signal conditioner to convert high impedance charge output sensor signals to low impedance voltage signals. They can also connect directly to DAQ system or readout device if system incorporates ICP® power.
Logic Signal Inverter connects incompatible signals.
Automation Systems Interconnect, Inc.
Mechanicsburg, PA 17055
Mar 25, 2014
Supplied in package that measures <˝ in. wide, DIN rail-mountable XNPNPNP logic signal inverter provides solution for hooking together sensors and controllers with incompatible DC signals. Product converts sensor I/O signals from positive logic (PNP) to negative logic (NPN) devices and vice versa. Featuring IEC DIN rail-mount terminal blocks, product aids machine builders or systems integrators requiring flexibility in selection of I/O devices.
Two-Wire Transmitter offers frequency/pulse measurement.
Wixom, MI 48393 7037
Mar 21, 2014
Configured via USB connection to PC, TT239 Frequency Transmitter supports frequency, pulse, and PWM input signals, and converts signals to proportional current output of 4-20 mA. Unit interfaces unipolar and bipolar input signals with amplitudes up to 120 Vrms and frequencies up to 100 KHz. Operating from -40 to +80°C with electrical noise immunity and surge protection, converter supports source and sink output wiring, with power being received from output loop current or DC supply.
HDMI to MIPI CSI-2 Bridge Chipset supports 4K video resolution.
Toshiba America Electronic Components (TAEC)
Irvine, CA 92618-1811
Mar 21, 2014
Suited for next-generation CE video applications, TC358840 Ultra HD HDMI® to MIPI® CSI-2 (Camera Serial Interface) converter chipset consists of follow on part to TC358743 and adds 297 MHz HDMI receiver (Rx) and dual MIPI CSI-2 interface. Max resolution supported is 4,096 x 2,160 @ 24 bpp at refresh rate of 24 fps or 3,840 x 2,160 @ 24 bpp at 30 fps, limited by max 297 MHz HDMI bandwidth. HDMI audio input stream is also supported and can be transmitted over I˛S, TDM, or MIPI SLIMbus®.
Block Upconverter covers commercial and military Ka bands.
Petach-Tikva 49130 Israel
Mar 18, 2014
Incorporating Wavestream's Spatial advantEdge™ technology, 50 W Ka-Wideband PowerStream Block Upconverter provides over 30 W of linear output power, per MIL-STD-188-164 definition. Unit features flexible, modular design that can be fitted to almost any antenna. Able to cover frequencies from 27.5–31.0 GHz, in up to 4 sub-bands, converter is biased for Class AB operation, drawing less power when backed off and generating less heat for maximum MTBF.
Buck Regulators address multiple voltage rail requirements.
Milpitas, CA 95035
Mar 07, 2014
Integrating both high-side and low-side field-effect transistors, Models ISL85410 and ISL85418 eliminate need for low-side diode and external compensation. Synchronous buck regulators down-convert DC voltage from power supply or battery to power multiple microprocessors and board components at various voltage requirements, minimizing power loss. Housed in 4 x 3 mm package, devices support input voltage range of 3–36 V and wide Vout range from 0.6–95% of Vin.
Data Converters drive 100G, 300G, and 400G active optics.
TE Connectivity Ltd.
Berwyn, PA 19312
Feb 28, 2014
Using 25G VCSEL and PIN devices, TIA amplifier, and driver IC, Coolbit optical engines convert data from electrical signals to optical signals and drive technology behind TE 100G, 300G, and 400G active optics. Platform engines help communication systems conserve power, and QSFP28 modules perform at <1.5 W per transceiver. Optical engines enhance performance while satisfying high density and high bandwidth requirements.
Bench Top Power Supplies provide frequency conversion.
Farnborough, Hants GU14 0NR United Kingdom
Jan 30, 2014
Targeting mission-critical industrial and military powers system, Behlman PF1350 offers 3 fixed, selectable output frequencies of 50, 60, and 400 Hz, along with 2 voltage ranges of 0–135 and 0–270 Vac. Unit provides up to 1,350 Va of AC power from local power inputs of 95–270 Vac. In addition to 100% power factor rating, power supply delivers ±0.7% load regulation and ±0.1% line regulation. Behlman PF1351 offers same performance, but with continuously variable output frequency from 45–500 Hz.
Signal Converter offers dimming control for 80 fixtures.
Sunpower Technology LLP
Berkshire RG7 8SN United Kingdom
Jan 27, 2014
Extracting dimming levels and address information from incoming DALI data, Model DAP-04 controls each of 4 PWM dimming outputs individually. Each channel can drive PWM input of any MEAN WELL LED power supply equipped with 3-in-1 dimming function. Model DAP-04 offers 1–100% dimming range, and choice of linear or logarithmic dimming curves which comply with IEC62386-207. Built-in relay and contact is provided for ON/OFF control of AC LED power supply.
Discrete Serial Link Aggregator ICs support data rates to 10 Gbps.
Texas Instruments, Inc., Semiconductors
Dallas, TX 75243
Jan 22, 2014
Using 2 power rails, 1- to 8-channel TLK10081 and 2-channel TLK10022 aggregate and de-aggregate point-to-point serial data streams for transmission over backplanes, copper cables, and optical links. Features include intelligent serial link switching and built-in digital equalization. While TLK10022 supports 4:1, 3:1, and 2:1 bidirectional serial link configurations, TLK10081 manages 8:1 bidirectional links. Both ICs help reduce required number of gigabit serial links in equipment.
SDI-DVI Converter/Extender carries video over fiber optic cable.
Network Technologies, Inc. (NTI)
Aurora, OH 44202
Dec 23, 2013
Supporting HDTV resolutions to 1080p, 3GSDI-DVI-FOSC converts SD/HD/3G-SDI video into DVI signal that can be extended up to 1,650 ft. Solution auto detects 3G, HD, or SD-SDI input formats and comprises 2 components – 3GSDI-DVI-FOSC converter/transmitter and optional ST-1FODVI-R-SC receiver – interconnected by single-strand multimode (50-micron or 62.5-micron) SC fiber optic cable. Main converter/transmitter support SMPTE 259M-C/292M/424M input signals.
Electromagnetic Signal Converter measures volumetric flow.
Peabody, MA 01960-3803
Dec 02, 2013
With accuracy of 0.5%, Model IFC 050 can be combined with OPTIFLUX and WATERLFUX flow sensors for wastewater treatment metering tasks as well as water distribution networks, irrigation installation, water abstraction, and CIP cleaning stations. Outputs represent measured values for flow, mass, and conductivity. They include current, active pulse/frequency, status, and Modbus. Protected with dual-layer paint, housing keeps converter safe from fluids such as salt water.
High-Speed Digitizer samples up to 2 GS/s.
Agilent Technologies, Inc.
Santa Clara, CA 95051
Nov 27, 2013
Supporting custom on-board signal processing capability, U5309A 8-bit PCIe® Digitizer features 2 channels with analog bandwidth from DC to 500 MHz, large DDR3 memory, and high data throughput with PCIe 2.0 8-lane interface. Xilinx Virtex-6 FPGA allows user to load custom real-time signal processing algorithms created with U5340A FPGA development kit software. Supporting multiple programmable interfaces, software driver facilitates integration of data converter into existing environments.
AC Power Sources/Frequency Converters feature PFC and CE mark.
Behlman Electronics, Inc.
Hauppauge, NY 11788
Nov 18, 2013
PF1350 provides 3 fixed, selectable output frequencies of 50, 60, and 400 Hz and 2 voltage ranges: 0–135 Vac and 0–270 Vac. From local power inputs of 95–270 Vac, unit delivers 1,350 VA of clean, regulated AC power @ 10 A max. In addition to PFC, benefits include clean sine wave output and overload protection system. PF1351 has continuously variable output frequency range of 45–500 Hz and can be controlled from front panel or remotely; optional 45–1,000 Hz output range is available.
D/A Converters feature 3 µs fast output settling time.
Mansfield, MA 02048
Nov 15, 2013
Housed in hermetically sealed, 24-pin DDIP or SMT gull-wing ceramic package, 12-bit DAC-88 Series features guaranteed monotonicity and is 100% tested for performance across 1 of 3 specified temperature ranges of 0 to +70°C, -40 to +100°C, or -55 to +125°C. Output range is programmable to 20 V, and includes bipolar options as well. Featuring input register for versatility, converters come in commercial and military/high-reliability versions as well as RoHS and non-RoHS versions.
Frequency Converter suits military/industrial applications.
Behlman Electronics, Inc.
Hauppauge, NY 11788
Nov 11, 2013
Housed in 6U, 19 in. rackmount chassis with handles on front and rear, Model FC5003 converts common 120/208 Vac, 3-phase, 60 Hz power to 115/200 Vac, 3-phase, 400 Hz power used by aircraft and other vehicles/equipment. COTS power supply features fast acting main circuit breaker with guard and indicator as well as internal temperature sensor that prevents heat damage. Overload automatically causes voltage fold back to provide max current without distorting output waveform.
XMC FPGA Module suits UAV, radar, communications applications.
Upper Saddle River, NJ 07458
Oct 24, 2013
Based on Xilinx Virtex-7 FPGA, single-channel Onyx® Model 71730 employs 1 GHz, 12-bit ADC and 1 GHz, 16-bit DAC. Module comes with 4 GB DDR3 memory (1,600 MHz) and can receive and transmit at same sampling rate, supporting signal bandwidths up to 400 MHz. Gen 3 PCIe interface delivers peak transfer rates to 8 GBps, and optional LVDS and gigabit serial connections to Virtex-7 FPGA are available. Built-in functions are provided for data capture, synchronization, time tagging, and formatting.
