Subcompact Board incorporates legacy technologies.

December 31, 2014

In addition to supporting ISA bus accessible via PC/104 interface, 3.5 in. Model GENE-A55E supports 2x RS232 and 2x RS232/422/485 COM ports, DDR3L 1066 SODIMM RAM up to 4 GB, and optimized Ethernet hardware for 10/100/1000Base x2 connection speeds. Fanless design emits almost no sound and vibration during operation. Legacy support includes 5 V power supply, use of CompactFlash card, and support for all Windows® operating systems since Windows® CE 6.0. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Multifunction Interface Board adds I/O options to serial devices.

December 2, 2014

Designed to mount on rear panel of host chassis with connectors protruding through rear panel, Model 9006 adds Ethernet, GPIB, and USB interfaces to RS-232/-485 serial devices. All interfaces are IEEE-488.2 compliant, respond to 488.2 Common Commands, and provide GPIB-like functionality to extent possible with interface protocol. Ethernet port supports VXI-11 and raw socket protocol as well as internal HTML Web server. All settings are saved in internal flash memory. Read More

Test & Measuring Instruments, Controls & Controllers

Controller and I/O Modules operate in harsh environments.

November 25, 2014

Comprising controller and I/O modules, X20c series is constructed to handle all environmental conditions. Coating on electronics module protects components and circuit board from effects of condensation and corrosive gases with effectiveness checked against BMW GS 95011-4 and EN 60068-2-6 test method 4. Functionally compatible with existing models, series operates from -25 to +60°C and features certification for maritime applications from Germanischer Lloyd. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Electronic Components & Devices

VPX Boards boost functional density.

November 12, 2014

Suitable for data acquisition, software radio, and digital signal processing, 6U VPX Model 57xxx accommodates one Cobalt® Virtex-6 or Onyx® Virtex-7 FPGA XMC module, while Model 58xxx accommodates 2 XMC modules. Boards take advantage of increased I/O to backplane by adding optional LVDS lines from FPGA on each XMC to user pins of VPX backplane connectors. Optional x4 user-configurable gigabit serial links provide additional interconnect options between 2 installed XMC modules to VPX backplane. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Electronic Components & Devices

Daughter Cards enable comprehensive external interfacing.

November 4, 2014

Available in 6 models, Arduino-compatible VM800P PLUS Boards are based on FT800 EVE graphic controller devices, in which display, audio, and touch functionality are integrated onto single chip. Boards also incorporate 8-bit ATMEGA microcontroller and TFT display with 3.5, 4.3, and 5.0 in. sizes available. Using 1 or 2 Micro-MaTch miniature connectors to interface with VM800P, daughter cards allow expansion of boards’ I/O capabilities so they can be implemented into wide range of applications. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Ruggedized 3U cPCI CPU Board has EN50155-compliant design.

November 3, 2014

In addition to 22 nm Intel® Atom™ E3827/E3845 CPUs that offer quad-core performance up to 1.91 GHz, CP3010-SA features built-in graphics core via Intel® HD Graphics Technology as well as up to 8 GB of soldered DDR3L memory running at 1,333 MHz. Onboard data storage is provided via CFAST option or soldered SATA Flash SSD and HDD/SSD option on 8HP extension module. Available as 4HP or 8HP version, board supports PCI 32-bit, 33 MHz (66 MHz optional) cPCI® interface and offers diverse I/O. Read More

Test & Measuring Instruments

I/O Module supports PROFINET standards.

October 22, 2014

Specifically designed for PROFINET networks, PFN-2042 Remote Output Module has 16-channel isolated digital outputs and is suitable for industrial, factory, and process automation. DIN rail mountable unit supports operating temperatures of -13 to 167°F and provides short circuit protection on DO channels. For configuration, PFN-2042 comes with Generic GSDML File v2.25.PFN_Tool configuration utility lets user configure network parameters and set power-on and safe values. Read More

Test & Measuring Instruments, Controls & Controllers

Industrial 96-Channel DIO Module is controlled via USB.

July 30, 2014

Supplied with DOT.net library, open source examples, and utilities for system integration, IA-2662-UiT supports 3.3 and 5 V TTL level while handling input signals up to 30 Vdc. Output stage is capable of ±24 mA drive, and output voltage may be set to 5 or 3.3 V. USB port is optically isolated, and onboard pluggable screw terminal blocks include 8 signal bits each, which facilitates wiring, rewiring, and interchange, as well as space management without requiring additional wiring boards. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Advanced Mezzanine Card suits wireless front end systems.

July 22, 2014

Based around Xilinx Virtex-7 FPGA, AMC-V7 is suited for LTE wireless front-end systems requiring multiple 10G CPRI links at up to rate option 8. IDT CPS-1848 Serial RapidIO Gen 2 switch supports SRIO V2.1 at up to 20 Gbps per port, while 3 front panel SFP+ optical interfaces provide flexible high-speed links, and are configurable as CPRI, OBSAI, GigE, SRIO, or other standards. In addition, optional SRIO mini-SAS connector provides high-speed cabled connectivity. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

AMC Module serves HPC and general multi-processor systems.

June 26, 2014

From 1U MicroTCA™ platform with 6 AdvancedMC™ slots to 13U ATCA® platform with up to 12 ATCA® slots, AM4024 acts as integral component for supporting streaming, live, and off-line video transcoding. This AdvancedMC™ (AMC) module supports choice of 4th generation Intel® Core™ i5 or i7 CPUs along with Intel Iris™ Pro Graphics 5200 engine and Intel HD Graphics hardware acceleration. Along with connectivity options, features include up to 16 GB ECC Memory DDR3 1600 MHz and up to 64 GB NAND Flash. Read More

Test & Measuring Instruments

PCI Express I/O Card provides 24 isolated digital inputs.

June 18, 2014

Designed for high-voltage protection in industrial control and monitoring applications, Model PCIe-IDIO-24 features 24 optically isolated digital inputs and 24 solid state FET relay outputs. Optocouplers are rated for 2,500 V isolation, and solid state outputs are capable of switching from 5–34 DC at 2 A continuous. With change of state detection on all inputs, card can generate interrupt whenever one or more digital input changes state, eliminating need for constant polling. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Electronic Components & Devices, Green & Clean

Data Processing Board routes 4 low latency signals to RTM.

May 23, 2014

Supplied in double module, mid-size format, Model CM045 meets MicroTCA.4 specification with rear I/O interface. Board features 16 GB of DDR3 memory, 8 SFP+ ports via front panel,  and Kintex-7 FPGA with x4 PCI Gen 3 signaling across fat pipes. Board is suited for several High Energy Physics applications such as cavity field stabilization and standing-wave linear accelerators, as well as other systems requiring high speed DSPs and low latency. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Ethernet Industrial DIO Module integrates in PC/104-based stacks.

May 19, 2014

Supplied in 4 x 4 x 1.7 in. steel enclosure with anti-skid bottom for control and monitoring applications, Model ETH-DIO-48 can add portable DIO to any Ethernet network. Module features 48 or 24 industrial strength TTL DIO lines, and each I/O line is buffered and capable of sourcing 32 mA or sinking 64 mA. Jumper selected resistors permit user configuration of I/O lines for pull-up to +5 Vdc, pull-down to ground, or floating. Connections to board are made via two 50-pin, IDC-type headers. Read More

Test & Measuring Instruments

Wireless ZigBee Module communicates over Modbus RTU protocol.

April 15, 2014

Offering 4 differential analog input channels, 2 analog output channels, 2 digital input channels, and 2 digital output channels, Model ZT-2026 supports communication distances up to 700 m. Users can configure analog input and output ranges, and each analog input channel has up to 240 Vrms overvoltage protection. Operating from -25 to +75°C, module is fully compliant with 2.4 G/ZigBee Specification and is suited for building, factory, and machine automation as well as remote maintenance. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

FPGA Mezzanine Carriers feature AMC form factor.

April 7, 2014

Supplied in single width size, FPGA Mezzanine Carriers come in versions that include Virtex®-5, Virtex®-6, Artix®-7, Kintex®-7, Virtex®-7 FPGAs and Zynq® All Programmable SoCs. Modules allow any VITA-57 compliant FMC mezzanines to be plugged in, providing variety of I/O options. Carriers include DDR3 memory, allowing large buffer sizes and queuing during processing. To eliminate potential single-point-of-failure in system, Virtex and Kintex versions have optional local processors. Read More

Test & Measuring Instruments, Electronic Components & Devices

DRS MUX/DEMUX 3G Cards handle 256 audio channels each.

April 1, 2014

Cheetah DEMUX-3G de-embedding card and MUX-3G embedding card fully integrate Cheetah 3G I/O video signals with Cheetah DRS audio routing distribution systems. From HD-SDI and 3G-SDI sources, both cards handle up to 16 individual video signals and up to 16 audio channels for each video signal. As many as 8 audio channels are supported from SD-SDI, 270 Mbps signals. Cards also detect compressed Dolby audio, 3G-SDI Level B, or ASI formatted 270 Mbps signals and pass them through unaltered. Read More

Test & Measuring Instruments

Compact Digital I/O Module withstands on site conditions.

February 27, 2014

Designed for distributed applications in confined spaces as well as those involving motion and subject to sustained accelerations of 5–10 g, IP67-rated Simatic ET200AL devices mount directly in machine or assembly line on site and offer M8 connections for sensors. Design allows unit to be flexibly screwed on through front or side in all mounting positions. Operating from -25 to +55°C, module comes in widths of 30 or 45 mm; up to 32 modules per station can be accommodated. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Controls & Controllers, Electronic Components & Devices

Microcontroller Development Board includes GPS/GNSS receiver.

December 30, 2013

Based on 100 MHz, 32-bit RISC with 16 KB I-Cache and 2 KB D-Cache, NavSpark includes IEEE-754 compliant floating point unit, 1 MB flash memory, and 212 KB SRAM. NavSpark-BD model has GPS/Beidou receiver onboard for smartphone manufacturers, while NavSpark-GL includes GPS/GLONASS receiver. Housed in 7 x 7 mm QFN56 package, Venus822 quad-mode GPS/GNSS processor with extended I/O pins can simultaneously process 34 GPS/GLONASS/Beidou/Galile /QZSS/SBAS signals in parallel. Read More

Test & Measuring Instruments, Electrical Equipment & Systems, Green & Clean

POL DC/DC Power Module provides two 12 A outputs (132 W max).

December 30, 2013

Non-isolated, board-mounted UDXS1212 includes PMBUS™ interface for digital configuration, communication, and control as well as adaptive voltage scaling for power reduction. With 20.3 x 11.4 mm footprint, module offers 4.5–14.4 V input range and regulated output from 0.51–5.5 Vdc. Current de-rating over temperature lets device achieve full load to 85°C without external airflow, and Tunable Loop™ technology lets user optimize dynamic response to match load with reduced output capacitance. Read More

Test & Measuring Instruments, Controls & Controllers

Distributed I/O System offers low parts variance.

November 22, 2013

Featuring scalable design, SIMATIC® ET 200MP I/O System includes digital I/O modules with short filtering times and analog modules with conversion times down to 125 µs for 8 channels. Digital modules offer IP20 protection and are scalable with self-assembling backplane bus. By guaranteeing clear assignment of module and front connector, mechanical slot coding system minimizes chance for incorrect wiring. One-to-one arrangement of modules and diagnostic LEDs clearly display operational status. Read More
