Analog & Digital I & O Boards

Controls & Controllers, Test & Measuring Instruments

Control and I/O Products offer total plant automation.

March 12, 2015

Consisting of DIN rail-mounted control and I/O products based on scalable architecture and flexible design, Symphony® Plus SD Series optimizes energy efficiency in diverse operating environments within power and water industries. Able to withstand  temperatures from -20 to +70°C without additional environmental protection, series is especially suited for applications where control is distributed over wide area in harsh conditions, such as wind and solar power plants. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

I/O Device helps accelerate daisy chain expansion.

March 6, 2015

Offering 4-in-1 smart data acquisition solution, ioLogik™ 2500 combines I/O functionality, Ethernet switch, serial/Modbus connectivity, and up to 32 GB of data logging into single remote device. Click&Go™ Plus logic technology is used to control I/O array, eliminating need for extensive rewiring during daisy chain expansion. ioLogik's slave Ethernet port can link up to 8 daisy-chained ioLogik E1200 expansion modules and convert more than 100 channels to one IP address. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers, Electrical Equipment & Systems

Remote I/O Module is programmable via FreeRTOS.

March 5, 2015

Suitable for environmental monitoring and I/O control, RIO-2010PG is powered by 32-bit NXP LPC1768 100 MHz ARM Cortex M3 processor that has 64 KB SRAM, 512 KB Flash, and FreeRTOS operating system. Industrial I/O includes one 10/100 MHz Ethernet port, one full modem RS-232, one isolated RS-485, 8 channels of relay, 16 photo-isolated digital inputs, and one 1-wire interface for temperature or humidity sensor. FreeRTOS+lwIP BSP, device manager utility, and example programs are also included. Read More

Controls & Controllers, Test & Measuring Instruments, Computer Hardware & Peripherals

Configurable XMC Modules feature Xilinx Kintex-7 FPGA.

February 25, 2015

XMC-7K series feature reconfigurable Xilinx® Kintex™-7 FPGA and 128M x 64-bit DDR3 SDRAM. Eight-lane, high-speed serial interface on rear P15 connector for PCIe Gen 1/2 (standard), Serial Rapid I/O, 10 GbE, and Xilinx Aurora implementations are supported. While rear I/O provides 4- or 8-lane, high-speed serial interface on P16 XMC port, select I/O or LVDS pairs plus global clock pairs direct to FPGA via rear P4 or P16 port. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Remote I/O Module delivers Web-based connectivity.

February 12, 2015

Powered by ARM Cortex M3 and FreeRTOS operating system, RIO-2017 interfaces sensor and instrument data to HMI with Web based connectivity. General features include 10/100 MHz Ethernet port, 8 channels of 16-bit isolated analog input, and form C relay. Web server supports AJAX, which allows access to analog input channels and relay via Web script language, and Web application can be placed in cloud, internal web server, or in RIO-2017 with 384 KB space. Read More

Sensors, Monitors & Transducers, Test & Measuring Instruments

PTC Thermistor Modules offer high sensor density.

January 29, 2015

Featuring 8 channels, Model 750-1425 is suitable for connecting to motor thermal monitoring PTC thermistors per DIN 44081/44082 standards. Up to 6 PTC thermistors can be connected in series per channel minimizing system footprint. Providing overload protection of motors within I/O node, PTC Digital Input Module features onboard diagnostics for short circuit, wire break, and out-of-measurement range as well as red/green LEDs that indicate over-temperature and wiring errors. Read More

Test & Measuring Instruments

RTD Analog Input Modules accurately read sensor data.

January 27, 2015

Connecting directly to Pt and Ni resistance sensors, 4-channel Model 750-450 and 8-channel Model 750-451 are suited for wide range of temperature data collection tasks. Modules are configurable for multiple sensor types or potentiometers, and include red status LED that indicates sensor errors such as short circuit, wire break, or out-of measurement range. Featuring compact 12 mm profile, modules are available with 2-, 3-, or 4-wire connection technology. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Subcompact Board incorporates legacy technologies.

December 31, 2014

In addition to supporting ISA bus accessible via PC/104 interface, 3.5 in. Model GENE-A55E supports 2x RS232 and 2x RS232/422/485 COM ports, DDR3L 1066 SODIMM RAM up to 4 GB, and optimized Ethernet hardware for 10/100/1000Base x2 connection speeds. Fanless design emits almost no sound and vibration during operation. Legacy support includes 5 V power supply, use of CompactFlash card, and support for all Windows® operating systems since Windows® CE 6.0. Read More

Test & Measuring Instruments

I/O System includes temperature and energy measurement modules.

December 30, 2014

X20 I/O system includes 12.5 mm wide X20ATB312 temperature measurement module and X20AP3161 energy measurement module. Up to 4 IEC 60751-compliant platinum PT100 temperature sensors can be connected to X20ATB312, which offers resistance temperature and direct resistance measurement capabilities. X20AP3161 offers 3 voltage inputs for max of 3x 480 Vac and 4 current inputs for connecting external current transformers with 333 mV output. It measures effective, reactive, and apparent power. Read More

Test & Measuring Instruments

Modular Platform facilitates RF test equipment and DUT wiring.

December 3, 2014

Modular R&S OSP gives test engineers options for setting up RF wiring configurations and controlling them manually or via computer. By offering 16 differential RS-422 outputs and 4 analog output voltages, I/O module also enables control of external equipment via differential lines. Transfer relay modules (DPDT) each have 2 SMA or N relays. Non-terminated octuple changeover relay (SP8T) and bistable versions of universal SPDT and SP6T monostable relay modules are also available. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Mini PCI Express Cards withstand harsh environments.

December 3, 2014

Measuring 30 x 51 mm, mPCIe-ICM Series offers 4 or 2 ports of isolated RS232 serial communications. Cards feature Tru-Iso™ 1.5 kV isolation port-to-computer and 500 V isolation port-to-port on all signals at I/O connectors. Designed with type 16C950 UARTS, cards use 128 byte transmit/receive FIFO buffers to minimize CPU loading. RoHS-compliant units operate from -40 to +85°C, offer ±15 kV ESD protection of all signal pins, and support data communication speeds up to 1 Mbps simultaneously. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Multifunction Interface Board adds I/O options to serial devices.

December 2, 2014

Designed to mount on rear panel of host chassis with connectors protruding through rear panel, Model 9006 adds Ethernet, GPIB, and USB interfaces to RS-232/-485 serial devices. All interfaces are IEEE-488.2 compliant, respond to 488.2 Common Commands, and provide GPIB-like functionality to extent possible with interface protocol. Ethernet port supports VXI-11 and raw socket protocol as well as internal HTML Web server. All settings are saved in internal flash memory. Read More

Test & Measuring Instruments, Electrical Equipment & Systems

Decentralized Supply/Mains Modules have cabinet-free design.

December 1, 2014

Rated IP65 against dust and water stream ingress, IndraDrive Mi modules let machine manufacturers integrate all drive components directly into machine without control cabinet. Mains module includes mains filter, mains regulator, and mains protection in one device. Energy recovering power supply, control electronics, brake resistor, and brake transistors are located in supply module. Units support all common Ethernet-based protocols and can be connected in series. Read More

Test & Measuring Instruments, Controls & Controllers

Controller and I/O Modules operate in harsh environments.

November 25, 2014

Comprising controller and I/O modules, X20c series is constructed to handle all environmental conditions. Coating on electronics module protects components and circuit board from effects of condensation and corrosive gases with effectiveness checked against BMW GS 95011-4 and EN 60068-2-6 test method 4. Functionally compatible with existing models, series operates from -25 to +60°C and features certification for maritime applications from Germanischer Lloyd. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Controls & Controllers

Communication Modules suit IoT and embedded applications.

November 25, 2014

Both using mPCIe interface, Model EMPL-G201 adds 1 or 2 isolated Gigabit Ethernet ports, while Model EMP2-X401 adds either 4 or 8 serial ports independently selectable by software to communicate in RS232, RS422, or RS485 mode. Both Embedded Peripheral Modules include ESD surge protection that can handle electrostatic shocks up to 15 KV. Modules allow system designers to expand Ethernet or serial connectivity of embedded systems for Internet of Things and industrial applications. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Communication Modules expand connectivity for embedded systems.

November 25, 2014

Via mPCIe interface, EMPL-G201 adds 1 or 2 isolated GigE ports to any embedded system. Daughter board with cable offers 2 RJ45 Ethernet jacks. Also available, multi-port serial module EMP2-X401 adds 4 or 8 serial ports, independently selectable by software, to communicate in either RS232, RS422, or RS485 mode. Flexible cable connects module with up to 8 daughter boards with DB9 serial port and power output selectable for 5 or 12 V. Optionally, 8 sets of GPIO are offered on expansion board. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Electronic Components & Devices

VPX Boards boost functional density.

November 12, 2014

Suitable for data acquisition, software radio, and digital signal processing, 6U VPX Model 57xxx accommodates one Cobalt® Virtex-6 or Onyx® Virtex-7 FPGA XMC module, while Model 58xxx accommodates 2 XMC modules. Boards take advantage of increased I/O to backplane by adding optional LVDS lines from FPGA on each XMC to user pins of VPX backplane connectors. Optional x4 user-configurable gigabit serial links provide additional interconnect options between 2 installed XMC modules to VPX backplane. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals, Electronic Components & Devices

Daughter Cards enable comprehensive external interfacing.

November 4, 2014

Available in 6 models, Arduino-compatible VM800P PLUS Boards are based on FT800 EVE graphic controller devices, in which display, audio, and touch functionality are integrated onto single chip. Boards also incorporate 8-bit ATMEGA microcontroller and TFT display with 3.5, 4.3, and 5.0 in. sizes available. Using 1 or 2 Micro-MaTch miniature connectors to interface with VM800P, daughter cards allow expansion of boards’ I/O capabilities so they can be implemented into wide range of applications. Read More

Test & Measuring Instruments, Computer Hardware & Peripherals

Ruggedized 3U cPCI CPU Board has EN50155-compliant design.

November 3, 2014

In addition to 22 nm Intel® Atom™ E3827/E3845 CPUs that offer quad-core performance up to 1.91 GHz, CP3010-SA features built-in graphics core via Intel® HD Graphics Technology as well as up to 8 GB of soldered DDR3L memory running at 1,333 MHz. Onboard data storage is provided via CFAST option or soldered SATA Flash SSD and HDD/SSD option on 8HP extension module. Available as 4HP or 8HP version, board supports PCI 32-bit, 33 MHz (66 MHz optional) cPCI® interface and offers diverse I/O. Read More

Test & Measuring Instruments

Boundary Scan Modules operate with Teradyne TestStation.

October 23, 2014

With XJLink2-CFM and XJLink2-CFMx, Teradyne users have integrated access to XJTAG's test and programming tools, operating under control of TestStation™ test program. XJLink2-CFM multi-TAP JTAG controller fits into 1 of 4 Custom Function Module locations on Teradyne Multi-Function Application Board. XJLink2-CFMx expander cards maximize connectivity from XJLink2-CFM controller, from 8 fixture-connectable signals when just using XJLink2-CFM, up to 18 signals by adding 1, 2, or 3 XJLink2-CFMx cards. Read More
