OpenVPX I/O Card supports up to 6 function modules.
North Atlantic Industries, Inc.
Bohemia, NY 11716
Oct 18, 2010
Suited for military, aerospace, and industrial applications, Model 67C3 contains 6 independent module slots, each of which can be populated with function-specific module and controlled by VME, dual Gigabit Ethernet, and sRIO or PCIe. Design eliminates need for multiple, specialized, single function cards by providing single board for assortment of signal interface and serial communication modules. Operating from -40 to +85°C, unit comes in conduction- or convection-cooled models.
CAN Bus Module provides 4 independent interfaces.
Marlborough, MA 01752 3014
Oct 15, 2010
Integrating into QuantumX universal measurement system, Model MX471 enables CAN messages to be synchronously acquired and stored for all analog or digital measured quantities such as torque, force, strain, displacement, pressure, and temperature. Module supports high-speed CAN and is connected to PC or data logger via Ethernet TCP/IP or FireWire. CAN messages can be used as trigger for measurement recordings while status of any network nodes can be logged and shown directly at device.
Data Computing Appliance collects disparate data for review.
Tampa, FL 33607
Oct 15, 2010
Using Greenplum MPP architecture, EMC® Greenplum® Data Computing Appliance helps organizations make sense of data generated from sources such as always-on networks, Web, consumers, surveillance systems, and sensors. Disruptive data warehousing technology aids in storage, management, and analysis of data for accelerated business insight. Data loading performance reaches 10 TB/hr, and half-, full-, and multi-rack configurations are avaialble for terabyte- to petabyte-scale requirements.
Process Controllers are available with software interface.
Marlborough, MA 01752 3014
Oct 14, 2010
Used for monitoring press-fitting processes or implementing switch checks, respectively, MP85A FASTpress and MP85A-S EASYswitch utilize software interface for connection to IPM process data management software. Controllers can be seamlessly integrated into appropriate system via IPM interface so that acquired production data can be directly transmitted to quality assurance server for visualization and archiving. In addition, data can be observed in real-time via web browser.
Interlock Relay Expansion Modules control up to 8 doors.
Dortronics Systems, Inc.
Sag Harbor, NY 11963
Oct 14, 2010
The 4900 Series Intelligent Interlock System features expansion modules that enable system designers to program additional interlock configurations or add operations such as switching lock power, traffic lights, sounders, and cameras. Each I/O module can control up to 4 normally locked doors, 8 normally unlocked doors, or mix of both. They include 4 DPDT form C Relays providing 8 dry contact outputs, 4 digital outputs, 4 voltage out terminals, and 4 common returns.
XMC Module combines FPGA with high-speed PCIe interface. .
Wixom, MI 48393 7037
Oct 14, 2010
Combining configurable Xilinx Virtex-5 FPGA with high-speed memory buffers and PCIe bus 4-lane interface, Model XMC-VLX is capable of executing custom instruction sets and algorithms. Field I/O interfaces to FPGA via rear J4/P4 connector and/or with optional front mezzanine plug-in I/O modules. Up to 64 I/O lines are accessible through J4 connector. Available in 3 versions, module offers choice of Xilinx VLX85T, VLX110T, or VLX155T FPGA with up to 155,000 logic cells and 128 DSP48E slices.
Strain Gage Signal Conditioner supports ¼, ½, and full bridge transducers.
Calex Mfg. Co., Inc.
Concord, CA 94520
Oct 13, 2010
Measuring 4.5 x 2.5 x 0.5 in., Model 163MK offers ¼ bridge completion and calibration for applications such as materials and structural testing. It also has 2 built-in precision ½ bridge completion resistors and can handle full bridge applications. Differential amplifier, 2 pole Butterworth filter, and 120 ma max excitation supply are also standard, and gain can be set as high as 5,000 V/V. Output filter cutoff frequency can be set at 10 Hz, 100 Hz, or 1 kHz.
Native PCIe Card offers multi-function capabilities.
Data Device Corp. (DDC)
Bohemia, NY 11716-2482
Oct 12, 2010
Model BU-67X06K takes advantage of PCIe features, power management, and bandwidth to expand capabilities of MIL-STD-1553 for embedded and test applications. Design does not require PCI-E to PCI bridging, features x1 lane PCIe interface, and supports Message Signaled Interrupt (MSI). Up to 4 dual redundant MIL-STD-1553 channels can each operate concurrently as bus controller, Multi-RT (0-31), and bus monitor.
Data Acquisition System supports 18-bit, sample rates.
CAS Data Loggers
Chesterland, OH 44026
Oct 12, 2010
Offering analog and digital I/O, Expert Key Series 100 enables data acquisition, test automation, or experiment monitoring from PC. Portable desktop model 100L and panel mount enclosure model 100C both offer USB Interface for data capture on local PC as well as 100-BaseT Ethernet Interface for remote monitoring across LAN. In addition to 14 analog inputs, systems provide 8 digital inputs, 2 counters, 4 digital outputs, 4 PWM outputs and 4 additional bidirectional digital channels.
ADC offers 23.9-bit effective resolution at less than 300 µA.
Maxim Integrated Products
Sunnyvale, CA 94086
Oct 12, 2010
Suited for precision 4-20 mA loop sensor applications, single-channel 24-bit MAX11210 offers 4 general-purpose I/O lines, and integrates buffer amplifiers on analog and reference inputs. Four GPIO lines can be used to control external 16-channel multiplexer, effectively converting MAX11210 into 16-channel ADC. Housed in 16-pin QSOP package, device offers software-programmable oversampling ratio for output rates up to 120 sps with zero latency and up to 480 sps in continuous-conversion mode.
Up-Converter targets microwave and millimeter wave applications.
RF Micro Devices, Inc.
Greensboro, NC 27409-9421
Oct 11, 2010
Consisting of GaAs MMIC I/Q up-converter in SMT ceramic package, Model RFUV5945A accelerates radio design and minimizes board space by integrating I/Q mixer, LO buffer amplifier, and output driver amplifier within 5 x 5 mm outline. Operating across frequencies of 10-16 GHz, device provides single up-converter solution for 11, 13, and 15 GHz microwave radios. DC to 4 GHz IF frequency range ensures multiple radio modulation schemes can be supported.
Intelligent Motion Controller integrates motion and logic.
Palatine, IL 60067-7399
Oct 07, 2010
Modicon® LMC058 expandable programmable automation controller offers motion control for synchronized axis, speed control, high-speed counting, and communication networks. Suited for OEMs, features include embedded Ethernet, CANmotion and CANopens, serial line, USB ports, compact I/O modules, slice I/O modules, removable terminal blocks, and spring terminals. Device utilizes SoMachine(TM) automation software to speed machine design through 6 programming languages and function blocks.
Incremental Encoders enable flexible speed, position monitoring.
Southington, CT 06489 1534
Oct 05, 2010
To accommodate diverse application requirements, available products include PC-programmable ITD2P optical encoder, PC-programmable BHF/BHG optical encoders and magnetic EcoMag encoders, EcoMag BRIH/BRID/BRIV magnetic encoders, and DIP switch-programmable BHK/BVK optical encoders. Available in various shaft designs, series allow both impulse count and rotational direction to be programmed. Users can also select and specify speed monitoring and positioning parameters for application.
Fieldbus I/O, RFID Solution supports CC-Link connectivity.
Florence, KY 41042-0937
Oct 04, 2010
Able to be placed near concentration of sensors and actuators, I/O Modules come in IP67 metal housing and feature pushbutton display for configuration as well as ports that accept 2- or 3-wire inputs. Heavy-duty, machine-mount I/O modules support full range of network and auxiliary power cordsets as well as use of both ISO 14443 and 15693, 13.56 MHz-based RFID data carriers. Overall, functionality affords full I/O and RFID connectivity for CC-Link fieldbus network.
16-bit ADC offers sampling rate of 250 MS/sec.
Analog Devices, Inc.
Norwood, MA 02062-9106
Oct 01, 2010
Featuring on-chip IF sampling circuit and buffered analog inputs, Model AD9467 offers 16-bit resolution, spurious-free dynamic range up to 100 dBFs, and signal-to-noise ratio performance of 76.4 dBFS. Signal bandwidths up to 300 MHz enable advances in radar systems, spectrum analyzers, and multi-carrier, multi-mode receiver designs for wireless infrastructure. Housed in Pb-free, 72-lead, LFCSP, Model AD9467 is specified over industrial temperature range −40 to +85°C.
I/O Board delivers 48 analog/digital I/O in single 6U VME slot.
GE Intelligent Platforms
Charlottesville, VA 22911
Oct 01, 2010
Addressing size, weight, and power constraints in military platforms, Model VME-6500 features 8 analog and 16 digital input channels as well as 8 analog and 16 digital output channels. Each analog input channel includes 16-bit ADC, while each analog output channel features 16-bit DAC. Analog inputs are software-programmable for flexibility in sample rates, gains, filters, and current ranges. Analog outputs offer programmable voltage and current rates, together with waveform generation.
Modular Incremental Encoder uses capacitive technology.
MicroMo Electronics, Inc.
Clearwater, FL 33762 3008
Sep 29, 2010
Supplied in RoHS-compliant package with 9 mm profile, AMT series includes radially mounted AMT102 and axially mounted AMT103. Both models have index pulse as well as onboard dip switch with 16 selectable resolution options from 48-2,048 ppr. Output is TTL voltage, and operating temperature is -40 to +100°C. Consuming 6 mA, products are resistant to magnetic influence, have frequency range to 250 kHz, and can serve as drop-in replacement for other industry-standard optical units.
Digital PCI-104 I/O Module features CAN bus controller.
Cypress, CA 90630
Sep 29, 2010
Model AR-B104D includes CAN bus controller that provides up to 1 Mbps baud rate and handles error detection and retransmission to simplify programming. Module has 12-channel digital inputs that function as optical isolated general purpose inputs as well as counter inputs. Able to operate as automatic pulse generators, 12-channel 500 mA digital outputs can also function as general purpose outputs. Product also includes 512 KB of SRAM and SDK for Windows and Linux OSs.
Embedded Computer Boards operate in -40 to +85°C temperatures.
American Portwell Technology, Inc.
Fremont, CA 94538
Sep 28, 2010
Measuring 2.75 x 2.75 in., PQ7-M105IT module board supports Intel® Atom(TM) processor E620T/E640T/E660T SoC and Intel® Platform Controller Hub EG20T. It features 1 GB system memory, dual independent display by LVDS/SDVO, GbE, and 7 USB ports. Model PQ7-C100XL, 3.5 in. ESB developer carrier board has VGA port and LVDS port for dual independent display, GbE port, 7 USB ports, 2 SATA ports, and SDIO socket. Both products used together suit various low-power, fanless applications.
Audio DAC integrates stereo line drivers.
Cirrus Logic, Inc.
Austin, TX 78744
Sep 28, 2010
Supplied as 14-pin SOIC, CS4354 uses on-chip charge pump to generate negative supply and outputs ground-centered, 2 Vrms filtered line level signal from 5 V supply. This optimizes low-frequency response and audio quality while eliminating need for DC blocking capacitors, mute and pop suppression circuits, and high-voltage power supply. Supporting 24-bit conversion and automatic detection of audio sampling rates to 192 kHz, DAC provides 101 dB dynamic range and -86 dB THD+N rating.
