Hot Swap 2-Wire I˛C Multiplexers provide capacitive buffering.
Linear Technology Corp.
Milpitas, CA 95035
Dec 20, 2010
Respectively multiplexing 2 and 4 channels, LTC4312 and LTC4314 provide enable pins to connect upstream I˛C bus to any combination of downstream busses or cards. Both foster I˛C address expansion by providing ability to address one of multiple identical devices, resolving address conflict issues. Additionally, bidirectional capacitive buffering allows extension of I˛C bus size beyond 400 pF specification and prevents signal corruption during live board insertion/removal.
PICMG 1.3 System Host Board suits image processing applications.
Poway, CA 92064
Dec 20, 2010
Equipped with Intel Q57 Express chipset, Kontron PCI-761 supports Intel Core i3/i5/i7 processors with four 3.06 GHz cores and up to 8 GB DDR3-1333 memory. Slot card-sized industrial server board includes 1 x PCIe x16; 1 x PCIe x4; 4 x PCI to backplane; 6 x 300 Mbps SATA II with RAID 0, 1, 5, and 10 functionality; 2 x 10/100/1000 Base-T Ethernet; and 12 x USB 2.0. Integrated Intel HD Graphics Adapter offers full DirectX 10 support and resolutions up to 2,560 x 1,600 at 75 Hz via VGA connection.
Analog Plugs convert analog signals into IO-Link signals.
Florence, KY 41042-0937
Dec 20, 2010
Featuring 14-bit resolution, IO-Link Analog Plugs are suited for systems with limited instances of analog signals. Units are connected directly to sensor and convert analog signals into IO-Link signals before transmission. Constructed with IP67-rated enclosure, plugs use unshielded, 3-conductor cable in place of shielded cables. Versions are available with current input of 4-20 mA, voltage from 0-10 V or PT 100, current output of 4-20 mA, and voltage output of 0-10 V.
Two-Channel I2C ADC includes 2.048 V internal reference.
Maxim Integrated Products
Sunnyvale, CA 94086
Dec 20, 2010
Housed in 1.9 x 2.2 mm WLP, 12-bit Model MAX11645 operates from 2.7-3.6 V supply and is capable of sample rates up to 94 ksps. Device offers up to 70 dB SINAD, ±1 LSB INL and DNL error, and 0.3 ppm/°C gain-error temperature drift. With 18 µW power dissipation at 1 ms conversion times, ADC is suited for energy-harvesting sensors, portable consumer electronics, and POL monitoring in networking and computer systems. A 4 x 3 bump array with 0.5 mm pitch facilitates layout on 4-layer PCBs.
Multi-Monitor Adapters support Mac notebooks and desktops.
Matrox Graphics Inc.
Dorval Quebec H9P 2T4, CD Canada
Dec 15, 2010
DualHead2Go DP Edition Graphics eXpansion Modules support uncompressed graphics and video across resolution of 1,920 x 1,200 pixels on 2 monitors, while TripleHead2Go modules support 1,360 x 768 pixels on 3 monitors. Both modules feature Mini DisplayPort-to-DisplayPort cable for connecting them to mini-DisplayPort output of Mac to drive multiple monitors or projectors. They allow use of laptop LCD as additional monitor and are compatible with Windows® OSs.
Flexible 16-Bit DAC is configured for demanding applications.
National Semiconductor Corp.
Santa Clara, CA 95051-0695
Dec 14, 2010
Compatible with 2.7-5.25 V analog supply, PowerWise® DAC161S055 delivers DC specifications of ±1 LSB INL max and ±1 LSB DNL max along with buffered output settling time of 5 µsec. Asynchronous load feature allows multiple DACs to provide synchronous outputs, while daisy chain capability enables multiple DACs to be linked in series. Dual-buffer SPI interface includes data read back feature, allowing verification of data sent to DAC.
Serial I/O Module suits motion control applications.
Temecula, CA 92590 3614
Dec 13, 2010
Providing 2 isolated serial synchronous inputs, SNAP-SCM-SSI Module offers communications interface between digital encoders and SNAP PAC System I/O processors or PACs. Unit connects to and accepts input from binary or Gray code encoders, allowing it to process and communicate position-related data. Accommodating SSI clock frequency up to 2.5 MHz, module functions at cable lengths up to 500 ft and can be configured for clock frequency, data bits, and time interval between data samples.
Synchro/Resolver USB Interface Device suits portable applications.
Data Device Corp. (DDC)
Bohemia, NY 11716-2482
Dec 08, 2010
Integrating with desktop, laptop, or tablet computers, Model SB-36610UX is designed for test applications involving angle measurements from synchro and resolver sensors. Portable synchro/resolver-to-digital interface device includes 2 independent channels programmable for inputs from 2-90 V, 47 Hz to 10 kHz, and on-board reference sine oscillator with output voltage options of 2-32 or 20-123 Vrms. Providing 1-min accuracy, device is suited for motor control, robotics, and valve control testing.
Airborne Laser Scanner can be mounted in any orientation.
Riegl USA, Inc.
Orlando, FL 32819
Dec 07, 2010
Especially designed to measure on snow/ice, VQ-580 provides non-contact data acquisition using narrow near-infrared (NIR) laser beam and line scanning mechanism. Laser ranging, based on echo digitization and online waveform processing, optimizes measurement results under adverse atmospheric conditions as well as evaluation of multiple target echoes. Scanning mechanism is based on rotating multi-facet polygonal mirror that provides fully linear, unidirectional, and parallel scan lines.
PCIe® Card offers 300 Gb of SLC solid-state storage capacity.
LSI Logic Corp.
Milpitas, CA 95035
Dec 07, 2010
With ability to operate with less than 25 W of power, LSI WarpDrive(TM) SLP-300 plug-and-play I/O acceleration card delivers up to 240,000 4K read IOPS and up to 200,000 4K write IOPS, with access latency of less than 50 microsec. Based on enterprise-proven LSI Fusion-MPT(TM) architecture, product can sustain up to 1,400 Mb/sec of throughput. Card features LSISAS2008 6 Gb/s SAS I/O controller and utilizes LSI SAS software drivers.
Compact WLAN Module offers 802.11b/g/n support.
Fujitsu Components America, Inc.
Sunnyvale, CA 94089
Dec 03, 2010
Model MBH7WLZ21 supports USB and antenna diversity to utilize 802.11n protocol's PHY rate of up to 150 Mbps for both transmit/receive modes. Measuring 14.7 x 18.8 x 2.1 mm, SMT module integrates into compact, low-profile devices requiring high-speed graphic/audio communication. Software support includes embedded 64/128-bit WEP, WPA, and WPA2 security for enciphering/deciphering wireless data. Product is also available as 17.5 x 59.0 x 4.8 mm dongle with USB header and built-in antenna.
Absolute Angle Encoders feature integral bearing.
Schaumburg, IL 60173-5337
Dec 02, 2010
Available in various hollow shaft diameters, Series RCN 2000/5000/8000 provide position and speed control through use on rotational axes. Encoders use single-field scanning principle with optical filtering to produce optimal scanning signals. In addition to evaluation electronics with diagnostic functions, units include plug-in cables with quick disconnect at encoder. Axial and radial deflection behavior, along with torsional rigidity of stator couplings, maximize mounting tolerances.
Multifunction DAQ Cards feature PCI/PCIe interface.
Dec 01, 2010
Multifunction MP/ME series Data Acquisition Cards offer synchronized analog measurements and control channels on PCI/PCIe interface. Cards have maximum 1 MS/sec speeds with 32 analog inputs, 2 analog outputs, 48 digital I/O lines, and 2 counters with 32-bit resolution. Included timing control logic allows simultaneous waveform generator and analog sampling. Units can also deliver high-speed, bidirectional data transfer and perform concurrent analogy, digital, and counter operations.
Dual Channel Recorder facilitates GLONASS system testing.
Buckingham United Kingdom
Nov 30, 2010
Capable of recording, replaying, and simulating GLONASS and GPS data, LabSat 2 enables developers to test professional and consumer GNSS-featured products. Unit uses computer with USB 2.0 connection to record raw signals from GPS/GLONASS antenna directly to hard disk, with no limitations on number of satellites being tracked or length of recording. When data is replayed, GNSS engine under test will re-create all movement and satellite reception encountered.
Low-Power, 16-Bit ADCs reduce energy draw to 185 mW.
Linear Technology Corp.
Milpitas, CA 95035
Nov 24, 2010
Models LTC2165 and LTC2185 are comprised of single- and 2-channel simultaneous sampling parallel ADCs, respectively. They offer choice of full-rate CMOS or DDR CMOS/LVDS digital outputs with programmable digital output timing, programmable LVDS output current, and optional LVDS output termination. Also available, LTC2195 series includes 2-channel, simultaneous sampling ADCs with serial LVDS outputs. Each series offers sampling from 25-125 Msps.
USB Serial/Hub Module facilitates system development efforts.
Future Technology Devices International Limited
Glasgow G41 1HH United Kingdom
Nov 17, 2010
Measuring 75.04 x 23.37 mm, FT4232H USB serial/hub module features FTDI FT4232H USB 2.0 Hi-Speed to UART/MPSSE chip that supports data rates of 40 Mbps and can manage all USB signaling and protocols. Unit includes 2 USB ports via dual USB connector and one via 0.1 in. pitch DIL connector pins, and 4 serial interfaces that can be configured for asynchronous or synchronous operation. Included GL850G USB 2.0 hub controller chip supports individual and gang power management modes.
CANbus I/O Modules enable flexible machine control expansion.
Trio Motion Technology Ltd.
Pittsburgh, PA 15238
Nov 17, 2010
Leveraging switchable TrioCAN I/O and CANopen DS401 protocols, P317/318/319/327 are DIN-rail mounted CAN I/O expansion modules. Range includes separate and combined 16-point DIO modules, 8 input + 4 output analog module, and 8-channel relay output module, all with fully certified EMC emission and immunity ratings. Modules may be freely mixed to max of 32 CAN addresses - all 500 kHz in Trio Mode or up to 1 MHz in CANopen Mode. Screw terminal blocks aid power supply and I/O interfacing.
Ruggedized XMC Module supports 8 I/O channels.
Extreme Engineering Solutions (X-ES)
Middleton, WI 53562
Nov 16, 2010
Model XPort9100 supports eight +28 V general purpose I/O channels, each configurable as either input or output. Each I/O signal is optically isolated, while every input channel can be configured to generate interrupt, and each output channel is capable of pulse-width modulation. Conduction-cooled product is suited for use in avionics, as well as ground vehicle and ship-board applications.
Dual-Channel SAR ADCs come in 3 x 3 mm WQFN package.
Texas Instruments, Inc. (TI)
Dallas, TX 75243-4136
Nov 15, 2010
Designed for portable data acquisition, X-Y positioning, battery monitoring, and instrumentation and control, successive approximation register (SAR) analog-to-digital converters (ADCs), models ADS7947, ADS7948, and ADS7949, provide 2 MSPS and 2-channel data conversion at 12-, 10-, and 8-bit resolution, respectively. Featuring analog power supply range of 2.7 to 5.5 V, units deliver 72 dB of SNR at 7.5 mW power consumption.
Biometric Data Capture System collects information for ID cards.
Speed Identity AB
Tyresö 135 26 Sweden
Nov 10, 2010
Designed to capture biographic and biometric data such as photos, fingerprints, and signatures in all-digital workflow, Speed Capture Station G3 is suited for e-Passports, visas, driving licenses, and national ID cards. System integrates with handling and administrative systems of national authorities, and ensures that biometric data supplied complies with industry standards and regulations, including ICAO-compliance for photos and fingerprints.
