Interface Modules work with Local SecurityNetwork bus.
Bosch Security Systems
Fairport, NY 14450 9199
Nov 12, 2008
Capable of monitoring up to 8 independent inputs with or without end-of-line resistance, Octo-input Interface Module includes changeover contact relay for providing potential-free output contact. Octo-relay Interface Module Low Voltage features 8 changeover contact relays for providing potential-free output contacts. When connected to Modular Fire Panel 5000 Series, modules enable T-tapping with up to 254 LSN optimized elements per loop or T-off.
USB Module can operate as RS-232 device.
Netanya, IL 42140
Nov 12, 2008
Offering dry contact I/O solution to any Notebook PC, model IA-2522 provides 2 change-over type output relays that can control any desired electric or electronic appliances, as well as monitor electric or electronic events. Portable device is powered through USB Port, and features 3 digital inputs that may be used both for status monitoring and event counting.
Digital Down Converter features four 200 MHz 16-bit A/Ds.
Upper Saddle River, NJ 07458
Nov 11, 2008
Designed for processing baseband RF/IF signals from communications receiver, Model 7153 4-channel, high-speed digitizer PMC module offers 2 modes of operation. Two-channel DDC mode delivers maximum decimation to 65,536 and lower bandwidth limit to 3 kHz, while 4-channel DDC mode provides independently programmable decimation range of 2-256 on each DDC, covering signal bandwidths of 700 kHz to 90 MHz. Unit also features built-in beamforming capabilities and 4 embedded power meters.
Signal Simulator suits RF link and range setup applications.
SRI Connector Gage Co.
Melbourne, FL 32934
Nov 11, 2008
Combining digital wideband waveform modulator with RF upconverter and link test capabilities, SE-4255 RF Exciter and Test Signal Simulator produces transmission-ready signals in Baseband, Upper L-, Lower L-, and both transmit and receive S-Band frequency ranges. It features Auto-BERT, automated test application for construction and display of waterfall performance curves. Product suits mobile tracking and data systems, as well as flight systems integration, simulation, and testing.
Frequency Converters support motors up to 450,000 rpm.
Sieb & Meyer USA, LLC
Cincinnati, OH 45242
Nov 10, 2008
Designed for high-speed asynchronous and synchronous motors, Models FC80 and FC82 serve as base for applications such as fuel cells, turbo compressors, vacuum pumps, and centrifuges. Intelligent magnetization control minimizes heating of spindle and provides maximum torque when required. Software allows parameterization of up to 8 motor configurations in device, while numerous features for analysis allow optimization of drive in real applications.
Inline I/O Modules target motion-based machine builders.
Bosch Rexroth Corp., Corporate Headquarters
Hoffman Estates, IL 60192-3707
Nov 07, 2008
Compatible with any Rexroth scalable PLC/PAC, Inline I/O Modules include SSI and INC IN, which bring encoder feedback capabilities. SSI features 4 inputs and position detection, which can identify motor position during rotation. Direction can be indicated with INC encoder quadrature signal, allowing machine builders to incrementally fine tune motor to specific degrees. Providing PWM and step and direction control, PWM/2 Module enables machine builders to alter width of pulse.
Signal Isolator suits control system applications.
Richmond, VA 23236
Nov 07, 2008
Offering savings on both I/O wiring and panel space with 12.5 mm width, ITXPlus measures, filters, and isolates different input parameters and converts them into 4-20 mA output. It can be programmed to suit full range of common analog signals and sensor types. Including selectable upscale or downscale sensor-break response, unit features built-in functionality for applications requiring temperature measurements and user-programmable characteristic table containing up to 101 measurement values.
PCIe Serial Interface Adapter adds two RS-232/422/485 ports.
Sealevel Systems Inc.
Liberty, SC 29657
Nov 06, 2008
Featuring UART architecture, COMM+2.PCIe includes 2 serial ports, each configurable for RS-232, RS-422, or RS-485 and capable of data rates to 921.6 Kbps. 16C950 UART includes 128-byte FIFOs and provides error-free operation in high-speed serial applications. Additionally, 16C950 UART supports 9-bit framing and is fully software compatible with legacy 16550 UART applications. Adapter includes software for Windows 98, ME, 2000, NT, XP, Vista, and Linux OS.
RTU Devices enable Modbus control over Ethernet.
Nottingham NG9 4AT United Kingdom
Nov 06, 2008
EDAM-9000 range is based on common 10/100 Ethernet networking standards and supports Modus/TCP protocol as well as UDP protocol over Ethernet networking. There are 6 models in range covering voltage, thermocouple and PRT analogue inputs, digital inputs, pulse counting and transistor outputs. All have 10-30 Vdc power supply range, full opto-isolation, and are housed in DIN rail mount enclosures.
Module processes vehicle network sensor data.
Ann Arbor, MA 48108-8942
Nov 06, 2008
Solo Matrix(TM) signal acquisition and translation module aggregates up to 32 analog or digital signals and converts them into vehicle network messages. It has 2 differential current measurement inputs, 2 variable reluctance and Hall-effect inputs, and 22 single-ended 12-bit analog inputs with ESD-protected, 28 V full scale signal conditioning. Unit is rated from -40 to +125°C, accepts signals from 12-24 V electrical systems, and connects directly to power sources from 9-36 Vdc.
Data Acquisition System is intended for rotating drive shaft.
Binsfeld Engineering Inc.
Maple City, MI 49664
Nov 05, 2008
Including software on CD, USB 2.0 cable, and printed manual, Op-Torq Field Test Data Acquisition System captures/analyzes mechanical torque, rpm and/or power data. Software is designed specifically for TorqueTrak 10K torque telemetry system and includes graphical tools and USB acquisition module to create plug-and-play interface. Timed acquisition mode enables Periodic or continuous data acquisition while high frequency acquisition mode can capture/analyze up to 500 Hz frequency.
PXI Modules support JTAG/Boundary Scan test.
GOEPEL electronics LLC
Austin, TX 78759
Nov 03, 2008
Offering 96 individually configurable, single-ended channels, PXI 5396-x Modules provide memory depth of 72 MB and 144 MB, and support structural JTAG/Boundary Scan test as well as dynamic I/O operation up to 100 MHz to execute functional tests. Groups of 32 channels from 1.8-5 V can be voltage programmed for adaptation of instrument to unit under test. Up to five 3U PXI 5396-x modules can be cascaded to I/O brick, whereby all PXI trigger signals are supported for synchronizations.
Interface Modules suit motion control applications.
Germantown, WI 53022
Nov 03, 2008
DIN-rail mountable model 51013375 26-pin D-sub interface modules offer straightforward integration with 1-to-1 pin contact for proper signal transmission/distribution. Male interface modules are paired with 737-109 triple-deck terminal strips for control-level connections of electromechanical devices. Utilizing CAGE CLAMP® spring pressure connection technology, units provide maintenance-free wiring along with operating temperature range of -25 to 55°C.
RFID System tracks safety equipment.
Red Wing, MN 55066-5005
Oct 30, 2008
Consisting of web portal for information management and mobile device for on-site inspections, i-Safe 2.0 wireless data collection system allows user to record and access information on inspection, inventory, and use; track equipment assignments by worker or location; view or download safety and equipment instructions; and access links to safety standards. Data import, export, and reporting allow user to produce files in multiple formats with filtering and sorting capabilities.
SAS-to-SATA Bridge Cards suit external storage applications.
LSI Logic Corp.
Milpitas, CA 95035
Oct 27, 2008
Allowing SAS capabilities to be added to existing SATA disk drives, 6 Gb/s Models LSISS9252 and LSISS9253, which are for 2.5 and 3.5 in. drives, respectively, consist of LSI(TM) AAMUX® technology, dual-ported SAS host interface, and SATA device interface. Cards support auto-speed negotiation and Native Command Queuing, as well as full SAS SSP protocol to host, removing SATA commands and signaling from SAS domain. Two SAS addresses per host port help eliminate failover issues with SATA drives.
Rotary Encoder suits angle and rotational applications.
Florence, KY 41042-0937
Oct 24, 2008
Used to monitor continuous and/or oscillating rotary shaft motion, BML S2E provides velocity and position information for applications such as conveyors, speed control, and angle measurement. Basic design, comprised of magnetically encoded ring and non-contact sensor head, facilitates installation and provides quadrature output at up to 46,000 ppr. Offering continuous feedback, encoder also provides angle measurement for any apparatus that revolves around shaft.
Data Converters offer sampling rates up to 250 MSPS.
Texas Instruments, Inc., Semiconductors
Dallas, TX 75243
Oct 24, 2008
Housed in 7 x 7 mm, 48-pin QFN package, 12-bit Model ADS6129 and 14-bit Model ADS6149 are suited for communications, defense, and test and measurement equipment. Model ADS6149 features 70 dB signal-to-noise ratio and 80 dB spurious-free dynamic range for input frequencies ranging from DC to 250 MHz. At max sample rate of 250 MSPS, ADS6149 consumes 687 mW, and at sample rate of 150 MSPS, with dynamic power scaling, device consumes as little 490 mW.
Clock Jitter Cleaners eliminate need for VCXO modules.
National Semiconductor Corp.
Santa Clara, CA 95051-0695
Oct 21, 2008
Models LMK04000B and LMK04001B offer 24.4 mW-ps/channel, while LMK04031B and LMK04033B are rated at 25.4 mW-ps/channel and LMK004011B is 37.4 mW-ps/channel. Units feature cascaded PLLatinum architecture as well as dual redundant inputs, 5 differential outputs, and input block equipped with loss of signal detection and automatic or manual selection of reference clock. LVPECL and LVDS outputs support clock rates up to 1,080 MHz, while LVCMOS outputs reach up to 250 MHz.
PCI Digitizer has memory capacity of up to 256 MSamples.
Agilent Technologies, Inc.
Santa Clara, CA 95051
Oct 20, 2008
Consuming less than 15 W, Acqiris U1071A digitizer is designed in short PCI card format (170 x 107 x 16 mm). Two-channel digitizer series can provide up to 1 GS/s simultaneous sampling rates on each input or, through channel interleaving, up to 2 GS/s on either channel. Analog bandwidths available are 1 GHz, 500 MHz, and 200 MHz. Commutable 50 ohm or 1 Mohm input impedances on input channel allow integration into applications requiring high bandwidth and high sample rate.
Isolated I/O Card includes 24 inputs and 24 outputs.
Richmond, CA 94806-1950
Oct 17, 2008
In addition to USB, 115.2K to 2.5M baud serial RS-422, and 10 Mbps SPI host interface methods, 7I64 offers 24 OPTO-isolated inputs that will operate with input voltages from 5-24 V. Reverse protection diodes are provided to allow use with ac inputs. There are also 24 isolated 48 Vdc 2.5 A output drivers, which are low-saturation voltage MOSFETS. Each of 24 output switches is isolated from others, allowing high side, low side, push-pull, and other output switch configurations.
