IPTV Encoder is blade-based.
Scotland United Kingdom
Jun 23, 2009
Able to support widescreen encoding (16:9 aspect ratio), Exterity IPTV encoder allows content from digital camera, satellite set-top box or DVD player to be streamed as channel on building's IP network. Available in modular blade format, unit supports RGBS video, composite and S-Video inputs using phono and S-Video connectors. Channels can be viewed using IPTV receiver or networked PC using streaming video client application.
Module enables high-density thermocouple measurements.
National Instruments Corp.
Austin, TX 78759-3504
Jun 19, 2009
Designed for C Series platform, NI 9213 enables engineers to create modular data acquisition system to collect data from up to 16 independent thermocouples with sampling rate of 75 samples/sec. Module can be deployed as quick measurement desktop DAQ device, remote measurement system over Ethernet or WiFi, or as part of embedded measurement and control system. With multiple NI 9213 modules in 1 chassis, NI CompactDAQ and CompactRIO can support up to 128 channels of thermocouple measurement.
A/D Converter targets image processing applications.
Murata Power Solutions, Inc.
Mansfield, MA 02048
Jun 18, 2009
DATEL Quad Sampling A/D converter, Model ADSQ-1410, is 14-bit, 10 MS/sec unit that converts full-scale step input signals at rate of 10 MHz. It offers 0.5 LSB RMS DC noise and dynamic performance of 80 dB, suiting it for time and multichannel frequency domain applications. Rising edge triggered start convert signal controls conversion of all 4 converters. Unit requires ±5 V for internal analog supplies and 2-5 V supply for logic outputs and operates in temperatures from 0-70°C.
RTD Simulator offers 8 individually programmable channels.
Highland Technology, Inc.
San Francisco, CA 94103
Jun 18, 2009
Allowing users to directly program resistances or simulated RTD temperatures, V420 simulates resistors, RTDs, thermistors, strain gages, and load cells, and remains accurate for DC, AC, or pulsed excitation. It simulates eight 2- or 4-wire resistive sensors and features fully isolated channels with up to 750 V common-mode range with overvoltage protection up to 50 V. Channels can be individually programmed in 4 ranges, from 5 W to 65.5 KW and operate from microvolts to 24 V/ 50 mA.
Signal Conditioner offers flexible operation.
VEGA Controls Ltd
West Sussex RH15 9NF United Kingdom
Jun 17, 2009
VEGAMET 391 can monitor remote tanks for theft of product/leakage or link to multi-pump system to respond to demand changes. It can take single 4-20 mA analog or HART input and compute level, flow (with totalizer), distance, weight, or temperature. Up to 6 relay alarms can be configured for standard tasks as well as tendency monitoring, and 2 modes of operation lets users evenly utilize, monitor, and control pumps as well as send notification of any failure from up to 4 digital inputs.
RTD to Frequency Signal Conditioner suits wind turbines.
Calex Mfg. Co., Inc.
Concord, CA 94520
Jun 17, 2009
Operating on common 24 V, 7 mA PLC high speed counter input, Model 8540 is designed for use with platinum 100 W RTD over temperature range of -100 to 400°C. Model 8540 is calibrated to the 0.00385 coefficient and output frequency is 100 Hz at -100°C to 5,100 Hz at +400°C, providing 12 bit resolution. Housed in 3.78 x 1.06 x 1.65 in. plastic case with built in DIN rail mounting foot, UL 508 and UL 1604 compliant unit is suited for remote temperature monitoring applications.
Digital I/O Board is suited for image sensor testing.
ADLINK Technology Inc.
Irvine, CA 92618
Jun 16, 2009
Offering 32 channels of bidirectional parallel I/O lines, PCIe-7350 PCI Express® supports up to 200 Mbps throughput and offers clock rate up to 50 MHz from internal timer or 100 MHz from external clock. It is based on x1 PCI Express® interface and supports selectable I/O direction per group of 8 bits. Onboard FPGA provides triggers, clock signals, handshaking lines, and I2C/SPI control interfaces to communicate with sensors. Board supports voltage levels of 1.8, 2.5, and 3.3 V.
Pulse Control Converter supplies time proportional output.
Athena Controls, Inc.
Plymouth Meeting, PA 19462 1129
Jun 16, 2009
Designed to mount directly to input terminals on 3-32 Vdc input solid state relay, APWM Series converts 4-20 mA input signal from process/temperature controller or computer to time proportional output. It supports single or 3-phase 50 or 60 Hz operation. Lever clamps are provided on converter for 4-20 mA input and relay's power section provides connection to line and load. Device tolerates inputs less than 4 mA.
Programmable Logic Controllers include 3 analog CPU modules.
Cumming, GA 30040-9905
Jun 15, 2009
Configured via software, CLICK Programmable Logic Controllers include analog CPU modules with 2 analog inputs and 2 outputs, voltage ranges up to 5 Vdc, and current up to 20 mA. Modules also feature one RS-485 and two RS-232 communication ports, real-time clock, and battery backup for internal SRAM. Units are differentiated by discrete I/O; all have 4 dc inputs, and choice of 4 dc sinking, dc sourcing, or relay outputs.
Analog Front End enables inductive touch sensing.
Microchip Technology, Inc.
Chandler, AZ 85224 6199
Jun 12, 2009
Designed to work with 8-, 16-, or 32-bit PIC® microcontroller or dsPIC® Digital Signal Controller, Model MCP2036 includes multiplexer, frequency mixer, amplifier, driver, and voltage reference. Inductive touch sensing works through plastic, stainless steel, or aluminum front panel, as well as through thick gloves and on surfaces where liquid is present. Housed in 16-pin 4 x 4 mm QFN package and 14-pin PDIP and SOIC packages, AFE is suited for appliance, industrial, and automotive markets.
DAQ System offers quality monitoring for injection molding.
Andover, MA 01810 2449
Jun 11, 2009
SenseLink(TM) QM v2.2 features multivariate analysis with partial least squares modeling to optimize quality monitoring and fault detection. Compact unit lets users track multiple quality parameters in real-time, identify product variability and defects, and determine root causes and incorporates multivariate libraries and automated modeling functions. Web browser user interface simplifies configuration and data analysis and results can be archived on local network storage servers.
Signal Conditioning Modules can be DIN rail mounted.
Advantech Automation Corp.
Cincinnati, OH 45240
Jun 09, 2009
ADAM-3112, an isolated AC voltage to DC voltage module, and ADAM-3114, an isolated AC current to DC voltage module convert up to 400 Vac or 5 Aac signals to 0-5 Vdc signals for DAQ cards. They can be exposed to severe environments and still protect system from high voltage input or power - both modules provide 1,000 Vdc between output and power; 2,500 Vrms between input and output and between input and power. ADAM-3112 provides 3 input modes, 0-120 Vrms, 0-250 Vrms, and 0-400 Vrms.
Converter handles HDTV video signals.
San Jose, CA 95131
Jun 09, 2009
Model AT-COMP500 Composite Video Down Converter takes component HDTV video signals up to 1080p and down converts them to composite and S-video signals simultaneously. Conversion is applicable in PAL or NTSC formats and component video pass-through connection is supported. Unit can remain powered on and enables HD to be integrated into various touchpanels in any commercial application.
Analog I/O Modules provide 16-channel 16-bit A/D interface.
Wixom, MI 48393 7037
Jun 09, 2009
Model 993EN BusWorks® Ethernet I/O modules accept DC current with ±20, 0-20, or 4-20 mA input ranges, while 994EN units accept ±5 or ±10 Vdc. Available in industrial-grade or commercial versions, 1 in. wide devices feature dual-format data registers supporting 16-bit integer and 32-bit floating point formats. Surge protection and 3-way 1,500 V isolation between I/O, power, and network circuits optimize reliability. Modules are configurable via web browser.
IC operates as capacitive sensor signal conditioner.
Jun 09, 2009
ZMD31210 cLite(TM) delivers 14-bit resolution and can be configured to interface with capacitive sensors from 2-260 pF with sensitivity as low as 125 atto-Farads/digital bit. Standard supply is 2.7-5.5 V with accuracy of 0.25% over -20 to +85°C range, and 0.5% from -40 to +125°C. ZMD31210 connects to micro-controllers but can also be utilized in stand-alone designs for transducer and switch applications, and calibration coefficients are stored in an on-board non-volatile EEPROM.
I/O Controllers handle USB's complex protocol details.
Saelig Co., Inc.
Pittsford, NY 14534
Jun 08, 2009
Appearing as Human Interface Device, Warrior ICs require no Windows software drivers. IO-Warrior56 features 50 pins that can be used as direct I/O lines, or more complex functions, such as I2C, SPI, controlling display modules, 8x8 switch matrices, and IR remote control decoding. IOW56 can run I2C master interface at 100 Kbps, with clock stretching for handshaking with slaves supported. SPI master function allows max bit rates of 12 MHz and peak data throughput of 62 KBps.
Gateway Module enables EtherCAT real-time data acquisition.
Marlborough, MA 01752 3014
Jun 05, 2009
QuantumX CX27 gateway module makes it possible to connect several QuantumX models in real-time via EtherCAT to superordinate automation system. With cycle times under 1 msec, measurement data can be rapidly integrated with Gateway module in automation routines and in parallel measurement and analysis processes. System allows data acquisition and control of test benches to be integrated in test bench itself in order to ensure precise data synchronization.
Data Acquisition Module features parallel design.
GAO Instruments Inc.,
Jun 05, 2009
Designed for embedded use as standard PC104 card, data acquisition module features 12-bit analog-to-digital resolution with 8 single ended inputs ranging from 40 mV to 40 V. It comes with 2 independent programmable gain channels and has sampling rate from 1 k to 20 m with low inter-channel phase difference of less than 1°. Module offers selectable/adjustable manual, external/internal triggering modes on conditions of rising and falling edge.
Data Acquisition Board is hot pluggable.
GAO Instruments Inc.,
Jun 05, 2009
Designed for field use, 4512UE 500 k, 12 bit multi-point data acquisition board is integrated with 16-channel parallel synchronous acquisition and can be expanded to 256 fully synchronized channels. It includes pre-panel that displays acquisition state of channels and post-panel that provides cascading interface for instruments. Unit provides switchable manual, external, and internal triggering modes with adjustable triggering levels.
DAC features integrated speaker amplifier.
Wolfson Microelectronics plc
Edinburgh EH11 2QB United Kingdom
Jun 04, 2009
Suited for portable navigation devices, mobile handsets, and digital radios, Model WM9081 features integrated 2.6 W switchable AB/D speaker amplifier, dynamic range controller, and ReTune(TM) Mobile 5 band Parametric Equalizer with fully programmable coefficients. Single chip mono DAC achieves audio performance of 92 dB SNR in Class D mode and 1% THD+N at 2.4 W output power into 4 W speaker loads. It supports 4 control interface addresses and 4-channel TDM.
