Other Gages

Sensors, Monitors & Transducers, Test & Measuring Instruments

Water Pressure Gauges keep lead out of drinking water.

June 18, 2015

Available with 2, 2½, and 4 in. dia dials, models UA20-X82, UA25-X82 and EA14-X82 are manufactured to comply with U.S. Safe Drinking Water Act (SDWA), January, 2014. These Weksler lead-free pressure gauges consequently offer safe method for monitoring pressures in potable water systems. Specific applications include potable water storage, water filtration, fresh-water plumbing systems, and ice production. Read More

Test & Measuring Instruments

Setting Masters eliminate master rings and gauge blocks.

June 12, 2015

Equipped with Heidenhain optical scale, 415 Series Electronic Automatic Adjustable Setting Masters set wide variety of ID and OD measuring instruments without requiring use of ID ring, OD disc, or gauge blocks. Sizes can be set by typing in exact value, which only takes seconds. Units feature ceramic reference pads, electronic LCD, and ability to store up to 100 preset positions to set most common gauges. Data can be stored via USB port and remote PC control is possible. Read More

Test & Measuring Instruments

Single-Channel Digital Thermocouple Gauge has compact design.

June 3, 2015

With 52 mm OD round housing, 38 mm depth, and IP65-rated face, model DPG-SD-1 series accepts Type K thermocouple sensor input. Microprocessor-based temperature gauge supports programming via front panel membrane keypad and offers field-selectable °C or °F as well as user-adjustable HI alarm set point. During high temperature alarm condition, red LED numeric display flashes and internal 2 A relay circuit activates. Display range is +32 to +2,282°F.
Read More

Test & Measuring Instruments

Diagnostics Suite helps determine well integrity issues.

May 12, 2015

Comprised of ultrasonic measurement tool, magnetic flux leakage tool, multisensory-caliper tool, and cement-bond tool, SecureView® wireline cased-hole evaluation suite provides single-trip, high-resolution diagnostics in cased-hole wells. Combination of 4 diagnostic technologies, used to inspect, identify, and determine root causes of well integrity issues, delivers conclusive data that lets operators address potential well threats that may lead to production loss and liabilities. Read More

Test & Measuring Instruments, Transportation Industry Products

Handheld Gap Measurement Device features sensor head with Wi-Fi.

February 23, 2015

Targeting automotive industry, CALIPRI enables testing of gaps and hem edges without use of mathematical approximation methods. Ergonomic and portable instrument measures object from various perspectives to record actual contour; gaps and hem edges are recorded in full and measured accurately by swiveling device. Preprocessing of recorded profile data occurs in sensor head, and data can be transmitted via Wi-Fi® to output device for detailed analysis. Read More

Test & Measuring Instruments

Portable Surface Finish Gauge offers one-button operation.

February 19, 2015

Available with 10 or 5 µm radius tip on provided general-purpose probe, Pocket Surf® IV displays Ra, Rz, or Rmax with one measurement stroke. MarConnect universal interface allows USB, RS-232, or Digimatic output of data by choosing appropriate cable, and LCD shows measured roughness value in microinches or micrometers within 0.5 sec after surface is traversed. Gauge offers 4 switchable probe positions — axial (folded) or at 90°, 180°, or 270° — and selectable traverse lengths. Read More

Test & Measuring Instruments

Length Gauge measures delicate materials with ±0.2 µm accuracy.

February 6, 2015

Designed to measure extremely sensitive, malleable materials without fear of product deformation, ZERO-FORCE METRO is suitable for medical device, chemical, and precision mechanics industries. Two new variants of 1 Vpp METRO gauge are available in 12 mm stroke lengths; one with gauging force of 0.25 N in any mounting orientation with weak spring and one with gauging force of ~0.0 N mounted vertically downward with ZERO-FORCE spring mechanism. Read More

Test & Measuring Instruments, Software

Industrial Gauge is cell-ready with software and process monitor.

December 17, 2014

Equator™ Flexible Gauge works with EZ-IO software, which facilitates cell controller communications configuration and allows intelligent functions, such as automatic re-mastering, upon detection of change in shop floor temperature and then directs robot/shuttle system to load master part into gauge. Process Monitor display provides graphical chart of history of feature measurements and enables management of mastering process according to temperature, time, or number of parts measured. Read More

Test & Measuring Instruments

End-of-Line Camshaft Inspection Machine can measure 200 parts/hr.

December 10, 2014

Adcole 1310 High-Speed Camshaft Gage provides robot-fed 100% camshaft inspection by measuring 10 or more parameters with 0.1 micron resolution per data point or 3,600 data points per revolution. Along with Windows® 7-based software, features include utility upgrades with chatter analysis options, parameter warnings for programmable reports, and qs-Stat quality options. Automatic programmable headstock with 100 mm travel and programmable tailstock accelerate changeovers. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Pb-Free Pressure Gauges carry NSF International certification.

November 18, 2014

Compliant with U.S. Safe Drinking Water Act, lead (Pb)-free pressure gauges feature wetted parts with lead content ≤0.25% and are safe for applications where water is anticipated to be consumed by humans. Gauges also meet lead content requirements for Pb-free plumbing as defined by CA, VT, MD, and LA state laws. Products comply with NSF/ANSI Standard 61, 372, and 61 (Annex G) and feature NSF mark, along with test standard, on dial and socket stamped with universal No Lead symbol. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Pressure Gauge includes data logging/charting software.

November 5, 2014

Suited for harsh industrial environments, DPG409S Sanitary/Clean-In-Place digital pressure gauges incorporate 316 SS enclosure, designed for washdown and marine applications, with precision 0.08% accuracy pressure transducer as well as 316L SS wetted parts and body. Gauge, Absolute, Compound Gauge, Vacuum, and Barometric models are available, all of which feature 1 in. backlit LCD, hi and lo alarms, MIN/MAX/AVG reading, and user-selectable analog output 0–5 Vdc, 0–10 Vdc, or 4–20 mA. Read More

Test & Measuring Instruments, Electrical Equipment & Systems

Wireless Bore Gauge extends operation via inductive charger.

November 3, 2014

Notifying operator via visual and audio pass/fail indicators to machine tool component specification compliance, IP65-rated WiGauge™ offers user-selectable resolution up to 0.1 µm. and utilizes Class 1 Bluetooth® technology to transmit data up to 15 m. Battery pack charges device when placed in charger cradle, minimizing or eliminating downtime. Built-in heat and time restrictions ensure tool will not overheat during extended charging periods or charge for over 24 hr. Read More

Test & Measuring Instruments

Marine Gauges fit any type of watercraft.

October 24, 2014

Offering optimized illumination and accuracy, VDO Allentare Series comprises 3 3/8 in. 35 mph and 60 mph speedometers; 4,000, 6,000, and 8,000 rpm tachometers; and 2 1/16 in. oil pressure, water temperature, fuel, trim, voltmeter, and water pressure gauges. Instruments provide straightforward installation and wiring and can be used with most commonly available marine senders and wiring harnesses. Available colors include grey, teak, yellow/blue, white, white/grey, and black. Read More

Test & Measuring Instruments

Shop-Floor Comparative Gauge supports two probing technologies.

September 19, 2014

Equator™ supports touch-trigger probing via TP20 probe for single-point probing applications. Suited for in-line gauging tasks, TP20 can be used for capture of discrete point data. Equator can also switch automatically to SP25 scanning module, which allows continuous scanning of features at speeds to 200 mm/s, and use integrated changing rack to provide any combination of measurement routines. Gauge uses principle of mastering to cope with changes in temperature on shop floor and offers Feature Compare function. Read More

Test & Measuring Instruments

Roundness, Cylindricity, and Contour Gauge aids QA operations.

May 6, 2014

Able to be used in all circumstances for workpiece evaluation to DIN ISO 1101, MarForm MMQ 400 comes in versions for high-precision, unusually long, and large/heavy workpieces. Precision Z and X measuring axes make it possible to perform any form measuring task. Modules can be used to customize unit to precise requirements: motor-driven or manual centering and tilting table; Z axis with measuring length of 35.4, 19.7, or 13.8 in.; and X axis with measuring length of 7.1 or 11.0 in. Read More

Test & Measuring Instruments, Controls & Controllers, Sensors, Monitors & Transducers

Humidity Sensor suits aircraft environmental control systems.

April 14, 2014

Intended for air ducting where humidified air is carried to seating areas, Model 8TJ315AAA1 contains sensing element and electronics that convert water concentration in air to CAN Bus output. Digital humidity sensor uses capacitance technique with specialized signal processing to measure water content. Sensor’s time response is function of airflow and typically is under 6 seconds. CAN Bus output has labels for duct humidity and temperature as well as Built-In-Test status. Read More

Test & Measuring Instruments

Camshaft Measuring Machine features Siemens motion control.

March 20, 2014

Designed for use on factory floor, Model 1000 Surface Finish Gauge enables users to press one button and have all surface measurements such as Ra, Rp, Tp, and Rsk performed in one sequence on main and rod journals and thrust faces. System is built on rugged platform of structural steel and granite, and uses 3 stylus tips which are capable of scanning 2,000 points/nm. Users can perform gauge repeatability and reproducibility tests, prove machine capability, and qualify production equipment. Read More

Test & Measuring Instruments, Controls & Controllers, Sensors, Monitors & Transducers

Clamp-On Ultrasonic Flowmeter has 0.33-32.8 fps measurement range.

March 14, 2014

Series UFM can measure velocity and flow in 0.98–4.62 OD steel, copper, and plastic pipes with accuracy of ±3% of flow reading for >0.98 fps. Supplied in IP54 plastic polycarbonate enclosure, 2.9 lb unit comes with volume pulsed output and 4–20 mA flow rate output. Capable of displaying instantaneous and totalized flow, meter incorporates backlit, 3.27 x 0.74 in., 2 line x 16 character screen for displaying text. Uses include monitoring/metering water flow in Building Automation Systems.
Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Liquid Level Gages offer adjustable centerlines.

February 13, 2014

Compensating for variances that can occur during production of plastic tanks, nylon liquid level gages accommodate centerline distances up to ¼ in. longer or shorter than specified measurement for total adjustability of ½ in. Adjustment can be made by hand, facilitating installation, and features include round Trogamid nylon sight that is clear and durable. Gages are available with centerline measurements from 6–36 in., and red line on back of sight enhances liquid level visibility. Read More

Test & Measuring Instruments, Sensors, Monitors & Transducers

Digital Pressure Gauge suits field and laboratory applications.

January 20, 2014

Powered by three AA alkaline batteries, Model PTG200 features backlit LCD screen with 5-digit resolution and choice of 9 pressure units. Standard models are housed in aluminum alloy case with atmospheric reference choices of gauge, sealed gauge, or absolute, compound, and differential. Gauge ranges measure over 2,500 bar, while compound ranges from -1 to 2.5 bar, and differential ranges from 0.0025–0.05 bar. Featuring 316L SS wetted parts, Model PTG200 offers accuracies of 0.1% or 0.2% FS. Read More
