Optical Encoder comes in 12 mm dia x 25 mm long package.
Gurley Precision Instruments
Troy, NY 12181
Jun 02, 2004 Models R112S and R112B optical rotary incremental encoders are available in shafted or blind-hollow shaft versions with resolutions up to 8,000 cycles/rev. Designed for light industrial applications that require high resolution in compact package, uses include x-y stages, medical devices, miniature/small instrumentation, compact motors, and actuators.
Redundant Control Platform ensures maximum uptime.
GE Intelligent Platforms
Charlottesville, VA 22911
Jun 02, 2004
PACSystems(TM) High Availability solutions provide scaleable, synchronized, redundant control platform with transparent process switchover. Solution consists of 2 physically independent controllers connected to I/O. Programming environment and Redundancy Wizard let users set-up shared data and I/O for both systems in redundant configuration. If any part of controller fails, its backup counterpart automatically assumes control.
Hollow-Shaft Encoder has compact design.
Servo Magnetics, Inc.
Canoga Park, CA 91303
Jun 02, 2004 Modular, hollow-shaft encoder provides dual-channel incremental shaft position at 500 lines/revolution with quadrature and index pulse. RS-422 output differential line driver device features one LED emitter/receiver as well as glass code disk mounted on aluminum hub. Low profile design adds 0.450 in. to length, and overall case diameter is 35 mm. No adjustments are required, and no mechanical rubbing exists once installed.
Pressure Transmitter measures 0-29 psi and 0-729 psi.
Irvine, CA 92614 5840
Jun 02, 2004
Type 8311 Pressure Mini-Transmitter features 2-wire, 4-20mA output and 2 NPN or PNP programmable transistor switch outputs. It offers indication, monitoring, transmitting, continuous on/off control, and high/low alarm capabilities. Menu-driven unit is programmed via 3-key pad, with critical data presented on 8-character digital display. Accuracy is ±1% fs, while repeatability is ±0.06%. Software permits display and storage of min/max values.
Data Acquisition System is USB 1.1 bus powered.
Bozeman, MT 59715
Jun 02, 2004 Model DAQ24USB-5V supports standalone and networked environments with full-featured Java and ANSI C applications and API libraries. In addition to four 24-bit analog input channels, unit offers 3 digital inputs and outputs and three 10-bit, analog input channels. Up to 16 digitizers can be attached to one host. Device can also utilize external power supply and comes with DAQ24Eval, which graphically displays and records data while providing key statistics.
Flat-Field Spectrometer suits EUV and soft X-ray.
Chelmsford, MA 01824
Jun 01, 2004 Optimized for Extreme Ultraviolet (EUV) and Soft X-ray wavelength regions, flat-field toroidal grating instrument works over 2 fixed wavelength ranges. Gratings are available for 1â€“5 nm and 5â€“20 nm. Angle of incidence and aberration corrections are optimized for area of interest, and effective blaze wavelengths are 1.6 and 10 nm, respectively. Geometry allows use of CCD detectors for direct detection and microchannel plate intensifiers for systems that require gating.
Digital IR Thermometer uses variable focus optics.
Mikron Infrared, Inc.
Oakland, NJ 07436
Jun 01, 2004 Non-contact, infrared temperature sensor M670S sees through view ports such as glass, quartz, or sapphire without any loss of accuracy. With 7.5 msec response time and temperature range from 350â€“3,000°C, unit provides digital interface communications with remote addressability for up to 32 sensors. It measures temperature by receiving passive incoming radiation from target at wavelengths from visible light to NIR portion of spectrum.
Portable Infrared Sensor measures temperature in 1 sec.
South Bend, IN 46628
Jun 01, 2004 Non-contact Model LTM-100 allows user to monitor temperature by holding measurement button down. It includes switchable °C/°F, auto-power off, and adjustable emissivity. Water-proof, dust-proof sensor can be washed with water or antibacterial resin. It is suited for applications where contact may cause contamination, operator may be at risk due to high temperature, or when object is in motion.
Temperature Recorders support all common thermocouples.
Warner, NH 03278
Jun 01, 2004 Thermocouple-Based Temperature Recorders feature non-volatile solid state memories for data security, and can be used with PC for real-time data monitoring. Eight-channel OctTemp reads and records up to 14,563 measurements/channel, while 4-channel QuadTemp handles up to 26,214 measurements/channel. Single channel units record 32,767. Providing ±0.5°C accuracy at 25°C and 16-bit resolution, recorders offer read rates from 1 every 5 sec to 12 hrs.
Hipot Testers feature PLC remote control.
Slaughter Test Systems
Ardmore, OK 73401
Jun 01, 2004 Models 2512 and 2515, rated 250 and 500 VA respectively, feature electronic ramp and dwell timers as well as memory storage for test parameters. Instruments control most functions remotely through switches and analog inputs and outputs. With PLC remote control, test, reset, and interlock inputs are provided. Outputs include test in process, pass, fail, and reset. Both testers offer microprocessor control and 100 mA of test current.
Test Simulator targets automotive transients.
Souderton, PA 18964-9990
Jun 01, 2004 Model UCS 200M incorporates EFT-Burst generation and Micropulse generation as per international standards and world-wide vehicle manufacturer specifications. Coupling network carries EUT currents of up to 200 A. Simulator offers FreeStyle Mode via ISM ISO 4 software to allow generation of Micropules with variable test voltages, rise-times, and pulse durations.
Custom Glass Scales are offered in three versions.
Bedford, MA 01730
May 28, 2004
Application-specific encoder scales are available as rotary, rotary segment, and linear scales. Compatible with Mercury(TM) encoders, chrome-on-glass scales exhibit thermal stability and include optical index specified by customer. Custom rotary glass scales can be manufactured with IDs to 254 mm and ODs to 304.8 mm for max resolution of 176 M CPR. Options include index mark outside main track and low-CTE materials. Maximum length available is 2 m.
Digital Caliper resists severe manufacturing environments.
Mitutoyo America Corp.
Aurora, IL 60504 9176
May 28, 2004 IP66-rated Coolant Proof Digimaticâ„¢ Caliper is dust-proof, chip-proof, and maintains ±.001 in. accuracy when submersed in coolant. It features Absolute® linear encoded measuring scale and single battery operation. Large LCD readout helps take readings under all shop lighting conditions. Optional accessories for digital SPC-enabled models include IP66 rated connector and cable; Digimaticâ„¢ gage/PC input device; and Digimaticâ„¢ Mini-processor.
Test Chambers simulate environmental conditions.
Caron Products & Services, Inc.
Marietta, OH 45750 0715
May 28, 2004 Standard and customized test chambers simulate various types of conditions involving temperature, humidity, and light. Temperature and humidity capabilities range from -20 to +80°C and 2â€“98% RH. Typical applications include stability and photostability testing, light fastness studies, freeze-thaw cycling and freezer storage, accelerated testing, forced degradation, plant growth, and TAPPI testing.
Pin-Compatible ADCs target signal processing applications.
Texas Instruments, Inc. (TI)
Dallas, TX 75243-4136
May 28, 2004 Series ADS5500 consists of three 14-bit ADCs and three 12-bit ADCs available in speeds of 80, 100, and 125 MSPS. Models ADS5520 and ADS5521 are 12-bit units operating at 125 and 105 MSPS with SNR of 69 dB at 100 MHz input frequency. Model ADS5522 is a 12-bit converter operating at 80 MSP with SNR of 70 dB. Models ADS5541 and ADS5542 are 14-bit, 105 and 80 MSPS devices with 710 and 670 power, respectively. Applications include communications, medical, video, and imaging.
DC/DC Controller offers choice of operating modes.
Linear Technology Corp.
Milpitas, CA 95035
May 28, 2004
Model LTC3737 2-phase, 2-channel DC/DC step-down switching controller offers output tracking for proper startup of multiple voltage systems. Device features user-selectable mode to specify light load operation at high efficiency or low output ripple. For operation over max range of battery voltage or minimum input-output voltage differential, LTC3737 operates at up to 100% duty cycle regulating each output voltage from 0.6 V up to voltage equal to input supply.
Pressure Transmitter/Transducer is accurate to ±0.25% BFSL.
Honeywell Sensing and Control
Golden Valley, MN 55422
May 28, 2004
Constructed from all-welded stainless steel, Model BDR universal pressure transducer/transmitter handles any process gas or fluid. It features configurable electrical connections that maximize adaptability to varied applications and delivers accuracies of ±0.5% or ±0.25% BFSL. Available in ranges from 0-150 psi through 0-15,000 psi, unit features ±0.01% FS/°C thermal error and serves as drop-in OEM replacement for older sensors.
Supervisor monitors up to 6 supplies.
Linear Technology Corp.
Milpitas, CA 95035
May 28, 2004
Available in SOT-23 and DFN packages, LTC2908 hex supply monitor is suited for densely packed systems with multiple, low-voltage supply rails as well as 5 or 3.3 V logic supplies. Product holds reset low with as little as 500 mV of input supply voltage. With 1.5% threshold accuracy over -40 to + 85°C operating temperature range, unit ensures reliable reset operation without false triggering. It features 2 adjustable inputs with nominal threshold of 0.5 V and 4 fitted thresholds.
On-Line Measuring Cabinet is suited for filter cartridges.
International Filter Testing Services Inc.
Springfield, NJ 07081
May 28, 2004
Designed for on-line continuous measurement of filter cartridge efficiency, particle counting cabinet is based on testing method that allows efficiency and retention capacity of filter to be assessed continuously. Dual flowmeters record actual flows through each sensor, while computer records and processes all data and displays number of particles before and after filter. Computer also displays instant filtration efficiency or ratio.
Test Kit tests all aspects of automotive performance.
Saelig Co., Inc.
Pittsford, NY 14534
May 27, 2004
Based upon Model ADC-212/3 PC-based oscilloscope, Pico Automotive Test Kit(TM) includes PicoScope Automotive software and information package. It turns laptop or desktop PC into automotive diagnostic tool for fault-finding sensors, actuators, and electronics circuits found in vehicles. Available in 4 versions, kit is suited for OEMs, garages, breakdown roadside recovery organizations, and mobile tuning and repair services.
