Flow & Level Sensors
(Showing headlines 1 - 20) more ....
Analog Level Sensor leverages non-contact Reed switch technology.
Elobau Sensor Technology, Inc.
Waukegan, IL 60085
Aug 26, 2014
Configured for containers or tanks, customized analog level sensor is offered with standard and 360° rotatable head options. Programmable switching points, optional temperature measurement, and materials range promote application versatility. With basic design, head is provided with closed cover, and switching points or resistance output are fed out directly. Another version offers head with pushbutton and LED; current and voltage signals can be output. Another variant offers LCD.
Bearingless Encoders suit limited space applications.
Southington, CT 06489 1534
Aug 05, 2014
Providing position and speed feedback in limited installation space, MIR 10 Encoders are fully encapsulated, non-contact magnetic sensors with up to 4096 ppr and IP66/IP67 ratings for harsh environments. Units are available with 5 Vdc supply and TTL/RS422-compatible line drivers as well as 10–30 Vdc version with pushpull. Both variants output 2 channels with 90° shift and inverted signals. Measuring 10 x 15 x 45.5 mm, encoders have matching pole wheels that fit shafts from 6–43.5 mm.
Ultrasonic Sensors offer flexible output configurations.
Carlo GAVAZZI Automation Components
Buffalo Grove, IL 60089
Jul 23, 2014
Suitable for difficult distance and level applications, Long Range UA30CAD60 Series offers two different output configurations: 2 digital NPN or PNP outputs, or analog output in either 4–20 mA or 0–10 Vdc as well as one digital NPN or PNP output. Units feature sensing distances of 250–6,000 mm and are available in either cabled or M12 quick-disconnect versions. Operating from 12–30 Vdc power supply, IP67-rated sensors are set up via simple teach routine.
Non-Contact Scanning Probe suits high-accuracy inspections.
Hexagon Metrology Inc.
North Kingstown, RI 02852
Jul 18, 2014
With 3 mm dia, measurement range up to 20 mm, acceptance angle of ±30°, and scanning speed of 1,000 points/sec, HP-O delivers force-free measurement of blisks, blades, gear profiles, and flank lines as well as other potentially deformable parts without loss of accuracy. Optical measurements can be captured in single point or scanning mode, and repeatability is <0.3 µm when used with Leitz PMM-C CMM. Scanning technology is not affected by ambient light.
Overfill Sensor prevents overflow of fuel tankers.
Emco Wheaton USA, Inc.
Houston, TX 77095
Jul 15, 2014
Using electronic signals, F2020 Overfill Sensor prevents product overflows of tanker compartments, ensuring valuable fluid is not lost. System is connected to controls of terminal through plug and socket connection and is designed for tankers with up to 8 compartments. When overfill is detected, system will override and shut down terminal pump and metering equipment. System has ISO 9000/2000 approval and is manufactured in compliance with EN13922 and European ATEX directive.
Digital Flowmeters monitor compressed air usage and waste.
Cincinnati, OH 45249-1621
Jun 30, 2014
Available for schedule 40 iron pipe in ½, ¾, 1, 1½, 2, 2½, 3, and 4 in. sizes, Digital Flowmeters measure air consumption and identify trends at all critical areas or individual legs of compressed air system. LED display directly indicates SCFM or m³/hr volume of airflow. USB data logger and included software can be preinstalled or purchased separately. Summing Remote Displays, which enable users to monitor compressed air consumption from convenient location, are also available.
Position Sensor utilizes inductive, non-contact technology.
Everight Position Technologies Corp.
Narberth, PA 19072
Jun 18, 2014
Gill Blade 20 lets engineers achieve 12-bit resolution with ≤1 bit of repeatability over span of 20 mm. There are no moving internal parts, and IP69K sealing is available. Able to be user-customized with regards to sensing distances, output ranges, PWM settings, and more, sensor is designed for facilitated installation and can be integrated into steering systems, manufacturing automation systems, and waste treatment systems.
Laser-Based Sensor enables non-contact vibration measurement.
SKF USA, Inc.
Lansdale, PA 19446
Jun 18, 2014
Delivering optimal results on every measurement surface regardless of environmental conditions, MSL-7000 series measures vibration and structure-borne noise from fans, electric motors, and pumps. Design employs contactless velocity proportional sensor and is suited for process-integrated, end of line acoustic inspections of noise-critical equipment. Covering acoustic measurements form 0.2 Hz to 22 kHz, this laser vibrometer integrates into manufacturing line and existing control systems.
Magnetoresistive Sensor ICs suit battery-operated equipment.
Houston, TX 77014
May 29, 2014
Supplied in subminiature SOT-23 surface mount package, Nanopower Anisotropic Magnetoresistive Sensor ICs feature solid state, non-contact design and are suitable for battery powered applications where previously only reed switches could be used. Model SM351LT provides magnetic sensitivity as low as 7 Gauss with current draw of 360 nA, while Model SM353LT offers sensitivity down to 14 Gauss with current draw of 310 nA. Omnipolarity allows sensors to be activated by north or south pole.
Doppler Flowmeter combines usability, repeatability, accuracy.
Greyline Instruments, Inc.
Massena, NY 13662
May 08, 2014
Able to measure flow from outside pipe, DFM 5.1 uses doppler signal processing technology and works with difficult liquids, such as wastewater, sludge, slurries, and abrasives, or any liquid with bubbles or suspended solids. Clamp-on ultrasonic sensor mounts on ½ in. ID or larger pipe, and calibration and start-up are facilitated via 5-button keypad. Standard features include backlit display and totalizer, isolated 4–20 mA output, and 6 control relays. Several options are also available.
Non-Contact Angle Sensors have compact design.
Novotechnik U.S., Inc.
Southborough, MA 01772
May 05, 2014
To facilitate mounting in tight spaces, Vert-X 1600 Series has 16 mm dia body and mounting flanges with metal inserts. Sensors measure 0° to 360° with full resolution and accuracy at programmed electrical angles as well. Along with independent linearity to ±0.3% of measurement range, features include resolution to 14 bits, repeatability to 0.1°, and life of 50 million movements. Analog and digital options as well as single and redundant versions are available.
Low-Water Cutoff Devices protect boilers and steam generators.
Gems Sensors Inc.
Plainville, CT 06062
May 05, 2014
Offered in configurations and functions to suit various water feed vessels, LWC-700/720/800 Series features redundant switches within liquid level sensors as well as electronic controllers to deactivate systems before water supply problem can damage or create critical situation. Controller box may be mounted directly on sensor unit head or up to 2 ft away via optional electrical conduit configuration. Other options include manual reset, power outage resets, and operation testing.
Oil Quality Sensor eliminates unnecessary oil changes.
Waldwick, NJ 07463
Apr 23, 2014
Eliminating need for interval oil changes, Oil Quality Sensor (OQS) monitors oil condition – contamination and moisture – to enable oil to be changed based on need. This live, flexible, condition-based monitoring solution can be permanently mounted within any lubrication system on any type of machine. Data can be displayed on existing system or STAUFF Oil Quality Display (OQD).
Electromagnetic Flow Meter achieves accuracy rate of ±0.3%.
Badger Meter, Inc.
Milwaukee, WI 53224
Apr 17, 2014
Combining general purpose detector with amplifier, ModMAG® M1000 features non-intrusive open flow tube that virtually eliminates pressure loss. Unit has no moving parts to impede flow stream, keeping maintenance to minimum, even in less than ideal fluid conditions. Available in ¼–8 in. sizes, meter provides flow range of 0.03–12 m/s and is best suited for bi-directional flow measurements of fluid >5 µS/cm. Amplifier includes LCD and is housed in weather-resistant, NEMA 4X (IP66) enclosure.
Inline Flow Sensors suit lubrication and pneumatic systems.
Thomas Products, Ltd., Flow Switch Div.
Southington, CT 06489
Apr 16, 2014
Made of brass or all SST, Model 1600 detects factory set points from .1–1.5 gpm in water. Model 1700 has set points as low as 1 cc/min in water. Both models handle various liquids to ensure adequate flow of coolant, lubrication, or injections of chemicals. Designed to also operate in pneumatic systems, set points of 2–8 scfm help ensure adequate air or gas flow is present. Along with standard ¼ in. FNPT process connections, features include max operating ranges up to 1,000 psig and 301°F.
Acrylic Flow Meters feature interchangeable scales.
Orangeburg, NY 10962
Apr 15, 2014
Configured for panel mounting, Series 6A02 is available with interchangeable direct reading scales for Water, Argon, Oxygen, Carbon Dioxide, Nitrogen, and Helium. Scales are mounted at front of flow body and are positioned and secured by clear front plate. Displaying flow rates in both metric and English units, meters feature max temperature of 150°F, max pressure of 100 psi, and accuracy of ±3% full scale. Low hysteresis, multi-turn needle valve is included.
Laser Sensor measures from 100-1,000 mm.
Banner Engineering Corp.
Minneapolis, MN 55441
Apr 10, 2014
Designed with linear array technology, Model LE550 provides repeatability and accurate measurement of challenging targets ranging from shiny metal to black rubber. Non-contact unit is suitable for roll diameter, loop control, thickness measurement, and positioning. Enclosed in die-cast zinc housing with IP67-rated polycarbonate lens cover, Model LE550 features 2-line, 8-character display and Class 2 laser beam. Metal, rotatable connector and multiple mounting bracket options are available.
Ultrasonic Flowmeter tracks movement of gas through pipelines.
Houston, TX 77014
Apr 08, 2014
Designed to help maintain pipeline metering, Model USM GT400 measures volume of natural gas at every stage of its movement, storage, and utilization. Compliant with CEESmaRT™ cloud-based solution for condition-based monitoring, unit provides stability during flow perturbations thanks to direct-path technology with 6 measuring paths on 3 levels. Orientation enables measurement of swirl, cross-flow, and asymmetry, as well as transparent path velocity weighting per Gauss-Chebyshev profile model.
Magnetic Inductive Flow Sensor provides ±1% accuracy.
Dwyer Instruments, Inc.
Michigan City, IN 46361
Mar 31, 2014
Unlike sensors with moving parts, Series MFS2 can measure contaminated media in ½, ¾, 1, or 1 ¼ in. diameter pipes. Electromagnetic PVDF flowmeter is available for flow ranges from 0.02–66 gpm. Any change in temperature, density, viscosity, concentration, or electrical conductivity does not affect output signal. Providing obstruction-free pipe cross section, Series MFS2 is suitable for accurate reversible gauging of volume flow of conductive liquids in closed piping.
Acrylic Flow Meters offer interchangeable scales.
Orangeburg, NY 10962
Mar 19, 2014
With respective flow capacities of 50 scfm, 10 gpm, 2,200 scfh, 2,400 scfh, 2,200 scfh, 2,650 scfh, 6,350 scfh, and 10,000 scfh, 6A03 series offers interchangeable, direct reading scales for air, water, argon, oxygen, carbon dioxide, nitrogen, helium, and hydrogen. Dual scales display flow rates in both metric and English units, and yellow back promotes readability. Supplied with in-line ¾ in. female NPT connections, meters deliver ±3% FS accuracy and have 316 stainless steel float and guide.
