K-Tek    Prairieville, LA 70769
May 06, 2005 MagWave incorporates dual-chamber design that includes magnetic level gauge for level indication and guided wave radar transmitter. Unit offers accurate level measurements with pressures up to 3000 psi or temperatures to 800°F. Custom configuration is available with second chamber fitted for guided wave radar, magnetostrictive, or capacitance transmitters. Unit provides independent, redundant measurements in oil, gas, petrochemical, and power applications.

Pfeiffer Vacuum Inc.    Nashua, NH 03063
May 06, 2005 SmartTest(TM) delivers results at max inlet pressure of 25 mbar, and detects helium leaks at rate of 5 x 10^-12 mbar l/sec. Unit features integrated test leak for self-calibration, vacuum and sniffer operating modes, and optional industrial proof hand held remote control. Backing pump is user-selectable to match application needs in semiconductor, automotive component testing, refrigeration, and air conditioning industries.

Balluff, Inc.    Florence, KY 41042-0937
May 06, 2005 Series BOS 2K sensor offers full functionality in package measuring 20 x 7.5 x 10 mm. It offers scan range of up to 1.2 m. Four different sensing modes are offered: diffuse, for part identification; diffuse with background suppression, for part configuration and placement; retroreflective, for parts verification and counting; and thru-beam versions for part sizing and position information. Each sensor contains pinpoint LED emission for exact aiming and positioning.

BEA Inc.    Pittsburgh, PA 15215
May 06, 2005 Bodyguard III overhead presence sensor uses diffused active IR sensing to protect entire swing path of automatic swinging doors, from guide rails through to threshold. Rain and snow mode reduces nuisance openings due to misread environmental cues, while learn time feature ensures that objects abandoned inside detection area will not inhibit sensor function. Microprocessor controlled unit can be programmed using BEA Universal remote.

Weber Sensors Inc.    Woodstock, GA 30189
May 06, 2005 Foto-captor lets users program set-points to specific applications from 300–800°C. It accepts input voltages of 24 Vdc or 110 Vac and provides transistor or opto-isolated output options. Additional options include water cooling, air purge, and application-specific viewing lenses.

Network Physics    Mountain View,, CA 94043
May 06, 2005 NP-500 appliance provides troubleshooting across network environments rated for up to 20 Mbps throughput and can store 160 Gb of data in a RAID-1 configuration. Non-intrusive product delivers detailed, real-time and historical information pertaining to over 60 network metrics. With included NetSensory OS, users can organize network data into business groups and applications for automated aggregation, analysis, correlation, and alerting.

Brijot Imaging Systems, Inc.    Orlando, FL 32819
May 06, 2005 With 45 ft range, BIS-WDSâ„¢ Prime uses passive millimeter wave sensor technology to detect guns, knives, or bombs of metal, plastic, or composite construction. Weapons Detection System (WDS) consists of millimeter wave camera combined with video camera and algorithm software that interfaces to other security devices/networks. Capable of identifying up to 50 threats simultaneously, system produces electronic alarm when suspicious item is detected.

Ascension Technology Corporation    Burlington, VT 05402
May 06, 2005 Hy-BIRD(TM) combines optical and inertial data streams for uninterrupted, all-attitude tracking. Optical technology provides 6 degrees-of-freedom tracking of its detector's location 240 times/sec with accuracy better than 1°, ensuring undistorted helmet tracking in fixed, motion-based, and mobile environments. Inertial sensor takes over when optical tracker is not operational, tracking Yaw, Pitch, and Roll angles until optical sensor is working.

austriamicrosystems AG    Premstätten   Austria
May 05, 2005 Manufactured in lead (Pb)-free SSOP 16 package, 8-bit AS5035 provides incremental quadrature A/B output signals and index output signal. It provides 64 ppr on each output channel for resolution of 2.8°/step over full turn of 360°. Able to operate at 10,000 rpm without missing any incremental pulses, product continuously monitors magnet presence for operational safety. Zero position can be programmed by user, and unit operates at 3.3 or 5 V.

Texas Instruments, Inc., Semiconductors    Dallas, TX 75243
May 05, 2005 Manufactured in SOT23-6 and MSOP-8 packages, TMP141 measures temperature from -40 to 125°C without external sensing components. It features 10-bit resolution digital output and single-wire SensorPathâ„¢ interface protocol. Suited for space-restricted applications, product has 170 µA max operating current and extended supply range of 2.7–5.5 V. It is suited for monitoring hardware systems in servers and PCs as well as battery-powered instruments.

TE Connectivity Ltd.    Berwyn, PA 19312
May 05, 2005 Integrated into AMP applicators, EDGE Counter displays cycles since installation to track tool usage and optimize maintenance scheduling. On-counter LCD display and EDGE Counter Software Pack provide access to operation counts and other applicator statistics. Tool enables operators to perform applicator maintenance and tool replacement at measured intervals with pre-set limits. Counter and software use wireless IR technology to transfer data.

E+E Elektronik GmbH    Engerwitzdorf A-4209  Austria
May 05, 2005 Suited for measuring CO₂ in ventilation channels, EE85 features closed loop air stream and diaphragm that protect CO₂ sensing cell from pollution. CO₂ detection is based on non-dispersive infrared technology (NDIR), and aging effects are compensated by auto-calibration procedure. Available for measuring ranges of 0–2,000 ppm and 0–5,000 ppm, transmitter has compact design that facilitates installation.

Rockwell Automation    Milwaukee, WI 53204
May 05, 2005 Key-operated SensEject detects presence or absence of key in control equipment and automatically ejects key to prevent inadvertent or unauthorized operation. It prevents key retention in momentary positions and also allows user to work on specific equipment within production line without shutting down entire process. Key-sensing contact block can signal alarms or annunciators and detects when operator overrides interlock.

Endress + Hauser Inc.    Greenwood, IN 46143
May 04, 2005 Able to withstand harsh process conditions, Micropilot M FMR250 non-contact level gauge is protected against dust, vapors, and product temperatures up to 392°F. Loop-powered, 2-wire device has max measuring range of 230 ft. Available with narrow beam parabolic antenna or 3 in. horn antenna, unit is set up via menu on local display or by connecting to PC with HART® modem. Device is designed to measure level of plastic pellets, corn, soy beans, cement, and fly ash.

Pipeline Inspection Company Ltd    Houston, TX 77055
May 04, 2005 Self-contained SPY® Models 780 and 790, equipped with topside handle and ergonomic pistol grip, have built-in jeep meter that lets users inspect coatings on 2–60 in. pipe diameters. To test integrity of thin film coatings, Model 780 has 1,000–5,000 V range, while Model 790, with 5,000–35,000 V range, inspects extra thick and somastic coatings. Both feature infinite voltage settings, audible alarm, and positive ground indicator light.

Cal Test Electronics    Yorba Linda, CA 92887-4604
May 04, 2005 General-purpose MiniProâ„¢ series test clips, suited for circuit and basic test interconnections, feature smooth, soft touch actuation and gold-plated beryllium copper hooks. Offered in 10 colors, series features secure, snap-lock assembly that withstands heavy use. EU- and RoHS-compliant products are available individually, with lead wires, or in 10-piece kit.

ifm efector, Inc.    Exton, PA 19341
May 04, 2005 Immune from long-term effects of magnetic fields, top-loading sensors incorporate giant magnetoresistive (GMR) technology and suit pneumatic cylinder applications. Polarity-independent sensors detect piston position regardless of magnet orientation. They measure 25 mm long and are secured with mounting screw that prevents cable-pulls. Offered in cabled and pigtail models, dc units include PNP/NPN, NO 2-wire models and PNP or NPN, NO 3-wire models.

Shockwatch    Dallas, TX 75247
May 04, 2005 To assist with scheduling maintenance based on actual operating hours, Shockswitch® RF Hourmeter measures running hours of various types of equipment by monitoring up to 3 independent inputs such as keyswitch, drive motor, and hydraulic motor. Runtime information is transmitted via 802.11/b/g wireless network to either local or remote computer running Java-based companion software. Device is also equipped with LED operating status indicators.

Air Logic, Div. Fred Knapp Engraving Co., Inc.    Racine, WI 53402
May 03, 2005 Snap-acting Switches Series interface from pressure or vacuum signals to electric control systems. SPDT switches are available with 0.1–25 A and max supply pressure of 100 psi with adjustment ranges from 0.5–100 psi. Various mountings are available.

DataCard Group    Minnetonka, MN 55343
May 03, 2005 Available in 5 languages, Datacard® ID Works® v5.1 grants administrators control over security of card programs by enabling them to grant users varying levels of access to settings and projects, monitor activity, and set login timeouts. Software supports biometrics and smart cards as well as Lightweight Directory Access Protocol, which lets security professionals in enterprise organizations automatically manage and update ID information in directory service.
