Omron Electronics, LLC    Schaumburg, IL 60173
Jan 16, 2006 With 110 µs response time and 0.25 µm resolution, ZS sensor can inspect moving workpieces and capture data on-the-fly, while customizable gain setting lets users optimize performance for specific environmental conditions. Modular, plug-and-play design employs 5 separate sensing heads for distances from 20-200 mm and measuring ranges from ±1-50 mm. Data is transferred between sensing head and amplifiers via high-speed interface with no signal degradation.

Jesco Products Company, Inc.    Sterling Heights, MI 48314
Jan 13, 2006 Insensitive to flow rate and moderate pressure variations, Bubble-Detect package alerts production operators or automated equipment to presence of air in fluid processing systems via triple alarm system comprised of audible, visual, and relay alarms. Inline-mounted manifold system can be added to any dispensing system for immediate air bubble detection. It has no internal moving parts, connected power receptacles, and adjustable bubble size sensitivity.

Omega Engineering, Inc.    Stamford, CT 06907
Jan 13, 2006 Packaged in transistor (TO-5) case, PX70 Series is available in full-scale ranges from 0.3-100 psi. Model PX71 is offered without fittings for gauge and absolute ranges, while PX72 has top-mounted tube fitting and bottom vent. Also available in gauge ranges, PX73 has bottom tube fitting and top vent. For differential measurements, PX74, with top and bottom tubes, can be used for uni- or bi-directional results. PX70 models are compatible with clean, dry, non-corrosive gases.

Emerson Process Management    Austin, TX 78754
Jan 13, 2006 Rated to 5,000 psi, Micro Motion® F-Series Meters provide flow and density measurements in demanding, high-pressure environments at flow rates to 300 lb/min. When combined with Micro Motion MVD(TM) Technology, meters deliver mass flow accuracy up to ±0.1% and volume flow accuracy up to ±0.15% when measuring liquids. On liquid density, meters are accurate to ±0.001 g/cc. Units have no moving parts to wear out or break down, and no need for periodic recalibration.

General Monitors    Lake Forest, CA 92630
Jan 12, 2006 Combining optical Multi-Spectral IR (MSIR) sensor array with neural network technology (NNT) processing, FL4000 protects people, equipment, and facilities from dangerous hydrocarbon flame sources within 230 ft range. Intelligent system discriminates between actual flames and nuisance false alarm sources using 4 separate IR spectrums which sample different IR spectral areas. Flame or non-flame decision is output via LEDs, relays, and MODBUS.

Panasonic Electric Works Corporation of America    New Providence, NJ 07974
Jan 10, 2006 Featuring aluminum, IP67-rated construction, LightPix AE20 integrated lighting, CCD color camera, and CPU vision sensor is suited for vision inspection and is programmed using AETOOL software. It offers 6 interchangeable inspection packages, which include color judgement, color area, color pattern matching, measurement, edge detection, and peak detection. In addition to PLC and HMI connectivity, sensor features optical red LED light for height adjustment.

Rockwell Automation    Milwaukee, WI 53204
Jan 10, 2006 As stand-alone monitors or part of networked solution, Allen-Bradley XM-160 Series (XM-160, -161, and -162) Overall Machinery Protection Modules serve applications requiring real-time monitoring of overall vibration levels. Machine monitoring and protection system, deployed on open standard industrial bus, links maintenance tools into control architecture for continuous monitoring and protection of critical plant-floor assets.

Schroeder Industries LLC    Leetsdale, PA 15056-1025
Jan 10, 2006 Designed to continuously monitor hydraulic and lubrication fluids, Testmate(TM) Water Sensor Model TWS-C measures water content relative to percent saturation of fluid in range of 0-100%. Capacitance sensor absorbs water molecules from fluid and changes capacity value that is directly related to saturation level. Integrated thermoelement on sensor measures temperature of fluid from -13º to 212ºF. Temperature and degree of saturation are reported as 4-20 mA signal.

MadgeTech    Warner, NH 03278
Jan 09, 2006 Incorporating TelAire® 7001 CO₂/temperature monitor, CO₂ and Temperature Recorder System provides real-time viewing of data when performing indoor air quality studies and balancing HVAC systems. With QuadVolt 4-channel data logger, system offers software that permits customizable engineering units, overlaid graphics, and export to MS Excel®. System provides ±0.10% FSR accuracy and 32,767 measurements per channel.

Toledo Integrated Systems    Holland, OH 43528
Jan 09, 2006 Dust-proof, 4-channel PWi PressWatch Production Monitor features 100 job storage capacity, reverse tonnage display, as well as top stop and e-stop relays. User interface consists of 6 tactile switches and backlit LCD graphic display, which provides menu system and relays tonnage deviation, alarm data, settings, and time-based tonnage signatures for PressNet and TTGraph. Included 7-segment LED displays tonnage of each channel as well as total tonnage.

STMicroelectronics    Lexington, MA 02421
Jan 06, 2006 Supplied in lead (Pb)-free, RoHS-compliant, SOT23-3L package, STM1061 series precision voltage detectors can be used for 1-bit A/D conversion, voltage limit monitoring, and microprocessor supervision. They are available with choice of 40 laser-trimmed voltage thresholds, offered in 0.1 V increments from 1.6-5.5 V, and typically consume 900 nA. Operating in -40 to +85°C temperatures, units can be used as MCU Reset ICs via external capacitor on open drain output.

VIP Sensors    San Juan Capistrano, CA 92675
Jan 06, 2006 Sealed against external contamination, stud-mounted Model 2010A utilizes integral electronics for taking general vibration measurements on structures and objects. It has bandwidth up to 10 kHz and transmits its low-impedance voltage output through same cable that supplies constant current power. Side connector is used with 10-ft coaxial cable terminated with 10-32 connector for error-free operation.

KAPPA opto-electronics Inc.    Monrovia, CA 91016
Jan 06, 2006 Suited for infantry and personal security, video-based Night Vision System provides night vision at 0.00047 lx min illumination without image intensifier. Product weighs 290 g and features 12-bit digital signal processing, 50 cm to infinity focus range, and -5 to +2 diopter adjustment. Adaptable lenses provide FOV of 8-80°. Usable in pitch dark as well as bright sunlight, system includes dynamic range enhancement feature that provides clearer view in fog, haze, smoke, or rain.

Banner Engineering Corp.    Minneapolis, MN 55441
Jan 06, 2006 Available with in-line and right-angle lens positions, PresencePLUS® P4 AREA series performs multiple analysis functions simultaneously at speeds to 10,000 parts/min. Model P4 AREA 1.3 offers 1280 x 1024 pixel resolution, and all sensors offer Gray Scale and BLOB analysis capabilities. Able to perform live inspections without PC, sensors directly connect all I/O to Ethernet IP and Modbus TCP and feature remote TEACH function for on-line, push-button inspection changeovers.

NetTalon    Fredericksburg, VA 22408
Jan 05, 2006 System 3000 networks local fire departments with buildings they protect, enabling firefighters to examine details of fire and begin to form strategies before leaving firehouse. Within 2 sec of sensor or smoke detector activation, system reports alarm conditions to all authorized monitoring stations. Icons representing heat sensors, duress buttons, and smoke detectors are overlaid on floor plan and change color to indicate alarm conditions.

HASCO Hasenclever GmbH + Co KG    Ludenscheid D-58513  Germany
Jan 04, 2006 With temperature resistance up to 140°C, Model Z 1477 inductive proximity switch is short-circuit proof, reverse polarity protected, and offers non-contact, wear-free operation. Aluminum housing protects it from impact and vibration. Applications include tool design, mold design, and general mechanical engineering.

Fortress Interlocks Ltd    Erlanger, KY 41018
Jan 04, 2006 Designed to control access to machinery and process lines operating in potentially explosive environments, UL- and CSA-Certified Stop XP is ingress protected to NEMA 1, 3, 4, 6, 7, 9 and 13. Heavy-duty product, manufactured from stainless steel and zinc alloys, is available with handle actuator (AmStop XP) or tongue actuator (AtStop XP) for use on hinged and sliding doors. It employs tamper-proof locking mechanism and dual-channel safety circuitry.

MAGNOVA, Inc.    PITTSFIELD, PA 01201
Jan 04, 2006 Featuring non-contact torque sensing, Series MLY torque transducer offers size compatible means to monitor and control motor and mechanism torques. Available with shaft sizes of 3.17-6.35 mm dia and torque ranges of ±10-±1,000 mNm, they can accommodate rigid and shaft mounted arrangements. Torque may be coupled to transducer shaft through gears, pulleys, linkages, as well as conventional inline couplings.

GE Energy    Atlanta, GA 30339
Jan 03, 2006 To satisfy PS-12A mercury CEMS performance standard required by Clean Air Mercury Rule, continuous emissions monitoring system (CEMS) employs Cold Vapor Atomic Fluorescence (CVAF) technology for measuring mercury. Product enables low detection limits and total vapor phase measurement while minimizing sample loss during transport. This eliminates need for external calibration gasses and optimizes mercury trading credits.

Ophir Optronics, Inc.    Wilmington, MA 01887
Dec 30, 2005 Featuring 0.5-1 µm spectral range and 65 mm aperture, convection-cooled L50(300)A-IPL (Intense Pulsed Light) detector is designed for applications in medical and cosmetic dermatology markets that call for very large beams, single shot energy, or IPL sources. It has window for gel coupled IPL sources, where IPL source is coupled to window where gel or water is used for measurement. Energy accuracy is ±6%, and uniformity over surface is ±1.5%.
