New Sensors, Monitors & Transducers Products

Thin Position Sensor measures all the angles.

NCAPS(R) non-contacting angular position sensor is less than 0.21 in. thick without housing and provides true 360 deg absolute rotary position feedback. It offers extremely thin solution for motion control, rotary position, or steering angle sensing. Sensor has multiple outputs with up to four functional output channels. Each sensor can be factory programmed to give pulse width modulation (PWM),...

Sensor offers universal mounting system.

Series 46 sensor has plastic housing with large-size lens system that is impervious to most chemicals and continues to work even when covered with dust. It features black/white distinction and background suppression towards shiny surfaces. Sensor is available as through-beam, retro-reflective or diffuse reflection model. It includes range adjustment function, choice of warning outputs or...

Encoder operates up to 1 MHz bandwidth.

H25D industrial encoder has T10 and T20 signal interpolation electronics that allow it to operate up to 1 MHz. Circuitry can electronically multiply base encoder resolution by factor of 10 and 20, respectively. Electronics are self-contained within rugged, sealed industrial encoder package allowing for simplified installation and reliable operation.

Displacement Transducers incorporate electronics.

WA-Electronic series of inductive displacement transducers provide 0 to 10 Vdc output signal via in-line electronics. Models include plunger and spring-loaded probe configurations. All have stainless steel construction and handle temperatures up to 300 deg F, making them able to handle harsh industrial environments and wash-down situations. Eight standard measuring lengths are available, from...

TOP 3 SEAL TROUBLE SIGNS and HOW TO FIX IT

If ignored, broken seals can lead to a loss in production and equipment shut down. For more information on seals and seal repairs, download now.

Thermocouple Cards provide low-noise temperature readings

DBK81(TM), DBK82(TM), DBK835(TM), and DBK84(TM) are available in 7 or 14-channel configurations to provide thermocouple inputs to company's DaqBook(R), DaqBoard(R), and LogBook(R) product lines. Each has individual channel filtering and amplification to achieve maximum peak-to-peak noise levels of less than 0.2 deg C. Input channels may be configured via software to support TC types J, K, T, E,...

Linear Position Sensor has linearity of 0.25%.

DC-operated HydraStar(R) variable inductance, non-contact linear position sensor is designed for use in hydraulic and pneumatic cylinders and actuators. Capable of working in pressures of 3,500 psi, DC HydraStar consists of body with threaded fitting and 0-ring seal. It requires 10 to 36 Vdc power, and produces either 0 to 10 Vdc or 4 to 20 mA output for full displacement. Measurement ranges from...

Document Scanner puts drawings on network.

Scan-to-Network Scanning Solution has monochrome 25 in. scanner that scans, automatically extracts title block information from drawings, and puts info into archived database, such as Access. Archived data can be pulled into Excel or saved as raw text. Users can immediately view scanned images over network, using standard web-browser. No client software or configuration is necessary. Applications...

Conductivity Sensors have electrodeless design.

Model 3700E-Series eliminates polarization and electrode coating problems that commonly affect contacting, electrode-type conductivity sensors. Only one wetted material contacts process media. Body materials are polypropylene, PVDF, PEEK(R), or PFA Teflon(R). Sensors are available in convertible or sanitary mounting styles. They can measure solutions with conductivity as high as 2,000,000...

Optical Encoders suit tight package constraint applications.

MOD 700 Series incremental rotary encoders are comprised of LED and OptoASIC in 17.7 x 9.6 x 8.89 mm package. They offer resolutions as high as 2,540 ppr. OptoASIC provides +/- 0.010 in. tolerance for axial movement, 40 mA power consumption, and operating temperature of 0 to 85 deg C. Stainless steel code disk features range of standard optical radii, from .375 to .860 in., and can accommodate...

Density Transmitter checks liquid concentration.

DT301 Touche transmitter performs continuous, on-line measurements. Capacitive, differential-pressure transmitter is coupled to pair of pressure repeaters immersed at different levels in process. Integral temperature sensor compensates for temperature variations. Software calculates fluid density. DT301 provides accuracy of +/-0.0004 g/cm3, with range of 0-0.5 to 0-5 g/cc. Models are available...
