Chicago Pneumatic Co.    Rock Hill, SC 29730-7463
May 07, 2013 Serving heavy-duty industrial maintenance applications, CP69 series delivers up to 1,920 lb-ft torque with 700 blows/min (bpm) and features pinless rocking dog clutch with oil bath lubrication system. Precision machined and finished steel rotor and end-plate components bolster durability and performance, while light aluminum alloy clutch housing protected by molded rubber front cover lends to durability. Ergonomic features include 8.7 m/s² vibration level and 97 dB(A) operating noise.

Chicago Pneumatic Co.    Rock Hill, SC 29730-7463
Feb 19, 2013 Delivering 59–1,217 lb–ft of torque, CP82 series includes 9 models that cover 3/8–¾ in. square drives with ring, pin, dual, as well as quick change socket retainers. Impact wrenches, suited for industrial maintenance applications, feature aluminum alloy clutch housing, reinforced back plate, and protective cover. Twin hammer clutch mechanism and hard chromium liner lend to reliability, while ergonomics are promoted via 89 dB(A) noise level, 5.8 m/s² vibration level, and composite housing.

Chicago Pneumatic Co.    Rock Hill, SC 29730-7463
Jan 07, 2013 Consuming 7.75 cfm, ¾ in. Models CP7769 and CP7769-6, with 6 in. extension shank, feature S2S side-to-side single-hand forward/reverse switching for operator comfort. Fiber-reinforced composite body and magnesium clutch housing help minimize arm stress and operator fatigue, while optimal balance and interaction between motor and clutch mechanism maximizes efficiency. CP7769 series is suited for heavy vehicle mechanical repair and maintenance repair operations.

Chicago Pneumatic Co.    Rock Hill, SC 29730-7463
Dec 11, 2012 With reverse impact torque of 2,140 lb-ft, CP7782 Series includes standard (CP7782), 6 in. extended (CP7782-6), and 6 in. extended spline anvils (CP7782-SP6) variants suited for truck and heavy equipment professionals performing wheel removal and general maintenance. In addition to full teasing trigger and pinless reinforced rocking dog clutch, features include angled down exhaust, 4-position, soft-grip side handle, and forward/reverse regulator.

Mountz, Inc.    San Jose, CA 95112
Jun 14, 2012 Designed for screw tightening, fastener audit, and general torque measurement, MTWD provides visual (green LED), acoustic, and sensory (handle vibration) signal when operator-programmable, pre-set torque is reached. Torque readings are shown in real-time on digital display, and tool supports 4 units of torque measurement: N.m, lbf.ft, lbf.in, and kgf.m. Functionality aids users in light industrial, automotive, electronics, and aircraft applications with noisy environments.

Makita U.S.A., Inc.    La Mirada, CA 90638
Mar 21, 2012 Powered by 18 V LXT Lithium-Ion battery, Model LXWT01 features 2-pole motor that delivers top no-load speed of 1,900 rpm and 2,200 ipm with 325 lb-ft max torque. Cordless tool has 7/16 in. quick-change hex chuck, ergonomic grip, large rocker trigger switch, and single LED light to illuminate work area. Measuring 10 3/4 in. long and weighing 7.8 lb, wrench delivers speed and power needed to drill and fasten into treated wood telephone poles without rotational torque.

Ten-Tec    Sevierville, TN 37862
May 20, 2011 Rugged SD Series torque wrenches have torque output ranging from 1,270-580,000 lb-ft. Units include push-through square drive to switch from loosen to tighten, anti-backlash mechanism that allows hands-free operation, and replaceable wear pad that protects reaction arm. Wrench arms can be changed by pressing protected release button. Full 360° x 360° swivel connections are integrated along with pressure/torque chart that is laser etched onto nose of tool.

Makita U.S.A., Inc.    La Mirada, CA 90638
May 19, 2011 Powered by 12 V Lithium-Ion battery, 3/8 in. Model WT01W is equipped with 0-2,300 rpm variable speed motor that delivers 1,000 lb-in. max torque for range of fastening applications. Wrench has heat hardened steel hammer and anvil and built-in LED light to illuminate work area. Measuring 6 3/8 in. long and weighing 2.1 lb, tool includes 2 batteries, charger, and tool case. It is also available in 3-piece combo kit with 3/8 in. drill-driver and LED flashlight.

Bosch Power Tools & Accessories    Mt. Prospect, IL 60056
Nov 23, 2010 Weighing 6.7 lb with 10 in. head length, 18 V Model IWTH180-01 features ½ in. friction ring for socket changes, while Model HTH181-01 has ½ in. detent-pin for positive accessory retention, and Model HTH182-01 includes 7/16 in. Quick Change for tool-less accessory removal. All-metal gear train drives each motor at 1,900 rpm with 2,100 imp for full range of fastening applications. For optimal visibility, wrenches are equipped with LED flashlight function that activates when trigger is depressed.

Norbar Torque Tools, Inc.    Willoughby, OH 44094
Oct 20, 2010 TrukTorque(TM) features banana-shaped reaction arm to accommodate bolt tightening on front and rear wheels of trucks and buses as well as wheel trims and deeply recessed wheel bolts. Delivering up to 1,000 Nm of torque, tool produces noise levels to 83 dBA and is designed so operator's hands cannot get trapped while wheel nuts are tightened. Product fastens nuts and ensures proper tightness, provides exact level of required torque in every application.

Ingersoll-Rand Co.    Bryan, OH 43506
Sep 28, 2010 Available in pistol, angle, and inline styles, QE2 Series operates with ICD and M Series controllers to apply precise torque to fasteners using variety of advanced tightening algorithms. Full closed-loop transducerized control delivers traceability and error-proofing to maximize product quality. Suitable for both critical and non-critical applications, tools feature ESD-safe composite bodies, comfortable handles, integral headlights, and status lights.

Mountz, Inc.    San Jose, CA 95112
Jul 15, 2010 Available in Auto Shut-Off and Non Shut-Off models, FlexPower Pulse Nutrunners suit industrial assembly applications covering bolt sizes M5-M14. Pneumatic tools are designed for safe, reaction-free operation in straight, pistol, and angle configurations with ¼ in. female hex and square drive options. Standard in-line models cover torque range of 5-47 nm, while pistol-grip models cover range of 5-148 nm, and angle configurations cover torque range of 8.5-60 nm.

Atlas Copco CMT USA, Inc.    Commerce City, CO 80022
Jun 25, 2010 Operating at up to 395 rpm, Tensor Revo Model ETP ST10 provides 1,000 Nm of torque and weighs only 6.1 kg. Swiveling front gear lets operators move reaction bar through 360°, and built-in transducer and encoder accurately control torque and angle. LEDs and clear display on tool give operator feedback on result of each tightening, and tool also collects tightening data for process improvement and traceability.

Mountz, Inc.    San Jose, CA 95112
Jun 15, 2010 TorqueMate® Digital Torque Wrench can be used for torque calibration, joint testing, auditing, or verification of torque applied. It includes memory for over 2,000 values; detailing date, time, torque and angle, and measurement values. Data can be downloaded to PC to evaluate torque results and store test data. Ergonomic unit features up to 99 programmable presets that can be uploaded from PC, and provides audible and visual alarm as user approaches and achieves preset torque values.

Chicago Pneumatic Co.    Rock Hill, SC 29730-7463
May 21, 2010 Designed with twin hammer clutch to remove stubborn fasteners, 3/8 in. Model CP7735 features 3-position regulator in forward that provides torque needed without over torquing fastener. Teasing throttle allows operator to have complete control when removing or starting fastener to prevent from stripping threads. Model CP7735 is also available in ½ in. version as well as quiet version that reduces impacted sound pressure to 86 dBA.

Tohnichi America Corp.    Northbrook, IL 60062-2420
May 06, 2010 Able to ensure precise tightening with ±3% accuracy of indicated value, CPT ProTork(TM) features LED indicator that lets user view increasing torque as it approaches preprogrammed target as well as red and blue indicator lights. Several modes - Preset Tightening, Judgment Tightening, Peak/Run - cater to range of applications, up to 50 different torque measurements can be saved, and up to 10 different target torque setting can be registered for tightening various fasteners.

Atlas Copco Tools & Assembly Systems    Auburn Hills, MI 48326
Apr 16, 2010 With intelligence to adapt pressure to joint characteristics during set-up, Pulsor C ensures proper target torque is delivered. System provides same accuracy in both hard and soft joints and shuts off automatically when target torque is reached. Monitoring features account for angle, number of pulses, rundown and tightening times, and rundown and pulsing pressures. Because Pulsor C is reaction-free, it can be operated with one hand at high torques.

Metabo Corp.    West Chester, PA 19380 4243
Mar 03, 2010 Operating from 18 V Li-Ion battery packs, ½ in. PowerMaster SSW18 features Variospeed electronics with 3 speed ranges from 0-1,600, 0-2,150, and 0-2,650 rpm. Air-cooled charging technology uses guided air flow ducting to cool battery pack to level temperature during charging, while Electronic Single Cell Protection electronically monitors battery cells to prevent damage. Weighing 4.1 lb, wrench has die cast aluminum gear housing for optimal heat dissipation.

Chicago Pneumatic Co.    Rock Hill, SC 29730-7463
Oct 15, 2009 Featuring 4,000 rpm speed and forward working torque range of 443-2,290 lb-ft with 4 adjustable settings, CP6930 PALED 1½ in. impact wrench is designed for plant maintenance, petrochemical, refinery, and off road construction equipment repair industries. It features inside or outside trigger, forward/reverse switch, and suspension bail to decrease operator fatigue. Adjustable exhaust helps to deflect exhaust away from operator.

Bosch Power Tools & Accessories    Mt. Prospect, IL 60056
Jun 16, 2009 Built around 18 V and 14 V Litheon(TM) cordless platforms, Impactor(TM) Drivers and Wrenches operate at up to 2,800 rpm and deliver up to 3,200 bpm. Bosch 25618 18 V model can drive 3 in. all-purpose screw into pressure-treated 4 x 4 in about 1 sec and 3 x ¼ in. lag bolt in less than 4 sec. Ergonomic handle grip optimizes control and minimizes fatigue, while Flexible Power System allows user to choose SlimPack battery for lightest weight or FatPack for longest run time.
