ESS Technologies, Inc.    Blacksburg, VA 24060
Feb 22, 2010 Accommodating bottles, micro-tubes, vials, and syringes, Monoblock Filler/Capper integrates scales to measure and record weight of containers prior to filling and again after filling to verify exact fill amounts with ±2 mg accuracy. System handles up to 70 containers/min, and color touchscreen lets users adjust servo controls for diving nozzles as well as pump fill rates. Construction, featuring stainless steel exterior and hard-anodized aluminum inner frame, meets cGMP standards.

Delkor Systems, Inc.    Minneapolis, MN 55449
Dec 16, 2009 Featuring tubular stainless steel frame and 38 x 104 in. inline configuration, Capstone Flange Seal Carton Closing System employs precision belt drive technology to position, close, and seal cover flange seal cartons. Positioning system within machine includes counters and accommodates full range of carton sizes. Equipped with Allen-Bradley Compact Logix controls and Panel View Plus 1000 HMI touchscreen, machine uses mechanical tuck or hot glue sealing to close cartons.

Delkor Systems, Inc.    Minneapolis, MN 55449
Dec 16, 2009 Constructed of stainless steel, Capstone Tri Seal Carton Closing Machine accurately positions, closes, and seals 3-flap cartons at line speeds of 150 cartons/min. Servomotor technology enables positive carton transfer, while right angle design conserves floor space. Designed to align leading edge of carton and scored fold over front flap during sealing, Intelligent Positioning(TM) technology produces symmetrical sealed carton that perfectly aligns graphics.

A-B-C Packaging Machine Corp.    Tarpon Springs, FL 34689
Dec 09, 2009 Incorporating floor-level case magazine, Model 800T runs cases from 14 x 12 x 7.25 in. to 29.25 x 22 x 25 in. KDs feed from top of stack, fed by combination gripper and slidebar system that stabilizes large cases as they feed to packer, while products are precisely packed by servo-controlled loading ram, guided into case by stainless steel packing funnels that protect exterior graphics and shrink wraps. Cases may be sealed with tape or hot melt adhesive.

KenBay    Mendham, NJ 07945
Nov 24, 2009 Equipped with 18 x 28.5 in. chute type opening, Series K100 can compact waste into stainless steel containers or plastic bags, or be used as baler for recycling materials. Depending upon type of material being compacted, users can expect compaction ratios from 6 times to double that amount. Units operate from 120/220 V single phase power or 240-480/600 V for marine use. Made of AISI 304 SS, marine version has stainless steel washdown motor and all electrical wiring in waterproof compartment.

Harris    Tyrone, GA 30290
Nov 11, 2009 Designed for long life and able to handle various materials, HRB Centurion 300 and HRB 1035 respectively deliver 300 and 357 tons of ram force to produce heavier, denser bales. Both machines have 8.5 sec dry cycle time and employ twin 100 hp power unit. Along with heavy-duty main frame uni-bodies, balers feature Harris control system and program that includes 10 in. touchscreen, Harris Bale Watch 2(TM) performance monitoring, and production reporting.

Global Trash Solutions    Lake Park, FL 33403
Nov 06, 2009 Combining trash compactor and cardboard baler, Model GTS 2000 is capable of reducing trash volumes by 80% or more. Compactor is coated with Kevlar-based polyethylene fiber that makes it virtually indestructible. Powered by hydraulic pump and electric motor, system is operated by computer technology, which allows it to be fully programmable.

Harris    Tyrone, GA 30290
Oct 26, 2009 Featuring ½ in. plate construction with 1 x 4 in. thick reinforcement, Piranha® Closed Door Horizontal Baler provides 110 lb/in² ram face pressure. Machine can handle paper stock, secondary fiber, aluminum/steel cans, PET, and HDPE. In addition to hydraulic door actuator and serrated shear knife, baler has category 3 safety system on conveyor hopper access door. Access to hopper is protected by dual circuit magnetic safety switch and dual trapped key interlock system.

Harris    Tyrone, GA 30290
Oct 20, 2009 Featuring 18 x 7 ft footprint, HLO 5443 offers baling cycle time of 7.6 sec using twin 25 hp motors. High volumetric displacement enables production rates up to 14 tons/hour. Economy mode shuts down one 25 hp motor to save energy, while rear access doors enable access to cylinders, and stamper automatically removes jams at shear knife. With max operating pressure of 3,000 psi and ram face pressure of 114 psi, baler is suited for processing OCC, ONP, PET, and plastics.

Harris    Tyrone, GA 30290
Oct 19, 2009 Harris HSO4529 50 hp baler features cycle times of 6.5 sec and volumetric displacement/production throughput for shredded OCC of up to 14 tons/hr and for shredded news up to 16 tons/hr. Maximum operating pressure is 3,000 psi and ram face pressure is 89 and 120 psi. In economy mode, one 25 hp motor shuts down to conserve energy. Baler features rear access door, for access to cylinders, and enclosed power unit with hinged wire tie inserters and twister units to simplify access.

Westfalia Technologies, Inc.    York, PA 17402
Oct 14, 2009 Utilizing 4 x 4 pack pattern, Fractional Quart Carton Caser packs quart (1 L), pint (500 mL), and ½ pint (250 mL) cartons. Servo control load head adjusts to various fractions of quart size cartons, is height adjustable, and comes with dual in-feed carton conveyors, case conveyor, and line breaks. Constructed of stainless steel, caser suits wet environments found in dairy and beverage facilities. Options include conveyor extensions and motor controls for incoming conveyors.

Automated Packaging Systems Inc.    Streetsboro, OH 44241
Oct 07, 2009 Offering packaging speeds up to 150 bags/min, SidePouch® FAS SPrint Revolution(TM) Bagging System presents conveyor of pre-opened bags that are ready for loading from 60 in. wide workspace. System operates in continuous, intermittent, or batch modes, and cycles on pre-set parameters or by using foot switch. Featuring stainless steel construction, system has 90° tilting load area, corrosion-resistant materials, NEMA 4X electronics protection, and Allen-Bradley® control package.

Brown Machine LLC    Beaverton, MI 48612-0434
Sep 15, 2009 B-Series Hot Sheet Thermoformer integrates sheet extruder close to machine and roll stack at entrance end, allowing material to be extruded directly onto conditioning rolls within it, helping save energy. Sheet with high core temperature creates forming conditions that enable precise material distribution, allowing use of 2-stop oven instead of 4 or 5-stop oven, which also saves energy. Available in sizes up to 50 x 60 in., system is configurable for production with wide variety of materials.

Brown Machine LLC    Beaverton, MI 48612-0434
Sep 11, 2009 Separating treadle movement into 2 independent motions, Servo Treadle Option allows punch to pilot into product prior to entering die, ensuring trim concentricity tolerances as low as ±.005 in. Sliding treadle is controlled through independent servo motor, giving treadle movement flexibility in positioning product for trimming. Treadle speed is electronically matched to press speed to ensure precise timing as speed of press is accelerated or decelerated.

Brown Machine LLC    Beaverton, MI 48612-0434
Sep 11, 2009 Quad Series incorporates forming station, featuring up to 260 tons of holding force and 150 tons of coining force, that lends to precise and consistent thermoformed product by ensuring virtually zero deflection across entire mold area. Also available, roller screw third motion technology enhances material distribution, reduces starting gauges, and promotes process window. Mold area sizes vary up to 64 x 64 in., with capabilities to produce parts with depths of 4-12 in.

EDL Packaging Engineers, Inc.    Green Bay, WI 54304
Aug 20, 2009 Designed to create close fitting bagged total enclosure, Tight Wrap Forming Shoe System is comprised of Tight Wrap Side Feed Automatic, model TWSFA 38-30 Wrapper with 53 in. Center Folded Film Feed, Infeed Conveyor, Film Forming Shoe, Lap Sealer, and Exit Conveyor. System completely encapsulates product, and vacuum evacuation removes excess air from pack (if necessary). During packaging, formed gusset creates handle to facilitate product handling.

Schneider Packaging Equipment Co., Inc.    Brewerton, NY 13029 0890
Aug 14, 2009 Designed to pack rigid cases, bags, cartons, or trayed products, Model HVCP utilizes FANUC robotic arms with HMI to facilitate changeover and eliminate programming. System can orient product vertically, horizontally, or combination of both, with press of button. Positive case erection optimizes system tolerance to case variations, while open design allows access for jam recovery, and standard Ethernet port enables remote monitoring and diagnosis.

Standard-Knapp, Inc.    Portland, CT 06480
Jun 26, 2009 Powered by servo motor, Versatron Active Product Transport (APT) is designed for high-speed packing of non-round and difficult-to-handle containers. APT technology pulls products into the packing area, eliminating line pressure and avoiding jams in packaging process, and beaded lane guide eliminates friction as containers are carried along conveyor belt to help avoid locking/shingling. Also, integral sensors detect number of bottles to ensure each case is packed properly.

PTi - Processing Technologies International, LLC.    Aurora, IL 60502
Jun 17, 2009 Offered in monolayer or coextrusion formats, GLOBALINE® produces sheet from materials such as PP, PS, PET, and polylactic acid in widths of 40 or 60 in. It can be configured for production outputs between 650-3,900 lb/hr. Design includes linear bearing mounted frame infrastructure; pivoting extruder base via hydraulic jacking system, simplifying screw removal/maintenance; and touchscreen controls. Available in NPE version for inline thermoforming or full-length for producing roll stock.

Econocorp. Inc.    Randolph, MA 02368
Jun 15, 2009 Measuring 60 x 32 in., ECONOSEAL E-System 2000 provides solution for automatic, horizontal cartoning at up to 1,500 cartons/hr. System handles cartons ranging from 1 x ¾ x 2 ½ in. to 12 x 4 x 12 in., and accommodates both paperboard and corrugated material. Machine erects all cartons on single product loading station, closes all end flaps using glue seal end or tuck closure methods, and automatically discharges completed cartons for next operation.
