Optical Breadboards serve critical laboratory applications.

April 4, 2013

Available in sizes from 1 x 1 ft to 3 x 6 ft, precision-grade (PG) optical breadboards feature constrained layer modal damping that minimizes torsional and bending modes. Sealed mounting aids containment and clean-up of spills or retrieval of small objects, while 3/16-inch steel triple-core interface honeycomb design helps reduce weight while promoting stiffness and dynamic rigidity. At 2 or 4 in. thick, breadboards offer surface flatness of <±0.004 in. over 2 ft². Read More

Test & Measuring Instruments, Optics & Photonics

Optical Breadboards include modal damping.

March 29, 2013

Suitable for critical laboratory applications, PG Series incorporates 3/16 in. steel triple-core interface honeycomb design and constrained layer modal damping to minimize torsional and bending modes. Precision-grade units are available in sizes from 1 x 1 ft to 3 x 6 ft  with thicknesses of 2 and 4 in. and surface flatness of less than ±0.004 in. over 2 sq ft. Imperial standard models feature ¼-20 tapped holes on 1 in. grid, while metric models feature M6 tapped holes on 25 mm grid. Read More

Test & Measuring Instruments, Optics & Photonics

Solid Aluminum Breadboard has lightweight, stable design.

February 1, 2013

Available in 4 x 6 in., 6 x 6 in., 8 x 8 in., 6 x 24 in., and 6 x 36 in. sizes, SA2 Series provides stable, lightweight platform for optical components and sub-assemblies. Grid of tapped holes extends to within 0.5 in. of plate edges, while in-grid counter-bored holes and edge chamfers facilitate lifting, aligning, and integrating SA2 onto standard optical tables. While imperial standard models feature ¼-20 tapped holes on 1 in. grid, metric models feature M6 tapped holes on 25 mm grid. Read More

Test & Measuring Instruments, Optics & Photonics

Solid Aluminum Breadboards offer vertical bracket accessories.

March 7, 2011

Offering stable platform for optical components and sub-assemblies, SA2 Series comes in 6 x 24 in., 6 x 36 in., 12 x 36 in., and 24 x 36 in. sizes to afford flexibility for optical experiments. Grid of tapped holes, which extends to within 0.5 in. of plate edges, optimizes mounting surface, while in-grid counter-bored holes and deep edge chamfers facilitate lifting, alignment, and integration onto optical tables. All versions are deep black anodized, minimizing surface reflection. Read More

Material Handling & Storage, Optics & Photonics

Optical Table System accommodates overhead shelf accessory.

August 6, 2010

Designed to connect directly to SmartTable-OTS frame, OTSE Integrated Overhead Shelf features 23.5 in. deep surface and 300 lb load capacity to accommodate large instruments. Blank front panel enables use in applications that may be sensitive to electrical fields generated by power outlet strips. Available in 6, 8, and 10 ft widths, shelf can be mounted in front, center, or rear of frame and provides full 5.5 in. of assembly height adjustment. Read More

Test & Measuring Instruments, Optics & Photonics

Aluminum Breadboards are suited for OEM optical assemblies

August 24, 2009

LABasix(TM) SA2 series solid aluminum breadboards are machined from 0.5 in. thick 6061 aluminum. Standard grid of tapped holes extends to within 0.5 in. of plate edges; imperial models feature 1/4-20 tapped holes on 1 in. grid while metric models feature M6 tapped holes on 25 mm grid. Counter-bored holes and deep edge chamfers aid in lifting, aligning, and integration of unit onto standard optical tables, while anodized deep black color minimizes surface reflections. Read More

Material Handling & Storage, Optics & Photonics

Optical Table System utilizes variety of accessories.

June 9, 2009

To optimize safety, ergonomics, and space efficiency, SmartTable® OTS(TM) is available with shelving and support rails. All accessories attach directly to table frame for system mobility. Shelving products expand storage space in lab, allowing researchers to remove non-essential items from table. Functioning as bumper guard for vibration-isolated table, Hip Bar lets users lean into experiment to adjust table components. Read More

Test & Measuring Instruments, Material Handling & Storage, Mechanical Power Transmission, Optics & Photonics

X-Y Tables deliver vision system positioning solution.

April 2, 2009

OFXY open frame X-Y tables combine high resolution ceramic motors and compact TONiC(TM) encoders in design that provides 50 x 50 mm working through-aperture with sub-micron resolution positioning, better than 1 micron repeatability and 200 mm/sec scanning performance. Available models provide X and Y travel of 50, 100, and 200 mm in 3-piece design with dual precision cross-roller bearings for max load and high stiffness. Standard range includes integrated end-of-travel limit and datum switches. Read More

Test & Measuring Instruments, Material Handling & Storage, Optics & Photonics

Vibration-Damping Breadboards suit OEM applications.

June 6, 2007

Available in 4 standard configurations, breadboards provide flat, stable surface for mounting or assembling lasers/small optical systems, prototyping, and precise inspections. Each configuration features natural frequency, nominal broadband damping and flatness of ±0.004 in. over 24 x 24 in. area. Depending on series, nonmagnetic and ferromagnetic products feature extruded aluminum or honeycomb structural cores and anodized aluminum or stainless steel skins. Read More

Test & Measuring Instruments, Optics & Photonics, Materials & Material Processing

Solderless Breadboard can be repaired in-field.

April 5, 2006

Sized for standard .012-.031 in. contact pins, PRO 555 Solderless Breadboard contains 2 side-by-side zones of 5 contacts by 43 rows for IC's and components, plus 5 lines of 5 x 5 contacts for power and grounding. Clear polycarbonate rear plate allows easy view of contacts. Board has 25,000 cycle contact life. Designed to work with standard and sheathed banana plugs, 5 binding posts facilitate user power, ground, and signal connections. Read More

Optics & Photonics

Optical Tables offer nonmagnetic option.

July 26, 2005

Constructed of stainless steel or aluminum, Nonmagnetic Optical Tables are suited for applications where magnetic field could receive interference from ferrous tabletop. Featuring epoxy-bonded honeycomb core, tabletops include SPILLPRUF(TM) design, whereby entire rows of mounting holes are sealed to protect core from accidental spills. Standard sizes range up to 6 x 20 ft with thicknesses from 8-36 in. All offer broadband damping and are Class 100 cleanroom compatible. Read More

Laboratory and Research Supplies & Equipment, Optics & Photonics

Optical Tables suit typical lab applications.

March 16, 2005

Vibration-damping Series 5100H is available in sizes up to 6 x 20 ft with thicknesses to 36 in. Tables offer stiff, highly damped surface with 270 Hz natural frequency, core shear modulus of 225,000 psi, and overall flatness of ±0.005 in. They feature 3/16 in. ferromagnetic stainless steel top skin, 3/16 in. carbon steel bottom skin, and steel honeycomb SPILLPRUF(TM) core design that seals rows of mounting holes, protecting core from accidental spills. Read More

Optics & Photonics

Optical Table offers tuned and broadband dampening.

July 6, 2004

Designed for precision laboratory applications in optics field, Class 100 Cleanroom compatible 5100T Series offers flat, stiff, surface. Tabletops, available in lengths to 20 ft, widths to 6 ft, and thicknesses to 36 in., have ferromagnetic stainless steel top skin and carbon steel bottom skin. Epoxy-bonded steel honeycomb SPILLPRUF(TM) core design seals entire rows of mounting holes, protecting core from accidental spills and facilitating cleanup. Read More

Optics & Photonics

Optical Tables are spill-proof.

April 9, 2004

CleanTop(TM) II Optical Tables feature damped, formed steel sidewalls for structural integrity; steel honeycomb core for rigidity; and small core cell size for stiffness and stability. Various sizes, thicknesses, and hole patterns are available to support lasers. Read More

Optics & Photonics

Optical Tables offer broadband dampening.

April 5, 2004

Vibration-damping Optical Tables provide flat, stiff surfaces with high natural frequencies. All tables offer broadband damping and are Class 100 Cleanroom compatible. Standard tabletops have ferromagnetic stainless steel top skin, carbon steel bottom skin, and proprietary epoxy-bonded steel honeycomb core with proprietary SPILLPRUF(TM) design. Offered in sizes to 6 x 20 ft, products range in thickness from 8-36 in. Read More

Test & Measuring Instruments, Material Handling & Storage, Plant Furnishings & Accessories, Optics & Photonics

Work Surfaces provide vibration isolation.

December 4, 2003

Tabletops, benchtops, platforms, and breadboards with MaxxAlign(TM) design feature mounting holes tapped at ½ in. intervals in rows 1 in. apart, with ¼-20 or M6 threads. Breadboards and BenchMates are portable units. Compact personal workstations, suited for small labs and other tight spaces, accommodate loads to 440 lb. Midrange models provide spacious work surfaces and control loads to 2,000 lb, while heavy-load models accommodate loads over 20,000 lb. Read More

Plant Furnishings & Accessories, Optics & Photonics

Optical Tables range in size up to 6 x 16 ft.

May 6, 2002

Optical Tables provide flat, stiff, highly damped surface with high natural frequency. OPTIPLANE(TM) table is designed for critical research applications; LABPLANE(TM) suits precision laboratory procedures; VALUPLANE(TM) is for nominal to low vibration applications; and ECONOPLANE(TM) is for minimal vibration environments and has thin top skin. Tabletops have honeycomb core and sealed mounting holes to protect core from spills. Read More

Test & Measuring Instruments, Optics & Photonics

Lightweight Breadboards provide flat, stable surfaces.

January 29, 2002

Vibralite breadboards are available for prototyping, small optical systems, mounting lasers, optical assembly, and inspection areas. Nonmagnetic Series 5500 has structural core of extruded aluminum surrounded by 3/16 in. anodized aluminum skin. Ferromagnetic Series 5600 has extruded aluminum core surrounded by 1/8 in. skin of SS. Honeycomb-core Series 5700 is made of corrosion-resistant, plated-steel hexagonal cells beneath 3/16 in. ferromagnetic SS top skin. Series 5800 has slightly thinner skin. Series 6100 has ferromagnetic SS skin covering aluminum core. Read More
