B & K Precision Corp.
Yorba Linda, CA 92887
Oct 01, 2004 Synthesized Bench In-Circuit LCR/ESR Meter, Model 889A, utilizes standard 115 Vac outlet as power source to test components with basic accuracy of 0.1%. It provides dc/ac voltage and current measurements as well as diode/audible continuity checks. Utilizing front panel-mounted BNC connectors and test leads, user can test variety of components such as inductors, capacitors, and resistors. Dual display permits simultaneous measurements.

Power Measurement
Saanichton, BC V8M2A5  Canada
Sep 10, 2004 Providing 1,024 samples/cycle, panel-mount ION® 7550 and ION® 7650 energy and power quality meters monitor key distribution points and sensitive loads. Onboard memory allows devices to store waveforms, event records, and load trend data. ANSI optical port provides secure access to billing data or historical event records from front panel. Both meters feature setpoint alarming and control, on-board analog and digital I/O, and high-visibility display.

Agilent Technologies, Inc.
Palo Alto, CA 94303
Jun 09, 2004 P-Series offers measurement frequency range up to 40 GHZ and backward compatibility with Agilent 8480 and E-Series power sensors. Maximum sampling rate of 100 Msamples/sec and video bandwidth of 30 MHz enables engineers to capture single shot events and perform repeatable peak power measurements. Continuous sampling capability means that multiple measurements of peak power and rise time of DUT, under same conditions, provide identical results.

B & K Precision Corp.
Placentia, CA 92870
Apr 27, 2004 Model 325 True RMS AC/DC Clamp Meter provides non-invasive measurements up to 400 kW, 400 Aac, 600 Vac, and 600 Vdc utilizing pair of standard test leads. It measures up to 4,000 ohms of resistance and 40 ohms of audible continuity. Portable, battery-powered unit includes front-panel 3¾ digit LCD display, max jaw opening of 1.41 in., automatic range selection, over-range and low battery indicators, and automatic power-off after 30 min.

Electro Industries/Gaugetech
Westbury, NY 11590
Aug 11, 2003 Nexus 1252 performs flicker analysis, which can be damaging to equipment and humans. It provides interharmonic analysis, with logging and monitoring for short- and long-term evaluation. Incorporating DNP 3.0 protocol, unit maps up to 136 measurements to DNP Static points. Up to 16 relays and 8 resets are controlled through DNP. Meter offers high-speed transient recording, fault recording, and voltage surge and sag recording at up to 512 samples/cycle.

Yokogawa Corp. Of America
Newnan, GA 30265 1040
May 21, 2003 Portable Models CW120 and CW121 measure up to 3P3W and 3P4W, respectively. They offer large backlit LCD display and measure V, A, W, VAR, PF, Hz, WH, and VARH. Memory is compatible with 128 MB compact flash memory cards. Sample rates include 1–30 sec, 1–30 min, and 1 hr. Parameter setting software for PC is included. External current clamps are available in 50, 200, 500, 700, and 1000–3000 A.

Square D Co.
Palatine, IL 60067
Apr 23, 2003 POWERLOGIC® Power Meter 800 allows user to view current or voltage of all 3 phases, plus neutral at one time. Logging functions capture power equipment data using 80–800 k memory. Combining data collection capabilities with firmware, PM800 can automatically forecast power usage. Users can access information such as real time trend plots, averages, and demand metering so that power control, load curtailments, and load preservation programs can be developed.

Power Measurement Ltd.
Saanichton, BC V8M 2A5  Canada
Mar 26, 2003 ION 6200â„¢ panel-mount meter, when equipped with Megawatt option, can measure electricity in megawatt/kilovolt range and offers solution for utility-management applications such as energy-cost tracking, load profiling, and substation panel metering. Bright LED display allows readability in adverse lighting conditions. Unit provides 4-quadrant power, demand, energy, power factor, and frequency measurements.

Electro Industries/Gaugetech
Westbury, NY 11590
Feb 07, 2003 With digital sampling architecture, SBM100 and SBM300 are suited for sub-metering and cost allocation applications. Standard Modbus Protocol via RS485 (up to 32 units daisy chained) or KYZ energy pulses simplify data acquisition and control. Housed in NEMA 4 outdoor rated enclosure, units interface with Energy Management Systems and Building Automation Systems. They mount to any surface and wire to existing or new circuits.

Absolute Process Instruments Inc.
Libertyville, IL 60048
Dec 27, 2002 Model A 210 measures current; voltage; active, reactive, and apparent power; power factor; frequency; neutral current; and active and reactive energy in 3-phase systems. Equipped with triple LED display, unit offers 2 digital outputs that can be used for pulse output to energy meters. Optional MODBUS RS485/RS232 communications and datalogging modules can be snapped onto back of instrument. Inputs, outputs, and power supply are electrically isolated.

TEGAM, Inc.
Geneva, OH 44041
Nov 01, 2002 Model 1804 Single Type IV RF Power Meter is designed for use with bolometer elements and external DVM to measure high frequency or microwave power. Substituted DC power levels ranging from 10 mW to 30 mW can be measured to within ±0.003%. Front panel switch selects operating resistance for power meter. Bolometer current meter and fault LED indicator illuminates under any condition preventing loop balance. Power meter is designed to bias either 100 or 200 ohm mounts.

Square D Co.
Palatine, IL 60067
Apr 17, 2002 POWERLOGIC(R) 480V monitors 240 to 480 V applications and allows commercial contractors and building managers to decide how to charge tenants based on real-time energy consumption. It is suitable for commercial and industrial submetering projects, including residential and commercial multi-tenant facilities. Palm OS interface and kYZ pulse output contact provide control systems and building automation systems with kWhr pulses.

Brunelle Instruments Inc.
Saint Elie D'Orford Quebec J0B 2SO, CD   Canada
Mar 26, 2002 Hand-held Model 2606 offers measuring ranges of 0 to 1000 amps Ac/Dc, 0 to 1000 Vdc, 0 to 750 Vac (True RMS), resistance from 0 to 40 MOhm, capacitance range of 4 nF to 40 uF, and frequency from 100 Hz to 400 KHz. It also provides Continuity Test and Diode Test. 4000-count instrument, with impact-resistant case and electronic overload protection, is suited for use in field servicing, industrial maintenance, heating/refrigeration and power utilities.

GMC Instruments, Inc.
Lake Zurich, IL 60047
Nov 08, 2001 A2000 Electric Power Meter, available with PROFIBUS DP, measures all variables in 3-phase power systems, such as voltage, current, frequency, active/reactive/apparent power as well as power factor and active/reactive energy. Up to 4 parameters are displayed on its 0.55 in. red LED, and up to 4 analog current, as well as 2 pulse outputs, are freely selectable. Up to 10 variables are monitored with adjustable set points and two relay alarm outputs.
