Mounting & Attaching Products

Mounting & Attaching Products, Electronic Components & Devices, Electrical Equipment & Systems

DDR4 DIMM Connector offers press-fit mounting.

November 27, 2015

Measuring 6.50 x 21.3 x 141 mm with 2.4 mm max module seating plane, Model FCN-074B288-G/0P conserves PCB space while optimizing airflow. Unit's 2.35 mm contacts accommodate 1.8 mm thick substrates. Dual-contact structure provides contact reliability with inserted memory module using 2 contacts points per pad. Design resists dust, flux, and vibration to eliminate intermittent signal loss. Operating from -55 to +85°C, connector has current rating of 0.75 A and voltage rating of 29 Vac/Vdc. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

MIMO Sector Antennas offer true 180-degree coverage.

November 25, 2015

Consisting of 180° dual-band MIMO sector antenna, Model HG2458-13P-180 combines high-gain and dual-band support for applications in 2.4 GHz and 5 GHz frequency bands. Model HG5813DP-180, a 180° dual-polarized MIMO sector antenna, delivers high-gain with vertical and horizontal polarization for applications in 4.9–5.8 GHz frequency bands. Both feature heavy-duty UV-resistant plastic radomes for all-weather operation, and dual-feed system via 2 integral N-Female connectors. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

Hybrid Lever Connectors withstand harsh environments.

November 23, 2015

Featuring heavy-duty, environmentally sealed design, AMPSEAL 16 Connectors stand up to harsh conditions of agricultural, construction, trucking, marine, and off-highway industries. Units are 28-position connectors that feature mix of 24 size 16 contacts and 4 size 12 contacts. Connectors incorporate lever slide mechanism for mating and use mounting clips for quick, tool-less mounting. To help prevent mismating, two keying options are available. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

Wireless Device provides secure cellular remote connectivity.

November 20, 2015

TC mGuard devices leverage cellular networks to provide secure remote communications wherever wired connection is not possible. For remote maintenance and support, connection through mGuard Secure Cloud service provides access to service their equipment remotely. Combination of cellular networks and VPN ensures secure solution for remote maintenance and support. For secure SCADA, features include active firewall, VPN technology, network redundancy, and multiple carrier support. Read More

Material Handling & Storage, Fasteners & Hardware, Mounting & Attaching Products, Plant Furnishings & Accessories

Cam Roller Carriages accommodate cam roller guide rails.

November 18, 2015

GN 2424 aluminum or steel cam roller carriages for GN 2422 cam roller guide rails are available in metric sizes. Used in building roller guide systems, RoHS-compliant carriages are used in mechanical engineering or jigmaking for linear movement of plant equipment. Cam roller carriage, depending on type, allows mounted in axial or radial direction to roller axes. Similarly dependent, matching wipers are mounted; type N features additional sealing lips in longitudinal direction. Read More

Mounting & Attaching Products

Objective Positioners can be screwed on machine or rail.

November 18, 2015

Designed as to not shorten distance between lens and sample, MIPOS 140 OEM has open loop travel range of 140 microns and 100 microns in closed loop operation. Resolution reaches sub-nanometer range, position of optical system remains unchanged after installation, and focal point continues to be at desired adjusted position. With travel range of 250 microns in open loop operation and 200 microns in closed loop, MIPOS 250 SG has flat design and is constructed to screw into flat surface. Read More

Mounting & Attaching Products, Electrical Equipment & Systems, Electronic Components & Devices

Horizontal Hi-Rel Connectors reduce PCB stacking height to 5.6 mm.

November 17, 2015

Fostering space conservation, Gecko G125 series includes 1.25 mm pitch connectors that are available in 8 standard positions: 6, 10, 12, 16, 20, 26, 34, and 50. Products facilitate mother and daughter board configuration, handle 2 A per contact, and function from -65 to +150°C and under extreme vibration (Z axis 100 g, 6 m/s). While polarization points prevent mismating, mechanical hold-down latching system promotes connection security. Optional latches aid de-latching. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

GPS/Multiband Vehicle-Mount Antenna offers magnetic mounting.

November 16, 2015

Panther series GPSMB501 consists of 5 connectors to access 5 antenna solutions: 2 MIMO cellular, 2 dual-band MIMO WLAN, and one global navigation satellite system (GPS plus Glonass). For signal clarity, antenna delivers >40 dB isolation across Wi-Fi® to Wi-Fi ports and >15 dB isolation from LTE-to-LTE ports with VSWR of <1.5:1 in LTE bands and 1.4:1 in Wi-Fi bands. GPS LNA is filtered for out-of-band rejection of >55 dB at 1,710 and 2,170 MHz bands and >75 dB at 824 and 960 MHz bands. Read More

Fluid & Gas Flow Equipment, Mounting & Attaching Products

Swivel Fitting enables precision blow off.

November 12, 2015

Offering 50° total angle of adjustment, Model 9204 1 MNPT x 1 FNPT Swivel enables Super Air Nozzles to be precisely adjusted to best position for maximum effectiveness. Unit is made of 303 stainless steel and can be used with 316 stainless steel and zinc/aluminum alloy nozzles. Swivel can help make nozzles more effective when replacing existing wasteful nozzles or open tubes and are suitable for blowoff, cooling, and drying applications. Read More

Mechanical Power Transmission, Controls & Controllers, Mounting & Attaching Products

Servomotor System offers simplified, modular programming.

November 11, 2015

Available in standard servo and hybrid versions, Class 6 EtherNet/IP™ SmartMotor™ integrates as Position Controller device for access to SmartMotor commands and parameters. Design maximizes uptime and optional redundant cabling through Device Level Ring (DLR) and offers simplified, modular programming through Add On Instructions (AOI). Along with additional AOI for use with Allen Bradley PLC, features include onboard dual-port Ethernet switch and fieldbus communication. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

Dual-Band 4x4 MIMO Omni-Directional Antenna has outdoor design.

November 10, 2015

Developed to work seamlessly with dual-band multiple-output (MIMO) access points, HyperLink® HG245806U-4-series features 4 separate 3 ft antennas leads and compact, unobtrusive, UV-resistant radome. Each dual-band lead operates on 2.4 and 5.8 GHz frequencies, allowing radio to select optimal frequency for obtaining highest data rates. Supporting IEEE 802.11ac standard as well as existing 802.11a/b/g/n standards, antenna is also available with RP-TNC plug or RP-SMA plug connectors. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

USB-C Connectors support Thunderbolt 3.

November 9, 2015

Featuring compact design that is suitable for laptops and mobile devices, Reversible USB-C Connectors can carry up to 10 Gbps of data with USB 3.1 or up to 40 Gbps with Thunderbolt 3. Devices also support DisplayPort 1.2 and can carry up to 100 W for charging full-size electronics. In addition, connectors are backwards compatible with USB 3.0 and USB 2.0. Read More

Architectural and Civil Engineering Products, Mounting & Attaching Products

Trim Plate increases medical gas outlet reliability.

November 5, 2015

Supporting up to 15 lb, Series B Outlet Hook Trim Plate takes unnecessary loads off medical gas outlets and equipment to help ensure consistent delivery of gas. Retractable hook design simplifies set-up without damaging equipment or medical gas outlet. Biomaster bacterial and mold growth reduction additive ensures protection for lifetime of product, which can be installed with any Series B or similar medical gas outlet in new construction facilities or used to replace existing dress frames. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

Transparent Connector integrates LED for troubleshooting.

November 4, 2015

DEUTSCH DT Detector connector provides visual confirmation of power by producing glow via integrated 12 or 24 V LED to facilitate troubleshooting in areas with difficult connector visibility/accessibility. Two-way plug has transparent housing and yellow or red wedgelock. Respectively available with and without end caps, DT06-2S-SDT-CE27 and -CE28 accept size 16 DEUTSCH contacts (13 A), feature environmentally sealed design, and are compatible with PWM control. Read More

Mounting & Attaching Products, Electrical Equipment & Systems

Omni-Directional Antenna suits in-building wireless networks.

November 3, 2015

With PIM rating of less than -150 dBc and coverage from 700–2,700 MHz, HyperLink® HG72705CUPR-NF supports cellular 4G/LTE, Personal Communication Services, and Wi-Fi 802.11b/g wireless networks. Unit can be mounted through single 11/16 in. hole in solid or suspended ceiling that is up to 1 in. thick. Antenna features single 15.7 in. coax lead terminated with N-Female connector. Single-feed system is achieved through use of internal combiner. Read More

Electrical Equipment & Systems, Controls & Controllers, Mounting & Attaching Products

Migration Platform updates legacy DCS systems.

October 28, 2015

Available for all legacy Honeywell IPC-620 DCS systems, Universal Conversion/Migration Platform permits existing field wiring to remain in place and undisturbed on front panel adapter, eliminating need to wire-trace or ring-out. System includes 2 versions of card adapter, 12- and 22-points, with connecting cable of either flying leads or pre-wired field connectors. All components are plug-and-play with keyed connectors to eliminate wiring errors. Cables are RoHS and FT4 rated at 300 V. Read More

Fasteners & Hardware, Mounting & Attaching Products

Hitch Adapter accepts Cat I attachments.

October 26, 2015

With Quick Hitch Adapter, operators can use Cat I non-PTO powered implements on skid steers. Hitch features lower hooks designed to capture and retain 7/8 in. lift pins without use of bushings, adjustable top hook for attaching to implements of varying heights, and floating top link bracket for implements that will not accept top link hook. Adapter is suitable for mounting box scrapers, landscape rakes, 3-pt blades, harrows, soil pulverizers, and single shank rippers. Read More

Mounting & Attaching Products, Electronic Components & Devices

USB 3.1 Type C Plugs and Sockets help shrink PCB footprints.

October 14, 2015

With bi-directional power capability and support for USB-1 standards with 10 Gbps top speed and up to 20 V (100 W), 3 A output, USB 3.1 Type C interconnects help accelerate data transfer, increase power transmission, and minimize PCB footprints. For circuit board socket use, USB-C receptacle (Cat No. 953) offers hybrid mount configuration. For standard or custom USB-C cable assemblies, Type C plug kit (Cat No. 954), supplied unassembled with metal housing, ensures strain relief. Read More

Mounting & Attaching Products, Electronic Components & Devices

Compression Connector offers 28+ Gbps transmission speed.

October 13, 2015

With 1.22 mm profile, IT11 Series single-mold compression connector provides second source for cStack™ and cLGA® products from Amphenol Intercon Systems. Signal integrity is optimized with 6 x 25 pin grid configuration, and standard 150- and 210-position versions have respective contact pitches of 1 and 1.27 mm. Custom positions are also available with pin counts up to 3,000+. Design uses C-shaped spring contacts with self-aligning centering feature and pin tips contained in housing. Read More

Material Handling & Storage, Mounting & Attaching Products, Mechanical Power Transmission

Support and Actuator System works in ultra-high vacuum conditions.

October 12, 2015

Optimized for load capacity and stiffness, mechanical systems employ strut-based mounting system that minimizes vibration and allows facilitated and precise (sub millimeter) position adjustment of hardware without adding stress or distortion. Strut mechanical positioner has up to 6 degrees of freedom: translational (X/Y/Z) and angular (pitch, roll, and yaw). While smallest design supports 200 lb, 6 struts provide solid (seismically adequate) support in all models. Read More
