Pulleys & Sheaves

Mechanical Power Transmission

Steel Pulley extends belt life and decreases noise.

June 9, 2014

Suited for conveyor owners requiring increased material handling operation performance and uptime, AR Chevron® Pulley comes in Mine Duty and Super Duty models available in 10–42 in. dia and face widths from 12–75 in. V-shaped wing pulley deflects fugitive material, extending life expectancy and protecting conveyor belts against punctures, while continuous pulley contact with conveyor belting reduces beating action caused by pulley wings and decreases noise by 50 dB. Read More

Controls & Controllers, Mechanical Power Transmission

Conveyor Pulleys withstand tough operating conditions.

May 23, 2014

Available in Heavy Duty, Mine Duty, and Mine Duty Extra (MDX) construction, Dodge Conveyor Pulleys with XT Hubs and Bushings come in both drum and wing designs. MDX conveyor pulleys feature thick end discs to power through tough operating conditions. In addition to elevator drum and single disc XT conveyor pulleys for grain handling applications, complete pulley offering also includes variety of vulcanized rubber lagging options. Read More

Material Handling & Storage, Chemical Processing & Waste Management, Mechanical Power Transmission, Fasteners & Hardware

Cast Nylon Shapes offer lighter alternative to metal parts.

March 25, 2014

Manufactured in ISO 9001:2008 facility, TECAST® Cast Nylon Stock Shapes and Custom Parts are available in variety of grades, each of which highlights various aspects and combinations of mechanical properties, as well as optimized bearing and wear characteristics. Products include rings up to 90 in. in diameter, rods in diameters up to 20 in., and discs in diameters over 40 in. Typical applications include sheaves, wear pads, bushings, bearings, gears, rollers, pulleys, and conveyor wheels. Read More

Mechanical Power Transmission

Elevator Pulleys meet CEMA standards.

November 18, 2013

Available in diameters from 6–72 in. with face widths up to 120 in., Dodge® Elevator Pulleys come in drum or single disc design with HE, XT, QD, or Taper-Lock hubs and bushings. Units meet CEMA standards, but are also available with Mine Duty Extra construction for strength and durability. Four lagging options are available, offering features such as bi-directional pulley rotation, flame and oil resistance, abrasion resistance, and various grooving options. Read More

Mechanical Power Transmission

Conveyor Pulleys feature wear-resistant rubber compound.

August 22, 2013

By increasing lagging life, Dodge® D-LAG conveyor pulleys extend operating life of conveyor pulley and conveyor belt. Lagging is 100% vulcanized for pulley bonding and strength, making it resistant to cuts and gouges. Available styles include D-LAG heavy-duty drum pulleys from 10–24 in. dia that are designed with flexible end discs, and D-LAG MDX® (mine duty extra) drum pulleys from 12–24 in. dia which feature integral hub design that eliminates welded hub. Read More

Electrical Equipment & Systems, Mechanical Power Transmission

Power Distribution Blocks accept up to 16 inputs.

October 18, 2011

As part of combiner box, Distribution Blocks deliver output up to 1 AWG/130 A, offering solution for both power distribution and collection. DIN rail mounted units can also offer method for UL approved ground wire collection. Available in complete range of configurations and colors, outlet boxes provide power source in control cabinet for laptops, test equipment, and lighting. Read More

Mechanical Power Transmission

Timing Belt Pulleys are suited for miniature applications.

July 8, 2011

Offered in 17 sizes with 18-75 grooves, metric A 6A18M... Series is designed for 3 and 6 mm wide belts. Standardized 1 mm pitch, clear anodized, aluminum alloy pulleys are offered with double flange and no flange options, pitch diameters from 5.73-23.87 mm, and bore sizes from 2-5 mm. While models with 18-45 grooves have one set screw, others have 2 at 90°. Products suit those attempting to miniaturize product designs for prototype or production application. Read More

Mechanical Power Transmission

Wing Pulleys are available in CEMA-rated style.

April 15, 2011

Chevron wing pulleys are rated for CEMA construction applications, which are often light-duty, portable conveyors that make infrequent starts and stops. Units have V-shape construction to deflect material and prevent it from lodging, maximizing pulley life and minimizing belt damage. They are available with diameters from 10-20 in. and face widths from 20-63 in., and in Mine Duty and Super Duty styles with diameters from 12-48 in. and face widths from 12-78 in. Read More

Material Handling & Storage, Electrical Equipment & Systems, Mechanical Power Transmission

Cable Feeding Sheaves feed utility cable into conduit.

March 9, 2011

With Cable Feeding Sheaves, utility cable can be smoothly fed into conduits and innerducts from any angle. Steel units accommodate 2-6 in. Schedule 40 and Schedule 80 ducts and feature half-circle, split-tube design that facilitates insertion and removal. Available in aluminum alloy or wear-resistant Nylatron®, sheave rollers utilize maintenance-free, self-lubricating bearings. Sheaves are bright yellow for visibility in dark work environments. Read More

Mechanical Power Transmission

Pulleys and Belts offer multiple design options.

November 18, 2010

HTD pulleys and belts include timing pulleys, starting at 5 mm pitch to suit 9, 15, and 25 mm wide belts, available with pilot or taper bore. Different versions are available depending on number of teeth required. Standard pitches also include 8 and 14 mm, which suit belts to 85 mm. Depending on size, pulleys are steel with zinc-plated steel flanges or cast iron, and belts are glass fiber reinforced, rubber back/teeth with nylon fabric tooth facing to DIN/ISO 5296. Read More

Mechanical Power Transmission

Pulleys and Belts suit power transmission applications.

October 20, 2010

Available with pitch from 2.5-10 mm, T Type Pulleys are made of aluminum with zinc-plated steel flanges and are either center-drilled or pilot-bored. Synchronous timing belts that accompany pulleys range in width from 6-32 mm and are double sided with Aramid tension members. Special polyurethanes, anti-static, machined, ground, and punched belt options are available. Read More

Safety & Security Equipment, Mechanical Components & Assemblies, Mechanical Power Transmission

Hand Line Utility Blocks feature fiberglass construction.

May 24, 2010

Weighing just over 1.5 lb each, Campbell® hand line blocks afford utility personnel accelerated means of getting down from working heights. Fiberglass construction gives products working load limit of half ton with 3:1 design factor. To further accelerate process of getting lines up and workers down, product features smooth rolling, permanently lubricated, 3 in. sheave that can run up to 5/8 in. rope. Read More

Mechanical Power Transmission

Timing Belt Drive has sag-resistant, one-piece design.

April 14, 2010

Offering smooth linear motion in positioning and indexing applications, AZ1040 features one-piece aluminum profile extrusion which serves as belt housing. T-slots and receiver grooves for load carriage guide bars are incorporated into the profile design, and load carriage measures 7.4 x 6.3 in. Depending on payload weight, max travel speed is 16.4 fps. Repeatability is rated at ±0.008 in. over travel spans of up to 6.5 ft. Read More

Mechanical Power Transmission

Pulleys/Belts are suited for small precision instruments.

July 7, 2009

Suited for used with 50-1,000 W motors, depending on size of pulley/belt chosen, synchronous belt drives and pulleys are available from 1.5-3 mm pitch with belt widths of 3-9 mm as standard. Pulleys are zero backlash and belts in sizes 1.5-2 mm are offered with special coating, which ensures low particle generation and that rubber powder is not spread. Bore and keyway modifications are also available, while specials can be manufactured to order. Read More

Material Handling & Storage, Mechanical Power Transmission, Non-Industrial Products

V-Blocks are designed for 14 in. cutting saws.

April 14, 2009

Metal Devil® V-BLOCKS improve cutting performance on 14 in. saws by strengthening clamping performance of the saws vice system by securely holding round, square, and rectangular materials in durable steel body. Several vice configurations can be used to optimize cutting results on variety of structural materials. V-BLOCKS promote blade life mitigate saw damage. Read More

Mechanical Power Transmission

Timing Belt Drives come in inch and metric versions.

July 11, 2008

Comprised of 162 pulleys, QPMAT10 (metric) and QPEAT10 (inch) Series are made from 2024-T4 or 2024-T351 Aluminum Alloy or AISI 1045 Steel. All series offer double flange and flangeless types, with and without set screws for fastening to shafts. They are designed to fit inch shafts from .3750-.7500 in. and metric shafts from 8-16 mm. Made from nylon covered fiberglass reinforced neoprene, series of 22 AT10 timing belts are stocked in pitch lengths from 500-4,030 mm with 50-403 teeth. Read More

Mechanical Power Transmission

Timing Pulleys feature configurable hub assortment.

April 24, 2008

Available in wide variety of materials/sizes, including high-torque versions, timing pulleys suit virtually any shaft hole and flange requirement. Dimensions for shaft hole and overall hub diameter are configurable in increments of 1 mm, while hub shoulder height is configurable in increments of 0.5 mm. Offered in several aluminum grades with clear anodize, electroless nickel plating, or hard anodized surface treatment, 1045 carbon steel and low carbon steel versions are also available. Read More

Mechanical Power Transmission

Timing Belt Drives accommodate narrow belts.

January 17, 2008

Self-guiding Conidrive(TM) timing belt drives feature N10 belt and pulley system which has offset conical projection profile on bearing surface. With symmetrical cone geometry and balanced tension member arrangement, drives minimize noise and vibration plus offer homogenous distribution of forces in belt. Nondirectional 10 mm pitch belts have same meshing performance in both directions of belt travel. They are manufactured with polyurethane and are reinforced with steel tensile cords. Read More

Mechanical Power Transmission, Optics & Photonics

Stopper Blocks and Brackets suit machine and assembly builds.

October 12, 2007

Featuring compact counterbore design for flush fitting in tight spaces, compact-style stopper blocks offer configurable heights from 3-20 mm in 1 mm increments. Products are available in 304 low-carbon steel with black oxide or electroless nickel plating as well as 304 stainless steel. Also available, compact stopper brackets come in hex or bolt styles and are are likewise offered in low-carbon steel with black oxide or EN plating as well as 304 stainless steel. Read More

Mechanical Power Transmission

Timing Belt Drives have self-guiding design.

May 8, 2007

Conidrive(TM) self-guiding timing belt drives feature N10 belt and pulley system, which offers offset conical projection profile on bearing surface to ensure positive fit. Made from polyurethane and reinforced with steel tensile cords, nondirectional 10 mm pitch belts come in double- and triple-row configurations and feature polygon-free construction. Conidrive pulleys come in 1-, 2- and 3-row types, featuring nonchordal action. They incorporate Fairloc® integral nonmarring shaft hubs. Read More
