AMETEK Technical & Industrial Products    Kent, OH 44240
Oct 11, 2007 Delivering open loop control, MAE® Motors offer holding torques from 12-2,018 oz-in., depending on model. HY Series comes in NEMA Sizes 16, 17, 23, and 42 with low rotor inertia, while Size 34 HN Series offers calculated balance between low rotor inertia and high torque. Available in Sizes 17, 23, and 34, HS Series exhibits optimal torque characteristics. All deliver step resolutions of 1.8º in full-step mode, and incorporate precision-honed stators and ground rotors.

Danaher Motion/Portescap    Radford, VA 24141
Oct 10, 2007 Suited for space-constrained medical and automation applications, nuvoDisc(TM) flat brushless dc miniature motors feature 11.7 x 32 mm dia footprint. Offering speeds of up to 50,000 rpm and mechanical power output of up to 30 W, motors provide high-speed slotless design that reduces vibration and eliminates cogging to provide smooth operation. Low power consuming units are also available in slotted design for applications that require detent torque.

Haydon Switch & Instrument, Inc.    Waterbury, CT 06705 3910
Sep 28, 2007 Available in wide variety of resolutions ranging from .0158 to .127 mm per step, 35000 Series (Size 14) double stack hybrid linear actuators deliver thrust voluntarily limited to 222 N. They come in captive, non-captive, and external linear versions, and can be micro stepped for finer resolution. Applications include medical equipment, semiconductor handling, valve control, X-Y tables, hand held instruments, and telecommunications.

White Hydraulics, Inc.    Hopkinsville, KY 42241 1127
Sep 21, 2007 WS series is designed with 3-zone commutator valve for optimal flow capacity, heavy-duty tapered roller bearings for handling side loads, and drive link sizable enough to help motors withstand pressure and torque spikes. Along with 9 displacements from 6.1-30.3 in.³/revolution, series is available with 9 shaft options, 7 mounting options, and variety of porting options. Motors are rated for continuous flow rates to 20 gpm, torque to 7,295 lb-in., and pressures to 3,000 psi.

Sevcon, Inc.    Burlington, MA 01803
Sep 18, 2007 Combining fly-by-wire electronic controller, brushless DC motor, and 2-stage planetary gearbox, Integrated Motor Control covers operating voltages from 24-48 Vdc, provides 35-235 Nm peak torque, and uses CANopen communications protocol. Gearbox uses straight and helical gears and is fully greased for quiet operation. Measuring 7.3 x 3.2 x 5.4 in., control can open and close hoppers, valves, and other equipment; steer AGVs, fork trucks, and powerboats; and raise and lower antennas.

MicroMo Electronics, Inc.    Clearwater, FL 33762 3008
Sep 06, 2007 Designed to facilitate work with MicroMo miniature synchronous motor, Microsystems Starter Kit contains drive electronics, adaptor board, and motor. Adapter board has integrated oscillator for speed control, PWM frequency of 500 kHz, and direction of motor rotation is reversible. Kit accommodates DC Brushless motors series 0206...B, 0308...B, and 1202...BS/BH, which offer respective continuous torque capabilities of 0.012, 0.014, and 0.012 mNm.

Magmotor    Worcester, MA 01603
Sep 06, 2007 Featuring peak torque of 4,800 oz-in., 8 pole NEMA 42 DC motor is suited for unmanned vehicle and HEV systems, hydraulic pumps and power steering systems, packaging equipment, and other automation applications where high torque to weight ratio is needed. Variety of electrical and mechanical options are available including encoders, connectors, or sealing for IP65 wash down requirements. Custom mounting and winding configurations are also available.

AMETEK Technical & Industrial Products    Kent, OH 44240
Sep 04, 2007 PITTMAN® Series 6000(TM) 22 mm dia brush-commutated motors incorporate skewed 5-slot armature design and bonded neodymium iron boron magnets. They are available in 1.256, 1.556, and 1.901 in. lengths with 0.80, 1.3, and 2 oz-in. continuous torque, respectively, and can generate maximum peak torques up to 10.2 oz-in. Features include sintered bronze bearings, 2-pole stators, heavy-gauge steel housing, silicon steel laminations, and copper graphite brushes.

ThinGap LLC    Ventura, CA 93003
Aug 31, 2007 Based on electromotive coil technologies, NEMA 23 size Centrifugal Fan/Blower Motor provides 85 oz-in. continuous torque at 16,300 rpm, while operating at 80 V and 17.65 A, including amplifier losses. By replacing iron core and wire windings of conventional motors with precision machined copper sheet, issues such as hysteresis, cogging, and iron losses have been eliminated.

Nippon Pulse America, Inc.    Radford, VA 24141
Aug 31, 2007 Incorporating 2 models, PRO Series combines NEMA 17 integrated 42 mm hybrid stepper motor with attached microstepping drive electronics in compact, RoHS-compliant package. Precision designed for medical technologies and semiconductor manufacturing applications, hybrid stepper motors are available in case lengths of 40, 48, and 60 mm. Depending on case length, PRO Series Size 17 motor can produce maximum holding torques (bipolar) ranging from 300-440 mNm.

Quicksilver Controls    San Dimas, CA 91773
Aug 28, 2007 Suited for driving large flywheel loads without additional gearing, Model QCI-A23K-3 NEMA 23 frame motor generates 145 oz-in. continuous torque, 165 oz-in. peak torque, and 58 W peak mechanical power. It comes standard with 8,000 count/rev encoder and is available in both IP50 and IP65 (wash down) packages. When combined with servo controller/drivers, motor creates high torque servo control system for speeds up to 2,000 rpm. Unit requires single cable for encoder and motor signals.

GE Intelligent Platforms    Charlottesville, VA 22911
Aug 24, 2007 VersaMotion AC Servo Motors and Amplifiers can be combined with VersaMax Micro for low-end position control applications or used as standalone single-axis position controller for indexing or electronic gear follower applications. Flexibility of command interface and user-defined operating modes translates to variety of system architectures. While power ratings range from 100 W to 3 kW, continuous torque varies from 2.7-169 lb-in. Motor speeds up to 5,000 rpm are available.

AMETEK Specialty Motors Division    Kent, OH 44240
Aug 24, 2007 Built to meet requirements of pool and spa blower applications, Green Powered ADVANTEK Spa motors feature design elements that promote optimal energy efficiency and minimal noise output. Air diffusion design allows blower motor to be tuned to optimum output and efficiency for each specific end use, and multiple laminations for each bracket design permit optimization of motor drive. Various fan sizes are available, including 4.2, 5.1, and 5.7 in. dia.

Portescap S.A.      Switzerland
Aug 22, 2007 Offered in 2 versions, 25 mm Brushed Ironless DC Motors feature metallic front end, optional integrated EMC filter, and carbon brush commutation method. Rotational spring delivers constant force, promoting brush life and minimizing motor sensitivity to vibration shocks. While 25G version measures 53 mm long, weighs 145 g, and provides 40 W of power with 40 mNm continuous torque, 25GST version is 43 mm long, weighs 111 g, and delivers 27 W of power with 30 mNm continuous torque.

Applimotion, Inc.    Loomis, CA 95650
Aug 14, 2007 Helping reduce system height, low-profile T Series come in axial lengths as low as 25 mm with through holes up to 450 mm. Products operate from 3-phase trapezoidal or sinusoidal motor controllers, rated 12-700 Vdc, and larger diameter motors achieve speeds up to 1,000 rpm. Hall Devices and various cable/connector options are available. Among other applications, areas of use include turrets and gimbals as well as traditional direct drive rotary table systems.

ThinGap LLC    Ventura, CA 93003
Aug 09, 2007 Delivering 300 oz-in. of peak torque and 460 W continuous shaft power, Model TGB2011 minimizes parasitic drag, allowing free-swinging movement of robotic leg. Unit replaces iron core and wire windings with precision machined copper sheet, virtually eliminating hysteresis, cogging, and iron losses, while minimizing impact of eddy currents and back EMF. Technology is based on freestanding electromotive coil, stationary stator, and rotating permanent magnets.

ABB Control Inc.    Wichita Falls, TX 76302
Aug 01, 2007 Incorporating FieldBusPlug communication system, PSR Series Softstarters are available in 3 sizes with widths from 1.77-2.13 in., covering rated currents from 3-45 A, up to 600 Vac, and with control voltages of 24 Vdc or 100-240 Vac. Devices include integrated by-pass, marked front panel with knob adjustments for 3 operational settings, and marked connection terminals. Cooling fan can be attached to increase starts from 10/hr to 20 starts/hr.

Midwest Motion Products    Watertown, MN 55388
Jul 31, 2007 Accepting any 24 Vdc source including battery power, IP54-rated Model MMP TM55-24V GP52-124 measures 2.14 in. dia x 7.7 in. long with keyed output shaft of 12 mm dia x 25 mm long. Mounting is accomplished with 4 face mount M5 threaded holes, equally spaced on 40 mm dia BC. Weighing less than 4 lb, reversible gearmotor requires 3.5 A at 24 Vdc to generate full load torque and is capable of producing peak torque up to 444 lb-in.

Bodine Electric Company    Northfield, IL 60093
Jul 27, 2007 Designed for ac inverter-duty and permanent magnet dc motors, CG Gearmotor features 1.0 in. dia driveshaft and 3-stage, selectively hardened, permanently lubricated gearing cluster. Motor and gearhead are assembled as integral unit, eliminating leaks or misalignment. Solid aluminum-cast body plus heavy-duty bearings and seals ensure unit will perform in demanding applications. Because gearhead is unvented, gearmotor can be mounted in any position via extra-wide face-mounting flange.

MicroMo Electronics, Inc.    Clearwater, FL 33762 3008
Jul 26, 2007 With 3 mm external motor diameter and 8 mm length, Smoovy Series 0308...B combines skewed winding with jewel bearings and rotor made of Neodymium rare-earth magnets. Motor can achieve continuous output torque up to 0.014 mNm at speeds to 15,000 rpm. Due to electronic commutation, service life of motor is only limited by bearings. Series 0308...B can be combined with gearbox and linear actuator for complete miniature DC drive system.
