Air Amplifiers

Mechanical Power Transmission, Electronic Components & Devices

Low-Power Rail-To-Rail Amplifiers drive 12-, 14-, and 16-bit ADCs.

October 1, 2014

Intended for high-speed DAQ applications, ADA4805-1 (single) and ADA4805-2 (dual) amplifiers come in SC70, SOT23, MSOP, and LFCSP package options. Dynamic Power Scaling feature lets user dynamically manage power consumption by shutting down amplifier between analog-to-digital converter samples. Along with slew rate of 160 V/µsec, 100 MHz ADA4805-1 and ADA4805-2 offer low noise (5.9 nV/√Hz at 100 kHz) and low distortion (-102 dBc/-116 dBc HD2/HD3 at 100 kHz) while consuming 1.5 mW.
Read More

Mechanical Power Transmission, Electronic Components & Devices

Driver Amplifier delivers 21 dB gain across 6-16 GHz bandwidth.

September 29, 2014

Operating from single positive supply voltage of +5.0 V @ 95 mA, CMD158C4 delivers 21 dB of gain across its bandwidth while providing +21 dBm of saturated output power at PAE of 24%. This 6–16 GHz driver amplifier comes in Pb-free, RoHs-compliant, ceramic, 4 x 4 mm QFN SMD package and does not require any external components for operation except bypass capacitors on VDD line. Areas of use include point-to-point/-multipoint radios, VSAT, LO driver amplifiers, and military applications. Read More

Communication Systems & Equipment, Mechanical Power Transmission, Electronic Components & Devices

GaN Power Amplifier is optimized for power and linearity.

September 8, 2014

As 28–32 GHz GaN power amplifier (PA) in die form, CMD217 features >20 dB gain across operating frequency range with corresponding output 1 dB compression point of +36.7 dBm and saturated output power of +39.3 dBm (8.5 W). Power added efficiency is 28%–35% across band. This fully matched 50 Ω design requires only external bypass capacitors to complete bias circuitry. Suited for Ka-band communication systems applications, die is passivated for reliability and moisture protection. Read More

Mechanical Power Transmission, Electronic Components & Devices

Class-D Audio Amp is suited for eCall, telematics applications.

August 28, 2014

Supplied in 16-pin HTSSOP with PowerPAD package, TAS5421-Q1 automotive Class-D audio amplifier integrates 40 V load-dump and over-temperature protection and diagnostics in one device for emergency call (eCall) and instrument cluster systems. Mono-channel, analog differential input product integrates I²C diagnostics and offers quiescent current that eliminates need to use additional battery cells. Integration helps simplify automotive-grade diagnostic design and extend battery back-up power. Read More

Test & Measuring Instruments, Mechanical Power Transmission, Electronic Components & Devices

High Voltage DAQ Module promotes safe and accurate measurement.

July 11, 2014

Capable of making 1,000 V measurements and acquiring data synchronously at all times to other physical quantities, MX403B amplifier offers 4 differential, isolated channels with analog anti-aliasing filters and 24-bit ADC. Users can also apply several digital filters to acquired data. Along with 10, 100, and 1,000 V measurement ranges, features include sampling rate of 100 kS/s per channel, signal bandwidth up to 38 kHz (78 kHz in dual-channel mode), and 0.05% accuracy. Read More

Mechanical Power Transmission, Electronic Components & Devices

Operational Amplifier drives heavy loads at high output.

June 25, 2014

Delivering over 1 A output current, 40 V Model ADA4870 provides wide bandwidth of 52 MHz and slew rate of 2,500 V/µs to facilitate high-voltage pulses necessary to drive piezoelectric transducer in high-intensity focused ultrasound for medical treatment and procedures. In small-cell base stations and compact military radios, op amp assists with drive of power amplifier’s low impedance bias control to track envelope of RF signal, only using as much power for PA as needed to pass signal. Read More

Communication Systems & Equipment, Mechanical Power Transmission, Electronic Components & Devices

Distribution Amplifiers (1.2 GHz) are DOCSIS 3.1 compliant.

May 16, 2014

AC1500 distribution and A2500 distribution trunk amplifiers ensure that downstream frequency band reaches up to 1.2 GHz and upstream is upgradable to 200 MHz. Both can be equipped with Remote Ingress Switching (RIS) system that allows ingress detection and countermeasures at headend. For management feature diversity, amplifiers can also be equipped with intelligent transponders with measuring capabilities as well as programmable signal and ingress monitoring. Read More

Safety & Security Equipment, Test & Measuring Instruments, Transportation Industry Products, Vision Systems, Computer Hardware & Peripherals, Mechanical Components & Assemblies, Electrical Equipment & Systems, Sensors, Monitors & Transducers, Mechanical Power Transmission, Electronic Components & Devices, Green & Clean, Display & Presentation Equipment

Flashing Dome LED Beacon Lights suit AC or DC applications.

April 10, 2014

Offering IP23 protection and vibration resistance, Models XPE and XME provide brightly colored triple-flash sequence that illuminates at 110 flashes/min, making them suited for indoor mobile equipment. XPE model measures 162 mm dia x 203 mm tall and has high-impact, heat-resistant ABS resin body, while XME version, made of stainless steel with melamine baked finish, is 187 mm in dia x 239 mm tall. Typical current consumption ranges from 0.07 A for 230 Vac models to 0.42 A for 12 Vdc models. Read More

Communication Systems & Equipment, Mechanical Power Transmission, Electronic Components & Devices

GaAs Distributed Driver Amp offers positive gain slope, low noise.

March 28, 2014

Supplied in Pb-free, RoHs-compliant, 5 x 5 mm, SMT package, CMD192C5 wideband GaAs MMIC distributed amplifier operates from DC to 20 GHz and has positive gain slope versus frequency. This allows for cascading of multiple amplifiers without requiring extra gain compensation circuitry. Driver amplifier, which delivers >19 dB of gain with corresponding output of 1 dB compression point of +25 dBm, has 50 Ω matched design and low noise figure of 1.9 dB at 10 GHz. Read More

Communication Systems & Equipment, Mechanical Power Transmission, Electronic Components & Devices

MMIC Driver Amplifier delivers +20 dBm of output power.

March 13, 2014

Featuring frequency range of 1–24 GHz, Model CMD197 offers 16 dB of flat gain with corresponding output 1 dB compression point of greater than +20 dBm and output IP3 of greater than +30 dBm across entire bandwidth. Distributed GaAs driver amplifier includes on-chip bias choke and 50 Ω port matches. Fully passivated for moisture protection, Model CMD197 is suited for military and space applications, wideband communication systems, microwave radio, VSAT, and test instrumentation. Read More

Mechanical Power Transmission, Electronic Components & Devices

Digital Load Cell Amplifier offers configurable alarm output.

January 31, 2014

Housed in compact enclosure with digital display, MAGPOWR Load Cell Amplifier is used to multiply millivolt tension signal to usable 0–10 Vdc and 4–20 mAdc analog output. DIN rail mounted unit features one pushbutton for re-zeroing, programmable filtering of each output, and 3 pushbuttons for setup and calibration. In addition, amplifier offers weightless load cell calibration as well as automatic load cell diagnostics and fault detection. Read More

Communication Systems & Equipment, Mechanical Power Transmission, Electronic Components & Devices

TTL Amplifier meets MIL-STD-883 standard.

January 23, 2014

Featuring customizable design, 10 W Model MSH-4627908-TTL is optimized for operating frequency range of 5.2–5.8 GHz with 28 dB min of gain and 6 A max fully matched to 50 Ω. Unit provides fast blanking and is manufactured in compliance with AS9100. Available with mounting plate, amplifier is suited for test systems as well as aerospace and defense applications. Read More

Communication Systems & Equipment, Mechanical Power Transmission, Electronic Components & Devices

Line Amplifiers support DOCSIS 3.1 systems.

October 30, 2013

Available in 12 and 24 V models, Models ACA1210, ACA1212, ACA1216, ACA2431, ACA2449, and ACA2461 provide signal fidelity over extended frequencies up to 1.2 GHz. Surface mount devices deliver optimal bit error rate, composite triple beat, composite second order, cross modulation, and carrier-to-intermodulation noise characteristics in fully loaded spectrum. Series leverages GaAs MESFET process for reliability along with GaN HEMT technology for high output power and optimum power efficiency. Read More

Mechanical Power Transmission

Millimeterwave Amplifier features UHF, 2-stage design.

October 10, 2013

Enclosed within rugged, laser-welded, SMA-connectorized housing with hermetic seal, model BXHF1075 operates from -40 to +85°C and is suited for military and high-end commercial applications. This 44 GHz millimeterwave (MMW) amplifier offers stability with 13 dB of return loss while generating 30 dB of gain and +17 dBm of output power off of +15 V supply. Along with field-replaceable 2.4 mm connectors, features include internal voltage regulator to accommodate +12 or +15 V. Read More

Test & Measuring Instruments, Machinery & Machining Tools, Sensors, Monitors & Transducers, Mechanical Power Transmission, Electronic Components & Devices

Power Amplifier features slew rate greater than 900 V/µs.

June 3, 2013

Featuring all-solid-state design, Model 10/40A-HS provides output voltage of 0 to ±10 KVdc or peak AC with output current of 0 to ±40 mAdc or ±120 mA peak AC for 1 ms. Signal bandwidth ranges from DC to greater than 23 kHz. Four-quadrant, active output stage sinks or sources current into reactive or resistive loads throughout output voltage range. Configured as non-inverting amplifier with fixed gain of 1,000 V/V, product is suited for automated or computer-controlled systems. Read More

Communication Systems & Equipment, Mechanical Power Transmission, Electronic Components & Devices

High Voltage Amplifiers offer output up to 20 KV.

May 30, 2013

Available with unipolar or bipolar output at 0–10 kV, 15 kV, and 20 kV, 10HVA-20HVA Series can operate in DC, reversible, and amplifier modes. Units provide high-voltage DC to full scale waveform capability greater than 500 Hz+ output depending on loading. Amplifiers operate precision filter/divider and linear HV switch, and can both source and sink current linearly through 0 V. Performing with 25 ppm temperature coefficient, devices come standard with differential precision, 0–10 Vdc control input. Read More

Communication Systems & Equipment, Mechanical Power Transmission, Electronic Components & Devices

Distributed and Drive Amplifiers have all-positive bias scheme.

May 7, 2013

Respectively operating from DC to 30 GHz and 2–30 GHz, distributed amplifiers CMD164 and CMD165 deliver >12 dB of gain with output 1 dB compression point of +15 dBm and noise figure of 2.4 dB at 10 GHz. Operating from DC to 20 GHz, distributed amplifier CMD173 delivers >15 dB of gain with output 1 dB compression point of +18 dBm and noise figure of 2 dB at 10 GHz. Driver amplifier CMD166 operates from 20–40 GHz with 9 dB of gain and output 1 dB compression point of +17 dBm. Read More

Material Handling & Storage, Controls & Controllers, Machinery & Machining Tools, Electrical Equipment & Systems, Mechanical Power Transmission, Electronic Components & Devices

Trip Amplifiers protect hoists and cranes against overload.

April 3, 2013

Providing dual volt-free relay outputs from load cell signal, LCTA Series Load Cell Trip/Relay Amplifiers offer hoist overload protection, safe crane lifting control, and personnel lifting platform protection. Units can power single load cell or load pin, or up to four 350 Ω load cells connected in parallel. Volt-free relay outputs have trip switching current of 10 A at 230 Vac and can be adjusted independently. For remote display, amplifiers also include 0-5 V analog output. Read More

Controls & Controllers, Mechanical Power Transmission

CNCs offer predictive maintenance tools for fans and motors.

December 17, 2012

With preventative maintenance tools for motors and fans, Series 30i/31i/32i-MODEL B CNCs enable maintenance staff to pre-plan servicing of machine during scheduled downtime rather than when machine has failed. FANUC amplifiers address predictive motor failures by checking resistance of windings. By monitoring speed of each cooling fan that is in CNC and amplifier, users can estimate when fan will fail. Read More

Mechanical Power Transmission

Transconductance Amplifier enables accurate calibration.

May 10, 2012

Transconductance Amplifier 52120A expands precision calibration capabilities to power and energy meters, clamp meters, current transformers, and Rogowski coils rated up to 6,000 A. Unit supplies DC current to 100 A and AC current up to 120 A at accuracies to 140 ppm; generates 3,000 or 6,000 A when using accessory coils; and can output up to 360 A when 3 amplifiers are connected in parallel. Also, amplifier has inductive drive capability of 1 mH and compliance voltage of 4.5 V. Read More
