Gear Drives

Mechanical Power Transmission

Twin Disc Transmission excels in well stimulation.

November 20, 2014

Featuring counter shaft design, TA90-7601 Power Shift Transmission offers expected L10 life of 10,000 hours. Coaxial, 9-speed unit can be power shifted under all loaded or unloaded conditions without any throttle dipping within range-to-range shifts. Flexible coupling allows transmission to be installed on engine's dry flywheel housing, minimizing torsional excitations by engine and pump. Transmission has max gross input power rating up to 1,939 kW (2,600 hp) at 1,900 rpm. Read More

Mechanical Power Transmission

All-Wheel Drive System incorporates disconnect function.

October 15, 2014

Intended for A-, B- and C-segment vehicle platforms, Disconnect All-Wheel Drive System responds to driver inputs and road conditions by connecting and disengaging drive to rear axle to enhance traction, dynamics, stability, and on-highway fuel efficiency. Monoblock housing fully integrates propshaft's constant velocity joint. Other features include power transfer unit, electro-mechanically actuated clutch in rear axle, dedicated driveline control unit, and active torque biasing function.
Read More

Mechanical Power Transmission

Variable Ratio Transmissions dispense seed and fertilizer.

June 10, 2014

With all internal parts machined to strict and consistent tolerances, VRT Infinitely Variable Ratio Transmissions provide operating link between advanced control systems such as GPS and mechanical dispensing mechanisms used in precision seeding machinery. Seed placement accuracy is maintained even when equipment ground speed varies. Designed to operate in harsh environments, maintenance-free VRTs feature pre-lubricated drives and aluminum housing that locks in mechanical components. Read More

Material Handling & Storage, Mechanical Power Transmission

Roller Pinion System yields up to 36 million meters of travel.

February 19, 2014

With more than 99% efficiency and operational life up to 60 million pinion revolutions, Roller Pinion System offers linear positioning with zero backlash for high-precision motion control applications. Pinion is comprised of bearing supported rollers that engage tooth profile. Each tooth profile is measured to ensure positional accuracy and eliminate cumulative error. Available in standard 1 m and ½ m cut lengths as well as custom lengths, racks leave no limit to travel distances. Read More

Transportation Industry Products, Mechanical Power Transmission, Green & Clean

Disconnecting All Wheel Drive lowers fuel consumption, emissions.

December 27, 2013

EcoTrac™ minimizes effect of inertia and drag on vehicle's driveline system by disconnecting select rotating components from driveline when not needed (while in front-wheel drive). Specifically, system disconnects at power transfer unit (PTU) and rear drive module (RDM) to allow portions of driveline – PTU and RDM hypoid gear sets and associated bearings and driveshaft – to discontinue rotating. This enables all-wheel-drive functionality without decreasing fuel economy or adding to emissions. Read More

Mechanical Power Transmission

Roller Pinion System features corrosion-resistant design.

July 3, 2013

Constructed of precipitation hardened stainless steel, Roller Pinion System offers positional accuracy and zero backlash as well as fatigue resistance, high stiffness, and corrosion resistance, making it suitable for any linear motion application. Typical applications can be found in food packaging, semiconductors, and clean room industries. Read More

Fluid & Gas Flow Equipment, Controls & Controllers, Mechanical Power Transmission

Valve Actuator and Controls offer diagnostic capabilities.

May 9, 2013

To simplify daily work practices, FieldQ™ rack and pinion valve actuator and controls utilize FieldQ Foundation Fieldbus v3, with device diagnostic alarm management in flexible modular package. Diagnostic alarm tools enable users to categorize and prioritize device alarms on criticality of device and severity of problem detected. Alarm settings can be configured to alert appropriate plant personnel so they can take action without being distracted by irrelevant alarms. Read More

Mechanical Power Transmission

Harmonic Drive Gearhead has lightweight design.

May 2, 2013

Comprised of axially compact gear units constructed with lightweight materials, SHD-2UH-LW Lightweight Series has hollow input shaft and robust cross roller bearing that enable loads to be mounted directly to unit without additional support bearings. Gearhead incorporates flanged output and Harmonic Drive™ gear component into aluminum housing, and hollow shaft allows cables, shafts, or pipes to pass directly through axis of rotation. Applications include industrial and mobile robots. Read More

Mechanical Power Transmission

Automatic Hybrid Propulsion System meets commercial vehicle needs.

March 13, 2013

Capturing otherwise wasted energy during braking to help propel and power medium- and heavy-duty vehicles in distribution, refuse, utility, and shuttle applications, H 3000 fully automatic parallel hybrid-propulsion system is based on 3000 Series transmission matched with hybrid components: motor-generator, power electronics, and lithium-ion cell battery packs. System is scalable to application and modular battery packs enable energy capacity to be tailored to specific vehicle/duty cycle. Read More

Mechanical Power Transmission

Helical-Bevel Screw Conveyor Drives have right-angle design.

February 14, 2013

Compatible with standard CEMA mounting, right-angle helical-bevel gear Screw Conveyor Package allows end users to install gearboxes in confined spaces. Drives produce up to 42,480 lb-in. torque and up to 30 hp, depending on model, and each model operates on 95% efficiency level or greater. In addition to eliminating need for separate V-belt, products have UNICASE™ design, adjustable flange, and sealing system. Drives use either direct coupled gearmotor or NEMA C-face input design. Read More

Mechanical Power Transmission

Powersplit Transmission promotes off-highway fuel economy.

April 26, 2012

Designed for front end loaders, graders, forestry skidders, and other off-highway applications requiring up to 360 hp, Dana Rexroth R3 hydromechanical variable transmission (HVT) enables sensitive, precise vehicle positioning and stepless drive without interrupted acceleration. HVT optimizes operating point of diesel engine by decoupling engine speed from drive speed, and entire system of gears and hydrostatics is managed by electronic control unit. Read More

Mechanical Power Transmission

Hydrostatic Transmission targets small-equipment segment.

March 13, 2012

Integrating closed circuit variable displacement piston pump with direct displacement control and fixed motor, LDU20 U-Style Transmission features low operating force of 25 Nm at 2,500 rpm max. Unit measures 170 x 180 x 240 mm high, allowing installation in space-constrained OEM equipment, including turf care machines, compact utility tractors up to 30 hp, and agricultural vehicles. By attaching directly to housing of customer's transmission, Model LDU20 eliminates hosing and piping. Read More

Mechanical Power Transmission

Rack and Pinion Drive Systems come in several configurations.

February 10, 2012

Precision Planetary Rack and Pinion Drive Systems offer helical or straight (spur) rack and pinions. HighForce ZTRS systems, for applications with thrust forces to 28,000 lb, feature drives available in 5 sizes with backlash levels down to 1 arc-min. For applications with thrust forces to 12,000 lb, ZTR and ZR systems come in 7 sizes with backlash levels down to 1 arc-min. Planetary reducers with solid output shafts are available for applications with thrust forces to 4,500 lb. Read More

Mechanical Power Transmission

Electronic Traction Drive uses software-based synchronization.

September 22, 2011

Dual-speed Geared Traction Drive (GTD) shifts electronically, using software-controlled motor synchronization, and provides respective max output torque values of 1,893 and 810 lb-ft per wheel in first and second gear (180 mph max). Featuring integrated inverter, electric motor, and 2-speed transmission, solution can fit many architectures and enables optimal performance by eliminating traditional compromise made in electric drivetrains between low-end torque and top-end speed. Read More

Mechanical Power Transmission

Right Angle Helical Gear Drives feature base or panel mount design.

August 23, 2011

Series A 2Z11 is comprised of right-angle helical gear drives made with fiberglass reinforced nylon housing, hardened steel helical gears, steel shafts, and nonmetallic bearings. Single and double output shaft configurations are available and suit industry applications such as printing, packaging, and textile machinery. Standard gear ratios are 1:1 and 2:1, max rpm is 1,800, and max continuous hp is 1/8. Read More

Mechanical Power Transmission

Automatic CVP Shifting System is available for bicycles.

August 12, 2011

Utilizing CVP (continuously variable planetary) technology, NuVinci® Harmony Intelligent Bicycle Drivetrain provides smooth, step-less shifting through infinite number of effective gear ratios for bicycle drivetrains. Harmony Base Controller intelligently manages ride by automatically maintaining slow, medium, or fast (typ) pedaling cadence as chosen by rider via pushbutton. Harmony Advanced Controller offers fully automatic and manual shifting options. Read More

Mechanical Power Transmission

Right Angle Helical Gear Drives offer left or right hand rotation.

April 22, 2011

Hollow-shaft right-angle helical gear drives in S991HY-... Series feature aluminum alloy, hard-anodized case; built-in keyways; and heavy-duty sealed ball bearings. They also include 1144 steel, hollow bore shafts, ranging in size from 5/8-¾ in., as well as 4140 heat-treated steel gears. Operating in temperatures up to 200°F, gear drives offer 1:1, 2:1, or 3:2 ratios plus rated speeds up to 1,200 rpm. They are suited for printing, packaging, and textile machinery applications. Read More

Mechanical Power Transmission

Rack and Pinion System delivers efficient force transfer.

April 13, 2011

Engineered for optimal transfer of maximum feeding forces, RP+ provides modular, standardized rack and pinion system. Rack assembly is designed for maximum power transmission with minimum weight and noise. Gearbox and pinion components increase allowable torques, while forces produced by meshing of rack and pinion teeth are controlled effectively to promote system rigidity and positioning accuracy. Read More

Mechanical Power Transmission

Gear Drives are built to withstand tough environments.

March 9, 2011

Featuring Magnum no-leak seals with oil drain backs and purgeable grease chamber, Falk V-Class(TM) comes in heavy-duty, horizontally split, ductile iron housing that enables max performance under load. Case-hardened and ground gears as well as 25° pressure angle gear teeth provide strength and durability, while optimized bevel and helical tooth forms ensure full contact under load for smooth torque transmission. Optional DuraPlate(TM) cooling system requires no water or electricity. Read More

Controls & Controllers, Mechanical Power Transmission

Bevel Gearbox Drives target electrical vehicles.

December 8, 2010

Developed as integrated traction and steer drives for use in mobile machines, Drive Platforms TPD 230 and TBD 254 feature wheel diameters of 230 and 254 mm, respectively. Both electrically steered, modular units incorporate induction motors, manufactured for specific vehicle battery voltage, and integrated holding brake. With minimal torsional backlash, drives provide low-noise operation. Output ranges are 1.2-2.5 kW on TBD 230 and 1.5-3.2 kW on TBD 254. Read More
