Conveyor Drives

Mechanical Power Transmission

Helical-Bevel Screw Conveyor Drives have right-angle design.

February 14, 2013

Compatible with standard CEMA mounting, right-angle helical-bevel gear Screw Conveyor Package allows end users to install gearboxes in confined spaces. Drives produce up to 42,480 lb-in. torque and up to 30 hp, depending on model, and each model operates on 95% efficiency level or greater. In addition to eliminating need for separate V-belt, products have UNICASE™ design, adjustable flange, and sealing system. Drives use either direct coupled gearmotor or NEMA C-face input design. Read More

Controls & Controllers, Electrical Equipment & Systems, Mechanical Power Transmission, Green & Clean

Single-Axis Drive covers 0.12-15 kW power range.

January 23, 2013

Available in 4 frame sizes from 1/6–20 hp, Sinamics V20 operates pumps, fans, compressors, and conveyor systems. Drive can be connected directly in-line and mounted as push-through installation in addition to conventional wall-mounting method. Equipped with Basic Operator Panel for trouble-free on-site commissioning and operation, drive uses Keep Running Mode to automatically adapt to power supply, and ECO-mode which automatically adapts magnetic flux in motor to optimum operating point. Read More

Controls & Controllers, Mechanical Power Transmission

Distributed Drive suits material handling applications.

December 14, 2010

Offering plug-and-play power and control, Sinamics® G110D operates with pumps, fans, compressors, and other industrial equipment. Drive is suited for either direct communication with PLC or control via I/O inputs. Housed in IP65 metal enclosure, unit can be installed in close proximity to motors where dust and water ingression are of concern. Optional Intelligent Operator Panel enables text application setup with alarm status alerts and resolution advice for troubleshooting. Read More

Material Handling & Storage, Mechanical Power Transmission

Roller Drive has spring-loaded rotor locking break mechanism.

August 5, 2008

Designed specifically for decline conveyors with fail safe requirement, Model EC100B RollerDrive features spring loaded fail safe brake that prevents drifting on inclines while ensuring smooth operation and low noise emission. Mechanical rotor-locking break is spring-loaded and cycles with main power; it does not cycle with each start and stop of the conveyor. As long as the power bus is on, the magnetic force created by solenoid keeps rotor free. Read More

Mechanical Power Transmission

Drives suit low-speed, high-torque applications.

March 22, 2005

Capable of producing output torques to 4,000,000 lb-in., Drive One High Torque Drives are offered in 6 sizes in parallel or right angle configurations. Drive arrangement options include base-mounted, coupling-connected; shaft-mounted, flange-connected; and shaft-mounted, hollow-shaft connected. Ratios are available from 145:1 to over 10,000,000:1, and standard accessory offerings include motor flanges, swing bases, and torque arm connections. Read More

Mechanical Power Transmission

Drum Motors solve material handling challenges.

February 3, 2005

With motor, transmission, and bearings totally enclosed in drum shell, Series BLD conveyor drive systems produce noise levels of 50 dB, meeting OSHA requirements. Rated from 0.11-7.5 hp and running at 96% efficiency, drum motors range in diameter from 3.18-12.6 in. with face widths from 7.8-67 in. Belt speeds range from 23-1,369 fpm. Mounted with 2 brackets, sealed-for-life units are virtually maintenance-free and protected from water, dirt, dust, and chemicals. Read More

Mechanical Power Transmission

Belt Drive is suited for airport and food industries.

January 20, 2005

Targeted for airport check-in counters and belt conveyors in food processing industry, Belt Drive 113E features helical steel gears and motor that delivers up to 0.75 hp. This 4.5 in. dia belt drive is available with carbon or stainless steel shell with crowned or parallel surface. Protected to IP66/67 to withstand washdown applications, drive operates from 230 or 460 V, 60 Hz, 3-phase power and comes in belt speeds from 12-347 fpm. Read More

Mechanical Power Transmission

Drive System suits belt conveyors and bucket elevators.

July 22, 2004

Drive One is offered in 9 sizes of pre-engineered assemblies, all mounted on common swing base, which is shaft mounted via TA Taper bushing system, and utilizes foot-mounted motor. Suited for conveyor powers from 25-1,000 hp using NEMA or IEC frame motors, system features 6-sided horizontal or vertical mounting and ranges from 58,000-840,000 lb-in. It includes surface-hardened/low-noise gearing, tapered roller bearings, cast-iron housing, and grease-purged seals. Read More

Mechanical Power Transmission

Square Shaft Belt Drive suits modular belt applications.

February 18, 2004

Compact 138EMB consists of 60 x 60 mm solid stainless steel square shaft extension that fits standard modular belt sprockets. It can be installed on shaft without extra tooling or modification and delivers up to 0.5 hp. Unit drives modular belts for conveying, positioning, drying, wash-down, and frosting processes. Available with 17.71-47.24 in. roller lengths, it is powered by 230/460 V, 60 Hz, 3-phase AC motor. Read More

Mechanical Power Transmission

Belt Drive operates quietly at grocery check-out stands.

December 5, 2003

Suited for use in grocery and retail environments, 113C Series belt drive system features noise reduction of 5-6 dbA. Minimum roller length is 9.84 in. to meet needs of narrower belts, and vibration arm reduces noise and vibration in gearbox. Operating on 115 V/60 Hz power, drive employs 0.15 and 0.20 hp, single-phase motors that provide speeds of 31, 35, 39, and 44 ft/min. Read More

Controls & Controllers, Mechanical Power Transmission

Variable Frequency Drive allows speed ranges up to 20:1.

August 5, 2003

Variable Frequency Drive fits new and existing Chainveyor® systems. It utilizes AC frequency controller with motor and gear reducer combination. Controller electronically controls speed and limits output torque to preprogrammed levels. Helical gear reducers with Inverter Duty TEFC motors allow full torque rating at broad range of speeds. Full function options include soft starting and overload protection. Read More

Mechanical Power Transmission

Stainless Steel Conveyor Belt Drives suit food applications.

January 6, 2003

Models 138E and 165E measure 5.45 and 6.44 in. in diameter, respectively. Model 135E is offered in 0.13-1.0 hp with belt speeds of 10-300 fpm, while Model 165E is available in 0.15-2.0 hp with belt speeds of 12-480 fpm. Each has 3-phase squirrel cage induction motor for 230, 380, 460, or 575 V power supplies. Triple shaft sealing system meets IP66/67 sealing standards necessary for harsh food and beverage processing applications. Read More
