Shipping Racks feature folding corner posts.
SPS Ideal Solutions
Naples, FL 34119
Aug 14, 2014
On steel shipping racks, Folding Corner Posts allow corner to be positioned in 3 different planes while staying attached to rack. First position is with corner post folded onto deck surface. In second position, corner is folded outward from deck, parallel to deck length. Third position enables corner to be placed to vertical for product protection when stacked. Deck can be designed for almost any product that needs to be moved from one place to another or stored in warehouse.
Linear Guides offer optimized weight carrying capacity.
East Providence, RI 02914 0349
Aug 14, 2014
As alternative to linear guide systems that run on ball bearings, DryLin W linear guide has flexible and modular design and comes in size 25 with lubrication-free, dirt-resistant linear technology. This model consists of 3 basic elements: guide rail of hard-anodized aluminum, bearing housings of zinc die casting, and plastic bearing liner of tribo-optimized plastic iglide J200. Available configurations include single-sided 25 mm bearing rail that spaces 2 guide shafts 129 mm apart.
Spoked Handwheels resist corrosion.
J.W. Winco, Inc.
New Berlin, WI 53151
Aug 12, 2014
Supplied with or without revolving handle, GN 227.4 Spoked Handwheels have pressed A4 (AISI 316L) stainless steel body with shot blast satin finish, and solid hub also made of A4 (AISIS 316L) stainless steel, welded to body. Inch versions come with round bore without keyway, while metric sizes are available with round bore without keyway, round bore with keyway, and square bore. Supplied in 160–400 mm (6.3–15.74 in.) diameters, handwheels are suited for marine and food industries.
Fume Extraction Systems offer telescoping arm option.
Miller Electric Mfg. Co.
Appleton, WI 54912 1079
Aug 07, 2014
Available in 8 in. diameter for FILTAIR® SWX Series of stationary fume extractors and 6 or 8 in. diameters for FILTRAIN 2000–12000 centralized systems, Telescoping Arm option can be shortened or extended from 3–4˝ ft, depending on weld booth space requirements. This ensures users obtain correct length to effectively capture weld fume and help maintain safe, clean environment. Arm can also be adjusted to variety of angles for maximum performance.
Development Kit enables testing of mobile robots.
Vilnius LT-06118 Lithuania
Aug 07, 2014
Intended for researchers, academic institutions, robotics developers, and hobbyists, SentiBotics Development Kit comes with software, sample programs, tracked platform and grasping robotic arm, 3D vision, object recognition, and autonomous navigation capabilities. Tracked platform is capable of carrying payload up to 10 kg, while modular robotic arm is capable of lifting objects up to 0.5 kg. With two 3D cameras, robot can see and recognize objects at range of 0.15–3.5 m.
Thin Film Couplers operate across WiFi spectrum.
Raleigh, NC 27604
Aug 05, 2014
Based on multilayer integrated thin film technology, High Directivity 0302 Couplers offer high frequency performance across 2,400–5,905 MHz WiFi spectrum. Miniature devices are rated for operating temperatures spanning -40 to +85°C and are supplied with lead-free and RoHS-compliant 100% tin terminations compatible with automatic soldering technology, including reflow, wave, vapor phase, and manual.
Kevlar Sleeves protect against cuts, abrasions, and burns.
Southern Glove, Inc.
Newton, NC 28658
Aug 04, 2014
Manufactured from flame-resistant Kevlar® yarns, Kevlar sleeves afford wearers protection in manufacturing environments where cuts and abrasions can occur. Sleeves are constructed from 100% single- and double-ply Kevlar and resist burning, combustion, and melting. Available in lengths from 10–24 in. and widths of 3 and 4 in., products come in 8 standard fitting options. They also can be custom-made to customer specifications.
Fully Redundant 1U MicroTCA Chassis maximizes computing density.
Henderson, NV 89052
Jul 31, 2014
By combining fan trays and power supplies on rear of chassis, VT840 allows 6 AMC slots – divided among 2 sets of 3 slots for full redundancy options with failover – in single module size. Each set of slots have their own dedicated PCIe Fabric, GbE, Power Module, clock structure, and management. Dual integrated shelf managers are also provided, and mezzanine approach permits various front panel I/O options in compact, dedicated space. There are 4 SFP+ ports for 10 GbE and 4 SFP for GbE.
Electric Cylinders and Slides are offered in lead screw versions.
Fort Wayne, IN 46899
Jul 30, 2014
In addition to ball screw design, Series ECV Electric Cylinders, Series ESK/ESL Electric Thruster Slides, and Series ESG Electric Gantry Slides come in lead screw designs. Precision ball screw or lead screw models are offered in 2 lead configurations per size, which are optimized for speed or thrust performance. PHD Plus™ linear solutions offer configurable system that lets users power unit with motor and controls of their choice. Motors may be mounted in inline or foldback configuration.
Web Guide Controller (24 Vdc) comes in compact package.
Madison, WI 53707
Jul 29, 2014
Compatible with existing AccuWeb web guide systems, EVO 150 features 150 W of power and can control brushed and brushless actuator motors. Control module, measuring 6.5 x 4.5 x 1.5 in., features EtherNet/IP communication protocol for uploading and downloading of guide system settings and performance parameters. Product can be mounted in EVO enclosure measuring 7 x 5 x 4 in., including one with flush-mounted, switch-pad HMI panel on face, or din-mounted in existing control panel.
UL-Approved Coils suit high-pressure CO2 systems.
Danfoss Inc. Air-Conditioning & Refrigeration Div.
Baltimore, MD 21220-2863
Jul 28, 2014
With optimized pulling force, BJ and BX coils are designed for use with AKVH electronic expansion valves to meet demands of high-pressure CO2 systems. Frame and robust encapsulation promote durability and extended lifetime expectancy, while clip-on fastening system with audible latch click minimizes installation time and ensures proper installation. Comprising 6 models, these products are designed in accordance with UL 429 and tested in harsh operating conditions from -40 to +122°F.
Linear Motor and Roller Guide Module offers 0.01 mm accuracy.
Morrisville, NC 27560
Jul 25, 2014
Combining linear motor drive with pre-loaded roller guide, ELB Linear Axis module is able to position high loads with repeat accuracy of 0.01 mm. Maximum acceleration is 100 ms-2 and maximum speed is 4 ms-1. Driving force of 150 N is transmitted directly and without gears to slide by play-free junction roller guide. Available in 50, 75, and 125 mm strokes, module is controlled by Bosch Rexroth IndraDrive controller or by Siemens SINAMICS inverter.
Carbon Brushes target wind turbine applications.
Morgan Advanced Ceramics
New Bedford, MA 02745
Jul 21, 2014
Designed to handle environmental extremes experienced by wind turbines, including scorching heat and corrosive sea salt, Carbon Brushes also withstand low-humidity environments, sudden changes in wind speed, and on/off cycling of generator. Units feature low friction due to optimized film formation, are tolerant to contamination, and provide maximum lifespan with minimal slip ring wear and low brush to brush wear differential.
Non-Volatile Memory IP suits high-voltage processes.
Mountain View, CA 94043 4033
Jul 11, 2014
Available in standard 180 nm 5 V CMOS and Bipolar CMOS DMOS processes without need for additional masks or process steps, DesignWare® AEON® Trim NVM IP supports -40 to 150°C temperature range required for automotive Grade 0 applications and exceeds AEC-Q100 quality standards. IP includes special test modes that accelerate programming speed and reduce NVM test time. Offering 15+ year data retention, IP lets designers implement ICs in harsh and safety-critical environments.
Pneumatic Valve Coil is suited for use in rotary hydraulic tables.
Ferndale, MI 48220
Jul 10, 2014
Coil for pneumatic valve used in rotary hydraulic table features case coated with zinc clear chromate, but multiple coatings are available. While glass filled nylon bobbins withstand temperatures up to 130°C, other bobbin materials are available based upon application and environment.
Camper Stabilization Product also prevents theft.
Torklift International Incorporated
Sumner, WA 98390
Jul 03, 2014
Using turnbuckle handle for lock down, FastGun Wobble Stopper reduces camper movement, prevents jackleg and frame stress, and serves as anti-theft device. Brace bridges camper frame to jacklegs to prevent side-to-side movement, thereby eliminating subsequent damage to camper frame and jacks while also preventing hardware from becoming lose within frame. Offered in high impact powder coat white, product is constructed of aircraft grade aluminum and stainless steel.
IP supports 28 nm high-performance compact process.
Mountain View, CA 94043 4033
Jul 02, 2014
Providing interface, analog, logic library, and embedded memory IP for TSMC 28HPC, DesignWare® IP delivers low leakage and active power in compact footprint, giving designers ability to optimize SoC designs for energy efficiency, area, and speed. Both process and IP are optimized for tablets, smartphones, and LTE basebands as well as ultra low-power Internet-of-Things applications.
IP Core supports 10 to 100 Gbps applications.
Claremore, OK 74017
Jul 01, 2014
Available for ASIC and FPGA technology, AES-GCM IP Core is suited for applications such as Optical Transport Network, broadband access, and storage. Authenticated encryption algorithm combines AES counter mode for encryption and Galois field multiplier for authentication. AES-GCM is referenced in multiple standards such as MACsec and IPsec.
Extruded Rubber meets smoke and flame requirements.
Grip-Tek, Div. Of Trim-Lok, Inc.
Buena Park, CA 90622
Jun 30, 2014
Flammability, Smoke, and Toxicity Certified Dense Rubber Material targets customers that have Smoke and Flame requirements typically found in mass transit and aviation applications. FST Rated Materials are certified to highest industry standards, including: ASTM E 162, ASTM E 662, ASTM E 1354, ASTM D 3675, ASTM C 542, BS 6853, BSS 7239, NF F 16-101, and SMP 800 C.
Clamp Attachment fosters excavator versatility.
West Fargo, ND 58078
Jun 27, 2014
Bobcat® Pro Clamp™ system will enable Bobcat M-Series models E32i, E32, E35i, E35, E42, E45, and E50 excavators to grab larger, more irregular-shaped material as well as perform more efficient grading tasks. Base attaches to excavator bucket and is equipped with pin-on adjustable standard tool or reversible grading tool. Both can be removed if desired to maximize visibility into trenches and provide unlimited bucket curl for reaching above truck height when loading material.
