Other Soldering Equipment & Supplies

Plant Furnishings & Accessories, Materials & Material Processing

Hand-Piece and Work-Stand meet high thermal demands.

January 8, 2015

Used with MX Series power supplies, MX-HPDC Dual Cartridge Hand-Piece with MX-WHPDC Work-Stand meet high thermal demands of conduction soldering. Applications include microwave shields, heavy block type housing and tabbing, preheat applications, BGA removal, cell phone shields, and industrial lugs and leads that require additional thermal energy during critical phases of flux activation and intermetallic bond formation. Five SMTC dual-shaft cartridges are available in 2 temperature series. Read More

Materials & Material Processing

Industrial 80 W Soldering Station supports continuous operation.

September 16, 2014

While decreasing operational expense via separately replaceable wear parts as well as standby and sleep functions, i-CON 1 ensures accelerated heating and heat recovery times as well as constant temperature of soldering tip via integrated measure and control technology. System uses 150 W i-Tool and can be operated via illuminated text display and i-Op control knob. All important soldering parameters, including secure password protection, can be configured. Read More

Materials & Material Processing

Dross Recovery System works on continuous process basis.

July 28, 2014

Designed for use with leaded and lead-free wave soldering machines, Solder Saver includes separate activation switch, enabling user to hold system in one hand and activate it with other hand. Unit scoops hot dross up from surface of wave solder pot and separates dross oxides from solder using high-speed rotary process system. Complete process is as fast as conventional de-drossing operations, but with added advantage of minimizing handling of toxic and weighty materials. Read More

Materials & Material Processing

Dip Soldering Systems suit short-run, batch applications.

May 14, 2014

Touchscreen controlled models of Auto-Dip series feature programmable preheat and dip height settings as well as adjustable, finger-type PCB holder that firmly grips edges of board throughout soldering cycle. Accommodating heavy component-laden assemblies and customized pallets of small, irregularly-shaped PCBs, systems offer programmable speed, dip angle, lift angle, and dwell time. Largest model handles PCBs up to 23.6 x 13.8 in. and has 100 Kg, titanium solder pot. Read More

Machinery & Machining Tools, Materials & Material Processing

Batch Selective Soldering System offers operational flexibility.

February 19, 2014

Able to be configured with single nozzle or 2 nozzles, CUBE.460 offers batch platform with flexibility for through-hole applications. Selective mini-wave soldering system supports exchangeable solder pot for dual alloys and comes with various features: heated nitrogen at soldering nozzle; 0° and 7° soldering to accommodate various types of nozzles, including wetted nozzle tips and non-wetted nozzles; live viewing camera, and Quartz IR bottom side preheater. Read More

Computer Hardware & Peripherals, Printing & Duplicating Equipment, Thermal & Heating Equipment, Robotics, Materials & Material Processing

Print-Place-Reflow Package performs prescision, high-mix assembly.

January 29, 2014

Occupying minimal floor space, 2500-MV accommodates companies that require short-run, in-house production capability for ultra-precise, high component-mix SMT assembly. Included MC-400 pick and place system features Cognex® on-the-fly and bottom vision alignment for high-accuracy, 2,500 cph placement of SMDs. Additional package components include heavy-duty MC-110 stencil printer, which offers ±0.02 mm (<1 mil) repeatability, and MC-301 profilable batch reflow oven with benchtop design. Read More

Materials & Material Processing

Desoldering System offers 2 hand-piece configurations.

July 27, 2011

With dual switchable output, standalone Model MFR-1300 enables user to swap grip on hand-piece from standard pencil-grip to pistol-grip style to meet variety of application requirements. Power supply features internal pump that provides 21 in. Hg of vacuum suction force combined with Smartheat® Technology, which delivers productivity-boosting response and control, simplifying through-hole soldering and ensuring products are safe from damage. Read More

Materials & Material Processing

Soldering System suits PV tabbing and bussing applications.

March 2, 2010

Designed to minimize micro cracking, Model PS900 features STV-DRH40 hoof tip geometry that optimizes power delivered to solder joint and temperature-sensitive heater that ensures low temperature soldering, which minimizes thermally induced stresses. SmartHeat® Technology will produce and maintain specific, self-regulated temperature with heater that requires no calibration and responds directly to thermal loads. Suitable solder alloys include Sn96Ag4 and bismuth containing Bi58Sn42. Read More

Materials & Material Processing

Soldering System handles high loads efficiently.

October 30, 2009

Providing optimal thermal control, PS-900 Soldering System offers repeatability to produce high-quality solder connections quickly. Powered by SmartHeat® Technology which enables system to solder at low temperatures, it requires no calibration. System is suited for demanding applications such as lead-free soldering processes, multi-layer boards, and thermally demanding components. Read More

Controls & Controllers, Sensors, Monitors & Transducers, Materials & Material Processing

Monitor detects level of solder paste for process control.

August 21, 2009

Paste Roll Height Monitor features lasers to detect presence of solder paste and Instinctiv® V9 user interface to simplify setup. Unit includes 2 sensors that sit on either side of squeegee blade framework support. Light curtain detects solder paste presence or absence and device sends signal to printer, which reads conditions as normal when paste breaks light beam. Automatic paste dispenser option is available for high-volume applications. Read More

Materials & Material Processing

Hot Bar Soldering Systems bond unlikely materials to PCBs.

February 5, 2009

Employing thermode technology, semi-automatic Hot Bar Soldering Systems generate rapid reflow by pulse heating. System PBS212 offers in/out shuttle that moves processing linearly, while system PBS213 utilizes in/out 180º rotating table. Both perform bonding process automatically and also exit without operator intervention. All elements of soldering profile are programmable, including pressure, temperature, heat-up, and cool-down times. Read More

Materials & Material Processing

Desktop Bonder features motorized X-, Y-, or XY-axis table.

October 24, 2008

Unitek Eapro DT-500-PH Desktop Hot Bar Bonding System is suited for applications which require hot bar bonding multiple parts in array at one time, bonding multiple flexes onto one PCB, or bonding one flex to both PCB and LCD. System includes Uniflow2 power supply for selective hot bar soldering, heat sealing, and conductive adhesive bonding applications. Utilizing pulsed heat technology, it provides targeted heating/precision temperature control for flex circuits, ribbon cables, and wires. Read More

Materials & Material Processing

Soldering Station is designed for Pb-free processes.

July 11, 2008

With up to 140 W of power, BT 8808 promotes throughput while working at lower temperatures. This fosters solder joint reliability and eliminates cold joint issues. For optimal thermal recovery times, station uses microprocessor-driven JBC Advanced Technology. Read More

Thermal & Heating Equipment, Materials & Material Processing

Preheater enables soldering at lower operating temperatures.

March 28, 2008

PCT-1000 Programmable Preheater is benchtop system delivering forced convection heat that can be controlled with 4 time and temperature zones and additional cooling zone. External thermocouple input can be used for control of output temperature based on board or component temperature and also as process monitor. Designed to create convection vortex, system can be operated in manual or programmable automatic mode where up to 50 thermal profiles can be stored. Read More

Materials & Material Processing

Soldering System meets high thermal demand applications.

December 27, 2007

Controlled and powered by SmartHeat® Technology, Model PS-900 enables lead-free soldering as well as soldering of multi-layer boards and large mass components. Fixed temperature system varies power to match thermal demand of device being soldered, while SmartHeat eliminates potential for thermal overshoot, and Auto-Sleep workstand automatically reduces tip temperature during idle periods. Over 30 tip geometries are available in dimensions as small as .016-.197 in. Read More

Materials & Material Processing

Soldering System can desolder components from PCBs.

December 20, 2007

Offering adjustable temperature range to 399°C, multi-purpose, mini wave System 120 is designed for single-point or single-edge soldering and removal of ICs, including DIPs, QFPs, PGAs, connectors, and odd forms. When wave is activated, Z-motion immersion takes place with nozzle encapsulating component and dwell time governed by foot switch. Bench-top unit is suited for lead-free or tin/lead processing, and short runs requiring selective soldering. Read More

Material Handling & Storage, Machinery & Machining Tools, Materials & Material Processing

SMT Rework Tweezer provides precision control.

November 30, 2007

Designed for Metcal MX-500 Soldering/Rework System, MX-PTZ Precision Tweezer is available with variety of soldering cartridges for reworking discreet and SOIC components. Unit thermally applies heat to end caps of devices while mechanically gripping component during removal. Powered by SmartHeat® Technology, tweezer features double-sided pivot, dual-position pitch adjustment, and fully adjustable tip alignment for both height and rotation. Read More

Materials & Material Processing, Services

Repair Station fixes electronic sub-assemblies.

November 27, 2007

Bundled with hot air pencil, soldering iron, desoldering iron, vacuum pencil, and safety rests, Weller WR 3M Repair Station delivers 400 W of power while operating 3 soldering tools simultaneously. Precise temperature control is provided by blend of digital control and heat-transfer with sensor. By connecting tool, users can automatically see tool's setting on large LCD display. USB port and software integrate system with PC for data logging and monitoring. Read More

Machinery & Machining Tools, Materials & Material Processing

Solder Dipping Machine offers lead-free mass soldering.

November 14, 2007

Featuring semi-automatic design, Auto Dip can process single board or pallets up to 19.3 x 12.5 in. in 2-12 sec. Boards are placed on fixtureless ultra-fine needle bed, which retains PCBs without components being dislodged when dipped into solder bath. Solder is evenly applied while surface tension floats boards at correct wetting height, and built-in motorized skimmer removes dross as needed. Adjustments exist for dwell time, temperature from 220-299 Cº, and dipping angle. Read More

Machinery & Machining Tools, Materials & Material Processing

Resistance Soldering Systems handle heavy-duty tasks.

November 2, 2007

Suited for soldering tasks such as large military pin connectors, Ultra High Heat Plier-Style Resistance Soldering Systems provide instantaneous, localized heat from cold to greater than 1,000°F in less than 1 sec, depending upon application. Footswitch-actuated systems allow cold fixture setup before soldering. Products are suited for soldering large single wire terminations up to 0 AWG into terminal lugs, electrical splices, and multi-pin connectors. Read More
