Techno Sommer Automatic
New Hyde Park, NY 11040
Oct 01, 2008 Designed for food-handling applications, GGL3060 features corrosion-resistant, stainless steel design that is sealed to IP69K standards and withstands high-pressure and high-temperature washdown cleanings. Angular design provides up to 24 lb-ft of gripping torque, and ability to swing open to 180° enables jaws to clear material below gripper. Solution meets DIN 1672-2 guidelines for hygienic food production machinery, and also features jaw position sensors.

Anver Corp. - Anver.Com
Hudson, MA 01749
Oct 01, 2008 With 2,800 lb capacity for feeding cutting tables and machining centers, Anver M250M Mechanical Lifter has 21 x 29 in. sealing ring suction pad for lifting heavy blocks of aluminum, steel, and plastic. Unaffected by power outages, self-contained unit lets users pick up loads from top, eliminating need for magnets, hooks, or grabs. Features include self-cycling valve and piston that creates vacuum, all-welded steel construction, vacuum loss sensor, and audible and visual alarm.

Caldwell Group, Inc., The
Rockford, IL 61109
Sep 18, 2008 Suitable for wide range of operations, Modular Spreader Beam is configurable at various spreads from 10-22 ft with capacities of 1 or 2 tons. It is lightweight, fits in the back of any pick-up truck, and can be easily assembled. Faspin with lanyard allows for quick adjustment of spread.

Anver Corp. - Anver.Com
Hudson, MA 01749
Sep 10, 2008 Able to lift heavy items measuring up to 8 x 10 ft, Anver E4000M16 Vacuum Lifter incorporates all-welded steel construction with double spring suspensions for equally forcing each of 8 square vacuum pads onto load and accommodating variations in load surface. Equipped with 78 cfm pump, motors, reservoir tanks, and audio-visual alarm system, it has safety interlock switch that prevents the release of any load until lifter has been lowered completely.

Anver Corp. - Anver.Com
Hudson, MA 01749
Sep 05, 2008 Used for loading and unloading operations, VT Series lets one person handle four 5 gal pails (50 lb each) at once without manual lifting. Unit can be integrated with ceiling mounted gantry crane and is available with range of vacuum pad attachments. Along with 4 pliable bellows-style suction pads that provide soft touch and secure hold under vacuum, product features ergonomic handle with up/down controls that can be adjusted to match user's hand strength.

Anver Corp. - Anver.Com
Hudson, MA 01749
Sep 04, 2008 Featuring Easy Tilt quad-link system that helps retain vertical/horizontal position when properly centered on load, VP-Series Vacuum Lifter-Tilter handles loads up to 500 lb. Suitable for stone, glass, and plate handling, it has side handlebar that can be mounted to left or right, and lets users control pick-up with one hand and tilt with other. Powered by electric, compressed air, or battery, unit can be equipped with range of suction pad attachments.

Anver Corp. - Anver.Com
Hudson, MA 01749
Aug 25, 2008 Anver VPFL4 Series Compressed Air Vacuum Lifter runs on 72-90 psi dry, clean shop air, can be operated from any overhead hoist, and has ergonomic handle for lifting loads up to 1,500 lb. With vacuum pad attachment that offers 12-18 in. adjustable vertical reach, unit can lift and install heavy parts. Lifter needs 8 in. of head room, and features 2 snap-on sealing ring suction cups, vacuum attach-and-release slide control valve, air filter, vacuum check valve, and leakage sensor.

Anver Corp. - Anver.Com
Hudson, MA 01749
Aug 01, 2008 Available as electric- or air-powered with pad configurations, Anver VFP-57 side-oriented vacuum lifter lets users feed large sheet or plate into presses and other equipment from narrower end. Featuring adjustable, telescoping arm assembly that slides into beam and is counterbalanced for smooth operation, it is suited for applications where stacked sheet or plate is only accessible from the end. Unit includes handlebar controls, vacuum guard system, and audio-visual alarm.

Anver Corp. - Anver.Com
Hudson, MA 01749
Jul 10, 2008 Able to handle large containers and products from side, Model VFP-57 features handle that extends from 36-60 in., and pivots for stacking. Adaptable to various loads, it has arm extensions which can adjust along beam and can come with wide range of vacuum suction pads. Available in capacities of up to 2,500 lb, unit can be equipped with air/electric vacuum pumps. Other features include handlebar controls, vacuum gauges, and audio-visual alarms.

Anver Corp. - Anver.Com
Hudson, MA 01749
Jul 02, 2008 Capable of handling steel fabrications up to 10,000 lb without chains or slings, High Capacity Vacuum Lifter & Tilter has all-steel welded frame with 2 hydraulic cylinders that rotate loads from horizontal to vertical position using fully integrated remote controls. It is equipped with 8 vacuum suction pads, each measuring 19 x 25 in., and 4 spring suspensions. Other features include electric vacuum pump, vacuum reservoir, check valve, vacuum gages, and safety audio-visual alarms.

Industrial Magnetics, Inc.
Boyne City, MI 49712
Jun 02, 2008 With 400 lb lifting capacity, Manhole PowerArm(TM) reduces back strain and increases employee safety when lifting and replacing manhole covers. When driven within 3 ft of center of manhole cover, unit adjusts to user's location with 3 ft, 180° swing radius and double-jointed elbow that allows positioning of magnet in center of manhole cover. Featuring welded, tubular steel construction, it fits into 2 in. square trailer hitch and comes with electric or manual winch control.

Anver Corp. - Anver.Com
Hudson, MA 01749
Jun 02, 2008 Anver VP-Series Vacuum Lifters feature beam equipped with 3 mount assemblies for replaceable vacuum pads which can be changed using clevis pins and quick-connect couplers. Designed for either one center vacuum pad or 2 pads along beam, lifter includes pendant controls, vacuum reservoir, audible and visual alarms, and automatically shuts-off above preset vacuum level. Incorporating all welded steel frames, units can handle large steel plates, individual cut-out discs, and skeletons.

Anver Corp. - Anver.Com
Hudson, MA 01749
May 14, 2008 Designed for general warehousing and shipping applications, VT-Series Vacuum Tube Lifter is offered with 90° tilt mechanism that lets users pick up boxes weighing up to 50 lb, under vacuum, and mechanically reorient them for loading and unloading conveyors. Unit has hand vacuum controls for picking up and releasing boxes with lever for manually reorienting them. It comes equipped with heavy-duty pump, vacuum gauge, wire-reinforced tube, and quick-connect coupling.

Robotic Accessories
Tipp City, OH 45371 9468
May 06, 2008 Enabling collet to grip part on either O.D. or I.D., C-8800 Heavy-Duty 5C Collet Gripper can rapidly pick and place uniformly sized objects, and features pneumatically adjustable 360° clamping force for parts transfer. Unit can also function as workholding device for grinding, deburring, or polishing operations.

Anver Corp. - Anver.Com
Hudson, MA 01749
Apr 28, 2008 Suited for handling multidimensional architectural panels and large metal plates, AT Series below-the-hook, air-powered lifter-tilter features fully adjustable suction cups with extended suspensions and individual air valves. It employs compressed air cylinder for powered tilting, while vacuum loss sensor and audio-visual alarm promotes operator awareness. Various suction cups can be supplied for handling different surfaces.

Kastalon, Inc.
Alsip, IL 60803 1810
Apr 16, 2008 Kastalon Mandrel Sleeves allow coil processor flexibility to unwind or rewind coils that are larger than maximum expansion of mandrel. Manufactured from Kastalon Polyurethane®, they are offered in slip-on or bolt-on versions with or without slot for tail gripper. Thin-walled sleeves prevent damage from coil creases, scratches, and marring; thick-walled units enable adjustments of ID size; and dual-durometer versions provide metal-like hard surface against mandrel with softer outer skin.

Anver Corp. - Anver.Com
Hudson, MA 01749
Apr 14, 2008 Equipped with aluminum beam with adjustable cross sections and vacuum cups, Anver VT Series Tube Lifter can accommodate cartons weighing up to 400 lb, depending upon model. Providing 100% continuous duty cycle, it features extended handle with release assist valve that pivots 45° up and 75° down for handling heavy porous loads. Suitable for variety of applications, ergonomic lifter is available with electric or compressed air powered vacuum pumps and range of suction cups.

Wood's Powr-Grip Co., Inc.
Laurel, MT 59044
Apr 09, 2008 Configurable to stretch to 183¾ in. in length, Model MT4FS818DCS can handle long sheets of cladding materials weighing up to 700 lb. It comes with dual vacuum system with vacuum reserve tanks to reduce risk of falling loads that could result from breakage or other accidents. Unit features on-board battery charging system, battery energy gauge, low vacuum level buzzer, and 90° manual tilt between upright and flat positions with hydraulic damping and automatic latching.

Anver Corp. - Anver.Com
Hudson, MA 01749
Mar 31, 2008 Eliminating need for electric/pneumatic power, Mechanical Vacuum Lifter has mechanism that creates suction through action of lifter being lowered onto load by hoist. It can be operated anywhere and features 36 in. long ergonomic safety handle, all-welded steel construction, and range of vacuum cups. Available in 500-18,000 lb capacities, unit is suited for handling ferrous and non-ferrous sheet and plate, steel, aluminum, and polished stone from top without hooks, grabs, or magnets.

Schunk
Morrisville, NC 27560
Mar 10, 2008 Suited for loading and unloading machines and for handling both small and large workpieces, MAGNOS Magnetic Gripper MAU offers 1,675-6,700 lb max holding force. Light weight unit does not require electricity to maintain magnetic field and needs energy only for activation and deactivation. It can be adapted to any robot arm and top tooling can be contoured to any workpiece surface.
