CCD Camera profiles large laser beams.

February 20, 2015

Measuring 43 x 43 x 65 mm, LT665 USB 3.0 Large Array Beam Profiling Camera features USB 3.0 interface that delivers 6 MP at up to 27 fps. Large, 1 in. format provides active area with 4.5 µm square pixels (2752 x 2192 array). Camera works with BeamGage beam profiling software, which includes all algorithms and calculations needed to make accurate, ISO-approved laser beam measurements, including beam size, shape, uniformity, divergence, and mode content. Read More

Sensors, Monitors & Transducers, Optics & Photonics, Test & Measuring Instruments, Machinery & Machining Tools

Non-Contact Industrial Beam Monitoring Systems offer 2D views.

February 17, 2015

Without requiring contact with beam, BeamWatch® instantly measures focus spots down to 80 µm dia in 60 msec intervals and position for YAG, disc, fiber, and diode lasers from 980–1,080 nm. Rayleigh scatter measurement allows monitoring at frequent intervals without shutting down or disrupting process, and 2D viewing of beams determines roundness or presence of astigmatism. Able to be run in Technician or Operator Mode, industrial laser beam profilers serve material processing applications. Read More

Machinery & Machining Tools, Optics & Photonics, Test & Measuring Instruments, Vision Systems

Pyroelectric Laser Beam Profiling Camera serves OEM applications.

February 17, 2015

Along with 80 µm pixel pitch, Pyrocam IIIHR has 160 x 160 pixel image array for profiling beams up to ½ in. without reduction optics. Pulsed and CW lasers, including CO2 and telecom NIR lasers and THz sources, can be measured from 13–355 nm and 1.06 to >3,000 µm. Interface to GigE camera supports high-speed applications, 16-bit ADC promotes reliable measurement and analysis of large and low level signals in wings of laser beam, and SNR of 1000:1 facilitates viewing of 30 mW/cm² beams. Read More

Machinery & Machining Tools, Sensors, Monitors & Transducers

Five-Axis Profiler offers high-speed metal removal.

May 8, 2014

Suited for aerospace titanium machining, 5-Axis Cincinnati XT super profiler offers 100 in.³/min metal removal rate (MRR). Cross rail and spindle design enable performance at high rate on sustained basis, and 5-axis gantry design utilizes high-stiffness frame. A/B rotary axes on each spindle can be independently calibrated and controlled to enhance accuracy. Gantries have 145 in. Y-axis range, with Z-axis travel of 28 in., and each spindle’s angular A and B axes can travel ±30°. Read More

Test & Measuring Instruments, Machinery & Machining Tools, Sensors, Monitors & Transducers, Laboratory and Research Supplies & Equipment, Optics & Photonics

Metrology System offers non-destructive, 3D surface profiling.

February 20, 2014

Combining lateral resolution up to 140 nm via confocal microscopy and vertical resolution up to 0.1 nm with interferometry, Leica DCM8 provides surface analysis of materials and components. Instrument is also suitable for color documentation of samples. Wide choice of Leica objectives, together with 4 LED light sources and integrated CCD camera, deliver true-to-life color images. With XY topography-stitching mode, users can obtain seamless, precise model of larger area. Read More

Software, Machinery & Machining Tools, Optics & Photonics

Laser Beam Profiler uses optimized computation engine.

February 17, 2014

Leveraging computation engine that improves cycle time and UI responsiveness while also enhancing ability to work with apertures and partitions, BeamGage® v6.1 performs data acquisition and analysis of laser beam parameters. Solution can analyze different beams or sources of light and incorporates strip chart function that allows for zooming and panning as well as charting of partitions and storage of 10,000+ data points. Solution also includes 55+ measurements and calculations. Read More

Machinery & Machining Tools, Sensors, Monitors & Transducers

Benchtop 3D Optical Profilers offer enhanced metrology abilities.

February 12, 2014

Based on non-contact optical technology and powered by Mx™ software, NewView™ 8000 series meets metrology requirements of applications in scientific research, product/process development, and manufacturing. Modular platform provides hundreds of surface results and analyses, including ISO 25178 area surface texture parameters for quantitative analysis. Features include surface visualization and surface detection algorithms and real-time interactive analysis with 2D and 3D plotting technology. Read More

Test & Measuring Instruments, Machinery & Machining Tools, Optics & Photonics

Laser Beam Profiling Camera has large array, GigE interface.

February 13, 2013

With 320 x 320 pixel pyroelectric array that can profile beams up to 25 mm without reduction optics, Pyrocam IV measures pulsed and CW (continuous wave) lasers from 13–355 nm and 1.06 to greater than 3,000 µm. Electronics control design includes interface to GigE (Gigabit Ethernet) cameras, and integral focal plane chopper is included for CW beams and thermal imaging. Other features include 14-bit ADC, SNR of 1,000:1, and Ultracal® baseline algorithm. Read More

Machinery & Machining Tools, Optics & Photonics

Scanning Slit Laser Beam Profiler features USB2 interface.

February 11, 2013

Using moving slits, NIST-calibrated NanoScan 2 measures continuous wave (CW) and pulsed beams across spectral range from UV to far IR. Beam size and beam pointing can be measured with 3 sigma precision of several hundred nanometers. While USB2 interface provides deep, 12-bit digitization of signal for dynamic range up to 35 dB power, digital controller improves accuracy and stability of measurements. Software can measure 1–16 beams in NanoScan aperture, all with sub-micron precision. Read More

Machinery & Machining Tools, Optics & Photonics

Laser Beam Profiling System measures widths to 35 mm.

February 7, 2013

Along with 4008 x 2672 pixel format that allows profiling of beams up to 24 x 36 mm without requiring reduction optics, L11059 USB Large Format Beam Profiling Camera features 50 mm ND filters that provide max power density measurements to 15 mW/cm² without additional attenuation. Frame rates of up to 3.1 fps are supported at full resolution (up to 17 Hz in 4x4 binning mode). Featuring 59 dB dynamic range, camera can measure CW laser beams over spectral range from 190–1,100 nm. Read More

Machinery & Machining Tools, Optics & Photonics

Laser Beam Profiling System measures quality in real-time.

January 24, 2013

Working with CW and pulsed lasers down to single shot rates, Photon M2-1780 automatically measures M2 beam propagation ratio and all associated ISO 11146 parameters instantaneously at video rates over 20 Hz. CCD camera-based system, sensitive to wavelengths from ~250–1,100 nm, automatically measures with NIST-traceable accuracy to better than 2%. This translates to M2 measurements with accuracy to -5%. System works in conjunction with FireWire BeamPro Acquisition and Analysis software. Read More

Test & Measuring Instruments, Machinery & Machining Tools, Sensors, Monitors & Transducers

Surface Roughness Measuring System serves on production lines.

July 18, 2011

Using array of probes and accessories, ergonomically designed Hommel-Etamic W5 can track 5 separate measurement programs, up to 100 separate profiles, with total storage capacity of up to 10,000 completed measurements. Integrated click wheel and color display with GUI facilitate operation, while support prism centers workpieces reliably on correct measuring position and protects probe for measurements in bores from 12 mm dia. All necessary connection are made via USB interface. Read More

Test & Measuring Instruments, Machinery & Machining Tools, Optics & Photonics

Laser Beam Propagation Analyzer measures M² at any wavelength.

March 24, 2011

Combining NanoScan near-field profiler with dedicated M² measurement hardware and software, NanoModeScan enables quantitative measurement and viewing of high-power CO2 laser beams in as little as 20 sec. System also reports beam waist diameter and location, divergence, and beam's Rayleigh range for each axis. With update rate of 20 Hz, system is suitable for CO2 laser-based material processing, machining, and marking applications where laser performance needs to be adjusted in real time. Read More

Machinery & Machining Tools, Optics & Photonics

Pipe Cutting Machine also includes profiling capabilities.

September 28, 2010

Suited for small- to medium-sized fabricators of tube frame assemblies, MasterPipe(TM) Profiler (MPP) 2-axis, CNC pipe cutting machine is powered by Windows®-based OS and operated via touchscreen. It consolidates setup, programming, and cutting into one operation, and pre-loaded cut library optimizes pipe configuration flexibility. Capable of performing range of standard cuts, machine handles 1-12 in. OD pipe in lengths up to 40 ft. Read More

Test & Measuring Instruments, Machinery & Machining Tools, Sensors, Monitors & Transducers, Optics & Photonics

Optical Surface Profiler suits automated HB-LED production QA/QC.

July 21, 2010

ContourGT(TM)-X8 PSS is optimized for characterizing high-brightness light emitting diode (HB-LED) patterned sapphire substrates (PSS). Combination of non-contact 3D measurement capabilities with Veeco PSS metrology hardware and software technology, as well as Wafer Automation System Developer's Kit (SDK) provides tailored solution for PSS QA/QC applications requiring high throughput and repeatability. TCP/IP-based remote control capabilities are also standard. Read More

Test & Measuring Instruments, Machinery & Machining Tools, Sensors, Monitors & Transducers, Laboratory and Research Supplies & Equipment, Optics & Photonics

3D Surface Metrology System has tabletop form factor.

June 9, 2010

ContourGT(TM)-K0 non-contact, 3D optical surface profiler combines streamlined architecture and functionality with measurement and computing hardware and software. Dual-LED illumination, combined with optimal vertical resolution, accommodates difficult applications and environments. In addition to Vision64(TM) Operation and Analysis Software, system features intuitive, modular nterface that offers user-level customization capabilities. Read More

Machinery & Machining Tools, Sensors, Monitors & Transducers

Hybrid Profiler combines thin film, optical capabilities.

April 22, 2010

As combined thin film and dimensional optical profiler, CCI SunStar merges non-contact dimensional measurement capability with thin and thick film technology. Integral 4 million pixel camera enables Hi-Res imaging, and film thickness measurement is possible from 5 µ down to 300 nm or less. While auto-range and auto-fringe-find functionality facilitates use, single mode of operation over all scan ranges lends to data reliability. Closed loop Z scanning mechanism is also standard. Read More

Machinery & Machining Tools, Sensors, Monitors & Transducers, Laboratory and Research Supplies & Equipment, Optics & Photonics

3D Optical Surface Profiler suits wide range of applications.

April 16, 2010

Based on white light interferometry (WLI) technology, ContourGT(TM) Surface Metrology Product Family addresses range of production QA/QC and R&D precision machining and manufacturing applications within high brightness LED, solar, ophthalmic, semiconductor, medical device, and academic research markets. High brightness dual-LED illumination facilitates precision, non-contact, 3D surface metrology, while Vision64 operating and analysis software provides user-level-customization capabilities. Read More

Test & Measuring Instruments, Machinery & Machining Tools, Sensors, Monitors & Transducers

Surface Profile System offers high-precision 3D inspection.

October 5, 2009

Model BW-H501 3D surface profile system features high-speed X-Cycle Imager allowing image capture of 900 fps with output/display of height images at 5 fps. It also integrates BridgeElements software which supports simultaneous capture of multiple images, allowing real-time image comparison. By utilizing fringe cycle method, system can achieve height resolution of 100 nm and perform surface profiling in as little as 200 ms for height of 40 µm. Read More

Machinery & Machining Tools, Optics & Photonics

CCD-Based Laser Beam Profiler delivers 12-bit resolution.

September 25, 2009

Operating under BeamProfiler Software in MS Windows®, USBeamPro CCD provides NIST-traceable measurements of ISO Standard laser beam profile parameters - laser beam diameter, centroid, power/energy - for CW, pulsed, and single-shot lasers. USB 2.0 interface facilitates use and promotes portability, while ½ in. format 1,360 x 1,024 array with 4.65 µm square pixels offers total imaging area of 6.32 x 4.76 mm. Camera dimensions (70 x 95 x 33 mm) aid placement into typical optical paths. Read More
