Milling Cutters

Machinery & Machining Tools, Fasteners & Hardware

Face Milling Tool targets automotive industry.

November 20, 2015

Featuring 8 edges, CoroMill® 425 optimizes metal removal rate and tool life in ISO K application area. Finishing tool is intended for face milling of cast materials, such as engine and cylinder components, axle housings, brake carriers, and crankcases made of GCI, NCI, and CGI materials. With patented setting system, tool offers precise insert positioning that facilitates set-up. Insert version with 25° entry angle and optimized chamfer minimizes breakouts and burr formation on workpiece. Read More

Machinery & Machining Tools

Solid-Carbide End Mill features eccentric relief design.

November 11, 2015

With 7-flute, eccentric relief design, VariMill III ER is engineered for high metal removal and extended tool life in demanding workpiece materials, such as titanium and stainless steel. True finishing end mill can take up to 30% radial engagement, enabling high-speed machining in high-strength alloys. Coating and proprietary pre- and post-coat treatment optimizes cutting edge consistency, while SAFE-LOCK™ option by Haimer eliminates pull-out risk, making assembly more stable and concentric. Read More

Fasteners & Hardware, Machinery & Machining Tools

Shoulder Mill Platform provides true 90-degree walls.

October 19, 2015

Designed for low horsepower draw and free machining, VSM17 Platform provides cutters for shoulder milling, profiling, face milling, slotting, ramping, and helical/circular interpolation. Cutter bodies have integral chip gash design for chip evacuation along with hardened-steel construction and hardened pocket seats. VSM17 offers aggressive ramping capability up to 8.8° and max 0.642 in. depth of cut. With multiple corner radii and positive rake faces, inserts provide true 90° wall. Read More

Machinery & Machining Tools

Multi-Flute End Mills support high-speed and peel milling.

October 15, 2015

Available in diameters from .0375–1 in. with flute length up to 2.5 times diameter, 6-flute Models S638 and S638R take larger radial depths of cut as compared with 7- and 9-flute tools. AlTiN coating allows end mills to achieve long, predictable tool life in milling applications that involve high temperatures and abrasive workpiece materials, such as titanium and pH stainless steels. For smooth cutting and high surface finishes, variable indexing minimizes harmonics. Read More

Machinery & Machining Tools

Octagon Finishing Face Mills are optimized for work on cast iron.

September 15, 2015

Built to produce flat surfaces on large cast iron components, Walter M2025/M2026 are equipped with 16-edged octagonal peripheral inserts and three 4-edged wiper inserts. Basic wiper insert shape is negative, while cutting edge geometry is positive. Convex edge wiper inserts ensure maximum surface quality, all inserts are precision ground, and cutter bodies, likewise, feature precision insert seats. Cutting edges can be changed rapidly due to wedge clamping of octagonal inserts. Read More

Portable Tools, Optics & Photonics, Machinery & Machining Tools

Solid Carbide Milling Cutters work on lightweight materials.

September 14, 2015

For machining thermoplastics, OptiMill-Thermoplastic has sharpened cutting edges and chip discharge-optimized geometry. Diamond-coated OptiMill-Thermoplastic-FR, for machining fiber-reinforced thermoplastics, cuts fibers without burr formation. For milling fiber composite parts, OptiMill-Composite-UD diamond-coated end milling cutter eliminates delaminations and fiber projections. OptiMill-Honeycomb end milling cutter meets honeycomb machining demands with 8-bladed design and 15° helix angle. Read More

Machinery & Machining Tools

Orbital Thread Mills handle tough to machine materials.

August 7, 2015

Available in 2xD and 3xD models, Orbital Unified National Fine Thread Mills feature large shank diameters that promote vibration-free machining. Tough micrograin carbide construction with TiCN coating renders mills suitable for use with ISO material types P, M, K, N, S, and O. In addition, short overhang makes tools particularly suitable for machining of challenging materials such as ISO S alloys, materials of high tensile strength, and materials with spring back effect. Read More

Machinery & Machining Tools

End Mills support multiple operations.

May 1, 2015

Consisting of 2- and 4-flute versions in square-end, chamfered-edge, and ball-nose configurations, VariMill GP End Mills are suitable for roughing, semi-finishing, and finishing in variety of materials, including aluminum, steels, stainless steels, and cast irons. General purpose tools feature 30° helix angle and eccentric relief, which provide strong edges and stability. Thick TiAlN coating contributes to extended tool life across milling, ramping, and slotting operations. Read More

Machinery & Machining Tools

Solid End Mills quickly remove large amounts of metal.

February 27, 2015

In addition to heavy roughing, CoroMill® Plura Heavy Duty End Mills are suitable for shoulder milling, full slot milling, ramping and helical interpolation in steel and stainless steel as well as cast iron and heat-resistant materials. Flute shape assures effective chip evacuation when machining large depth of cut. Design also prevents re-cutting of chips and sudden tool breakage. One grade was developed for dry machining, while another grade handles large engagements in wet machining. Read More

Machinery & Machining Tools

End Mills suit machining of hi-temp alloys.

December 5, 2014

Featuring carbide core and 6 flutes with optimized rake and relief angles for maximum cutting engagement, INCONEX M8 Series is suitable for machining Inconel, Hastalloy, Waspalloy, and similar hi-temp alloys. All tools are made with corner radius to prevent chipping in strong metals. Designed to keep tools lubricated, AlCrNX coating protects cutting edges from intense heat generated in cutting zone. As added benefit, tools produce small chips that can be easily flushed from work zone. Read More

Machinery & Machining Tools

Universal Milling System reduces tooling requirements.

September 30, 2014

Able to be used with all steel and cast iron materials, stainless steels, and difficult-to-cut materials, M4000 comprises 3 cutter bodies and 4 indexable inserts and can be employed in such applications as face milling, shoulder milling, and chamfering. Flank faces on 4 cutting edges of inserts feature wave profile that displays geometry. Coated with Tiger•tec Silver®, inserts have rake face markings, come in stable and universal geometries, and have positive shape with clearance angle of 15°. Read More

Machinery & Machining Tools

Milling Grade is suited for machining cast iron.

April 30, 2014

Designed for extended tool life, WK15CM WIDIA Victory™ grade is available for face mills, shoulder mills, and copy mills. Fine-grained alumina layer promotes wear resistance by optimizing coating integrity at elevated speeds, while post-coat treatment increases cutting edge toughness by improving coating stress. This helps fight thermal cracking and coating flaking. Furthermore, cutting edges are micro-polished to lessen cutting forces and friction and workpiece sticking. Read More

Machinery & Machining Tools

End Mills handle machining of hardened steels.

March 28, 2014

Suitable for machining hardened steels up to 58–62 HRC, running wet or dry, Omega M726 End Mills feature 6 flutes, 50° helix angle, and AITiNX coating to protect cutting edges from heat generated in cutting zone. Omega M7 Series is available in sizes from 1/8–¾ in. and in variety of lengths with neck relief and corner radii as standard options. Sizes 1/8–3/16 in. have 5 flutes for maximum chip evacuation and are designated M725 series. All other geometries are same as those on M726 models. Read More

Machinery & Machining Tools

High Performance End Mill serves aluminum roughing applications.

March 11, 2014

Available in sizes from 3/16–¾ in., Alumigator is designed for accelerated ramping into pockets at angles up to 45°. End mill, once at full depth of cut, will chew through material as aided by core and engineered cutting edges that maximize cutter strength. Combination of geometries produces short curled chip, which is evacuated at accelerated rates to help prevent double cutting chips and keep flutes from packing. Read More

Machinery & Machining Tools

Solid Carbide Endmill combines performance, extended tool life.

March 7, 2014

Used on steel, stainless steel, cast iron, and super alloys, Prototyp Proto•max™TG (Tough Guys) is available in 2–25 mm dia variants with 3, 4, or 5 cutting edges. Design promotes chip removal, rear cutting edge has reinforced core to promote stability, and carbide substrate provides toughness for counteracting vibration induced fractures to cutting edge. Pre-treatment provides optimum surface for titanium aluminum nitride coating, which helps protect against wear and increase tool life.
Read More

Portable Tools, Machinery & Machining Tools

Face Milling Platform addresses cast iron, steel challenges.

February 21, 2014

Featuring double-sided insert design with 8 cutting edges, KSSM8+™ maximizes metal-cutting performance in cast irons and steel workpieces. Respectively, IC10 and IC 12.7 sizes provide 0.354 and 0.236 in. depth of cut and lead angles of 88° and 87°; suitable applications include those where fixture limitations or part designs call for close to 90° shoulders. Lowering cutting forces and optimizing floor finish quality while machining, –LD geometry has positive rake face and honed edges.
Read More

Machinery & Machining Tools, Fasteners & Hardware

Medium Roughing Inserts cut stainless steels.

February 20, 2014

Suitable for wide range of workpiece materials, but optimized for stainless steels, Beyond™ MR Inserts feature unique geometry that maximizes smooth cutting and chip flow. Geometry of chip step is designed in continuous curve so that alternating stresses are reduced and uniform chip forming occurs. High positive rake angle works with smoothly curved cutting edge to reduce cutting forces. In addition, inserts have formed-in coolant channels that efficiently deliver flood coolant to cutting edge. Read More

Machinery & Machining Tools

Face Mills help eliminate burrs.

February 6, 2014

With unique insert chipbreaker design, WGX Wave Mill Series delivers optimized surface finish and run-out accuracy. Units also offer low cutting force due to high rake angle and optimized edge treatment for extended tool life with Super ZX and Super FF coatings. Also available, ACM200 and ACM300 insert grades are suitable for milling exotic and stainless steel materials. ACM200 CVD grade offers wear and heat resistance, while ACM300 PVD grade features balanced wear and fracture resistance. Read More

Machinery & Machining Tools

Solid Carbide Endmills offer fine balance and 5 ìm run-out.

October 18, 2013

Made from fine grain carbide, Power Mill PVD-coated endmills come in 2–20 mm cutting diameters and with 3, 4, and 5 cutting edges. Safe-Lock™ pull out protection system is available starting from 6 mm shank diameter, and all shanks are based on h5 tolerance. Cutting edge solutions include sharp, chamfer, and radius, and roughing geometry with cord profile is also available. For chatter-free, high-end machining, endmill geometries are based on unequal flute and helix design. Read More

Machinery & Machining Tools

Compression End Mill supports composite machining.

July 15, 2013

Combining positive and negative helix to compress top and bottom of component edge, CoroMill® Plura minimizes potential for delamination, which is common when machining carbon-fiber reinforced polymers. Tool supports edge milling applications on workpieces with minimum thickness of 6 mm. Offered in diameters from 0.24-0.63 in. with lengths from 2.99-3.94 in., tool features 6 effective cutting edges, achieves surface finish of well below 0.0001 in., and supports cutting speeds of 656–1312 fpm. Read More
