Brown Machine LLC    Beaverton, MI 48612-0434
Sep 15, 2009 B-Series Hot Sheet Thermoformer integrates sheet extruder close to machine and roll stack at entrance end, allowing material to be extruded directly onto conditioning rolls within it, helping save energy. Sheet with high core temperature creates forming conditions that enable precise material distribution, allowing use of 2-stop oven instead of 4 or 5-stop oven, which also saves energy. Available in sizes up to 50 x 60 in., system is configurable for production with wide variety of materials.

Brown Machine LLC    Beaverton, MI 48612-0434
Sep 14, 2009 Intended for trim press offerings that incorporate process features coupled with quick change capabilities, treadle lift system (incorporated within treadle assembly) moves sheet guides up and out of the way for tool loading. Canopy is moved fore or aft, providing clearance above feed area, and treadle will adjust upward on cylinder-actuated guide system. Die-set can be rolled out of side of trim press for tool change, and new die-set is installed.

Emhart Teknologies, A Black & Decker Co.    Shelton, CT 06484
Sep 14, 2009 With no loose mandrel heads present in final assembly, 3 mm steel counter-sunk rivets suit electronics applications. Manufactured to ISO, QS, and TS requirements, they can handle applications with no protrusion as well as those requiring installation from either side of application. RoHS and DFAR compliant units have been color coded for quick visual identification on production floor.

Brown Machine LLC    Beaverton, MI 48612-0434
Sep 11, 2009 Quad Series incorporates forming station, featuring up to 260 tons of holding force and 150 tons of coining force, that lends to precise and consistent thermoformed product by ensuring virtually zero deflection across entire mold area. Also available, roller screw third motion technology enhances material distribution, reduces starting gauges, and promotes process window. Mold area sizes vary up to 64 x 64 in., with capabilities to produce parts with depths of 4-12 in.

Wet Technologies    Holbrook, NY 11741
Sep 10, 2009 Enabling replacement of dry grit with wet grit blasting to reduce or eliminate parent material removal, Wet Tech Process helps meet and exceed SPOP for wet grit blasting of major rotating parts. Aqueous wet and water blast cleaning equipment and machinery suit advanced applications for OEM parts cleaning. In addition to automatic pushbutton method for determining media concentration, features include stainless steel tig welded construction and gun with controllable air pressure.

Molecular Imprints, Inc.    Austin, TX 78758-3605
Sep 10, 2009 Perfecta(TM) TR1100, leveraging J-FIL(TM) technology, enables mass-replication of master imprint templates for patterned media applications. Combined with nanopatterning systems, it provides critical component for manufacturing high-density HDDs. Once master template is initially created using traditional e-beam technologies, platform can replicate it thousands of times with optimal pattern fidelity. Each subsequent template replica can then be employed to produce thousands of disks.

Technifor, Inc.    Charlotte, NC 28273
Sep 09, 2009 Models XF510Sp and XF510Dp pneumatic micropercussion marking machines offer fields of 100 x 80 mm and 200 x 80 mm, respectively. Devices include optimized marking head shuttle trajectory, motor control system, micromechanical components, as well as 8 inputs and 4 outputs and RS232/USB/Ethernet ports. They are controlled by UC500 remote control unit and incorporate control software based on pictograms. Supporting 14 types of keyboard, systems can also execute DataMatrix(TM) code in under 5 sec.

Reel-O-Matic By Reel-Neat Systems, Inc.    Oklahoma City, OK 73143
Sep 08, 2009 Operated with wireless radio remote control, Cat-Walk FMPT4/FMP8 is powered by AC Vector variable-speed torque controlled drive system and accommodates respooling speeds from 0-115 rpm. Shaftless FMPT4 handles reel diameters up to 60 in. OD and up to 4,000 lb, while FMP8 is engineered to support same reel diameters but up to 8,000 lb. Latter also includes hydraulically powered pay-off and rewind assist benefit which feeds and rewinds cable to and from FMPT4.

Mate Precision Tooling    Anoka, MN 55303
Sep 04, 2009 Designed to extend tool life and promote quality punching, AMX(TM) punches and strippers are 100% compatible with Amada ABS assemblies and holders. Operating benefits, which include internal lubrication within punch guide and external lubrication between punch guide and turret bore, help prevent galling, slivering, and slug pulling. Precision machined of M2 high speed steel, AMX punches combine with hardened and ground stripper guides to reduce galling, wear, and heat.

Posi Lock Puller, Inc.    Cooperstown, ND 58425 0246
Sep 02, 2009 Constructed with Safety Cage® design, PH-200T 4-jaw, 200 ton puller features jaws with 50 in. reach and 8-52.5 in. spread range. Hydraulic-powered dual mast lift cart will extend from ground to 5 ft, and puller can be removed from cart and used in horizontal/vertical positions. Additional components include manually adjustable jaw tips and 2-stage electric pump with 10 ft remote jog switch.

SERAPID, Inc.    Sterling Heights, MI 48314
Sep 02, 2009 Designed for Quick Die eXchange (QDX) equipment, Motorized Bolster Extensions (MBEs) combine functionality of bolster extensions and push-pull systems into one integrated unit. They support die outside of press and move die in and out of press. Able to be loaded with overhead crane or fork-truck, each product features Rigid Chain Technology that allows die to be positioned several inches onto bolster without special attachments. Capacity ranges from 10-25 tons.

Daimer Industries Inc    Woburn, MA 01801
Aug 26, 2009 Featuring 17 gal solution tanks and 15 gal recovery tanks, commercial-grade, unheated, 150 psi XTreme Power® XPC-9200 carpet cleaners can accept hot water of up 210ºF. They feature 2 two-stage motors, air flow of 200 cfm, and water lift of 150 in. Carpet shampooers come with 12 in. dual-jet wand, 25 ft of solution hose, and 25 ft of vacuum hose. Low-flow technology in units produce less dampening in carpets and helps them dry in approx. 6 hr.

EDL Packaging Engineers, Inc.    Green Bay, WI 54304
Aug 20, 2009 Designed to create close fitting bagged total enclosure, Tight Wrap Forming Shoe System is comprised of Tight Wrap Side Feed Automatic, model TWSFA 38-30 Wrapper with 53 in. Center Folded Film Feed, Infeed Conveyor, Film Forming Shoe, Lap Sealer, and Exit Conveyor. System completely encapsulates product, and vacuum evacuation removes excess air from pack (if necessary). During packaging, formed gusset creates handle to facilitate product handling.

Robert Bosch GmbH    Waiblingen D-71332  Germany
Aug 20, 2009 Suited for variety of food and non-food applications, intermittent SVI Series produces bags with corner seal and doy style bags with optional zippers. Production of doy style bag can be performed by turning machine cross seal jaws to 90° position. With outputs from 10-120 bags/min, SVI 4020 packages bags with max width of 400 mm, while SVI 2620 forms bags with max width of 260 mm. There is no need to adapt machine height or dosing platform when package style is changed.

DEK    Rolling Meadows, IL 60006
Aug 18, 2009 With Cp greater than 2@±12.5 µm and 7 µm Total Thickness Variation, process capability of its DirEKt Coat(TM) wafer coating technology effectively addresses needs of current and future thinned wafer products. Backside coating technique, capable of depositing 25 µm thick coatings onto wafers as thin as 150 µm, promotes accelerated processing times and optimizes chip footprints. Parallel process can deposit materials on wafers as large as 200 mm in one stroke, increasing processing speed.

MAG IAS, LLC    Erlanger, KY 41018
Aug 18, 2009 Providing 5-axis contouring with no chip attendant, blow-off, or re-cutting, H12000 HyperMach(TM) Processing Cell allows horizontal part loading on 39.4 x 6.5 ft pallet for machining of aluminum or titanium aerospace parts such as wing spars, ribs, fuselage frames, and floor components. Featuring full-portal, closed-loop construction and scale/encoder feedback on all 5 axes, cell-ready machine offers choice of 30,000 rpm/100 kW HSK63A or 20,000 rpm/85 kW HSK100A motorized spindles.

Yasda Precision America Corporation    Elk Grove Village, IL 60007
Aug 11, 2009 Able to machine hard materials in complicated shapes, 5-axis YBM-Vi40 Jig borer can tilt work pieces and features cutting feed rates of 2,000 mm/min with surface roughness of Ra 0.25 µm. Device integrates rotary B/C-axis on Y-axis, maximizing control, rigid worm gear mechanism providing high reduction ratio for tilting axis, and Thermal Distortion Stabilized System. Borer features spindle speeds up to 24,000 rpm and offers 3+2 axes, 4+1 axes, and all axes simultaneous machining options.

DEK    Rolling Meadows, IL 60006
Aug 07, 2009 Designed to handle delicate wafer products, Galaxy Thin Wafer System uses wafer pallet to secure wafers as thin as 75 µm during transport and processing. Approximately 400 mm square, wafer pallet is flat to less than 10 µm and can accommodate wafers as large as 300 mm. System's DirEKt Coat(TM) process for deposition of 25 µm thick die attach adhesives and other coatings boasts process capability of Cp greater than 2 at ±12.5 µm and TTV as low as 7 µm on 150 µm thin wafers as large as 200 mm dia.

Datron Dynamics, Inc.    Milford, NH 03055
Aug 04, 2009 With useable machining area of 60 x 40 in., ML-1500 is suited for sheet material, lengthy extrusions, and large-run batch machining. Design elements include solid-granite, vibration-dampened construction with precision linear guides as well as high-frequency spindles up to 60,000 rpm and minimal-quantity, electronically measured, spray-mist coolant system. Windows®-based controller works with any CAD/CAM software, and integrated vacuum table is optional.

Powr-Flite    Fort Worth, TX 76140
Jul 28, 2009 Environmentally friendly, multistep Diamabrush concrete polishing floor system includes Millennium floor machine, concrete tool, and 5 different blades varying from 100 to 2,000 grit. Different grit blades allow user to choose desired floor finish level from moderate gloss to high-gloss, retail-store-like finish.
