Water Jet Cutting Machines
(Showing headlines 1 - 20) more ....
|
Waterjet System features 8 x 13 ft work envelope.Jet Edge
St. Michael, MN 55376
Aug 28, 2008
Equipped with exposed tank that accommodates overhead loading, Mid Rail Gantry Waterjet System features 1 abrasivejet cutting head, but can accommodate second head to increase productivity. Ball-screw driven with heavy-wall tubular steel construction to eliminate vibration, Mid Rail Gantry utilizes direct-coupled ac brushless digital servo motors and single or double carriages. Industrial PC controller can be configured so that all 3 axes are fully programmable.
|
 Waterjet System suits large scale precision machining.OMAX Corp.
Kent, WA 98032
Jul 18, 2008
Measuring 265 x 152 in., Model 80X JetMachining® Center has Intelli-TRAX traction drive that enables expansion of cutting envelope to 20 ft. It features X-Y travel of 165 x 80 in., Intelli-MAX® Software, programmable motorized Z-axis with precision MAXJET® 5 Nozzle Assembly, high pressure direct drive pump, and rapid water level control for submerged cutting. System can calculate velocity of tool path at over 2,000 points/in., enabling complete control over motion of abrasivejet.
|
 Waterjet Cutting Head utilizes Roctec 500® mixing chamber.AccuStream, Inc.
New Brighton, MN 55112
Jun 30, 2008
DiaLine features embedded diamond orifice, which helps eliminate misalignment and wear that is sometimes caused by damaged ruby orifices. It is equipped with abrasive flow concept that ensures proper protection of diamond orifice and maximizes life of diamond. Cutting head adapts to all major manufacturers on/off valves.
|
 Patterned Glass is custom-made in over 90 styles.GrayGlass
Queens Village, NY 11429
Jun 06, 2008
Made possible by precision CNC machining and water jet cutting capabilities, Patterned Glass is available in clear soda lime, low iron, and borosilicate from over 90 different styles and can be tempered or laminated for safety glazing. Decorative glass styles include clear, opaque, etched, colored, and mirror. Customizable for all engineering specifications, all glass styles are available for cutting and sizing, hole drilling, polishing, laminating, etching, and UV bonding.
|
 Water Jet Lance has UHP seal that lasts average of 40 hr.NLB Corporation
Wixom, MI 48393 2824
May 27, 2008
Featuring dual-trigger operation and instant pressure dump, Model NCG8450A-3 delivers UHP water (up to 40,000 psi) with rotating action, widening spray pattern and making product removal productive. Unit is used with multi-orifice heads, which suit variety of applications. Rotation speed is variable up to 3,000 rpm, and is provided by air-driven swivel. Available with 36 in. barrel, field-repairable lance requires NLB 8488 Bi-Mode(TM) valve and hose assembly.
|
 Dual Pump Package enables waterjet cutting at 80 hp.OMAX Corp.
Kent, WA 98032
Apr 01, 2008
Designed for shops that specialize in cutting thick, difficult-to-machine materials, Dual Pump Package operates both pumps at optimum efficiency and offers seal life in excess of 500 hr. Direct drive plunger pump, Model P4055V is driven by variable speed electric motor for variable output pressure. Based on single design platform, pump delivers more than 90% of electrical input power to cutting nozzle. Variable frequency drive prevents in-rush of current upon starting pump.
|
 Waterjet Cutter is optimized for handling large sheets.Bystronic, Inc.
Hauppauge, NY 11788 3904
Feb 20, 2008
Suited for steel service centers, Byjet L series features modular base frame that can be expanded in 6.5 ft increments and cutting areas from 6.5 x 10 ft (Byjet L 2030) to 52.5 x 10 ft (Byjet L 16030). All models include 2 High Precision Technology abrasive waterjet cutting heads with automatic head spacing, height sensing, and collision protection. Optional third and fourth cutting heads are available, and removable cassettes facilitate and accelerate material loading and unloading.
|
 Water Jet Lance offers 60 sec cartridge change.NLB Corporation
Wixom, MI 48393 2824
Feb 07, 2008
Weighing 13.5 lb, Model NCG40-286 40,000 psi water jet lance features trigger design that requires light squeeze to initiate water jet action, and operator can dump pressure by pushing trigger forward. One-finger latch prevents accidental actuation, and hand grip and shoulder stock are adjustable to suit operator. When used with company's Viper 40(TM) self-rotating head, lance produces rotating water jet action without compressed air.
|
Abrasive Waterjet System measures 131 x 95 in.OMAX Corp.
Kent, WA 98032
Jan 24, 2008
Suited for short run part production, JIT manufacturing, tooling, and prototype art development of material sizes up to 5 x 5 ft, Model 5555 JetMachining® Center does not require tool changes or fixturing. It comes with standard motion control technology which incorporates Windows® XP software, and has accuracy of motion up to .003 in. System calculates velocity of tool path at over 2,000 points/in., allowing for control over motion of abrasive jet and enabling precise machining.
|
 Machining Center cuts large parts from stock up to 5 x 10 ft.OMAX Corp.
Kent, WA 98032
Dec 12, 2007
Model 60120 JetMachining® Center abrasive waterjet cuts ceramics, composites, glass and stone, aluminum, tool steel, stainless steel, and titanium with accuracy of motion up to .003 in. It calculates velocity of tool path at over 2,000 points per inch, allowing for complete control over motion of abrasive jet. Unit features Compute First - Move Later motion control technology, abrasive feed system, MAXJET® 5 Diamond Nozzle Assembly, and ultra-high pressure direct drive pump.
|
Waterjet Trimming System comes with robot controller.KMT Robotic Solutions, Inc.
Auburn Hills, MI 48326
Oct 19, 2007
Designed for waterjet trimming of headliners, carpets, dashboards, and insulation products in automotive interior industry, Cutting Box Original V can be customized to meet specific trimming needs, and comes with IRC5 robot controller for single and multi move operation. System can be equipped with 6 different and pre-designed robot configurations. It features HMI, tailor-made vacuum systems, and WaterjetWare robot software that helps customers reduce online programming time.
|
Waterjet Machine targets medical manufacturers.MC Machinery Systems
Wood Dale, IL 60191
Sep 26, 2007
Constructed of all stainless steel with fully enclosed work area, MD+JET is available with 1 or 2 heads and is equipped with Mitsubishi 700 Series Control, which provides advanced programming capabilities from separate pedestal. Suprema's 4-axis software features Intelligent Tapering Control, which corrects tapering of cut automatically. Exclusive 5-axis Evolution 3D System uses self-positioning device on material to maintain constant distance from nozzle to workpiece.
|
 Laser and Waterjet Cutters feature CNC control.MC Machinery Systems
Wood Dale, IL 60191
Sep 06, 2007
With resonators available in 4,000 and 6,000 W, NX series features structural configuration that allows optimal G-force and height sensor that promotes accelerated cutting. Also available, 4-axis Waterjet Suprema(TM) series features Intelligent Tapering Control software that automatically corrects natural tapering of cut. CNC control inclines water jet head up to ±2° while pointing jet towards cutting direction. Both series are both operated via Mitsubishi 700 Series Control.
|
 High Pressure Multi-Gun Valve is field repairable.NLB Corporation
Wixom, MI 48393 2824
Sep 06, 2007
Designed for operating pressures from 4,000-15,000 psi and flows up to 30 gpm per side, Model MGV15-3000 comes with disposable screw-in cartridge seal that can be replaced at job site in less than 5 minutes. It comes with mounting plate, guard, pressure gauge, and NPT couplers for inlet/outlet connections, and can be used with any dump-style water jet lance. Each operator independently controls loading and dumping of its own lance, and nozzles in lances can be of different sizes.
|
Waterjet Machining Center provides 87,000 psi cutting.Flow International Corp.
Kent, WA 98032 2618
Aug 22, 2007
Equipped with HyperJet pumps, Model WMC2 cuts parts out of almost any material, including metal, stone, plastics, composites, glass, ceramics, and rubber up to 8 in. thick with no heat-affected zone. Machine minimizes abrasive consumption while producing taper-free parts. Modular design adapts as user's needs change.
|
Waterjet Cutting Tool is designed with few parts.KMT Water Jet Systems, Inc.
Baxter Springs, KS 66713
Jun 21, 2007
IDE(TM) (Integrated Diamond Eductor) Assembly abrasive waterjet cutting head combines head body, orifice, and mixing chamber into one piece, which eliminates guesswork on individual piece wear and tear. It is based on coalescing plenum design for mixing of water and abrasive that minimizes jet stream disruption. Permanently mounted diamond orifice helps prevent mis-alignment or breakage.
|
Water Jet Pump features 6 pressure options.NLB Corporation
Wixom, MI 48393 2824
Jun 20, 2007
NLB 125 Series convertible high-pressure water jet pumps can be converted without manifold changes to run at 6 different pressures. Pump can operate at 6,000, 8,000, 10,000, 15,000, 20,000, and 24,000 psi. Series features flow ranges of 6.5-32.5 gpm, 115, 125, or 145 hp diesel or electric engine, and conversion kits. Applications include contractor and industrial uses such as, surface preparation, coatings removal, and concrete hydro demolition.
|
 Cutting Systems employ laser and water mediums.Bystronic, Inc.
Hauppauge, NY 11788 3904
Jan 17, 2007
Occupying 20 ft², ByVention laser cutting machine handles material up to 5 x 10 ft and is capable of round-the-clock operation. It has integrated safety system and operating area completely accessible without photoelectric barriers. Also available, Byjet waterjet cutting machine is available with shuttle table and swing arm loader as well as rotary axis. It supports multiple cutting heads and employs constant height sensing feature. Parts are produced with minimal kerf angles.
|
 Waterjet Cutting Head has quick-change orifice design.KMT Water Jet Systems, Inc.
Baxter Springs, KS 66713
Oct 04, 2006
Autoline II(TM) abrasive cutting head is designed for quick, tool-less orifice changes. Size and placement of wear insert accelerates replacement, and abrasive inlet facilitates connection of abrasive feed line. Weep hole indicates whether orifice is seated correctly. While ideal ratio between focusing tube and orifice is 3:1, using 2.2:1 or 2:1 ratio allows faster cutting at cost of shorter focusing tube life. Product uses abrasive efficiently for optimal cut speeds.
|
Waterjet Cutting Systems produce precision parts.Flow International Corp.
Kent, WA 98032 2618
Sep 21, 2006
Featuring HyperPressure Technology, IFB waterjet machine incorporates 87,000 psi waterjet cutting to optimize cutting speeds and jet efficiency while minimizing abrasive consumption and part taper. MicroJet Waterjet Cutting System, built to perform precision machining, complements EDM operations and can cut and drill holes with same machine. Small envelope waterjet system cuts with kerf width of 0.015 in. and radius of 0.0075 in. for fine parts manufacturing.
|
(Showing headlines 1 - 20) more ....
|
