Sawing & Cutoff Machines
(Showing headlines 1 - 20) more ....
Precision Waterjet Cutting System conserves materials and power.
Itasca, IL 60143
Dec 04, 2013
Occupying 57 x 81 in. footprint, Katana2 precision waterjet cutter is suited for cutting titanium, stainless-steel, CFRP, and other hard materials (such as copper or glass). Extra-fine abrasive nozzle enables system to achieve cutting diameters down to 0.012 in. at pressures up to 43,500 psi. System's design minimizes abrasive materials use as well as power consumption.
Fiber Laser Cutting System offers ±0.05 in. position accuracy.
NTC America Corporation
Novi, MI 48377
Dec 03, 2013
Cantilever-style TLH models offer control system and teach pendant for facilitated operation. With optimized readability and touchscreen activation, 06R controller accelerates processing. Teach pendant, along with 0.5 sec response time, has ergonomic design and automatic shut off safety feature that initiates if one of 2 required hands is removed from unit. Both models TLH-414N, with shuttle pallet system, and TLH-408N, with 110 in. dia rotary table, offer cutting speeds to 1,575 ipm.
Test Strip Cutter reduces waste and tooling expense.
Fairfield, NJ 07004
Nov 26, 2013
Using rotary shear cut blades driven by digital motors, touchscreen-operated AZCO test strip cutter allows original format of diagnostic test sheets to be cut into individual strips. First station cuts diagnostic sheet into 10 individual cards, and second station cuts cards into 50, 6 mm strips. After diagnostic sheet/card is fed into unit, it automatically cuts to size and feeds strips onto out-feed tray. Optic eye registration sensor allows for ±.006 in. accuracy at rate of 1,000 strips/min.
Power Skiving Systems produce internal gears.
Rochester, NY 14692 2970
Nov 11, 2013
Available for workpieces up to 700 mm in diameter, Power Skiving Systems are suited for production of internal gears, and for all gears with interfering contours and features. Machines utilize extremely rigid guideways, oversized spindles, and rigid bearings. Profile modifications as well as tooth tip chamfer can be built into cutter while lead modifications are realized by additional movements of axes. With software, users can simulate cutting process and plan most effective process strategy.
Bandsaw increases output while lowering power consumption.
Behringer Saws, Inc.
Morgantown, PA 19543
Nov 05, 2013
Designed for high-production metal cutting operations, HBE Dynamic Series utilizes frequency-controlled blade drive motor. Gearing in drive optimizes blade power and speed for maximum cutting and peak throughput rates, while horsepower (3.4–6.4 hp) and efficiency of drive lend to power consumption reduction. Offering blade speed ranges from 50–350 fpm, all 4 models automatically adjusts blade pressure as needed to create optimum balance between feed rate and blade pressure.
Automatic Circular Saw supports infeed/outfeed options.
Southampton United Kingdom
Oct 28, 2013
Able to process materials with tensile strength up to 1,400 N/mm², KASTOgripspeed C10 employs tungsten carbide tipped saw blades. Coated or cermet blades are used for some materials. Along with equipment for continuous stock infeed, saw accommodates various outfeed options. Cutting range is 15–100 mm dia for rounds or up to 80 mm for square stock. Infinite variability applies to infeed speed (10–4,000 mm/min), blade speed (17–175 m/min), and workpiece clamping force (2–12.5 kN).
2D Laser Cutting Machine supports high-speed operation.
Mazak Optonics Corp.
Elgin, IL 60124
Oct 14, 2013
Available with 2.5 or 4 kW resonator, TUBE GEAR can process round and rectangular tube and pipe with diameters up to 6 in., has standard 5 in. Servo Focus torch, and can make cuts at rapid traverse rate of up to 6,299 ipm. Triple chuck system minimizes warp and material vibration, allowing accurate, high-speed processing of material up to 21.3 ft long, while bundle material load/unload system increases throughput for lot sizes up to 4.2 tons. Automated calibration function is standard.
Waterjet Cutting Machines target carpet and turf industries.
Dalton, GA 30721
Oct 11, 2013
Available in variety of sizes ranging from 10–16 ft wide by as long as needed, Cobra Series is best suited for large areas, which allows for mass production and cutting of large materials. Linear drive belt maximizes speed and acceleration on all axes, while additional cutting heads enable double production on same machine. Other features include stainless steel covers, central controller for all modules, and optimized CAM software.
Pipe Cutting Machines virtually eliminate burrs.
Reading, PA 19605
Oct 01, 2013
Suited for high strength materials found in Oil Country Tubular Goods and other demanding applications, RingSaw Machines rotate blade by turning outside diameter, using enlarged center hole for cutting instead of traditional spindle design. Milling-type carbide inserts optimize material removal rates and produce large chips that do not stick to machine's sides. Machines are equipped to support wet or dry cutting, integral cutting fluid, and chip management systems.
Tube Laser System accepts raw tubes to 24 ft.
AltaMAR Laser & Control Inc.
Fridley, MN 55432
Sep 20, 2013
Equipped with 1,000 W fiber laser, Model LT2012 processes small round tubes from 1/8–3 in. diameter, and square and rectangular tubes to 2 x 2 in. System is capable of cutting mild steel, stainless, aluminum, or copper. LT2012 can produce completed parts in one process – end profiles and internal features are cut in one pass. With touchscreen interface and magazine style in-feed, machine can handle quantities ranging from a few parts to tens of thousands of parts.
Six-Axis Laser System processes 2D and 3D components.
Prima Power North America
Arlington Heights, IL 60005
Sep 19, 2013
Used for cutting, welding, and drilling of 2D and 3D component parts, LASERDYNE 430 series accommodates market segments requiring manufacturing flexibility, rapid prototyping, and accelerated changeovers. System can also integrate BeamDirector® motion and process control capabilities coupled with fiber laser; contouring head provides C (rotary) axis motion of 900° and D (tilt) axis motion of 300°. System operates at up to 800 ipm in all axes with bidirectional accuracy of 0.0005 in.
Grooving/Cut-Off System offers plunging and turning geometry.
Latrobe, PA 15650
Sep 18, 2013
Providing precise insert positioning and overall system rigidity, WMT™ Grooving and Cut-off System is available with PH geometry, designed for plunging and turning in materials harder than 35 HRC or in heavily interrupted cuts across broad range of work materials such as steel, stainless steel, aluminum, cast iron, and high-temperature alloys. PH WMT insert has 90° top and bottom clamping design, rigid cutting edges, and positive geometry.
CO2 Laser offers large engraving table in optimized footprint.
Epilog Laser Corp.
Golden, CO 80403
Sep 11, 2013
Available in up to 120 W configurations, Fusion 40 has 40 x 28 in. engraving table and is designed to maximize engraving space while optimizing physical footprint. Motion control system allows for high-speed engraving and precision cutting, while joystick control allows operators to move table and fire laser directly. Along with industrial DC servo motors, features include drop-down front door and job management software with job-time estimator.
Circular Saw Blade features FMF Mexican Soccer logo.
Makita U.S.A., Inc.
La Mirada, CA 90638
Aug 13, 2013
Intended for Hispanic contractors that follow FMF soccer, 7 ¼ in. 24T FMF Framing Blade is engineered with 24 teeth, each of which has M shape with 2 cutting points for quick cuts with smooth finish. Blade is ultra-coated to minimize pitch built-up, and has high-grade C-3 fine-grain tungsten carbide tips for durability. Blade is suitable for cutting rough framing lumber, pressure treated wood, plywood, OSB, and other engineered lumber.
Laser Tube Cutting System handles small to medium-sized tubes.
BLM Group USA
Wixom, MI 48393
Aug 01, 2013
Equipped with 1 kW IPG fiber laser, Lasertube LT5 cuts stainless steel up to 4 mm thick, mild steel up to 6 mm, aluminum and brass up to 3 mm, and copper up to 2 mm. Compared to CO2 laser, fiber laser offers optimized energy efficiency while eliminating routine maintenance and optical beam alignments. Automated cutting system can handle round tubes up to 120 mm in diameter, square tubes up to 100 mm, and rectangles, ovals, and elliptical semi-flat/full up to 120 x 70 mm.
Roll Slabbing and Core Recycling System handles non-wovens.
Appleton Mfg. Div., Productive Solutions, Inc.
Neenah, WI 54957
Jul 29, 2013
Designed to handle roll sizes ranging from 10–62 in. in length with ODs from 18–64 in. and core IDs from 6.0–6.75 in., Slabber XLA™ for Non-Wovens includes conveyor for loading and moving rolls onto slabbing arm, laser to assist with roll positioning, and programmable cutting device mounted at top of enclosed cutting area. Automated system provides programmed vertical lifting of roll for each cutting pass. Exit conveyor or elevator moves waste material to downstream processes.
Water Jet System cuts taper-free and beveled parts.
St. Michael, MN 55376
Jul 22, 2013
Featuring Permalign® EDGE technology, EDGE X-5 can cut chamfers, weld bevels, and sophisticated 3D parts from virtually any material. Five-axis system includes AquaVision Di® Controller with open architecture design that enables operators to fine-tune programs from any CAD/CAM/nesting software, using standard G&M code. Ranging in size from 5 x 5 to 24 x 13 ft, system is ball-screw driven with direct-coupled AC brushless digital servo motors, single or double carriages, and 30–200 hp pumps.
Scrap Chopper facilitates recycling of plastic and PET banding.
Sweed Machinery, Inc.
Gold Hill, OR 97525
Jul 19, 2013
Model 450 DX handles high volumes of ¾ in. steel banding with clips, plastic banding, lightweight wire, and other manufacturing byproducts. Single-drive feedworks and infeed width aid feeding of scrap material, accommodating large handfuls at ~106 fpm. One stationary and one rotating knife provide cut length of ~3 in., while 1 hp motor and external flywheel provides cutting capacity for tough materials. Unit also accommodates in-line placement to process slitter-line trim and tube scarf.
Waterjet Cutting Systems deliver high-speed operation.
Tallmadge, OH 44278
Jul 18, 2013
Using belt drive technology, J-Series modular, water-only waterjet cuts at speeds of 2,500 ipm with acceleration and deceleration rate of 0.2 m/s². Machines can also accommodate addition of material handling solutions. Using linear motion drive system, L-Series can be used for water-only or abrasive cutting at speeds of 7,000 ipm with acceleration and deceleration rate of 1 m/s². Frame is of thick-walled steel tubing, and design can accommodate multiple 5-axis cutting heads.
Portable Bandsaw Mill meets needs of global customers.
Buffalo, NY 14225
Jul 17, 2013
With 70 cm throat opening and ability to handle logs up to 90 cm in diameter, LumberPro HD36 enables sawyers to mill virtually any hardwood or softwood tree into valuable lumber. System features auto-locking sawhead, auto-on/off blade lube, and laminated sawhead construction. Wide-track log deck is built of twin double-plated commercial-grade steel rails. LumberPro HD36 can be configured manually or hydraulically, or combination of both.
(Showing headlines 1 - 20) more ....
