Servo Roll Former handles tube ODs up to 3/4 in. .

November 25, 2014

Featuring servo driven ball screw unit, Servo Roll Former has max jaw opening of 1.25 in. and is driven by 5 hp variable speed Hause Head. Machine operates by advancing and closing spinning head containing either rolling or cutting tools over clamped tube. Through machine's HMI, depth of rolled or cut grooves can be adjusted. Measuring 48 x 72 x 72 in., ISO 9001:2008 Certified roll forming machine requires 40–80 psi and 3 cfm. Read More

Machinery & Machining Tools

Roll Bending Machine uses 3 radial piston hydraulic motors.

March 24, 2011

Series 3000, 6 in. capacity Model 310HV4 Universal Angle Roll features horizontal layout and double pinch geometry which allows prebending on both ends of material. Suited for use in machine pit, 6 x 8 x 7 ft unit has articulated overhead pendant control arm with joysticks and hydraulic drive train with infinitely variable speed rotation. Machine has 2 LED digital displays to monitor bending roll positions and 6 LED displays to monitor lateral material guide positions. Read More

Machinery & Machining Tools

Hydraulic Machine combines end forming and roll forming.

July 30, 2010

Featuring 72 x 96 in. footprint, Model M10-H3-R includes programmable control system and diagnostics for machine maintenance. Tube end forms that require both end forming and roll forming processes can be completed without staging of materials between processes. Model M10-H3-R can also be designed with 6-position end form station for tube end forms that require components to be assembled onto tube before rolling processes. Read More

Machinery & Machining Tools

Blown Film Surface Winder handles up to 60 in. dia rolls.

July 16, 2010

Available in widths from 44-134 in., AC-driven SLC (SLiding Carriage) Series employs pneumatic cylinders for controlling winding force and is capable of winding rolls on 3 or 6 in. cores. Finished roll unloading system is independent from winding transfer cycle sequence, while roll carts and shaft handling are available to add automation. Other features include horizontal flat bed design, touch screen controls for winder settings, and 2 center slitters for multiple lane production. Read More

Packaging Equipment, Machinery & Machining Tools, Materials & Material Processing

Sheet Extrusion System suits inline thermoforming/roll stock.

June 17, 2009

Offered in monolayer or coextrusion formats, GLOBALINE® produces sheet from materials such as PP, PS, PET, and polylactic acid in widths of 40 or 60 in. It can be configured for production outputs between 650-3,900 lb/hr. Design includes linear bearing mounted frame infrastructure; pivoting extruder base via hydraulic jacking system, simplifying screw removal/maintenance; and touchscreen controls. Available in NPE version for inline thermoforming or full-length for producing roll stock. Read More

Machinery & Machining Tools

Roll Bender operates in vertical or horizontal position.

April 14, 2009

Model R-M55H utilizes single pinch hydraulic adjustment for bending variety of materials. Bending speed can be adjusted through variable speed, thermal overload protected Siemens inverter drive system coupled to direct drive gearbox, and independent operator station features programmable digital readout of roll position for accurate, repeatable bends. Hardened segment rolls are included along with adjustable guide rolls to assist with coiling operations. Read More

Material Handling & Storage, Machinery & Machining Tools

Roll Former winds stretch film material without core.

July 31, 2008

Eliminating need for cardboard tube core, NO.EL Coreless Rewinder II enables winding of stretch film material into standard-sized roll so stretch film supports roll's structure. System operates offline and delivers standard rolls for automatic and manual wrapping applications. For automatic feeding, internal reel diameter is 3 in., with 3,600-4,800 ft of material supported, while for manual applications, minimum diameter of 1.5 in. and above, and 600-1,640 ft of material, is supported. Read More

Portable Tools, Machinery & Machining Tools, Services

Angle Rolls feature 40 mm forged roll shafts.

May 8, 2008

Capable of bending wide range of profiles and materials to centerline radius as small as 4 times diameter of workpiece, Ercolina CE35 Angle Rolls offer capacity of 1½ in. schedule 40 pipe and 1½ in. angle iron. Units are designed to operate in vertical or horizontal position with roll speed up to 20 fpm. All include remote foot pedal for hands-free operation. With single-phase 220 V connection, machines are suited for shop and jobsite fabrication. Read More

Machinery & Machining Tools, Materials & Material Processing, Services

Angle Profiles are galvanized for corrosion protection.

September 21, 2006

Made from high-strength steel and manufactured to application requirements, roll-formed Flo-Form(TM) Angle Profiles feature multi-layer protective coating that consists of 99.99% pure zinc, conversion coating, and clear organic topcoat to seal surface. Topcoat acts as natural primer, minimizing labor involved with pre-paint surface preparation. With in-line galvanizing process, pre-punched holes are coated and protected like remaining surface. Read More

Machinery & Machining Tools

Thread and Form Rolling System offers automated operation.

September 18, 2006

Integrating Fanuc robot with Kinefac® MC-15 FI CNC Kine-Roller®, Robo Roller production system is designed for rolling threads, knurls, worms, and other forms on bolts, shafts, and similar parts. It lets users utilize automated rolling from pallet system, bulk feed unit, hopper feed, manual load-unload station, or in conveyorized system. Machine handles parts weighing up to 3 lb, and each die spindle has independent servo drive system. Read More

Machinery & Machining Tools

Angle Roll bends heavy materials.

May 18, 2005

Able to operate in horizontal or vertical position, CE100 has solid steel frame fitted with conical roller bearings on all shafts. For driving power and bending speed up to 20 fpm, unit features separate drive motors for each drive shaft, which are coupled to oil-filled reduction gearboxes. Center roll is hydraulically positioned using joystick control, digital readout monitors center roll position, and programmable control allows for multiple programs and infinite passes. Read More

Machinery & Machining Tools, Services

Roll Bending Service is offered for multiple materials.

May 12, 2005

Angle roll bending services are provided for materials such as aluminum, steel, stainless steel, brass, and bronze. Tooling exists for bending shapes, including round pipe, round and square tube, angles, and channel up to 4.50 in. OD. Other services are provided via CNC measuring devices and pipe and tube cleaning, finishing, and forming machines. Read More

Machinery & Machining Tools

Controller works with portable roll forming machines.

January 6, 2003

Model MP550 features graphics- and symbols-driven menu presented on 2.5 x 4.5 in. LCD screen, which can easily be viewed in low-light or bright-light conditions. Controller includes ¼ in. thick cast aluminum case made weather-tight with built-in, temperature-controlled heat source for cold weather environments. Full-sized, 20-key keypad is sealed against elements, fingertip grime, and airborne dust and grit. Read More
