Electrode Forming Machines

Machinery & Machining Tools

Accessories optimize tungsten grinder performance.

April 10, 2008

Suited for Triad(TM) Tungsten Grinder, Cutting Holder accessory safely cuts 0.040, 1/16, and 3/32 in. diameter tungsten to fixed length of 15/32, 33/64, 19/32, and 43/64 in. Double-Decker Kit allows second, rough-finish grinding wheel to be attached to grinder. Second wheel is included in kit and is intended for scrubbing and/or preparing larger diameter tungsten (3/32 or 1/8 in.). To prevent tungsten contamination, protective Dust Cover attaches to grinding head. Read More

Machinery & Machining Tools

Tungsten Electrode Grinder provides operational clarity.

September 21, 2007

Techweld TEG-3 uses diamond wheel to produce ground and polished electrode tips necessary for TIG and plasma welding. Designed in 6 o'clock position, grinding head ensures dust is expelled downwards, directly towards vacuum collection point, to help machine operator see grinding progress. Machine grinds electrodes longitudinally, and its holding system accommodates electrode sizes from 1.6-4 mm. Front cover prevents grinding of other materials. Read More

Machinery & Machining Tools, Materials & Material Processing

Tungsten Grinder features precision-drilled entries.

June 25, 2007

Triad(TM) (TTG Plus) tungsten grinder accommodates 6 different tungsten electrode diameters including 0.040, 1/16, 5/64, 3/32, 1/8, and 5/32 in., and offers 4 different grinding angles such as 15, 18, 22.5, and 30º. Industrial-grade motor provides consistent cutting and facing capabilities (up to 5/32 in.) to eliminate need for additional tungsten preparation tools. Grinder is suited for orbital or hand-held TIG applications. Read More

Machinery & Machining Tools

Tungsten Grinder includes built-in dust collection system.

January 31, 2005

Hand-held Sharpie(TM) DXV Vacuum Grinder allows dust-free electrode preparation to facilitate maintenance of clean weld environment, while delivering consistent grind angle and diamond-ground finish. Read More

Machinery & Machining Tools

Tungsten Electrode Grinder has consistent grind profile.

September 3, 2004

Able to work from 115 or 230 V input supply, WIG 10/175 grinds tungsten electrodes to exact profile for precision and orbital welding applications. Machine provides accurate grind angle with clearly scaled setting mechanism. Tungsten electrode is secured in collet and loaded into main body, where it is then introduced to diamond impregnated grinding wheel via slide. Collet is then rotated as it is introduced to grinding wheel. Read More

Machinery & Machining Tools

Tungsten-Electrode Grinder provides consistent welds.

June 7, 2004

Suited for TIG and plasma welders, Model TEG-3 employs diamond wheel that grinds tungsten electrodes longitudinally and at set angle for consistent angle and shape. Ground and polished tips prevent arc instability and require minimal resetting or re-welding. Available in 110 and 220 V, 50/60 Hz versions, grinder eliminates circumferential lines and ridges on electrodes and accommodates sizes from 1.6-4 mm. Read More

Machinery & Machining Tools

Tungsten Grinder suits nearly all welding applications.

March 25, 2003

Piranha III allows operators to grind tungsten longitudinally on diamond wheels and improve arc starting, arc stability, and electrode life. Enclosed grinding area protects operator from hazardous dust, sparks, abrasions and other injury while allowing for dust collection and disposal. Diamond grinds, flats and notches tungsten with no vibration. Piranha III grinds .040 through 3/16 in. tungsten at any angle from 10-60° with minimum length of 1.75 in. Read More

Machinery & Machining Tools

Tungsten Grinder operates with no vibration.

February 13, 2003

Piranha II allows operators to grind tungsten longitudinally on diamond wheels and improve arc starting, arc stability, and electrode life. Enclosed grinding area protects operator from hazardous dust, sparks, abrasions, and other injury while allowing dust collection and disposal. Portable unit weighs less than 10 lb and grinds .040 through 3/32 in. tungsten at any angle from 15-45° with minimum length of 1.75 in. Read More

Machinery & Machining Tools

Grinding Machine has grinding head in six o'clock position.

April 10, 2002

TEG-3 Tungsten Electrode Grinding Machine prevents dust from being thrown upwards so that users can see clearly how grinding is progressing. It is designed for grinding tips on tungsten electrodes as used in Tungsten Inert Gas and Plasma welding. Tool will axially grind all diameters of tungsten welding electrode from 1.0 to 6.4 mm and lengths down to 15 mm with collet accessory. Its electric motor is rated at either 110 or 220 V, 50/60 Hz single phase. Read More

Machinery & Machining Tools

Tungsten Grinder suits high-production use.

March 8, 2002

Sharp Shooter(TM) tungsten electrode grinder offers enclosed grinding area that collects 100% of dangerous tungsten dust. Electrode wand guarantees precision and consistency for any tungsten electrode from .040 to 3/16 in. as well as non-standard sizes. Measurable tip flat determination and no burr cutting are standard. Optional vacuum system provides 0.3 micron HEPA(TM) filter safety. Read More
