Drilling Machines

Machinery & Machining Tools, Fasteners & Hardware

Point Drill Insert supports drilling of cast materials.

January 20, 2016

In addition to optimized geometry for maximum productivity in cast iron materials, Model P6005-WKK45C has 110° prismatic seat for minimal run-out and stable positioning as well as chamfered corners for stability in abrasive conditions. Thick coating with multi-layer structure provides alternate layers of hard wear, heat, and abrasive resistance. Inserts are color-coded for easy selection and wear detection. Read More

Machinery & Machining Tools

Deep Hole Drilling Machine accelerates gundrilling/BTA changeover.

January 11, 2016

Able to change from BTA to gundrill deep hole drilling tooling, UNI-50BTA can drill 0.31–2.56 in. dia holes at depth-to-diameter ratios of 100:1 or greater. Functionality allows drilling with either tooling method within diameter range in same part without secondary operations, and pressure head design enables tool change in as little as 10 min. Available in modular lengths, machine features high-accuracy feed and zero-endplay spindles, counter rotation, and preloaded ballscrew drives. Read More

Machinery & Machining Tools

Solid Carbide Coolant Through Drill increases overall throughput.

January 8, 2016

With CTW™ (Continually Thinned Web) flute geometry that optimizes flute volume and breaks chips into small, manageable pieces, MP-X 8xD reduces machining time for operators by eliminating pecking process. Chip evacuation speed and efficacy helps reduce cost-per-hole while also increasing throughput. Promoting wear resistance and tool life, construction is of microgram carbide. Multi-layer TiAIN coating lends stability to cutting edges and provides oxidation stability. Read More

Machinery & Machining Tools

Cast Iron/Steel Drill is offered in various cutting depths.

December 16, 2015

Designed for steel and cast iron, DC170 comes in 16xD and 20xD lengths as well as 3xD, 5xD, 8xD, and 12xD dimensions. Custom-made versions are also available. In addition to orienting margins radially and with copper-color finish (DPP Coating) to optimize performance, lands feature shallow cooling grooves at drill end. Coolant flow encompasses entire drill point to benefit both drill and workpiece. Design also maximizes material behind cutting edge for sturdiness and minimized vibration. Read More

Machinery & Machining Tools

Indexable Drill supports variety of operations and materials.

October 28, 2015

Suited for machining broad assortment of products, Top Cut 4™ is capable of through- and cross-holes, inclined entry/exit opportunity, 45° corner, half-cylindrical, concave, and chain drilling. Periphery and center inserts feature proprietary cutting profiles for optimized centering and workpiece penetration. Available in 0.473–2.5 in. diameters, drill has high-stability shank in lengths of 2XD, 3XD, 4XD, and 5XD. Cutter bodies are marked by deep helix angled flutes for efficient chip evacuation. Read More

Machinery & Machining Tools

Indexable Insert Drills offer extended tool life.

October 22, 2015

With stiffer, optimized drill body, CoroDrill® 880 Series covers hole diameters from 0.472-3.307 in. off-the-shelf, as well as engineered solutions up to 5.078 in. Drills produce holes with tolerances of H12–13 and are suitable for holes up to 5 X drill diameter. GC4324 and GC4334 insert grades are designed with Inveio™ coating for wear resistance, while GC4344, produced with Zertivo™ technology, provides edge-line security as a result of optimal coating and substrate adhesion properties. Read More

Controls & Controllers, Machinery & Machining Tools

Intelligent Control System automates well chemical maintenance.

September 23, 2015

Eliminating travel to well sites, iWaV seamlessly interfaces with existing SCADA (Supervisory Control and Data Acquisition) infrastructure to completely automate well location chemical maintenance on both solar/electric as well as pneumatic driven systems. This intelligent injection control system, suited for oil and gas chemical injection, allows operator to regulate all aspects of chemical titration remotely.
Read More

Machinery & Machining Tools, Portable Tools

Magnetic Drilling Units are designed for heavy-duty applications.

September 15, 2015

Equipped with ACCUDRILL pressure indicator and material and thickness detector, ICECUT 100 (850 W, 600 rpm) and ICECUT 200 (300 and 600 rpm) promote safe and reliable use. ACCUDRILL safety amp meter in central control panel lets users optimize drilling operation productivity while preventing motor from overloading/overheating. Also included, material and thickness detector will not let drill start when magnetic holding power is insufficient to secure unit to work piece and operate safely. Read More

Machinery & Machining Tools

AlCrN-Coated, Solid Carbide Drill has multipurpose geometry.

September 8, 2015

Used for high-volume production, Universal Drill features rigid, 4-facet point geometry that maximizes centering capability, maintains IT8/9 hole tolerance, and facilitates regrind. Polished AlCrN coating promotes abrasion resistance, toughness, and chip evacuation. Available in 3–20 mm dia in 0.1 mm increments, drill can be used on such materials as steels, stainless steels, and cast irons. Through-tool coolant capability is offered by 5 x D and 3 x D length drills with cylindrical shanks. Read More

Machinery & Machining Tools, Portable Tools

Portable Magnetic Drill features automatic feed mechanism.

August 7, 2015

Suitable for production applications, MAB 825 V incorporates automatic feed mechanism with power retraction; double-insulated, 16 A, reversible motor with 4-speed oil bath gearbox; infinitely variable torque control; and full-wave electronics. Heavy-duty drill cuts holes up to 4 in. dia. in structural steel and other metals. Additional capabilities include twist drilling and reaming up to 1 ¼ in. dia, tapping up to 1 1/8 in. dia, and countersinking up to 2 in. Magnet holding force is 6,600 lb. Read More

Machinery & Machining Tools

Right-Angle Heads serve new applications with tool adapter.

August 3, 2015

U-tec® right-angle heads are available with U-tec flexible adapter system, which provides rigidity and quick-change capabilities for users performing deep hole drilling with extended tools. Flexible tool adapter system allows standard ER output live tool to accept various adapters for different applications. With polygonal drive system that ensures power transmission stability and accelerates setup, adapter enables cutting tool to be brought into close proximity to bearing. Read More

Machinery & Machining Tools

Rotary-Steerable System delivers precise directional drilling.

July 23, 2015

Featuring point-the-bit technology, Revolution® RSS delivers clean, accurately placed, and completion-ready wellbores in unconventional fields, deepwater fields, damaged and underbalanced formation, and brown fields. Advanced sensors and telemetry enable precise drilling control in long laterals, high-angle curves, and parallel vertical sections in single run. With system, operators can drill in high-pressure, high-temperature zones with temperatures exceeding 300°F. Read More

Machinery & Machining Tools

Solid Carbide Drills feature double-margin flute design.

June 22, 2015

Made of special sub-micron grain carbide grade for abrasion resistance and durability, EF Series features multi-layer PVD coating that resists chipping/cracking for extended tool life. Flute construction enables optimized chip evacuation, while self-centering design allows drilling in one shot, eliminating peck cycles and pre-spot operations. Products are available in 3XD, 5XD, and 8XD drill styles in solid and coolant-fed designs. Read More

Machinery & Machining Tools, Portable Tools

Drilling and Chamfering Tool reduces tool changes, downtime.

June 18, 2015

Able to reduce machining time by minimizing required tool changes, D4580 chamfer body provides drilling and chamfering in one tool. Product is available in 6 in. and metric body sizes with chamfer widths up to 0.011 in. (2.8 mm). Suitable for use with all corresponding solid carbide drills, tool is compatible with such materials as ISO material groups P, M, K, N, and S and suitable for all holes with 45° chamfers. Read More

Mining, Oil Drilling & Refining, Sensors, Monitors & Transducers, Machinery & Machining Tools

Monitoring System helps visualize well performance.

May 21, 2015

Designed to monitor Packers Plus multi-stage completion systems, ePLUS™ Retina™ Monitoring System lets users observe downhole events and their effects on reservoir. Self-contained unit offers clear indications of downhole operations in real-time, enabling operators to make on-the-fly operational adjustments. In addition, system optimizes reservoir stimulation and remedial operations, delivers detailed recorded data for future use, and provides redundancy for all measurements. Read More

Machinery & Machining Tools, Portable Tools

Portable Magnetic Drill facilitates positioning via swivel base.

April 6, 2015

When attached to workpiece with 8,000 lb holding force magnet, MAB 525 SB provides 20° movement left and right and 5/8 in. forward and backward. Hole cutting capacity is up to 2 ½ in. dia in structural steel and other metals, and other capabilities include twist drilling up to 1 in. dia, tapping up to 15/16 in. dia, reaming up to 7/8 in. dia, and countersinking up to 2 in. Double-insulated, 14.5 A, reversible motor has 2-speed (70–280 rpm and 180–580 rpm) oil bath gearbox. Read More

Machinery & Machining Tools

Insert Drills offer optimized clamping system, cutting material.

March 18, 2015

Featuring Walter Capto™ clamping system and indexable inserts with Tiger·tec Silver® cutting tool material, 16–45 mm dia Xtra·tec® Insert Drills can be used on materials from steel and cast iron to stainless and difficult-to-cut materials. Drills offer depth of cut of 3xD and can handle chain drilling, sloping, and convex surfaces. Indexable inserts comes in 3 geometries and 4 grades and have 4 cutting edges. Ground indexable inserts are also fitted with wiper edge for optimal finish. Read More

Machinery & Machining Tools

Solid Carbide Pilot Drill enhances deep hole productivity.

February 25, 2015

Used for drilling depths from approximately 2 x D, X•treme Pilot 180 comes in 1/8–7/8 in. dia, features internal cooling (emulsion or oil), and supports use with coolant pressures as low as 145 psi. Point angle is 180°, and corner protection chamfer maximizes reliability. Along with 4 margins for optimum alignment, features include TFT coating for protection against wear. Drill can be used for cross holes, spot-facing inclined or convex surfaces, and counterboring drilled holes. Read More

Machinery & Machining Tools

Micro Drill accelerates starter hole creation in wire EDM.

February 25, 2015

With its flute- and cutting-edge geometry, Sphinx micro deep-hole drill helps conserve time during creation of wire EDM starter holes. Functionality replaces process of plunge EDM to establish starter hole, and construction of carbide with abrasion-resistant coating promotes efficacy during use on high-strength alloyed tool steels. Holes with length/diameter ratio of up to 80 x Ø are possible in range of Ø.25–1.50 mm in steps of .1 mm for hole depths up to 20/40/60/80 x Ø. Read More

Machinery & Machining Tools

Rig-Mounted Core Drill offers multi-speed operation.

January 27, 2015

Used for drilling up to 14 in. dia holes in concrete, reinforced concrete, asphalt, and natural stone, 77 lb EBM 352/3 PSA employs 20 A motor and rugged gearbox with drilling speeds of 230, 500, and 1,030 rpm. Internal oil pump lubricates gearbox and shaft for extended life. Along with soft start and overload protection, features include mechanical slip clutch that provides protection in case of jamming. Screw jack for bracing is also included along with 39 in. tall anchor stand. Read More
