Boring Tools

Machinery & Machining Tools

Fine Boring Tool provides optimized chip control.

November 3, 2015

For trouble-free machining and close hole tolerances of IT6, CoroBore® 826 utilizes high-precision nozzle to direct coolant jet to cutting edge, efficiently controlling and breaking chips which are then evacuated from hole. Stepwise scale setting of tool diameter optimizes process security and eliminates setting mistakes, while rigid interfaces between head and cartridge ensure stable and vibration-free boring. CoroBore 826 HP meets fine boring requirements from 1.417–49.606 in. Read More

Machinery & Machining Tools, Portable Tools

Holemaking Tools are engineered for performance, durability.

September 4, 2015

Made from heavy-duty steel, holemaking products are engineered for optimized for life expectancy and performance. Bi-metal hole saws cut stainless steel, mile steel, drywall, ceiling tile, laminate, wood, and plastic. Double-fluted step drill bits have thick, extra-long, 3/8 in. hex shank that provides firm, positive grip in drill and won’t spin out. Also available, wood boring bits feature low-torque design and can change direction when drilling holes to customize shape. Read More

Machinery & Machining Tools

Boring Kit supports wide diameter range with one head.

July 9, 2015

With just one head, EWN 2-50XL Boring Kit offers precision boring solution for diameter range of .700–6.000 in. Kit features rigid, dynamic center-mounted boring bar/insert holder capable of maintaining consistent precision throughout full range. Boring head offers adjustments of Ø.0002 in./div, and coolant through is standard with max pressure of 300 psi. When using outboard insert holders, coolant nozzle inserts to center of head for direct coolant delivery to cutting edge. Read More

Machinery & Machining Tools, Fasteners & Hardware

Indexable Boring Tool permits small-hole rough boring.

July 7, 2015

With boring range of 16–21 mm diameter, MW Boring Tool is suited for semi-finish boring operations of workpieces with die cast holes. Product is built with 20 mm diameter straight shank and performs best when paired with milling chuck at fixed bore depths up to 4 x D. Spiral groove carved into body facilitates clean chip removal with help of coolant holes near end of groove. For blind-hole situations, additional center-through coolant option was added. Read More

Machinery & Machining Tools

Single Edge Fine Boring Tool features modular design.

May 4, 2015

Available in diameters from 0.078–7.992 in. with adjustment accuracy of 0.0001 in. on diameter, B3230 Walter Capto™ can be used for standard and reverse machining. Unit features internal coolant supply up to cutting edge, and is available with Walter Capto™ modular toolholding interface, as well as NCT and ScrewFit. Range of indexable inserts adapted for precision boring is available for use with tool, allowing for optimal cutting parameters to be employed for each material. Read More

Machinery & Machining Tools

Single-Edged Precision Boring Tool comes in lightweight design.

April 2, 2015

LWS (Light Weight Solution) version of Walter PrecisionMEDIUM B4031.C weighs 3.2 kg and features backlash-free Walter Capto™ modular toolholding interface. Diameters range from 90–110 mm and 110–153 mm. In addition to facilitating handling in assembly and setting area, design accommodates application where tool magazine can handle limited weight. Reduced weight also helps protect machine and spindle during acceleration and deceleration. Read More

Machinery & Machining Tools

Boring Tool System supports seal ring groove machining.

March 19, 2015

Used with CoroBore® XL System, SpiroGrooving™ utilizes spirograph tool path to create close-tolerance seal ring grooves. Parts of insert cutting edge have interrupted cutting behavior, eliminating long chips that can tangle tool and spindle. With internal coolant feature, CoreBore XL solution is suited for making seal ring grooves in pre-clad machining of steel and stainless steel components. Roughing and finishing are carried out in same operation, maximizing productivity. Read More

Machinery & Machining Tools

Asymmetric Line-Boring Bar increases process speeds, bore quality.

February 16, 2015

Asymmetric line-boring bar has supports on rotated guide pad that provide freedom to enter and exit guide part, even when passing through raw bores, while geometry allows feeding bar through raw bores on eccentric path. Such boring offers support on both ends of tool without necessitating expensive lift functions, obstructive counter bearings, or critical mechanisms inside tool. Also, complete feed-in and feed-out moves can be done at increased feed rates on conventional machining centers. Read More

Portable Tools, Machinery & Machining Tools

Counterboring, Precision Boring Tools use Capto technology.

July 2, 2014

Counterboring and precision boring tools are available with connections for Walter Capto™ adaptors, which allow multiple processes to be performed with single tooling interface. Allowing use on small and large machines, connections are available in 5 coupling sizes. Capto variants feature completely backlash-free, self-centering connection that does not require special locking device. Resistant to bending, Capto adaptor also minimizes vibration tendency. Read More

Material Handling & Storage, Machinery & Machining Tools, Green & Clean

Rotary Table Horizontal Boring Mill aids large parts production.

May 16, 2014

Designed for multi-axis contour milling, precision boring, drilling, and tapping, MC 1600 meets automated large-part production requirements for oil/gas and wind energy components up to 10 ft long and 7,000 lb. Modular design features dual 63.0 x 63.0 in. pallet shuttle system, one-piece cast iron column base and bed, and built-in 360,000 position contouring rotary table with programmable mechanical clamp and 55,000 lb part handing capacity. Feed thrust in all 3 linear axes is 6,744 lb. Read More

Mechanical Components & Assemblies, Machinery & Machining Tools, Construction Equipment & Supplies

Planetary Drive Augers feature high-torque gearbox.

February 28, 2014

Measuring 11.5 in. W x 39.6 in. L, Bobcat® 35PH and 50PH can dig to depths of 73 in. without extension. Model 35PH provides 4,177 lb-ft of torque at 3,500 psi, while Model 50HP delivers 5,291 lb-ft. Drive housing, measuring 12 in. long, allows augers to follow bit into hole to achieve maximum depth. Compatible with Bobcat skid-steer loaders, compact track loaders, all-wheel steer loaders, and compact excavators, augers are suitable for working in rock, clay, coral, and frost. Read More

Material Handling & Storage, Machinery & Machining Tools

Chuck Jaws are available up to 10 in. high.

November 26, 2013

Manufactured from 1018 steel, 4140 steel, or 6061 aluminum, DMI Series suits precision boring, tapping, drilling, and finishing operations. Extended jaws lengths, with heights available to 10 in., promote workpiece stability and allow multiple uses of blank before it is consumed. Also, length lets machinist avoid extra time and expense associated with welding and bracing needed to lengthen standard height top jaw. Products are available in all standard chuck mounting styles.
Read More

Machinery & Machining Tools

Vertical Jig Boring-Milling Machine is repeatable, thermally stable.

November 18, 2013

Three-axis CNC vertical jig borer, Yasda YBM 640V3, performs high-speed, precision boring and milling operations for mold, die, and complex component manufacturing in aerospace, automotive, medical, and defense industries. In addition to 27.5 x 17.7 in. table with loading capacity of 661 lb, features include respective X-, Y-, and Z-axis travels of 23.6, 15.7, and 13.8 in; standard spindle speed of up to 24,000 rpm (30,000 rpm optional); and 7/24 taper, No. 40 spindle taper hole. Read More

Machinery & Machining Tools, Mechanical Power Transmission, Mounting & Attaching Products

Heads, Cutters, and Holders offer exchangeable head coupling.

October 22, 2013

Compatible with solid carbide heads, indexable milling cutters, boring heads, integrated machine adapters, and different shanks, Exchangeable Head Coupling is based on self-centering screw thread for secure mounting. Physical stop enables users to feel when head is correctly tightened and helps to not overstress clamping. Conical portion is shaped to provide best run-out, while pre-loaded taper and flange contacts provide optimized modular connection with extreme rigidity. Read More

Machinery & Machining Tools, Services

Fine-Boring System achieves closed-loop operation.

June 21, 2013

Allowing users to dial in tolerances while tool is mounted in machine tool, Romicron® systems produce high-accuracy holes at high RPMs. Users can produce finish bores with tolerances of few microns in diameter and bore-to-bore variations of few tenths of one micron. Using cartridges or boring bars, every tool can be adjusted in diameter via dial ring in 2 micron increments to achieve close tolerances. Romicron AVS tooling covers 0.984–3.11 in. dia and can run in spindles up to 20,000 rpm. Read More

Machinery & Machining Tools

Finish Boring Head targets micro-machining applications.

February 22, 2013

Offered in diameters from Ø.016-.276 in. with max through-tool coolant pressure of 300 psi, Series EWN 04-7 is intended for use on micro-milling machines with high-speed spindles such as HSK-E25, E32, or E40. Product features high precision adjustment accuracy of .0005 in./Ø and .0001 in./Ø through use of Vernier scale. Available with Kaiser KA1 modular connection or Ø10 mm straight shank, head can accept boring bars with Ø4 mm shanks. Read More

Machinery & Machining Tools

Digital Boring Heads feature IP69K seal rating.

February 6, 2013

Kaiser Series 310 EWD Precision Finish Digital Boring Heads cover 1.614–8.000 in. dia range, feature through-spindle coolant capability with directional coolant ports, and can perform back boring operations via reversal of insert holder. Kaiser Series 318 Large Diameter Finish Boring System features digital display and is based on aluminum extension slides. Supporting variety of aluminum as well as some steel components, series also features through-tool coolant supply to cutting edge. Read More

Machinery & Machining Tools

Earth Auger complements portable, hand-held hole diggers.

November 16, 2012

Cast into one-piece, integral assembly from steel to promote service life, 4450 Series serves such industries as rental, fencing, landscaping, and general construction. Screw bit design has male shaft that slides into end of earth auger, accelerating installation process, and reduces risk of screw bit breaking as well as resulting damage to auger. Tooth position and location on screw bits have been optimized via computer 3D simulation, and optional tooth configurations are available. Read More

Portable Tools, Machinery & Machining Tools

Welding End Prep Tool features variable speed 14 A motor.

April 18, 2012

Esco Electric Wart MILLHOG® performs any angle of end prep and bevel, face, and bore simultaneously to produce clean, smooth, and square end preps. Designed for for applications where compressed air is not available, tool features Metalbo® 14 A electric grinder motor and gear reduction mechanism that produce variable speeds from 100-200 rpm. Portable tool is able to machine highly alloyed stainless steel pipe and tube from 3/4 in. ID to 4½ in. OD without requiring cutting oils. Read More

Machinery & Machining Tools

Boring Head includes built-in digital display.

February 16, 2012

Providing through-tool coolant supply and max spindle speed of 20,000 rpm, Series 112 EWD 2-54 enables precision adjustments on-the-fly. On-board electronic measurement system in tool carrier allows diameter adjustments for boring range of .079-2.126 in., while display relates diameter corrections with resolution of .00005 in./diameter, or .001 mm/diameter on metric heads. Featuring coated tool body with IP69K seal rating, boring head includes power management system and automatic switch-off. Read More
