Lathe Centers

Machinery & Machining Tools

Milling Lathe/CNC Turning Center has true Y-axis and sub-spindle.

February 27, 2015

In addition to 30 hp, 3,500 rpm, 10 in. (chuck dia) primary spindle and 20 hp, 4,500 rpm, 8 in. sub-spindle, FEELER FT-250SY features true Y-Axis with 100 mm (±50 mm) travel for maximum rigidity and robust machining environment. Single-piece structure with boxways, 45° slant bed, and base lend dampen vibration when turning in hard materials. Other features include heavy-duty, 12-station turret; 210 mm +/- 10 mm X-axis travel; 1,050 mm Z-Axis travel; and FANUC 31i-TB CNC control. Read More

Machinery & Machining Tools, Materials & Material Processing

Grinding Center supports ISO standard insert grinding.

June 25, 2012

Utilizing Windows OS, DOM Semi 4-Axis Grinding Center performs periphery grinding, including K-Lands on one side for materials such as tungsten carbide, ceramics, and CBN. Machine features optimized infeed axis with linear motor, polymer concrete base for vibration dampening, and fully enclosed grinding area that keeps all moving axes and handling systems in dry environment. Auto-handling of each workpiece takes place during grinding via integrated pick-and-place linear handling system. Read More

Machinery & Machining Tools

Turning/Milling Center delivers 5-axis multifunctionality.

September 2, 2008

Featuring B-axis with 270° range of motion and capable of 5-face machining in one set-up, Mi8 is suited for manufacturing complex and multi-operation work pieces for industries that demand precision parts. Components include fixed station tools for turning, 20-station tool changer for rotary tools, as well as 8,000 rpm main turning and 20,000 rpm milling spindles. With integration of robot, machine can also perform unattended small production runs of carbon and copper electrodes. Read More

Machinery & Machining Tools

Turning Center performs complete machining in one setup.

May 9, 2008

Offered as true chuck-and-bar machine, SR 200 BB (Big Bore) can cut tough materials and handle deep interrupted cuts while maintaining overall part accuracy. Vibration damping is accomplished through heavy-duty linear roller guides mounted to Harcrete®-reinforced cast iron base. In addition to various multi-tasking functions, unit incorporates 30 hp, 4,000 rpm spindle; Sure-Grip lever type 10 in., 3-jaw chuck; and Hardinge/GE Fanuc i-Series SR control unit. Read More

Machinery & Machining Tools

CNC Production Turn-Mill handles fixed headstock work.

January 28, 2008

Equipped with three 14-position tool turrets and identical main and counterspindles, INDEX C100 series is designed for production of medium-complexity turned parts from 30-42 mm dia bar stock. Machine has various synchronized and simultaneous work capabilities as well as 42 quick-change tools, fixed and driven. While 30 mm bar capacity model comes with 9,000 rpm spindles, 42 mm bar capacity model is available with 7,000 rpm spindles. Both run parts to 200 mm long. Read More

Machinery & Machining Tools

Automated Turning Center features 4-position turret.

March 20, 2007

Intended for large production runs, Model FS4-3500 incorporates 30° bed design and changes parts with loading/unloading time of less than 5 sec. Saddle and cross slides are coated with TURCITE type material to minimize stick slip. Suitable for bearing applications as well as transmission parts, Model FS4-3500 provides both OD and ID turning of parts up to 6.0 in. dia. Automatic gauging can be integrated into high accuracy applications where 100% inspection is required. Read More

Machinery & Machining Tools

Turning Center features automated gang tool.

January 9, 2007

Changing parts with load/unload time under 5 sec, FS4-3500 is suited for large production runs. Machine incorporates 30° bed design and allows loading and unloading of workpiece during spindle rotation via 2 separate loaders. Applicable for applications requiring both OD and ID turning, product has 6.0 in. max part dia and can be connected with part flip station for complete OP-10/OP-20 turning. Automatic gauging can be integrated into applications where 100% inspection is required. Read More

Machinery & Machining Tools

Turning/Milling Center has 2-channel workshop programming.

December 4, 2006

Equipped with 12,000 rpm (18,000 rpm optional), 29.5 hp spindle, GMX 250 S linear Turning/Milling Center incorporates linear drive in Z-axis as well as cross-carriage slide with Y and B axes. Machine allows graphically-supported, 2-channel workshop programming on basis of adapted Plus IT controls from Heidenhain with integrated TurnPlus programming. Capable of 3D-workpiece simulation, modular VMC includes 12x turret as well as absolute, direct measuring systems in all linear axes. Read More

Machinery & Machining Tools

Turning Center features 3 turrets, each with Y axis.

October 4, 2006

Combining turning and milling operations, Super NTY3 features three 6,000 rpm milling motors that can simultaneously machine 2 flat surfaces on one spindle and one surface on the other. Each turret holds 12 driven or 24 stationary tools. Accelerating Y axes have travels of 2.44 in., and up to 29/20 hp is available for shaft/work turning with synchronized spindles. Super NTY3 has max turning diameter of 6.89 in., max turning length of 23.5 in., and bar capacity of 1.65 in. Read More

Machinery & Machining Tools

Turning Center features less than 5 sec load/unload time.

September 6, 2006

Incorporating 30° bed design, FS4-3500 compact automated gang tooled turning center allows loading and unloading of workpiece during spindle rotation. Two separate loaders are included, and maximum part diameter is 6.0 in. Hardened and ground combination square and dovetail way system support gang slide, and saddle and cross slides are coated with TURCITE type material to reduce stick slip. Optional 4-station indexable turret is available. Read More

Machinery & Machining Tools

Turning Center accommodates larger parts.

January 24, 2006

Super NTJX multitasking turning center incorporates Fanuc 31iA CNC control and features more than 12 milling/turning combinations through 2 spindle motors. Generating 34.9 hp (8000 rpm) and 24.8 hp (6000 rpm) on left and right spindles, NTJX is capable of synchronized shaft/work turning with turning dia of 9.65 in.,turning length of 42.91 in., and bar capacity of 2 in. Forty-station servo-driven ATC provides 1.3 sec tool changes (tool-to-tool). Read More

Machinery & Machining Tools

Horizontal Grinding Center uses CBN grinding wheels.

November 22, 2005

Constructed on Meehanite cast iron base, Model HGC 400 offers 3, 4, and 5 axis capabilities and utilizes Heidenhain scales for X, Y, and Z axes. Five-axis rotary trunnion features roller gear table with zero backlash mounting 400 x 400 mm pallet. Machine is equipped with HSK-100, 35-50 hp, 12,000 rpm direct drive spindle with chiller and GE Fanuc 16 IM CNC control. Automatic tool changer features 40 positions to accommodate all CBN and conventional vitrified grinding wheels. Read More

Machinery & Machining Tools

Vertical Turning Center is suited for mid-size parts.

June 17, 2005

With dual-axis capability, V35R is suited for complex configurations in hard materials. Spindle is powered by 30 hp motor with speeds from 25-2,500 rpm, and unit utilizes Fanuc 18i-T control. Able to handle parts up to 551 lb, machine features 9.25 in. X-axis travel and 16.93 in. Z-axis travel, both with rapid traverse of 787 ipm. Max cutting diameter is 13.78 in., max cutting length is 16.93 in., and max swing is 19.69 in. Read More

Machinery & Machining Tools

CNC Turning Center offers off-center Y-axis cutting.

April 22, 2005

Quick Turn Nexus 250MSY employs 35, 10, and 7.5 hp spindles with respective 4,000, 6,000, and 4,500 rpm max speeds. Rotary and turning tools can be mounted at any position of 12-station drum turret, and workpiece can be automatically oriented in phase. Features include quick-change toolholders, Fusion 640T Nexus CNC, and automatic tool presetting arm. X-, Y-, and Z-axis traverse rates are 1,181, 826, and 1,299 ipm respectively. Read More

Machinery & Machining Tools

Tooling System facilitates hard part turning.

February 7, 2005

Machining steels and alloys hardened to 45-62 Rc levels, ValEDGE Hard Part Turning System utilizes ceramic and CBN inserts as well as ValTURN(TM) ProGRIP(TM) toolholders. It is provided with T-Land corner break width and angle as well as light hone finish. For vibration-free machining, spring-loaded clamp grips insert in 2 places. Inserts, offered with 35, 55, 60, 80, and 90° geometries, result in projected surface finishes from 32-12 Ra @ 0.003 ipr feed rate. Read More

Machinery & Machining Tools

Vertical Turning Center offers self-loading operation.

October 1, 2004

Suited for automotive parts suppliers and production job shops, inverted-spindle BLUETURN 250 features turn/swing diameter of 250/320 mm, rapid traverse rates of 60 m/min, and acceleration rate of 6 m/s². It includes 12-station turret with DIN 69880 VDI 40 tool holder adapter. GE Fanuc 21i controller provides straightforward operator interface and interactive screens. Turning program can be simulated in 2D or 3D solid model view, displaying cutting path and tooling. Read More

Machinery & Machining Tools

Vertical Turning Center suits large parts applications.

September 16, 2004

Designed for use with high tensile alloys and cast materials, V100R has cutting envelope with 39.37 in. max cutting dia, 49.21 in. max swing dia, and 35.04 in. max cutting length. It utilizes Fanuc 18iT control and 74 hp motor with 4-750 rpm range. V12 turret carries 12 tools and accommodates standard tooling from 1.25-2 in. and boring bars from 2.0-2.5 in. X-axis travel is 22.24 in., Z axis is 35.04 in., and rapid traverse rate in both is 945 ipm. Read More

Machinery & Machining Tools

Turning Center offers multitasking flexibility.

June 22, 2004

Controlled by GE Fanuc 21I-TB CNC, E 280 offers turning, boring, milling, and tapping capabilities, all in one setup. It can be configured with one or 2 spindles, C axis, live tools, and Y axis. With 25.6 in. swing, 15.75 in. max cutting length, and 11.02 in. cutting diameter, product has 104.33 x 70.87 in. footprint for mid- and high-volume production. Travels are 15.94, 7.67, 3.34, and 23.23 in. for Z, X, Y, and B axes respectively. Read More

Portable Tools, Machinery & Machining Tools

Grinding Centers allow multi-process machining.

May 25, 2004

MGC-Special grinding centers provide horizontal, vertical, and inclined spindle orientations to enable face, bore and diameter grinding, as well as turning, milling, boring and drilling. Equipped with hydrostatic rotary NC table, machine provides index accuracy of ± 1 arc sec and variable table speed up to 80 RPM. X-axis travels range from 1300-3300 mm, 3 independent Y-axis spindle heads travel up to 1050 mm, and Z-axis travels are up to 220 mm. Read More

Machinery & Machining Tools

Turning Center features 8 in. chuck and 2 in. bar capacity.

October 31, 2002

Model J-3 has cast-iron beds, with hardened and ground box ways, and double sets of angular contact bearings to ensure precision. CNC control includes .00001 in. X and Z offset control capability to allow for finer adjustment of machining tolerances. Loader features Fanuc AC servo with vertical and horizontal rapid traverse rates of 3200 and 4728 ipm, respectively. Spindle motor is 15 hp and provides speeds to 4000 rpm. X- and Z-axis travels are 5 and 12.6 in., respectively. Read More
